先锋PIONEER M-AX10音响电路图

分类：电子电工 日期： 点击：0
先锋PIONEER M-AX10音响电路图-0 先锋PIONEER M-AX10音响电路图-1 先锋PIONEER M-AX10音响电路图-2 先锋PIONEER M-AX10音响电路图-3 先锋PIONEER M-AX10音响电路图-4 先锋PIONEER M-AX10音响电路图-5 先锋PIONEER M-AX10音响电路图-6 先锋PIONEER M-AX10音响电路图-7 先锋PIONEER M-AX10音响电路图-8 先锋PIONEER M-AX10音响电路图-9

ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 � � � � � � � � � �PIONEER CORPORATION 2000 c M-AX10 RRV2345 1. SAFETY INFORMATION ...................................... 2 2. EXPLODED VIEWS AND PARTS LIST ................ 3 3. SCHEMATIC DIAGRAM ..................................... 12 4. PCB CONNECTION DIAGRAM .......................... 24 5. PCB PARTS LIST ............................................... 36 6. ADJUSTMENT .................................................... 41 CONTENTS 7. GENERAL INFORMATION ................................ 42 7.1 IC ................................................................. 42 7.2 PROTECTION CIRCUIT ............................. 52 7.3 EXPLANATION............................................ 54 7.3.1 PRODUCT OVERVIEW ....................... 54 7.3.2 CIRCUIT DESCRIPTION ..................... 55 8. PANEL FACILITIES AND SPECIFICATIONS .... 58 T – ZZV JULY. 2000 Printed in Japan Type Model Power Requirement Remarks M-AX10 KU/CA AC120V NY AC230V THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S). DUAL DRIVE AMPLIFIER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 M-AX10 1. SAFETY INFORMATION This service manual is intended for qualified service technicians ; it is not meant for the casual do-it- yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. WARNING This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 – Proposition 65 NOTICE (FOR CANADIAN MODEL ONLY) Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must be of identical designation. REMARQUE (POUR MODÈLE CANADIEN SEULEMENT) Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que les pièces de remplacement doivent avoir la même désignation. ANY MEASUREMENTS NOT WITHIN THE LIMITS OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL SHOCK HAZARD AND MUST BE CORRECTED BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER. 2. PRODUCT SAFETY NOTICE Many electrical and mechanical parts in the appliance have special safety related characteristics. These are often not evident from visual inspection nor the protection afforded by them necessarily can be obtained by using replacement components rated for voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this Service Manual. Electrical components having such features are identified by marking with a on the schematics and on the parts list in this Service Manual. The use of a substitute replacement component which does not have the same safety characteristics as the PIONEER recommended replacement one, shown in the parts list in this Service Manual, may create shock, fire, or other hazards. Product Safety is continuously under review and new instructions are issued from time to time. For the latest information, always consult the current PIONEER Service Manual. A subscription to, or additional copies of, PIONEER Service Manual may be obtained at a nominal charge from PIONEER. 1. SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Measure leakage current to a known earth ground (water pipe, conduit, etc.) by connecting a leakage current tester such as Simpson Model 229-2 or equivalent between the earth ground and all exposed metal parts of the appliance (input/output terminals, screwheads, metal overlays, control shaft, etc.). Plug the AC line cord of the appliance directly into a 120V AC 60Hz outlet and turn the AC power switch on. Any current measured must not exceed 0.5mA. (FOR USA MODEL ONLY) Leakage current tester Reading should not be above 0.5mA Device under test Test all exposed metal surfaces Also test with plug reversed (Using AC adapter plug as required) Earth ground AC Leakage Test www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 M-AX10 2.1 PACKING NSP 1 Literature Bag AHG-117 2 Instruction Manual (E) ARB7217 NSP 3 Warranty Card See Contrast table (2) NSP 4 Warranty Card See Contrast table (2) 5 Styrol Protector L AHA9014 6 Styrol Protector R AHA9015 7 Packing Case See Contrast table (2) 8 Door Sheet AHG7064 9 Mirror Mat RHC1024 10 Polyester Bag VHL1004 11 Recycle Label See Contrast table (2) (1) PACKING PARTS LIST Mark No. Description Part No. 2. EXPLODED VIEWS AND PARTS LIST NOTES: • Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. • Screws adjacent to mark on the product are used for disassembly. Mark (2) CONTRAST TABLE M-AX10/KU/CA and M-AX10/NY are constructed the same except for the following: Part No. Remarks Symbol and Description No. NSP 3 Warranty Card ARY7045 Not used NSP 4 Warranty Card Not used ARY7022 7 Packing Case AHD7875 AHD7874 11 Recycle Label ARW7091 Not used M-AX10/KU/CA M-AX10/NY FRONT 7 6 9 10 11 8 1 3 4 5 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 M-AX10 2.2 EXTERIOR H I J K A B C D E F G G H I J K L M N O P D A B C F E H I J K L M N O Q Q P 7 77 77 49 68 90 89 45 39 67 39 67 39 39 39 39 49 42 45 45 62 42 62 39 39 36 36 32 32 73 73 73 73 73 64 83 for NY type 73 75 73 64 83 73 49 49 39 39 73 67 39 34 39 67 79 56 55 52 6 57 57 57 57 59 58 57 76 31 31 78 78 78 78 23 75 67 67 67 43 67 43 14 76 57 52 11 52 52 11 71 71 71 46 71 27 71 71 71 46 25 25 38 47 28 68 45 80 68 60 73 53 37 21 44 44 69 80 65 65 44 44 10 71 6 64 64 23 15 4 5 15 1 2 4 22 44 44 26 33 37 45 38 61 61 45 54 33 61 45 61 45 45 37 19 88 24 62 62 62 62 70 70 70 70 70 70 62 62 62 62 16 16 85 40 42 42 44 44 42 42 42 51 40 20 30 35 50 75 3 9 35 36 50 67 8 67 91 24 73 29 4 44 44 22 4 26 74 48 72 76 72 76 74 48 22 22 17 47 29 18 37 30 5 Refer to "2.4 FRONT PANEL" 73 73 73 3434 Refer to "2.3 REAR PANEL" Take care to the edge when servicing Take care to the edge when sevicing L I B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 M-AX10 C D E F 32 32 73 73 73 73 64 73 75 73 64 52 6 52 11 52 52 11 71 71 71 46 71 27 71 71 71 46 25 25 60 71 6 87 83 81 82 75 12 12 75 86 12 12 82 81 83 for KU type www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 M-AX10 1 C.AMP (L) ASSY See Contrast table (2) 2 C.AMP (R) ASSY See Contrast table (2) 3 POWER SUPPLY ASSY See Contrast table (2) 4 Power MOS FET IRFP140 (Q1,Q2,Q5,Q6) 5 Power MOS FET IRFP9140 (Q3,Q4,Q7,Q8) 6 Electric Capacitor(C1-C4) ACH7156 7 Power Transformer See Contrast table (2) 8 Fuse (FU1) See Contrast table (2) 9 16P FFC 60V (J17) ADD7155 10 Wire with 2P Housing (J18) ADX7336 11 Cable (J9,J10) ADX7337 NSP 12 Cable (J23,J24) See Contrast table (2) 13 • • • • • • • • • • 14 PCB Holder (PLS) AEC7316 15 Plate AEE7030 16 Stay L (MET) ANA9006 17 Stay S (MET) ANA9007 18 Side Frame R ANA9008 19 Side Frame L ANA9009 20 Panel Stay (MET) AND7033 NSP 21 Bottom Plate ANF7012 22 PCB Holder ANG1474 23 Transistor Cover L ANG1724 24 L Type Plate ANG7248 25 Earth Plate ANG9102 NSP 26 Heat Sink (AL) ANH7105 27 Sub Inner Plate (MET) ANK7080 28 AC Code Cover (MET) ANK9024 29 Insulator ANL7012 30 Cord Clamper RNH-184 NSP 31 Spacer AEB7168 NSP 32 Spacer AEB7170 NSP 33 Damping Plate AMR7280 NSP 34 Damping Plate AMR7281 35 Cushion A PED1001 NSP 36 Sheet PED1006 NSP 37 Tape PNM-045 NSP 38 Tape PNM1160 NSP 39 Tape PNM1249 NSP 40 Washer (Plastic) RBF-085 41 • • • • • • • • • • 42 Screw ABA1011 43 Screw ABA1082 44 Screw (Steel) ABA1192 45 Screw (Steel) ABA1193 (1) EXTERIOR PARTS LIST Mark No. Description Part No. 46 Screw (Steel) ABA1207 47 Screw (Steel) ABA7006 48 Screw (Steel) ABA7045 49 M4 SH Screw ABA7051 50 PCB Spacer (3 × 12) AEC1372 51 Washer (PVC) RBF1034 52 Screw VBA1056 53 Side AL L AAH7033 54 Side AL R AAH7034 55 Top Plate F (AL) AAH7035 56 Top Plate R (AL) AAH7036 57 Bonnet Escutcheon AAK7658 58 Rear Mole R AAP7056 59 Rear Mole L AAP7057 60 Innner Plate (MET) ANK7081 61 Screw BBT30P100FCC 62 Screw BBT30P080FCC 63 • • • • • • • • • • 64 Screw IBZ40P140FCC 65 Screw BBZ40P180FCC 66 • • • • • • • • • • 67 Screw IBZ30P060FCC 68 Screw IBZ30P080FCC 69 Screw IBZ40P080FCC 70 PCB Holder (MET) ANG9101 71 Screw PMZ40P060FCU 72 Screw VBZ35P080FMC 73 Washer (CU) WG40FCC 74 Washer WH30FUC 75 Binder ZCA-SKB90BK 76 Screw ABA1050 77 Screw IBZ40P080FCC 78 Screw ABA1208 79 Trans Shield ANK7074 80 Screw VCZ30P100FMC 81 Fuse (FU2,FU3) See Contrast table (2) 82 Fuse Holder See Contrast table (2) 83 Screw BBZ40P080FCC 84 UL Caution Card AAX-313 NSP 85 IPC Caution Label See Contrast table (2) NSP 86 Fuse Card See Contrast table (2) NSP 87 Fuse Card See Contrast table (2) NSP 88 Micro Fuse Caution Card See Contrast table (2) 89 65 Label See Contrast table (2) NSP 90 FCC Label See Contrast table (2) NSP 91 Fuse Card See Contrast table (2) Refer to next page about Contrast table (2). Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 M-AX10 Mark (2) CONTRAST TABLE M-AX10/KU/CA and M-AX10/NY are constructed the same except for the following: Part No. Remarks Symbol and Description No. 1 C. AMP(L) ASSY AWX7673 AWX7280 2 C. AMP(R) ASSY AWX7674 AWX7281 3 POWER SUPPLY ASSY AWX7664 AWX7662 7 Power Transformer ATS7277 ATS7251 8 Fuse (FU1) VEK1029 REK-106 (10A) (4A) NSP 12 Cable (J23,J24) ADX7335 Not used 81 Fuse (FU2,FU3) AEK7069 Not used (20A) 82 Fuse Holder AKR7002 Not used NSP 85 IPC Caution Label AAX7784 Not used NSP 86 Fuse Card AAX7795 Not used NSP 87 Fuse Card AAX7796 Not used NSP 88 Micro Fuse Caution Label AAX7810 Not used 89 65 Label ARW7050 Not used NSP 90 FCC Label VRW1559 Not used NSP 91 Fuse Card Not used AAX1589 M-AX10/KU/CA M-AX10/NY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 M-AX10 2.3 REAR PANEL G H G H 46 46 45 A A C C B B D D E F F E 3 or 4 26 27 26 27 25 40 21 32 1 or 2 26 27 26 25 21 33 32 31 31 23 20 30 13 14 35 22 11 11 19 24 22 15 28 38 28 29 44 28 28 42 28 38 6 37 38 28 37 16 8 8 10 13 8 8 17 41 9 38 38 38 38 18 18 18 18 9 24 39 43 47 5 34 36 30 32 27 40 7 7 10 G I H K A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 M-AX10 1 V.AMP (L) ASSY AWX7278 2 V.AMP (R) ASSY AWX7279 3 INPUT (L) ASSY AWX7273 4 INPUT (R) ASSY AWX7274 NSP 5 JOINT ASSY AWX7283 6 Ground Terminal AKE-046 7 Speaker Terminal 1P AKE7009 (CN1,CN2,CN5,CN6) 8 Speaker Terminal 1P AKE7010 (CN3,CN4,CN7,CN8) 9 23P FFC 60V (J5,J6) ADD7154 10 AC Cord with Plug See contrast tabel (2) 11 11P Housing Wire (J3,J4) ADX7278 12 • • • • • • • • • • 13 Connector Assy (J7) PG10MM-F15 14 Connector Assy (J8) PG10MM2F15 15 Rear Panel (MET) ANC7820 16 Rear Panel Plate R See contrast tabel (2) 17 Rear Panel Plate L See contrast tabel (2) 18 PCB Holder (MET) ANG9101 19 Shield Plate(PLS) ANK7076 20 AC Shield L ANK9025 21 Shield Cover ANK9026 NSP 22 Spacer AEB7169 NSP 23 Tape AEH7008 NSP 24 Damping Plate AMR7278 NSP 25 Damping Plate AMR7281 NSP 26 Tape PNM1249 27 Fiber Washer RBF1045 28 Screw ABA1192 29 Screw BBT30P100FCC 30 Screw ABA1207 31 Rivet AEC-441 32 Nylon Rivet AEC7242 NSP 33 PCB Spacer (14) DEC1387 34 Card Spacer DEC1772 35 PC Support VEC1549 36 Cushion A PED1001 37 Screw BBZ30P080FCC 38 Screw IBZ30P060FCC 39 Nut NK70FCU 40 Binder ZCA-SKB90BK 41 Input Plate (MET) ANG7274 42 Locking Card Spacer VEC1596 43 Ferrite Core See contrast tabel (2 44 Screw ABA1011 45 AC Shield Case (PLS) ANK7075 NSP 46 Earth Lead Wire DE025BF0 47 AC Cord Spacer ANG1153 (1)REAR PANEL PARTS LIST Mark No. Description Part No. Mark (2) CONTRAST TABLE M-AX10/KU/CA and M-AX10/NY are constructed the same except for the following: Part No. Remarks Symbol and Description No. 10 AC Cord with Plug ADG7041 ADG7038 16 Rear Panel Plate R ANC7288 ANC7285 17 Rear Panel Plate L ANC7289 ANC7286 43 Ferrite Core Not used ATX1031 M-AX10/KU/CA M-AX10/NY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 M-AX10 2.4 FRONT PANEL 43 43 38(1/3) 6 7 22 19 24 20 25 16 11 4 12 39 32 42 46 44 44 2 1 38(2/3) 38(3/3) 37 42 34 30 44 44 43 44 28 33 45 9 21 8 27 10 12 29 27 29 5 13 44 48 44 41 44 49 44 41 44 31 47 49 42 42 47 44 3 36 40 35 10 14 15 26 18 17 23 E D C F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 M-AX10 NSP 1 SW ASSY AWX7282 NSP 2 VR ASSY AWX7334 3 FRONT ASSY AWX7276 NSP 4 LED ASSY AWX7277 NSP 5 Cord with Plug ADH7022 NSP 6 Cord with Plug (J20) DE005VF0 7 Magnet AMF7003 8 Door Hinji L (PLS) AMR9199 9 Door Hinji R (PLS) AMR9200 10 Door Assy (MET) ANG9100 11 Inner Panel (AL) ANB7184 12 Damper Assy AXA9013 NSP 13 Spacer AEB7169 NSP 14 Damping Plate AMR7282 NSP 15 Tape PNM1249 NSP 16 Cushion A REB1060 NSP 17 Cushion B REB1061 18 LED Lens AAK2459 19 LED Filter S(PLS) AAK7657 20 LED Film (PLS) AAK7669 21 Display Panel L (PLS) AAK9044 22 Cover AAK9045 23 LED Filter L (PLS) AAK9046 24 Mode Panel (PLS) AAK9047 25 Mode Lens (PLS) AAK9048 26 Panel S (PLS) AAK9049 27 Door Cushion AED9014 28 Tape AEH7009 29 Door Yoke (MET) ANB7187 30 Name Plate G (AL) PAN1377 31 Cushion A PED1001 32 Knob S (PLS) AAB7200 33 Knob M (AL) AAB7201 34 Block ANL7015 35 Power Button (ABS) VNK4159 36 Side Panel L (AL) AAH7037 37 Side Panel R (AL) AAH7038 38 Panel Base (PLS) AMB9020 39 Door Panel (AL) ANB7182 40 Front Panel (AL) ANB7183 41 Screw BBT30P080FCC 42 Screw BBZ30P080FCC 43 Screw IBZ30P060FCC 44 Screw IBZ30P080FCC 45 Nut NK90FCU 46 Screw PMH30P060FMC 47 Screw PSZ20P060FMC 48 Screw (STEEL) ABA1050 49 Washer (PLS) ABF7007 • FRONT PANEL PARTS LIST Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 12 A B C D 1 2 3 4 1 2 3 4 A 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 OVERALL CONNECTION DIAGRAM AND JOINT ASSY L712 RTF1167 R712 2.2 L711 RTF1167 VR ASSY (AWX7334) LED ASSY (AWX7277) FRONT ASSY (AWX7276) F E D B INPUT(L) ASSY (AWX7273) V.AMP(L) ASSY (AWX7278) C.AMP(L) ASSY KU/CA : (AWX7673) NY : (AWX7280) POWER SUPPLY ASSY KU/CA : (AWX7664) NY : (AWX7662) G H I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 13 A B C D 5 6 7 8 5 6 7 8 Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". A From AC Power Cord JOINT ASSY (AWX7283) SW ASSY (AWX7282) A C INPUT(R) ASSY (AWX7274) C.AMP(R) ASSY KU/CA : (AWX7674) NY : (AWX7281) V.AMP(R) ASSY (AWX7279) J K L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 14 A B C D 1 2 3 4 1 2 3 4 B C 3.2 POWER SUPPLY, SW ASSY PIOWER TRANSFORMER 6 6 5 5 1 1 2 2 4 4 3 3 CN701 120V(KU/CA) 230V (/NY) J805 J803 J801 CN803 J802 J804 CN853 CN852 FU1 CN851 FU1 KU :VEK1029(10A) NY :REK-106(4A) J806 J808 POWER SUPPLY ASSY (KU/CX :AWX7664 ,NY :AWX7662) B K CN601 C2, C4 and SW ASSY (AWX7282) C I CN501 C1, C3 and www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 15 A B C D 5 6 7 8 5 6 7 8B CN806 CN804 CN805 +24V +24V A CN711 A CN712 D CN901 • NOTE FOR FUSE REPLACEMENT FOR CONTINUED PROTECTION AGAINST RISK OF FIRE. REPLACE WITH SAME TYPE AND RATINGS ONLY. CAUTION - www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 16 A B C D 1 2 3 4 1 2 3 4 D E F 3.3 FRONT, LED, VR ASSY CN901 J902 CN751 J901 CN761 VR ASSY (AWX7334) F LED ASSY (AWX7277) E B CN804 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 17 A B C D 5 6 7 8 5 6 7 8D SWITCHES S901 : ATT THROUGH S902 : ATT HOLD S903 : INPUT S904 : ILLUMINATION S905 : MODE FRONT ASSY (AWX7276) D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 18 A B C D 1 2 3 4 1 2 3 4 G 3.4 INPUT (L), INPUT (R) ASSY JA101 12dB FLAT AMP JA102 INPUT(L) ASSY (AWX7273) G www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 19 A B C D 5 6 7 8 5 6 7 8 G J201 CN201 JA201 JA202 DAC VR J101 CN101 INPUT(R) ASSY (AWX7274) J K CN401 A CN714 H CN301 A CN713 : AUDIO SIGNAL SIGNAL ROUTE J www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 20 A B C D 1 2 3 4 1 2 3 4 H 3.5 V.AMP (L) ,V.AMP (R) ASSY CN301 CN302 14dB POWER AMP G J101 A CN715 V. AMP(L) ASSY (AWX7278) H DC ADJ(HL) DC ADJ(LL) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 21 A B C D 5 6 7 8 5 6 7 8 H J401 J402 CN403 CN401 CN402 J301 J302 CN303 J306 V. AMP(R) ASSY (AWX7279) K L CN607 L CN608 L CN602 J J201 A CN716 I CN507 I CN508 I CN502 : AUDIO SIGNAL SIGNAL ROUTE K www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 22 A B C D 1 2 3 4 1 2 3 4 I 3.6 C.AMP (L), C.AMP (R) ASSY CN505 CN507 CN508 CN502 CURRENT AMP C. AMP(L) ASSY (KU/CA : AWX7673) ( NY : AWX7280) I H J301 H J302 H CN303 IDLE ADJ(HL) IDLE ADJ(LL) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 23 A B C D 5 6 7 8 5 6 7 8 I L CN605 CN607 CN608 CN602 CN601 CN603 CN604 R R R R R R R R R R R R R R R R To C1,C3 To C2,C4 J501 J514 CN501 J513 J512 J511 C. AMP(R) ASSY (KU/CA : AWX7674) ( NY : AWX7281) L K J401 K J402 K CN403 : AUDIO SIGNAL SIGNAL ROUTE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 24 A B C D 1 2 3 4 1 2 3 4 B CN852 B CN805 G CN101 H CN302 B CN806 J CN201 K CN402 D J902 D J901 JOINT ASSY A SW ASSY C LED ASSY E VR ASSY F (ANP7281-A) (ANP7281-A) (ANP7282-C) (ANP7281-A) SIDE A 4. PCB CONNECTION DIAGRAM 4.1 JOINT, SW, LED, VR ASSY NOTE FOR PCB DIAGRAMS : 1. Part numbers in PCB diagrams match those in the schematic diagrams. 2. A comparison between the main parts of PCB and schematic diagrams is shown below. 3. The parts mounted on this PCB include all necessary parts for several destinations. For further information for respective destinations, be sure to check with the schematic diagram. 4. View point of PCB diagrams. Symbol In PCB Diagrams Symbol In Schematic Diagrams Part Name B C E D D G G S S B C E B C E D G S B C E B C E B C E Transistor Transistor with resistor Field effect transistor Resistor array 3-terminal regulator Capacitor Connector P.C.Board Chip Part SIDE A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 25 A B C D 1 2 3 4 1 2 3 4 JOINT ASSY A SW ASSY C LED ASSY E VR ASSY F (ANP7281-A) (ANP7281-A) (ANP7282-C) (ANP7281-A) SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 26 A B C D 1 2 3 4 1 2 3 4 D CN901 L CN601 A CN712 POWER TRANSFORMER A CN711 I CN501 AC POWER CODE POWER TRANSFORMER C CN701 IC805 IC803 Q812 Q810 Q811 Q809 Q808 Q806 Q807 Q805 Q804 IC801 Q802 IC802 IC804 Q803 Q801 (ANP7282-C) POWER SUPPLY ASSY B SIDE A 4.2 POWER SUPPLY ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 27 A B C D 1 2 3 4 1 2 3 4 Q816 Q821 Q814 Q818 Q817 Q820 Q819 Q815 Q813 (ANP7282-C) POWER SUPPLY ASSY B SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 28 A B C D 1 2 3 4 1 2 3 4 B CN804 E CN751 F CN761 FRONT ASSY D IC903 Q946 Q949 Q945 IC902 Q943 Q904 Q901 Q903 Q947 Q918 Q902 Q952 Q935 Q934 Q932 Q933 IC904 Q942 IC901 (ANP7282-C) SIDE A 4.3 FRONT ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 29 A B C D 1 2 3 4 1 2 3 4 FRONT ASSY D Q916 Q915 Q919 Q926 Q928 Q930 Q951 Q950 Q948 Q917 Q907 Q914 (ANP7282-C) SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 30 A B C D 1 2 3 4 1 2 3 4 A CN713 H CN301 INPUT(L) ASSY G INPUT(L) ASSY G Q101 Q106 IC101 IC102 Q119 Q120 Q129–Q131 Q116 Q117 Q115 Q126–Q128 Q118 Q107 Q110 Q111 Q114 SIDE A SIDE B (ANP7281-A) 4.4 INPUT(L) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 31 A B C D 1 2 3 4 1 2 3 4 A CN714 K CN401 INPUT(R) ASSY J INPUT(R) ASSY J Q216 Q217 Q215 Q226–Q228 Q218 Q201 Q206 IC201 IC202 Q219 Q220 Q229–Q231 Q207 Q210 Q211 Q214 SIDE A SIDE B (ANP7281-A) 4.5 INPUT(R) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 32 A B C D 1 2 3 4 1 2 3 4 I CN508 I CN502 I CN507 A CN715 G J101 Q321 Q324 Q333 VR301 VR302 Q334 Q309 Q316 Q305 Q308 Q301 Q304 Q337 Q340 Q338 Q329 Q332 Q331 Q336 Q335 Q325 Q328 Q341 Q344 V. AMP(L) ASSY H V. AMP(L) ASSY H SIDE A SIDE B (ANP7294-C) 4.6 V. AMP(L) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 33 A B C D 1 2 3 4 1 2 3 4 A CN716 L CN608 L CN602 L CN607 J J201 Q437 Q440 Q438 Q429 Q432 Q431 Q436 Q435 Q425 Q428 Q441 Q444 Q421 Q424 Q433 VR401 VR402 Q434 Q409 Q416 Q405 Q408 Q401 Q404 V. AMP(R) ASSY K V. AMP(R) ASSY K SIDE A SIDE B (ANP7294-C) 4.7 V. AMP(R) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 34 A B C D 1 2 3 4 1 2 3 4 H H J302 J301 H CN303 VR502, VR501 Q515 Q502, Q501 Q520, Q519 Q504, Q506, Q508, Q510 Q507, Q509, Q505, Q503 Q512, Q511, Q517 Q518 Q513 C. AMP(L) ASSY I C. AMP(L) ASSY I SIDE A SIDE B (ANP7294-C) 4.8 C. AMP(L) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com M-AX10 35 A B C D 1 2 3 4 1 2 3 4 K CN403 K K J401 J402 Q601, Q602 Q619, Q620 Q608, Q610, Q606, Q604 Q603, Q605, Q607, Q609 Q617, Q611, Q612 Q618 VR602, VR601 Q615 Q613 C. AMP(R) ASSY L C. AMP(R) ASSY L SIDE A SIDE B (ANP7294-C) 4.9 C. AMP(R) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 M-AX10 Mark No. Description Part No. Mark No. Description Part No. 5. PCB PARTS LIST NOTES: •Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. •The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. •When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). 560 Ω → 56 × 10 1 → 561 ........................................................ RD1/4PU 5 6 1 J 47k Ω → 47 × 10 3 → 473 ........................................................ RD1/4PU 4 7 3 J 0.5 Ω → R50 ..................................................................................... RN2H R 5 0 K 1 Ω → 1R0 ..................................................................................... RS1P 1 R 0 K Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 5.62k Ω → 562 × 10 1 → 5621 ...................................................... RN1/4PC 5 6 2 1 F NSP POWER AMP ASSY AWH7003 AWH7002 V. AMP (L) ASSY AWX7278 AWX7278 V. AMP (R) ASSY AWX7279 AWX7279 C. AMP (L) ASSY AWX7673 AWX7280 C. AMP (R) ASSY AWX7674 AWX7281 NSP AF COMPLEX (A) ASSY AWM7410 AWM7410 INPUT (L) ASSY AWX7273 AWX7273 INPUT (R) ASSY AWX7274 AWX7274 NSP SW ASSY AWX7282 AWX7282 NSP JOINT ASSY AWX7283 AWX7283 NSP VR ASSY AWX7334 AWX7334 NSP AF COMPLEX (B) ASSY AWM7507 AWM7506 POWER SUPPLY ASSY AWX7664 AWX7662 FRONT ASSY AWX7276 AWX7276 NSP LED ASSY AWX7277 AWX7277 Mark Symbol and Description Part No. M-AX10 /KU/CA M-AX10 /NY Remarks CONTRAST OF PCB ASSEMBLIES Part No. IC501,IC502 AEK7022 Not used IC Protector (10A/125V) C.AMP (L) ASSY AWX7673and AWX7680 are constructed the same except for the following: Symbol & Description Remarks AWX7680 AWX7673 Mark I Part No. IC601,IC602 AEK7022 Not used IC Protector (10A/125V) C.AMP (R) ASSY AWX7674and AWX7681 are constructed the same except for the following: Symbol & Description Remarks AWX7681 AWX7674 Mark L Part No. R849 -R852 Not used RS2LMF222J POWER SUPPLY ASSY AWX7664and AWX7662 are constructed the same except for the following: Symbol & Description Remarks AWX7662 AWX7664 Mark B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 M-AX10 Mark No. Description Part No. Mark No. Description Part No. JOINT ASSY COILS AND FILTERS L711,L712 RTF1167 CAPACITORS C711,C712 CEAT100M50 RESISTORS Other Resistors RS1/10S J OTHERS CN711,CN712 10P MT CONNECTOR 1-173981-0 CN713,CN714 11P PLUG KM200TA11 711,712 PCB BINDER VEF1040 POWER SUPPLY ASSY (AWX7664) SEMICONDUCTORS IC803 AEK7019 IC801,IC802 AEK7021 IC804,IC805 BA178M24T Q815,Q816,Q819,Q820 2SA1255 Q803,Q804,Q811,Q812 2SA1837 Q805,Q806 2SA970 Q807,Q808 2SC2240 Q821 2SC2712 Q813,Q814,Q817,Q818 2SC3138 Q801,Q802,Q809,Q810 2SC4793 D821-D828 1SS355 D801-D804 F10KF20 D805-D812,D833-D837 S5566G(TPB2) D829-D832 UDZ16B D813-D816,D841-D844 UDZ24B D817-D820 UDZ36B D838 UDZS10B COILS AND FILTERS L801,L802 RTF1167 CAPACITORS C851 (0.01µF/250V) ACE7014 C803,C804,C833 CEANP1R0M50 C829-C832,C836 CEAT100M50 C813-C820 CEAT100M63 C809-C812 CEAT471M2A C821-C824 CEATR10M2A C838,C840 CEHAT100M50 C839,C841 CEHAZA220M25 C825-C828 CEHAZL101M50 C834 CEHAZL182M35 C837 CEHAZL331M35 C805-C808 CEHAZL471M50 C842 CFTYA224J50 C801,C802 CKCYF103Z50 RESISTORS R803,R804 RD1/4LMF470J R813,R814 RD1/4MUF124J R831,R839 RS1/10S100J R815-R818 RS1/10S101J R819-R822 RS1/10S301J R836-R838 RS1/10S3R3J R805-R808 RS1LMF103J Other Resistors RS1/10S J OTHERS CN805,CN806 10P MT CONNECTOR 1-173981-0 CN804 16P CONNECTOR 9604S-16C H851,H852 FUSE CLIP AKR1004 811-822 HEAT SINK ANH7100 CN851 AC CODE SOCKET RKP1751 CN852 AMP U-P CONNECTOR RKP1833 CN853 AMP U-P CONNECTOR RKP1834 805 PCB BINDER VEF1040 KN801-KN803 EARTH METAL FITTING VNF1084 SW ASSY SWITCHES AND RELAYS S701 ASG-553 CAPACITORS C701 (0.01µF/250V) ACE7014 OTHERS CN701 AMP U-P CONNECTOR RKP1833 FRONT ASSY SEMICONDUCTORS IC904 AT24C01-10PC IC902 BA178M05T IC903 BA178M15T IC901 PD5508B9 Q952 2SA1048 Q903,Q904 2SC2458 Q901,Q902 2SC2705 Q943,Q946 2SJ146 Q907-Q914,Q942,Q945 DTA124EK Q918 DTA143EK Q915-Q917,Q919,Q926,Q928 DTC124EK Q930,Q947-Q951 DTC124EK Q932-Q935 DTC124ES D933-D935,D953 1SS355 D927 DAN202K D936 DAP202K D901-D914 NSCW100-8511 D929-D932 SLP6118C51H D951,D952 UDZS7.5B COILS AND FILTERS X901 (4.19MHz) VSS1014 SWITCHES AND RELAYS S905 ASD7014 S901-S904 VSG1009 CAPACITORS C921,C922,C942 CEHAZA220M25 C961,C963,C964 CEHAZA470M6R3 C941,C955,C957 CEJA100M35 C953 CEJA2R2M50 A B C D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 M-AX10 Mark No. Description Part No. Mark No. Description Part No. C927,C954 CKSQYF103Z50 C901-C914,C923-C926 CKSQYF104Z50 C931-C934,C951,C956 CKSQYF104Z50 RESISTORS Other Resistors RS1/10S J OTHERS 902 3P CABLE HOLDER 51048-0300 901 7P CABLE HOLDER 51048-0700 CN901 16P CONNECTOR 52492-1620 J902 3P JUMP WIRE D20PDY0310E J901 7P JUMP WIRE D20PDY0715G LED ASSY SEMICONDUCTORS D752-D754 NSCW100-8511 RESISTORS All Resistors RS1/10S J OTHERS CN751 3P JUMPER CONNECTOR 52151-0310 VR ASSY SEMICONDUCTORS IC761 TC74HC86AP Q761,Q762 2SK1132 SWITCHES AND RELAYS S761 ASX7028 CAPACITORS C761 CEAT100M50 C762 CKSQYF104Z50 RESISTORS All Resistors RS1/10S J OTHERS CN761 7P JUMPER CONNECTOR 52147-0710 INPUT (L) ASSY SEMICONDUCTORS IC101 DAC8043FP IC102 OP275GP Q101,Q102 2SA1048 Q107,Q108,Q113,Q114 2SA1145 Q120 2SA1145 Q103-Q106 2SA970 Q109-Q112 2SC2705 Q119 2SC2705 Q123,Q124,Q129-Q131 2SK1132 Q115,Q117,Q126-Q128 DTA124EK Q116,Q118 DTC124EK D101-D112 1SS355 D113,D114 UDZ18B D115 UDZS5.1B COILS AND FILTERS L101 RTF1167 SWITCHES AND RELAYS RY101-RY103 VSR1008 CAPACITORS C101,C102,C105-C108 (220pF) ACE7012 C140 (47µF) ACH7116 C103,C104 CCCSL560K2H C135 CCSQCH100D50 C132-C134 CCSQCH101J50 C128 CCSQCH470J50 C129,C130 CEAT100M50 C121,C122 CEHAZA101M25 C131 CEHAZA220M25 C125,C126 CEHAZL471M25 C115-C118 CEHAZL471M50 C119,C120,C123,C124 CFTYA104J50 C109,C110 CQHA561J2A C141,C142 (22µF) RCH1077 C111-C114 (47µF/10V) RCH1139 C127 (100µF/6.3V) VCH1156 RESISTORS R137,R138 RDR1/4VM1001F R135,R136,R166 RDR1/4VM2400F R139,R140 RDR1/4VM3001F R101,R102 RDR1/4VM391J R103,R104 RDR1/4VM473J R157,R158 RS1/10S1002F Other Resistors RS1/10S J OTHERS J101 6P HOUSING SHIELD WIRE ADX7253 JA101,JA102 PIN JACK(1P) AKB7102 CN101 11P SOCKET KP200TA11L V. AMP (L) ASSY SEMICONDUCTORS Q325,Q326,Q341,Q342 2SA1162 Q309,Q310 2SA1929 Q301,Q302,Q307,Q308 2SA970 Q313,Q314,Q323,Q324 2SA970 Q303-Q306,Q315,Q316 2SC2240 Q321,Q322 2SC2240 Q327,Q328,Q343,Q344 2SC2712 Q329,Q331,Q332 2SC3326 Q311,Q312 2SC5170 Q333,Q334,Q339 2SK1132 Q335-Q337,Q340 DTA124EK Q338 DTC124EK D307,D313-D316 1SS355 D309-D312 UDZS7.5B SWITCHES AND RELAYS RY301,RY302 VSR1008 CAPACITORS C303,C304,C333-C336 (220pF) ACE7012 C313,C314 (10µF) ACH7124 C301,C302,C319 (10µF) ACH7125 E F G H www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 M-AX10 Mark No. Description Part No. Mark No. Description Part No. C305-C308,C323-C326 CCSQCH270J50 C311,C312 CEAT470M25 C315-C318 CEGA471M50 C309,C310 CEHAZA470M10 C331 CFTYA683J50 C337,C338 CSZSR100M16 RESISTORS R303,R304 RDM1/2P221J R345 RDM1/2P3600F R343,R344 RDM1/2P7500F R341,R342 RDM1P3001F R379,R380 RDR1/4PM470J R301,R302 RDR1/4VM104J R315 RS1/10S1001D R349-R352 RS1/10S101J R314 RS1/10S1101D R386 RS1/10S30R0D R385 RS1/10S33R0D R313,R316,R325-R328 RS1/10S3900D R347,R348 RS1/10S5100D VR301,VR302 (220Ω) ACP7002 Other Resistors RS1/10S J OTHERS CN303 23P CONNECTOR 9604S-23C J301 2WIRE SHIELD HOUSING ADX7258 J302 2WIRE SHIELD HOUSING ADX7259 KN301 EARTH METAL FITTING VNF1084 C. AMP (L) ASSY (AWX7673) SEMICONDUCTORS IC501,IC502 IC PROTECTOR(10A) AEK7022 Q503,Q504 2SA1162 Q507-Q510 2SC2712 Q517,Q518 2SC3138 Q513,Q515 2SK1132 Q511,Q512 DTA124EK Q505,Q506 DTC143EK Q501,Q502,Q519,Q520 IMX1 D501,D502 1SS355 D503,D504 BR3371XJ30A COILS AND FILTERS L501 RTF1167 SWITCHES AND RELAYS RY501,RY502 ASR1035 CAPACITORS C505,C506 CEANP470M10 C507 CEAT100M50 C508 CEHAZA220M25 C511,C512 CEHAZL471M50 C501-C504 CFTYA224J50 C509 CFTYA474J50 C517,C518 CKSQYF104Z50 C515,C516 (47µF/10V) RCH1139 RESISTORS R519,R520,R535,R536 RS1/10S1502F R501,R502 RS1/10S1602F R503,R504 RS1/10S6801F R521,R522,R537,R538 RS1/10S8201F R509-R512,R531-R534 RS2LMFR22J R513,R514 RS3LMF2R2J VR501,VR502 (4.7KΩ) ACP7003 Other Resistors RS1/10S J OTHERS CN502 23P CONECTOR 9604S-23C CN507,CN508 2P TOP POST B2B-EH 501 PCB BINDER VEF1040 KN501,KN502 EARTH METAL FITTING VNF1084 INPUT (R) ASSY SEMICONDUCTORS IC201 DAC8043FP IC202 OP275GP Q201,Q202 2SA1048 Q207,Q208,Q213,Q214 2SA1145 Q220 2SA1145 Q203-Q206 2SA970 Q209-Q212 2SC2705 Q219 2SC2705 Q223,Q224,Q229-Q231 2SK1132 Q215,Q217,Q226-Q228 DTA124EK Q216,Q218 DTC124EK D201-D212 1SS355 D213,D214 UDZ18B D215 UDZS5.1B COILS AND FILTERS L201 RTF1167 SWITCHES AND RELAYS RY201-RY203 VSR1008 CAPACITORS C201,C202,C205-C208 (220pF) ACE7012 C240 (47µF) ACH7116 C203,C204 CCCSL560K2H C235 CCSQCH100D50 C232-C234 CCSQCH101J50 C228 CCSQCH470J50 C229,C230 CEAT100M50 C221,C222 CEHAZA101M25 C231 CEHAZA220M25 C225,C226 CEHAZL471M25 C215-C218 CEHAZL471M50 C219,C220,C223,C224 CFTYA104J50 C209,C210 CQHA561J2A C241,C242 (22µF) RCH1077 C211-C214 (47µF/10V) RCH1139 C227 (100µF/6.3V) VCH1156 RESISTORS R237,R238 RDR1/4VM1001F R235,R236,R266 RDR1/4VM2400F R239,R240 RDR1/4VM3001F R201,R202 RDR1/4VM391J R203,R204 RDR1/4VM473J I J www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 M-AX10 Mark No. Description Part No. Mark No. Description Part No. R257,R258 RS1/10S1002F Other Resistors RS1/10S J OTHERS J201 6P HOUSING SHIELD WIRE ADX7253 JA201,JA202 PIN JACK(1P) AKB7102 CN201 11P SOCKET KP200TA11L V. AMP (R) ASSY SEMICONDUCTORS Q425,Q426,Q441,Q442 2SA1162 Q409,Q410 2SA1929 Q401,Q402,Q407,Q408 2SA970 Q413,Q414,Q423,Q424 2SA970 Q403-Q406,Q415,Q416 2SC2240 Q421,Q422 2SC2240 Q427,Q428,Q443,Q444 2SC2712 Q429,Q431,Q432 2SC3326 Q411,Q412 2SC5170 Q433,Q434,Q439 2SK1132 Q435-Q437,Q440 DTA124EK Q438 DTC124EK D407,D413-D416 1SS355 D409-D412 UDZS7.5B SWITCHES AND RELAYS RY401,RY402 VSR1008 CAPACITORS C403,C404,C433-C436 (220pF) ACE7012 C413,C414 (10µF) ACH7124 C401,C402,C419 (10µF) ACH7125 C405-C408,C423-C426 CCSQCH270J50 C411,C412 CEAT470M25 C415-C418 CEGA471M50 C409,C410 CEHAZA470M10 C431 CFTYA683J50 C437,C438 CSZSR100M16 RESISTORS R403,R404 RDM1/2P221J R445 RDM1/2P3600F R443,R444 RDM1/2P7500F R441,R442 RDM1P3001F R479,R480 RDR1/4PM470J R401,R402 RDR1/4VM104J R415 RS1/10S1001D R449-R452 RS1/10S101J R414 RS1/10S1101D R486 RS1/10S30R0D R485 RS1/10S33R0D R413,R416,R425-R428 RS1/10S3900D R447,R448 RS1/10S5100D VR401,VR402 (220Ω) ACP7002 Other Resistors RS1/10S J OTHERS CN403 23P CONNECTOR 9604S-23C J401 2WIRE SHIELD HOUSING ADX7258 J402 2WIRE SHIELD HOUSING ADX7259 KN401 EARTH METAL FITTING VNF1084 C. AMP (R) ASSY (AWX7674) SEMICONDUCTORS IC601,IC602 IC PROTECTOR(10A) AEK7022 Q603,Q604 2SA1162 Q607-Q610 2SC2712 Q617,Q618 2SC3138 Q613,Q615 2SK1132 Q611,Q612 DTA124EK Q605,Q606 DTC143EK Q601,Q602,Q619,Q620 IMX1 D601,D602 1SS355 D603,D604 BR3371XJ30A COILS AND FILTERS L601 RTF1167 SWITCHES AND RELAYS RY601,RY602 ASR1035 CAPACITORS C605,C606 CEANP470M10 C607 CEAT100M50 C608 CEHAZA220M25 C611,C612 CEHAZL471M50 C601-C604 CFTYA224J50 C609 CFTYA474J50 C617,C618 CKSQYF104Z50 C615,C616 (47µF/10V) RCH1139 RESISTORS R619,R620,R635,R636 RS1/10S1502F R601,R602 RS1/10S1602F R603,R604 RS1/10S6801F R621,R622,R637,R638 RS1/10S8201F R609-R612,R631-R634 RS2LMFR22J R613,R614 RS3LMF2R2J VR601,VR602 (4.7kΩ) ACP7003 Other Resistors RS1/10S J OTHERS CN602 23P CONNECTOR 9604S-23C CN607,CN608 2P TOP POST B2B-EH 601 PCB BINDER VEF1040 KN601,KN602 EARTH METAL FITTING VNF1084 K L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 M-AX10 6. ADJUSTMENT 6.1 IDLE CURRENT ADJUSTMENT The idle current is adjusted in two steps: coarse and fine. Note that the adjustment value for fine adjustment depends on the elapsed time from the coarse adjustment. For the points to be adjusted or measured, see Table 6-1 and Fig. 6- 1. For the adjustment timing and values, see Table 6-2. Be sure to turn VR501, VR502, VR601 and VR602 fully counter- clockwise before turning the power on. 6.2 DC OFFSET ADJUSTMENT Adjust the DC offset with the power on immediately before fine adjustment of the idle current. For the points to be adjusted or measured, and the adjustment values, see Table 6-3 and Fig. 6-1. 6.3 OPERATION CHECK OF THE PROTECTION CIRCUIT While supplying a sine wave of 1 Hz, 1.2 Vrms in DUAL MODE, with ATT.THROUGH OFF, increase the volume level and check that the protection circuit activates before the level reaches the maximum value. It works about before twelve o'clock position. CAUTION : This check mode may damage the speaker(s) when it is connected to the output terminal. It is recommended that output terminal is open at this check mode. Channel L High ch L Low ch R High ch R Low ch Adjustment point VR501 VR502 VR601 VR602 Measurement point CN505 CN505 CN605 CN605 Between pins 1 and 2 Between pins 3 and 4 Between pins 1 and 2 Between pins 3 and 4 Table 6-1 Adjustment points of idle current Table 6-2 Adjustment values of idle current Adjustment Timing Adjustment value (Pin voltage) Coarse Adjustment Power ON immediately 14.5mV ± 1.0mV Fine Adjustment Elapsed time from the coarse adjustment More than 5 min. and less than 10 min. 16.0mV ± 0.5mV More than 10 min. and less than 15 min. 15.5mV ± 0.5mV More than 15 min. and less than 30 min. 15.0mV ± 0.5mV More than 30 min. 14.5mV ± 0.5mV Table 6-3 DC offset adjustment method Channel Adjustment Point Measurement Point Adjustment Value L High ch VR301 Apply channel speaker terminals (Red, Black) 0V ± 10mV L Low ch VR302 R High ch VR401 R Low ch VR402 VR302 L Low ch DC OFFSET ADJ VR301 L High ch DC OFFSET ADJ VR502 L Low ch Idle Current ADJ VR501 L High ch Idle Current ADJ VR402 R Low ch DC OFFSET ADJ VR401 R High ch DC OFFSET ADJ VR602 R Low ch Idle Current ADJ VR601 R High ch Idle Current ADJ CN505 Fig. 6-1 Adjustment and measurement points CN605 Rear Side Front Side www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 M-AX10 7. GENERAL INFORMATION • The information shown in the list is basic information and may not correspond exactly to that shown in the schematic diagrams. PD5508B9 (FRONT ASSY : IC901) • Control Microcomputer • Pin Function 7.1 IC •List of IC PD5508B9, DAC8043FP No. Mark Pin Name I/O Pin Function 1 P53 VR2 I 2 P17/Srdy/A10 LD O Serial I/O pins 3 P16/CLK/A9 CLK O 4 P15/Sout/A8 SRD O 5 P14/Sin/A7 IND. IN1 O 6 P13/T1/A6 IND. IN2 O Timer output 7 P12/T0/A5 IND. SEPA O 8 P11/A4 IND.BRD O 9 P10 IND. DUAL O 10 P27/IN7 IND. ATT.THROUGH O Analog input 11 P26/IN6 IND. ATT. HOLD O 12 P25/IN5 INPUT2 O 13 P24/IN4 DACVR O 14 P23/IN3/A3 SEPARATE O 15 P22/IN2/A2 INVERT O 16 P21/IN1/A1 SPRYH O 17 P20/IN0/A0 SPRYG O 18 Vref/CE Vref - Reference voltage input 19 Xin Xin I Clock input 20 Xout Xout O Clock output 21 Vss Vss - Power supply voltage input 22 Vcc Vcc - Power supply voltage input 23 P50/Xcin VR4 I 24 P51/Xcout VR5 I 25 RESET RESET I Reset input 26 P30/INT0/A11 BACKUP I External inrerrupt input 27 P31/INT1/A12 BRD. I 28 P32/CNTR0/OE DAL. I Timer input 29 P33/CNTR1/Vpp VR1 I 30 P40/A13 SEPA I 31 P41/A14 FMT O 32 P42 ILL2 O 33 P43 ILL1 O 34 P00/D0 SDA I/O Key ON wake-up function 35 P01/D1 SCL O 36 P02/D2 MD WKUP I 37 P03/D3 ATT. THROUGH I 38 P04/D4 ATT. HOLD I 39 P05/D5 INPUT I 40 P06/D6 ILL. I 41 P07/D7 P-DET I 42 P52 VR3 I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 M-AX10 Perform reading from the EEPROM while RAM is being initialized after the AC power is turned on (port 25 (Pin25) (RESET): L). Set the read data to RAM using "initcont" after resetting is completed. (See "2. Initializing.(P.44)") RESET RAM set complete flag of EEPROM readout data [ f_eeprom_rd_set ] = 0 AC check (Voltage of ACSUB) (IC901 Internal Port) Register initialize RAM initialize EEPROM readout BACKUP check OK ? Flag for the power ON [ f_power ] = 1 Flag for initializing [ f_i nit ] = 1 RAM clear for memory communication Timer [ tminit ] = 50 msec set RETURN Fig. Flow chart of RESET N Y SPECIFICATIONS 1. Basics 1.1 Reset Perform the reset when connecting the AC power supply. 1.2 BACKUP Mode Backup is performed when the AC power is turned off. SPRYH (port 16) and SPRYG (port 17) are set to "L" 10 ms after the BACKUP port becomes "L." All the indicators and lamps go dark. Execution of the BACKUP processes (port processing and register processing) begins 30 ms later. Last memory writing to the EEPROM is performed each time a key is operated, but not performed in the backup processes. Port processing 1) I/O ports are specified as output ports. 2) Output ports are set to "L." Backup targets INPUT1/2, ATT.THROUGH, ATT. HOLD (The level value is also backed up when ON), ILL. (The VOLUME level and mode settings at the mechanical switch are checked each time the power is turned on.) As writing to ROM may require 40 ms at maximum, 5 V will be supplied to the microcomputer for about 100 ms after the AC power is turned off at the hardware. The data to be written are composed of the following 3 bytes: BRD. DUAL Bright / dark / off PRO. ON/OFF ON/OFF 1/2 ILL INPUT ATT. THR ATT. HOLD ATT. LEVEL At ATT. HOLD ON only Communication is made using ports 34 (SDA) and 35 (SCL) as output ports. 1 Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 ILL1 ON/OFF ILL2 ON/OFF INPUT 1/2 ATT. THROUGH ON/OFF ATT. HOLD ON/OFF SEPARATE ON/OFF DUAL ON/OFF BRIDGE ON/OFF 2 3 VOLUME position (5 bit) * At ATT. HOLD ON only BACKUP code Following item "1."~"7." (P.43~P.51) describe about the specifications of IC901 PD5508B9. IC901 PD5508B9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 M-AX10 1.3 Last Memory Last memory writing to the EEPROM (IC904:AT24C01-10OC) is performed each time a key is operated. Input-independent last memory is not provided. The ILL and ATT.THROUGH settings remain the same in switching between INPUT 1 and 2. 1.4 TEST Mode None 1.5 SILENT Mode The unit can enter SILENT mode in a condition other than the following: • The BACKUP port is "L." (BACKUP mode) • A volume operation is being processed. • A key input is being processed. • Caution status for mode switching (caution indication state at the operation of OPERATION MODE SW during Power-On state) When 200 ms have elapsed after such a process is completed, the unit can enter SILENT mode. The unit restarts upon key input, a volume operation, mode switching, or P-DET input. The timer is set for 5-second restarting. When 200 ms have elapsed after the restarting process is completed, the unit can enter SILENT mode again. (SILENT mode : The control µ-com enter the low power consump- tion mode and stops the oscillation of system clock.) 1.6 POWER ON/OFF (1) POWER ON After POWER ON, port 16 (SPRYH)(Pin16) is set to "L" and port 31 (FMT)(Pin31) is set to "H." Port 31 (FMT) is set to "L" after 3 seconds, and muting is set to OFF. After another 5 seconds (8 seconds after POWER ON), ports 16 (SPRYH) and 17 (SPRYG)(Pin17) are set to "H," and relay is set to ON. Power ON 3 sec 5 sec 16 (SPRYH) 31 (FMT) (2) POWER OFF Port 16 (SPRYH)(Pin16) is set to "L" 10 ms after POWER OFF (port 26 (BACKUP)(Pin26) becomes "L"). Ports that must be processed other than port 16 are operated immediately after this. 10 msec 26 (BACKUP) 16 (SPRYH) 2. Initializing The main routine starts after reset processing. Normal processing starts after the initializing process is completed with "initcont". The data read during the reset processing are written to RAM. (See the "1. Basics"(P.43).) If the MODE switch was not operated during the POWER OFF period, the read data are written to RAM. If the MODE switch was operated during the POWER OFF period, the default settings are made. Default: INPUT1 ATT.THROUGH OFF ATT.HOLD OFF ILL Bright Then the timers are set. Refer to the next page Fig.1. (normal operation mode) IC901 PD5508B9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 M-AX10 200 msec 50 msec 100 msec 40 msec 8 sec Reset INITCONT start ACTION start AC check Register initial setting RAM initial setting when EEPROM read out is OK. RAM initial setting when EEPROM read out is NG. Timer [tminit] INITCONT processing Relay Timer [tmprot] MUTE Timer [tmmute] INPUT SW set ATT. through SW set MODE SW set ILL. lights processing DAC VOL transfer processing At ATT. through ON At ATT. through OFF Tact key accept start Timer [tmdcerr] Silent mode Fig.1 Timing chart of initializing process from the reset LED lights processing 1 2 3 4 5 6 $ 3 sec # 7 8 ! ~ 200 msec % 9 0 - 2 sec = 5 sec @ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 M-AX10 36 (MD WKUP) SW1 SW2 37 (ATT.THROUGH) 38 (ATT.HOLD) 39 (INPUT) 40 (ILL) Microcomputer IC901 SW3 SW4 SW5 3. Key Input (IC901) Key Input Port Indicator Process Port ACT DUAL BRIDGE Contents of Process Key input, indicators and processes Cycles Bright/Dark/Off at each key input. (ILL1, ILL2) Bright (H, L) Dark (L, H) Lamp Off (H, H) LED Off (L, L) Factory setting: Bright (H, L) SEPARATE 37 (ATT. THROUGH) 10 (IND ATT. THROUGH) L Alternates "H" and "L" alternately at each key input. Alternates "H" and "L" alternately at each key input. Key disabled with ATT.HOLD ON. 39 (INPUT) 5 (IND IN1) 6 (IND IN2) L Sets INDIN1 and INDIN2 to "H" and "L" alternately at each key input. Alternates "H" and "L" alternately at each key input. Sets INDIN1 and INDIN2 to "H" and "L" alternately at each key input. Key disabled. Both INDIN1 and INDIN2 always lit ("H"). 38 (ATT. HOLD) 11 (IND ATT. HOLD) L 40 (ILL) None Key disabled. Always "L". Key disabled. Always "L". Alternates "H" and "L" at each key input. Key disabled with ATT. THROUGH ON. Key Input Port Indicator Process Port ACT DUAL BRIDGE Contents of Process SEPARATE 37 (ATT. THROUGH) 13 (DAC VR) L ON : "H" OFF : "L" ON : "H" OFF : "L" INPUT1 : "L" INPUT2 : "H" INPUT1 : "L" INPUT2 : "H" 39 (INPUT) 12 (INPUT2) L Fixed at L. ON : "H" (VOL invalid) OFF : "L" (VOL valid) Key disabled with ATT. HOLD ON. 38 (ATT. HOLD) L L 40 (ILL) 32 (ILL2) 33 (ILL1) Key disabled. Key disabled. ON : HOLD data valid VOL invalid OFF : VOL valid Key disabled with ATT. THROUGH ON. IC901 PD5508B9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 M-AX10 3.1 Key Inputs A key input becomes valid after 40 ms, to eliminate chatter. The ATT.THROUGH key input from OFF to ON becomes valid when the key is held pressed for 2 seconds. 3.2 Switch inputs The MODE switch (rotary switch) setting is read when the power is turned on. The switch operation with POWER ON is invalid. (See "7. WARNING."(P.50)) 4. KEY PROCESSING (IC901) 4.1 ATT.THROUGH Switching The ATT.THROUGH key input from ON to OFF becomes valid when the key is held pressed for 2 seconds. Any other key input during these 2 seconds is invalid. When switching from OFF to ON, the key input becomes valid at normal timing. Key input valid 2 sec 5 sec 10 msec 1 EEPROM writing Relay Mute LED ON/OFF processing Switching VOL. processing (ON → OFF) VOL. data line processing (OFF → ON) Silent processing Fig.2 Timing chart when ATT. through key is pressed 2 3 40 msec 4 5 40 msec 6 9 0 2 sec 8 100 msec 200 msec 7 Port 16 (SPRYH)(Pin16) is set to "L" 10 ms after ATT.THROUGH switching signal input, and relay is set to OFF. After another 30 ms, the INDICATOR port is processed. Port 31 (FMT)(Pin31) is set to "H," and muting is set to ON. Switching process is performed 100 ms after ATT.THROUGH switching signal input. When switching ATT THROUGH from ON to OFF: Data transfer to the DAC IC is performed 2 seconds after the key input. When switching ATT.THROUGH from OFF to ON: Port 2 (LD), port 3 (CLK), and port 4 (SRD) are fixed to "L" before DACVR (pin 13) is set to "L," 30 ms after relay becomes OFF. (See "6. DAC Volume Transfer."(P.49)) After another 2 seconds, port 31 (FMT)(Pin31) is set to "L," and muting is set to OFF. After another 3 seconds, port 16 (SPRYH)(Pin16) is set to "H," and relay becomes OFF. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 M-AX10 EEPROM writing LED processing Switching processing Silent processing Fig.3 Timing chart when INPUT key is pressed 4.2 INPUT switching INDICATOR port processing and switching process start 30 ms after INPUT key input [port 39 (INPUT)(Pin39): "L"]. No muting process is performed. INPUT key is pressed. 1 2 40 msec 3 4 40 msec EEPROM writing (OFF → ON) EEPROM writing (ON → OFF) VOL. transfer (ON → OFF) LED processing Port processing SILENT processing HOLD processing (OFF → ON) SILENT (OFF → ON) SILENT (ON → OFF) Fig.4 Timing chart when ATT. HOLD key is pressed Fig.5 Timing chart when ILL key is pressed 4.3 ATT.HOLD Key Processing ATT. HOLD key is pressed. typ. 8 msec 1 ILL key is pressed 1 2 typ. 1 msec 2 typ. 0 msec 4 5 typ. 10 msec 3 6 3 6’ Upon ATT.HOLD key input, the specified current volume value is held. While ATT.HOLD is ON, the volume level stays at the held value even if the volume control is operated. In Muting mode (when the power is turned on or ATT. THROUGH is switched from ON to OFF), the ATT.HOLD key is disabled. 4.4 ILL Key Processing Each press of the key cycles Bright, Dark, Lamp Off, and LED Off. Fig.6 Timing chart when volume is input 4.5 VOL Key Processing 4.6 Invalid Key Input 4 Data transfer to DAC SILENT processing VOL input valid VOL operation typ. 15 msec 1 An invalid key is pressed. typ. 16 msec 2 5 sec 3 Fig.7 Timing chart when an invalid key is pressed 1 SILENT processing 5 sec www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 M-AX10 5. Mode Switching Processing (IC901) Mode Input Port Indicator Process Port ACT Contents of Process Table Mode select indicator processing 27 (BRIDGE) 8 (IND BRD.) L Sets to "H". Sets to "H". Sets to "H". 28 (DUAL) 9 (IND DUAL) L 30 (SEPA.) 7 (IND SEPA.) L Select the mode of the speakers using the MODE switch (rotary switch). Any of three modes (BRIDGE, DUAL and SEPARATE) can be selected. Mode Input Port ACT 12 (INPUT2) Contents of Process Process Port Table Mode select port processing 27 (BRIDGE) INPUT1 : "L" ATT. through : "L" ATT. exist : "H" ATT. exist : "H" "L" "H" "L" INPUT2 : "H" ATT. through : "H" L 13 (DACVR) 14 (SEPARATE) 15 (INVERT) 16 (SPRYH) 17 (SPRYG) 28 (DUAL) INPUT1 : "L" ATT. through : "L" ATT. exist : "H" ATT. exist : "L" "L" "H" "L" INPUT2 : "H" ATT. through : "L" L 30 (SEPA.) Fixed at "L" ATT. through : "L" ATT. exist : "H" ATT. exist : "L" "H" "H" "L" ATT. through : "L" L The MODE switch is disabled while power is ON. (See "7. WARNING.") DACVR (pin 13) Data transfer Relay Three data lines "L" DACVR (pin 13) Switching 2 sec 6. DAC Volume Transfer (IC901) When the status of port 29 (VR1) changes, port 29 (VR1), port 30 (VR2), port 42 (VR3), port 23 (VR4), and port 24 (VR5) are checked to detect the VOLUME position. With DUAL, BRIDGE, or SEPARATE, the attenuation volume is read from the VOLUME position/ATT volume table and transferred to the DAC IC in Serial mode (MSB first). When the transfer is completed, LD (port 2) is set to "L" then returned to "H." When ATT.THROUGH is ON or port 13 (ATT.THROUGH) is "L," port 2 (LD), port 3 (CLK), and port 4 (SRD) are fixed at "L." Then the data are transferred again when port 13 (ATT.THROUGH) is set to "H." When switching ATT.THROUGH from ON to OFF or when turning power ON: Data transfer is performed 2 seconds after the switch is operated. When switching ATT THROUGH from OFF to ON or when turning the power ON: Port 2 (LD), port 3 (CLK), and port 4 (SRD) are fixed at "L" before DACVR (pin 13) is set to "L," 30 ms after relay becomes OFF. Data transfer is performed once in the following conditions and terminated: • When the power is turned on • When the VOL is operated • When ATT.THROUGH is switched from ON to OFF • When ATT.HOLD is switched from ON to OFF IC901 PD5508B9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 M-AX10 Position BRIDGE / DUAL Attenuation (dB) Serial Data Binary Code 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 00000 00001 00010 00011 00100 00101 00110 00111 01000 01001 01010 01011 01100 01101 01110 01111 10000 10001 10010 10011 10100 10101 10110 10111 11000 11001 11010 11011 11100 11101 11110 0 -2 -4 -6 -8 -10 -12 -14 -16 -18 -20 -22 -24 -26 -28 -30 -32 -34 -36 -38 -40 -42 -44 -46 -48 -50 -52 -54 -56 -58 Infinity FFF CB4 A17 804 65E 50E 404 331 289 203 199 145 102 CD A3 81 66 51 40 33 28 20 19 14 10 C A 8 6 5 0 -2.0021 -4.0026 -6.0015 -8.0013 -10.0064 -12.0052 -14.0006 -16.0002 -18.0089 -20.0106 -22.0074 -24.0127 -26.0100 -28.0013 -30.0333 -32.0731 -34.0754 -36.1215 -38.0937 -40.2039 -42.1421 -44.2863 -46.2245 -48.1627 -50.6615 -52.2451 -54.1833 -56.6821 -58.2657 #NUM! 0.0 -0.5 -1.0 -1.5 -2.0 -2.5 -3.0 -3.5 -4.0 -4.5 -5.0 -5.5 -6.0 -6.5 -7.0 -7.5 -8.0 -8.5 -9.0 -9.5 -10.0 -10.5 -11.0 -11.5 -12.0 -12.5 -13.0 -13.5 -14.0 -14.5 -15.0 FFF F19 E41 D75 CB4 BFE B53 AB0 A17 987 8FE 87D 804 791 725 6BE 65E 603 5AC 55B 50E 4C6 482 441 404 3CB 394 361 331 303 2D8 -0.5021 -1.0016 -1.5013 -2.0021 -2.5023 -3.0001 -3.5028 -4.0026 -4.5008 -5.0030 -5.5039 -6.0015 -6.5025 -7.0008 -7.5043 -8.0013 -8.5003 -9.0057 -9.5043 -10.0064 -10.5037 -11.0010 -11.5045 -12.0052 -12.5007 -13.0072 -13.5048 -14.0006 -14.5040 -15.0025 PROCESSOR Attenuation (dB) Serial Data 0.5 sec 1.0 sec ON OFF ON OFF Indicator of the operating mode Indicator after the switch is operated 7. WARNING 7.1 Protection When abnormal amplifier output is detected, the protection relay and function muting are controlled to warn the user. When P-DET (port 41) becomes "L," FMT (port 31) is set to "H" and port 16 (SPRYH) is set to "L" immediately. At the same time, ILL indicators flash in 1-second cycle. (ILL1, ILL2) = (H, L) ↔ (L, L) (ILL1=port33(Pin33) Flashing : Mode illumination light ILL2=port32(Pin32)) Mode indicator Panel light When the POWER OFF key is pressed, POWER OFF processing is performed. (All other keys are disabled.) Refer to 7.2 PROTECTION CIRCUIT about the circuit explanation. 7.2 Mode Switching Mode switching is allowed only when the power is OFF. If mode switching is performed with the power ON, relay is set to OFF. When the previous status is restored, relay is returned to ON. As a caution, the LED of the selected mode and the LED of the operating mode flash with the timing shown below. When the MODE switch is returned to its original setting, the LED flashing as a caution stops, and normal status is resumed. The MODE switch is read every loop. When the MODE switch is operated when the ILL indicator is dark, the indicator is forcibly turned on. When the MODE switch setting matches the operating mode setting, the ILL mode resumes its original status. Relay is set to OFF in the MODE CAUTION status. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 M-AX10 Switching (restoring the original setting) Switching Acknowledgment of switching [f_mderr_rq] Flag for Mode error LED Warning ILL lights if it is off Mode error LED warning Key disabled Relay ILL processing Silent mode Fig.8 Timing of mode switching error processing 20 msec 20 msec 10 msec 200 msec 4 3 2 1 VREF RFB IOUT GND VDD CLK SRI LD 8 7 6 5 12-BIT D/A CONVERTER 12-BIT DAC REGISTER 12 12 GND IOUT VDD CLK SRI 12-BIT INPUT SHIFT REGISTER LD VREF RFB RFB 2 3 1 5 7 6 4 8 7.3 Warning when switching ATT.THROUGH from OFF to ON When ATT.THROUGH is switched from OFF to ON, the key becomes valid when it is held pressed for 2 seconds. The ATT.THROUGH ON/OFF LED flashes during those 2 seconds. DAC8043FP (INPUT(L) ASSY : IC101, INPUT(R) ASSY : IC201) • D/A Converter IC • Block Diagram • Pin Assignment (Top View) IC901 PD5508B9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 M-AX10 7.2 PROTECTION CIRCUIT The protection circuits are provided for this unit. When these protection circuits are activated ,the hardware muting is activated and muting and the output relays are controlled by the microcomputer. There are two protection circuits. 1) DC voltage detection at the output 2) Overcurrent detection due to the short circuit at the load end 1. DC voltage detection circuit At the High-CH (Low-CH) output current amp of C.AMP (L)ASSY, DC voltage is detected by Q507 and Q509 (Q508 and Q510) and these transistors turned ON and P-DET signal becomes Low. When P-DET signal becomes Low ,relay control Tr. Q515 ,Q511 and Q512 becomes open and shut down the relay RY501 and RY502. Also microcomputer receive P-DET Low signal and activate the mute circuit and set OFF the relay control Tr. Q513. 2. Overcurrent detection circuit At the High-CH (Low-CH) output current amp of C.AMP (L)ASSY, (+) side overcurrent is detected by Q503 and Q505 (Q518,Q504 and Q506) and these transistors turned ON and P-DET signal becomes Low. Following is same as above. (–) side overcurrent is detected by Q517,Q503 and Q505 (Q504 and Q506) and these transistors turned ON and P-DET signal becomes Low. Following is same as above. Refer to next page FIg.1 about the circuit description. 3. Starting condition of the protection circuit The above protection circuits works under the following condition. DC voltage detection : about over ± 3V Overrcurrent detection : about over 14~15A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 M-AX10 C.AMP (L) ASSY (KU/CA : AWX7673) ( NY : AWX7280) OVERCURRENT DETECTION CIRCUIT OVERCURRENT DETECTION CIRCUIT DC VOLTAGE DETECTION CIRCUIT DC VOLTAGE DETECTION CIRCUIT Fig.1 PROTECTION CIRCUITS +HOUT L [H – CH L] [L – CH L] –HOUT L +LOUT L –LOUT L SPRYH P-DET P-DET To U-com IC901 +23V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 M-AX10 7.3 DESCRIPTIONS 7.3.1 Product Overview Features of this product Three-mode drive power amplifiers This product is equipped with power amplifiers for two right and two left channels (total of 4 channels). Three types of speaker drive formats can be selected. 1. SEPARATE mode The product functions as a 4-channel power amplifier (115 watts, 4 ohms for each of 4 channels). By connecting to a 2-way channel divider, a high-grade multi-amplifier system can be established. Using two units of this product provides a Hi-Fi surround system for up to 8 channels. The product can also be used for DVD multi- channel audio, DOLBY DIGITAL, and DTS applications. 2. DUAL mode By connecting speakers that conform to tandem-wiring use, a Bi- amplifier (tandem amplifier) system can be established. By driving tweeters and woofers separately with different amplifiers, interference between speaker units is virtually eliminated. Thus, super hi-fi stereo playback with a high degree of purity is enabled. 3. BRIDGE mode The product functions as bridge-output high-power amplifiers (230 watts, 6 ohms for each of 2 channels). Symmetrical twin-stereo structure High-performance stereo amplifiers are symmetrically mounted left and right. Of course in SEPARATE or DUAL mode, enlargement of a large current loop can be eliminated even in BRIDGE mode, restraining sound degradation due to magnetic coupling, which is a disadvantage of bridge amplifiers. The important parts are isolated by shield plates and shield cases to achieve excellent channel separation at high frequencies (104 dB or more at 20 kHz between the left and right channels). You can enjoy high-grade stereophonic playback in a rich sound field. Advanced direct-energy MOSFET power amplifiers This product employs MOSFETs of larger capacity than with conventional models. For insulation between each large heat sink and MOSFET, a quite small zero-resistance ceramic sheet is employed to improve the radiation characteristics. Not only a rise in temperature with continuous signal input, but also instantaneous rises in temperature with pulse-type input can be minimized. For higher sound quality, the response speed to an input of large sound volume and the clarity are highly improved. In addition, a newly developed Z (ZETT) BIAS circuit that precisely reproduces the thermal factors of a MOSFET is mounted for temperature compensation for the idle current. This drastically improves the drift of the idle current which may greatly affect sound quality, and enables playback at constantly stable sound quality immediately after you turn on the power. Wide-range linear circuit The wide range linear circuit has been enhanced to improve DC stability by newly employing highly accurate parts of 0.5% error and single-chip dual transistors for a completely discrete structure that uses no DC servo or operational amplifier. This enables natural and clear playback of low frequencies by keeping NFB stable from very low frequencies. DAC (Digital Accurate Control) attenuator A high-precision 12-bit D/A converter of ladder resistance type is used. Advantages of the DAC attenuator (when compared with conventional mechanical sliding-type controls) 1. Excellent S/N in practical usage 2. The frequency response is not affected by the attenuation volume setting. 3. The attenuation volume can be programmed. This product provides two curves, for high-frequency attenuation in a multi- amplifier system and for normal volume control. 4. No tracking error (gain error between channels) 5. No signal irregularity from vibration, providing pure sound 6. The operation block and the circuit block can be separated. The signal path length can be minimized by free layout. Large-sized super ring toroidal transformer A large-sized super ring toroidal transformer of 450 VA is employed for the lowest possible loss and lowest impedance at the power block. In addition, repression of power harmonics, which has been regarded as impossible with large-capacity toroidal transformer, has been achieved, enabling powerful and smooth playback at high speeds. Silent control microcomputer When the knobs and buttons are not operated, the control microcomputer enters Low-Power-Consumption mode (system clock oscillation stops). This decreases power consumption, and eliminates high-frequency interference caused by clock oscillation to maintain high sound quality. In addition, the microcomputer continuously monitors the amplifier status and if it detects an abnormality, it immediately activates the protection circuit. By using the microcomputer in combination with the conventional hardware- protection circuit, higher reliability and safety are ensured. Ultra-Low-Impedance Power Circuit Power de-coupling by an ultra-low-impedance condenser, ample jumper lines and a No. 16 wire power cable are employed for very low impedance in the power and ground lines. In the low frequency range, channel separation is greatly improved (achieving 115 dB at 20 Hz) by decreasing ground common impedance. In the high frequency range, the rise in impedance due to the inductance component is suppressed, for higher frequency stability. Thus a power amplifier that is virtually impervious to changes in speaker impedance and connection cables has been created. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 M-AX10 7.3.2 Circuit Description Block Diagram + – + – + – + – + – µ-COM EEPROM 1V/50kΩ Input 2 (Low ch) 12dB FLAT AMP ±30V Power Amp Current Stage (Full-wave voltage doubler rectifier) (for Rch same as L ch) ±40V Power Amp Current Stage FLAT AMP 14dB POWER AMP Input 1 (High ch) Silent microcomputer Interruption ATT DATA input KEY input MODE SW INDICATOR FUNC MUTE MODE RY INPUT RY PROTECTION RY ATT CONTROL Protection circuit detection AC ON/OFF information BACK UP RESET Backup Microcomputer Microcomputer LOCAL CIRCUT ON/OFF MUTE 10A(/KU/CA) 4A (/NY) Vref Iout MUTE Protection circuit detection Red Blk Blk Red Low ch OUTPUT VOLTAGE DUAL SEPARATE BRIDGE 37.1V(200W)/6Ω 20V(100W)/4Ω High ch +5V DAC IC LED LED 15V 24V + ~ ~ – 24V 5V Microcomputer RY AC for Lch LED Bridge ±18V Op Amp IC AC IN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 M-AX10 IN 1 IN 2 Each mode of block diagram 12dB 12dB 14dB 14dB DAC VR – Dual Drive Mode – Low ch High ch + + + + RED BLK RED BLK RED BLK RED BLK RED BLK RED BLK Low ch High ch 12dB 12dB 14dB 14dB DAC VR – Separate Drive Mode – Low ch High ch + + + + IN 1 IN 2 12dB 12dB 14dB 14dB DAC VR – Bridge Drive Mode – Full Range + + + – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 M-AX10 Descriptions of the Block Diagram 1. INPUT switching block Four small-signal relays for individual channels are used for input signal switching. 2. 12-dB flat amplifier block The input signal is amplified by 12 dB (4 times) to increase the input level at the DAC attenuator block to improve the dynamic range and signal-to-noise ratio. In DUAL or BRIDGE mode, the flat amplifier on the low-channel side is shut down by the LOCAL CIRCUIT OFF circuit. The circuits are mounted in a shielded box to completely eliminate electrostatic and magnetic coupling. 3. DAC attenuator block Attenuator section This is a digitally controlled high-precision analog attenuator that uses a ladder resistance block of R-2R-type DAC ICs for volume control. The signal is input to the Vref (reference-voltage) terminal and the attenuated signal current is obtained from the Iout (current- output) terminal. The signal at this terminal is converted to a voltage signal by an I-V converter of the operational amplifier. An output signal of the same phase as the input signal is obtained through inversion by the operational amplifier. The attenuation volume adjustment is controlled using serial data from the microcomputer. Control section A 5-bit (31-position) digital rotary switch is used. The rotation angle and information can be sent to the microcomputer, enabling the silent function (Low-Power-Consumption mode) of the microcomputer. Two DAC ICs are used for two individual channels. There is no mechanical contact, resulting in fewer errors in attenuation volume and gang errors within 0.1 dB at any position. The attenuation volume can be flexibly adjusted by the microcomputer software. With this product, it can be set in 2-dB steps (up to -58 dB) in BRIDGE mode and in 0.5 dB steps (up to -15 dB) in SEPARATE mode. When this product is used in combination with a preamplifier, you can bypass the DAC attenuator block using the ATT.THROUGH function. For this bypass switching, the same small-signal relay as with the INPUT switching clock is used. 4. 14-dB power amplifier block Pioneer's original "Direct-Energy MOSFET Amplifier" and "Wide- Range Linear Circuits" are mounted. The circuits function as the inversion/noninversion switching amplifier on the high-channel side and as an inversion amplifier in BRIDGE mode. This eliminates the necessity for an inversion amplifier otherwise essential for a bridge amplifier. 5. Protection circuit When a DC voltage at the output end or a short circuit at the load end is detected, hardware muting is activated and muting and output relays are controlled by the microcomputer. When a short circuit at the load end is detected, a resistance inserted between the MOSFET drain power sources is used (for current detection) in place of a bridge detection circuit, a device greatly affected by the phase difference between the output power voltage and current. Thus, possible malfunction of the protection circuit in practical use is prevented. 6. Power block A large (450-VA) Super Ring is employed for the transformer. The second coils are separated into three coil windings for left channel, right channel, and a subcircuit. For the power amplifier, a full-wave voltage doubler rectifier system is used to suppress high-frequency current. For the voltage amplifier, a half-wave voltage doubler rectifier system is used to obtain the specified voltage without using additional coils. Each signal stage has a local stabilized power source, and the lamps are driven at a constant current for low power consumption. 40dBV (100Vrms) 30dBV 20dBV (10Vrms) 10dBV 1Vrms 4Vrms, 12dBV 40Vrms, 32dBV 20Vrms, 26dBV Bridge Dual Separate 0dBV (1Vrms) -10dBV Maximum permission input level with attenuator (4Vrms) Input 1, 2 Speaker Out Input high, low 12dB 0dB (-58dB MIN) 20dB Bridge 14dB Dual, Separate Input Buffer Amp. Power Amp. DAC VR ATT through ATT ON Level Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 58 M-AX10 9. PANEL FACILITIES AND SPECIFICATIONS FRONT SECTION 1 0 - 8 ~ 9 = 4 3 2 6 5 7 1 POWER Press to switch the appliance on and off. 2 OPERATION MODE Use this to switch between the three modes: bridge,dual and separate. Be sure to turn the power off before switching between modes. Switching with the power on will activate the warning circuit. The mode illumination light and mode indicator will flash, and the output will be muted. If it happens, you should turn the operation mode switch back to its original position. The flashing will stop, and your M-AX10 will return to normal. 3 ATT HOLD This button is activated only if the OPERATION MODE switch is pointing to SEPARATE. Press the ATT HOLD (attenuator hold) button while in separate mode allows whatever atten- uation has been set with the ATTENUATOR knob to be retained. Pressing it again will cancel the operation. Note,however, that it is not possible to turn ATT HOLD on and off while the output is muted (eight seconds after switching the power on). 4 ATT THROUGH BEWARE: If this button is used ,the volume will be herted at maximum level. Pressing the ATT THROUGH button for two seconds or longer causes the sound to be output through the speakers without passing through the attenuator circuit. However, because the mute circuit is activated, thereis no sound for five seconds after the button is depressed. The sound will emerge from the speakers five seconds after the ATT THROUGH button is pressed. Note that it will be maximaum volume. Pressing the button again will cancel the operation. 5 ILLUMINATION Pressing the ILLUMINATION button once, twice or three times alters the brightness of the panel light, mode indicator as indicated below. Pressing it a fourth time will return the lights to their initial settings. Panel light Mode illumination light Mode indicator initial setting Press once Press twice Press three times Bright On On Off On On Dim On On Off Off Off www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 M-AX10 6 INPUT This button allows you to switch between INPUT 1 and INPUT 2. Note,however,that this is not possible if the the OPERATION MODE switch is set to SEPARATE. 7 ATTENUATOR This Knob allows you to adjust the attenuation in 31 stages.In dual and bridge modes it functions as a volume control : 0 dB when turned full right, and - ∞ when turned full left. In Separate mode it functions as an attenuator for adjusting the volume of the high-frequncy channel (0 to -15 dB,in 0.5 dB steps): turning it to the left lowers the volume. 8 MODE ILLUMINATION LIGHT The lamp display changes as illustrated below depending on whether the OPERATION MODE switch is set to BRIDEGE, DUAL or SEPARATE. Switching operations modes while the power is on will activate the warning circuit and cause the mode illumination light to flash. Bridge mode Separate mode Dual mode 9 MODE INDICATOR The lettering lights up to show whether the OPERATION MODE switch is pointing to BRIDGE, DUAL ,SEPARATE. Switching operation modes while the power is on will activate the warning circuit and cause the mode indicator to flash. 0 ATT THROUGH INDICATOR This indicator lights up when ATT THROUGH is ON. - ATT HOLD INDICATOR This indicator lights up when ATT HOLD is ON. = INPUT INDICATORS These indicators light up to show whether INPUT 1 or INPUT 2 has been selected. They both light up in Sepa- rate mode. ~ PANEL LIGHT This illuminates the display panel. The M-AX10 has four built-in amplifier channels, which can be connected by means of three different operation modes: BRIDGE ,DUAL and SEPARATE. You may select the mode which best suits your purpose and the equipment you are co- nnecting to your M-AX10. Bridge conection • The four channels are connected two by two, so as to act as two high-output amplifier channels. • Output comprises two 230 W/ 6 Ω (DIN),200 W/ 6 Ω (FTC) channels. • Your speakers must be at least 6 Ω . Dual conection • The four channels act as two parallel sets of twin amplifier channels. • Output comprises two 110 W/ 3 Ω (DIN),90 W/ 3 Ω (FTC) channels. • Speakers with bi-wire terminals will allow you to achieve high-quality sound. Separate conection • The channels act separately as four amplifier channels. • Output comprises two 110 W/ 3 Ω (DIN),90 W/ 3 Ω (FTC) channels. • Connecting a channel divider will allow you to use the appliance as an amplifier for a multi-channel system. • You can adjust the volume of speakers connected to the HIGH channels (INPUT 1) in a range from 0 to 15 dB. You can also retain the attenuation once you have set it. • Speakers connected to the LOW channels (INPUT 2) will always be at maximum volume. METHODS OF CONNECTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 M-AX10 SPEAKERS (R) These are terminal for right-hand speakers. SPEAKERS (L) These are terminal for left-hand speakers. INPUT 2 This is an input terminal for connecting CD players,control amplifiers,channel dividers and other components. INPUT 1 This is an input terminal for connecting CD players,control amplifiers,channel dividers and other components. Earth This is used for an earth connection with a source appearance equipped with an earth-floating function. The rear and under sections of this appliance are copper plated to ensure high quality sound. It may somtimes happen that marks are left during the plating process,but this does not affect performance. BEWARE When connecting,make sure that the power switch is off,and the power cord is disconnected from the power supply. The terminals are arranged symmetrically. Special care is required when connecting the speaker cords: failure to connect them in the correct manner for the desired mode will result in lost or imperfect sound. REAR SECTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 M-AX10 Continuous power output (driven simultaneously at 20Hz to 20kHz) ** (European mode only) Bridge mode T.H.D. 0.15% 6 Ω .................................................................... 220W × 2 T.H.D. 0.09% 8 Ω .................................................................... 190W × 2 Dual, Seaprate mode T.H.D. 0.15% 3 Ω .................................................................... 100W × 4 T.H.D. 0.09% 4 Ω ...................................................................... 90W × 4 T.H.D. 0.08% 8 Ω ...................................................................... 60W × 4 DIN Continuous power output (driven simultaneously at 1kHz) (European mode only) Bridge mode T.H.D. 1% 6 Ω .......................................................................... 230W × 2 T.H.D. 1% 8 Ω .......................................................................... 200W × 2 Dual, Seaprate mode T.H.D. 1% 3 Ω .......................................................................... 110W × 4 T.H.D. 1% 4 Ω .......................................................................... 105W × 4 T.H.D. 1% 8 Ω ............................................................................ 65W × 4 Total harmonic distortion ** Bridge mode 20 Hz to 20 kHz,100W, 8Ω .......................................................... 0.08% Dual, Seaprate mode 20 Hz to 20 kHz,30W, 8Ω ............................................................. 0.06% Input sensitivity/Impedance INPUT 1,2 .......................................................................... 1V/47kΩ Frequency Response INPUT 1,2 ............................................ 5Hz to 150 kHz +0dB, -3dB Damping factor (1kHz/20Hz to 20kHz) ............................................................................................ 400/300 SPECIFICATIONS Amplifier Section (U.S model only) When set to Bridge mode: Continuous average power output is 200 Watts* per channel, min.,at 6 ohms from 20 Herz to 20,000 Herz with no more than 0.2%** total harmonic distortion. When set to Dual mode ,Seaprate mode: Continuous average power output is 90 Watts* per channel, min.,at 3 ohms from 20 Herz to 20,000 Herz with no more than 0.2%** total harmonic distortion. Signal-to Noise ratio (IHF short circuit, A network ATT THROUGH ON) INPUT 1,2 .............................................................................. 125dB Channel separation(20Hz to 20 kHz) Bridge mode ........................................................................... 104dB Dual, Seaprate mode ............................................................. 115dB Power supply/Mischellaneouse Power requirements U.S.model ................................................................. AC120V 60Hz European model ................................................... AC230V 50/60Hz Power comsumption U.S.model ............................................................................... 370W European model ...................................................................... 400W Dimensions ................................... 440 (W) × 420 (D) × 178 (H) mm 175/16 (W) × 161/2 (D) × 7 (H)in.) Weight (without package) ..............................25.8 kg (56 lbs 14oz) Accessories Operation instructions .................................................................... 1 Warranty card ................................................................................ 1 NOTE Specifications and design subject to possible modifications without notice ,due to improvement. * Mesured pursuant to the Federal Trade Commissions' Trade Regulation rule on Power Claims for Amplifier. ** Mesured by Audio Spectrum Analyzer. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
