PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936 C PIONEER CORPORATION 1999 K-ZZB. DEC. 1999 Printed in Japan ORDER NO. CRT2354 MULTI CD CONTROL FM/AM CASSETTE DECK KEH-M8196ZT�X1N/ES Service Manual TOYOTA VEHICLE DESTINATION PRODUCED AFTER PART No. ID No. PIONEER MODEL No. CAMRY THAILAND January 2000 86120-YZB18 T7408 KEH-M8196ZT/X1N/ES CONTENTS 1. SAFETY INFORMATION............................................2 2. EXPLODED VIEWS AND PARTS LIST ......................3 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ....8 4. PCB CONNECTION DIAGRAM................................20 5. ELECTRICAL PARTS LIST........................................29 6. ADJUSTMENT.........................................................36 7. GENERAL INFORMATION.......................................38 7.1 DIAGNOSIS .......................................................38 7.1.1 TEST MODE .............................................38 7.1.2 SELF-DIAGNOSTIC FUNCTION ..............39 7.1.3 DISASSEMBLY.........................................43 7.1.4 CONNECTOR FUNCTION DESCRIPTION ......44 7.2 PARTS ................................................................45 7.2.1 IC...............................................................45 7.2.2 DISPLAY ...................................................47 7.3 SYSTEM BLOCK DIAGRAM .............................48 8. OPERATIONS AND SPECIFICATIONS....................49 - Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. - This service manual should be used together with the following manual(s): Model No. Order No. Mech. Module Remarks CX-631 CRT1640 2L Cassette Mech. Module:Mech.Description, Disassembly www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 KEH-M8196ZT - Service Precautions 1. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector is plugged or unplugged. 2. Whenever the amplifier may be put into operation, a heat sink should be mounted. ICs and transistors may be damaged if the amplifier should be put into operation without mounting any heat sink. 3. When operating with large output power, the heat sink becomes very hot. Be careful not to touch it. 1. SAFETY INFORMATION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so and refer the repair to a qualified service technician. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEH-M8196ZT 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 KEH-M8196ZT 2. EXPLODED VIEWS AND PARTS LIST 2.1 EXTERIOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 KEH-M8196ZT - EXTERIOR SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. 1 Screw BMZ26P050FMC 2 Screw BMZ26P180FMC 3 Screw BMZ30P060FMC 4 Case CNB2460 5 Holder CNC7121 * 6 Cushion CNM5281 7 Insulator CNM6079 8 Heat Sink CNR1510 9 Main Unit CWM6621 10 Screw BMZ30P050FMC 11 Screw CBA1339 12 Connector(CN302) CKM1306 13 Connector(CN301) CKM1307 14 Plug(CN304) CKS3537 15 Connector(CN571) CKS3568 16 Antenna Jack(CN601) CKX1006 17 Holder(CN303) CNC5399 * 18 Holder CNC6066 19 Holder CNC7523 20 Holder CNC8105 21 Tuner Unit CWE1426 22 Holder CNC6122 23 Chassis Unit CXB3361 24 Screw BPZ26P100FMC 25 Button( , ) CAC5914 26 Button( ) CAC5915 27 Button(1,2) CAC5916 28 Button(3,4) CAC5917 29 Button(5,6) CAC5918 30 Button(SCAN) CAC5919 31 Button(CD,AM/FM,TAPE) CAC5920 32 Holder CNC8133 33 Lighting Conductor CNV5647 34 Lighting Conductor CNV5657 35 Lighting Conductor CNV5725 36 Lighting Conductor CNV5726 37 Keyboard Unit CWM6231 38 LCD(LCD901) CAW1564 39 Socket(CN901) CKS3550 40 Holder CNC8103 41 Holder CNV5644 42 Lighting Conductor CNV5645 43 Connector CNV5646 44 Knob Unit(VOLUME) CXB3359 45 Spring CBL-108 46 Knob Unit(AUDIO CONTROL) CXB3360 47 Antenna Jack(CN602) CKX1005 48 Grille Unit CXB5566 49 Door CAT2022 50 Spring CBH1712 51 Holder CNV5656 52 Cassette Mechanism ModuleEXK3875 53 Cushion CNM6078 54 Screw IMS30P050FMC 55 IC(IC404) TDA7385 56 IC(IC381) PA2024A 57 Spacer CNM6468 58 Spacer CNM6549 59 Cushion CNM6091 NOTE: - Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List. - Screws adjacent to ∇ mark on the product are used for disassembly. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 KEH-M8196ZT 2.2 CASSETTE MECHANISM MODULE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 KEH-M8196ZT 1 Screw BSZ20P040FMC 2 Washer CBF1037 3 Washer CBF1038 4 Washer CBG1003 5 Deck Unit EWM1016 6 Screw EBA1028 7 Screw EBA1037 8 Spring EBH1531 9 Spring EBH1589 10 Plug(CN251) CKS3540 11 Spring EBH1515 12 Spring EBH1587 13 Spring EBH1517 14 Spring EBH1518 15 Spring EBH1519 16 Spring EBH1537 17 Wire EDD1020 18 Photo-interrupter(EGN2,3) EGN1006 19 Photo-interrupter(EGN1) EGN1005 20 Roller ENR1031 21 Shaft ELA1362 22 Roller ELA1348 23 Arm ENC1490 24 Arm ENC1397 25 Guide ENC1519 26 Holder ENC1516 27 Lever ENC1448 28 Arm ENC1488 29 Roller ENR1023 30 Belt ENT1027 31 Gear ENV1347 32 Collar ENV1508 33 Gear ENV1350 34 Flywheel ENV1500 35 Worm Gear ENV1439 36 Worm Wheel ENV1440 37 Gear ENR1037 38 Lever ENV1533 39 Arm ENV1525 40 Gathering PCB ENX1037 41 Gathering PCB ENX1042 42 Switch(S1,S2) ESG1004 43 Motor Unit(M2) EXA1382 44 Chassis Unit EXA1559 45 Tube ENM1039 46 Roller ENR1027 47 Reel Unit EXA1560 48 Head Base Unit EXA1434 49 Lever Unit EXA1578 50 Gear Unit EXA1545 51 Frame Unit EXA1476 52 Lever Unit EXA1439 53 Head Assy(HD1) EXA1593 54 Motor Unit(M1) EXA1499 55 Washer HBF-179 56 Screw JGZ20P025FNI 57 Spring EBH1545 58 Washer YE20FUC 59 Pinch Roller Unit EXA1533 60 Pinch Roller Unit EXA1532 Mark No. Description Part No. Mark No. Description Part No. - CASSETTE MECHANISM MODULE SECTION PARTS LIST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM A B D E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MODEL MODEL MODEL 11.4 C KEYBOARD UNIT B TUNER UNIT F CASSETTE MECHANISM MODULE E D 11.3 ANTENNA JACK ANTENNA JACK 10 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 A-a A-b A-a A-b A-b A-a Large size SCH diagram Guide page Detailed page A C 3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE) Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. A-a www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1.4 1.4 6 FM:0V AM,SW:4.5V TAPE,CD:11.5V ANT ANT A MAIN UNIT 11 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 A-b A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 11.4 B TUNER UNIT 11.3 ANTENNA JACK ANTENNA JACK A-a A-a A-b 1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 MODEL MODEL MODEL ANT ANT C KEYBOARD UNIT F CASSETTE MECHANISM MODULE E D A-a A-a A-b C 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 1.4 1.4 6 A MAIN UNIT A-a A-b A-b 1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 FM:0V AM,SW:4.5V TAPE,CD:11.5V A-a A-b A-b 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 3.3 TUNER UNIT B PA4023B DSP-201M-A11F IC1 B TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8B IC2 PA4024A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Fwd-R Fwd-L Rev-R Rev-L EXA1593 18 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 3.4 CASSETTE MECHANISM MODULE D DECK UNIT D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 . EXA1499 EXA1382 SWITCHES: PCB UNIT S1:LOAD SWITCH..........EJECT-PLAY S2:70µs SWITCH............ON-OFF The underlined indicates the switch position. E PCB UNIT F REEL PCB F E D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 A MAIN UNIT 4. PCB CONNECTION DIAGRAM 4.1 MAIN UNIT NOTE FOR PCB DIAGRAMS 1. The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic diagram. 2. Viewpoint of PCB diagrams Capacitor Connector P.C.Board Chip Part SIDE A SIDE B A B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8 CN901 D A CN251 C SIDE A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 A A MAIN UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 KEH-M8196ZT 5 6 7 8 A B C D 5 6 7 8A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 4.2 TUNER UNIT B SIDE A B A TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 KEH-M8196ZT 1 2 3 4 A B C D 1 2 3 4 B SIDE B B TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 4.3 KEYBOARD UNIT C C KEYBOARD UNIT 26 CN304 A SIDE B SIDE A C KEYBOARD UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A CN602 27 KEH-M8196ZT 1 2 3 4 A B C D 1 2 3 4D D DECK UNIT 4.4 CASSETTE MECHANISM MODULE CN571 IC,Q ADJ VR302 IC351 IC251 Q351 Q352 VR301 HEAD ASSY E M1 M2 E A SIDE A SIDE B D DECK UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 KEH-M8196ZT A 1 2 3 4 B C D 1 2 3 4 E PCB UNIT E PCB UNIT F REEL PCB F E D SIDE A SIDE B CN253 E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 KEH-M8196ZT D 351 Diode ERA15-02VH D 352 Diode RD5R6JS(B2) D 353 Diode 1SS133 D 381 Chip Diode MA151WK D 421 Diode RD4R7JS(B2) D 422 Diode 1SS133 D 423 Diode 1SS133 D 601 Diode 1SV241 D 651 Chip Diode MA151WK D 652 Diode RD3R0ES(B2) L 301 Coil CTH1191 L 381 Ferri-Inductor LAU4R7K L 501 Ferri-Inductor LAU150K L 502 Ferri-Inductor LAU150K L 571 Inductor LFEA4R7J L 601 Inductor LCTBR15K3216 L 602 Inductor LCTBR15K3216 L 603 Inductor LCTB4R7K3216 L 604 Inductor LCTB4R7K3216 L 605 Inductor LCTBR15K3216 L 609 Ferri-Inductor LAU150K L 610 Inductor LCTA561J4532 L 651 Ferri-Inductor LAU4R7K L 652 Ferri-Inductor LAU470K L 653 Ferri-Inductor LAU4R7K L 654 Ferri-Inductor LAU150K X 501 Radiator 6.291456MHz CSS1303 X 651 Crystal Resonator 4.500MHz CSS1077 FU 301 Fuse 6.3A CEK1008 AR 601 Surge Protector DSP-201M AR 602 Surge Protector DSP-201M Tuner Unit CWE1426 RESISTORS R 301 RS1/10S473J R 302 RS1/10S223J R 303 RS1/10S222J R 304 RD1/4PU120J R 305 RS1/10S332J R 306 RS1/10S473J R 307 RS1/10S223J R 308 RD1/4PU102J R 309 RS1/10S472J R 310 RS1/10S473J R 311 RS1/10S104J R 312 RS1/10S473J R 313 RS1/10S104J R 314 RD1/4PU222J R 315 RS1/10S472J R 316 RS1/10S473J R 317 RS1/10S104J R 319 RS1/10S103J R 320 RS1/10S272J R 325 RS1/10S472J 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... Unit Number : CWM6621 Unit Name : Main Unit MISCELLANEOUS IC 331 IC NJM78L08UA IC 381 IC PA2024A IC 401 IC SN761029DL IC 402 IC NJM4558MD IC 403 IC NJM4558MD IC 404 IC TDA7385 IC 501 IC PE5033A IC 502 IC S-80740AND4I IC 531 IC CA0008AM IC 601 IC LA1061M IC 651 IC LC72146M Q 301 Transistor 2SB1238 Q 302 Transistor 2SB1198K Q 303 Chip Transistor 2SC2712 Q 304 Chip Transistor 2SC2712 Q 305 Chip Transistor 2SC2712 Q 306 Chip Transistor 2SC2712 Q 307 Transistor 2SA1162 Q 308 Transistor DTC114EK Q 311 Transistor DTC114EK Q 332 Transistor 2SB1198K Q 333 Transistor DTC114EK Q 334 Transistor 2SA1162 Q 335 Transistor DTC114EK Q 351 Transistor 2SD1859 Q 431 Chip Transistor 2SC2712 Q 432 Transistor DTC144EK Q 433 Chip Transistor 2SC2712 Q 434 Transistor DTC114EK Q 435 Transistor 2SA1162 Q 451 Transistor 2SC4081LN Q 452 Transistor 2SC4081LN Q 453 Transistor 2SC4081LN Q 454 Transistor 2SC4081LN Q 455 Transistor 2SC4081LN Q 456 Transistor 2SC4081LN Q 457 Transistor 2SC4081LN Q 458 Transistor 2SC4081LN Q 459 Transistor 2SC4081LN Q 460 Transistor 2SC4081LN Q 601 Chip Transistor 2SC2712 Q 602 Transistor DTC143TK Q 651 Transistor DTC114TK Q 652 Transistor DTC144EK Q 655 Chip Transistor 2SC2712 Q 656 Transistor 2SK330 D 301 Diode ERC04-02 D 304 Diode RD8R2JS(B1) D 305 Diode RD8R2JS(B1) D 306 Diode RD8R2JS(B2) =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 KEH-M8196ZT R 333 RS1/10S223J R 334 RS1/10S272J R 335 RS1/10S223J R 336 RS1/10S332J R 351 RS1/10S103J R 352 RS1/10S332J R 381 RS1/10S102J R 382 RS1/10S103J R 401 RS1/10S393J R 402 RS1/10S393J R 403 RS1/10S102J R 404 RS1/10S102J R 405 RS1/10S102J R 406 RS1/10S102J R 407 RS1/10S102J R 408 RS1/10S102J R 409 RS1/10S153J R 410 RS1/10S153J R 411 RS1/10S471J R 412 RS1/10S471J R 413 RS1/10S222J R 414 RS1/10S473J R 415 RS1/10S473J R 416 RS1/10S473J R 417 RS1/10S473J R 418 RS1/10S512J R 419 RS1/10S512J R 420 RS1/10S512J R 421 RS1/10S512J R 422 RS1/10S512J R 423 RS1/10S512J R 424 RS1/10S512J R 425 RS1/10S512J R 426 RS1/10S0R0J R 427 RS1/10S0R0J R 428 RS1/10S0R0J R 429 RS1/10S0R0J R 430 RS1/10S103J R 431 RS1/10S103J R 432 RS1/10S103J R 433 RS1/10S103J R 434 RS1/10S104J R 435 RS1/10S102J R 436 RS1/10S103J R 437 RS1/10S103J R 438 RS1/10S103J R 439 RS1/10S331J R 440 RS1/10S222J R 441 RS1/10S103J R 442 RS1/10S103J R 443 RS1/10S103J R 444 RS1/10S564J R 445 RS1/10S564J R 446 RS1/10S473J R 447 RS1/10S473J R 451 RS1/10S272J R 452 RS1/10S683J R 453 RS1/10S152J R 454 RS1/10S332J R 455 RS1/10S752J R 456 RS1/10S753J R 457 RS1/10S122J R 458 RS1/10S332J R 459 RS1/10S512J R 460 RS1/10S683J R 461 RS1/10S122J R 462 RS1/10S332J R 463 RS1/10S272J R 464 RS1/10S683J R 465 RS1/10S152J R 466 RS1/10S332J R 467 RS1/10S752J R 468 RS1/10S753J R 469 RS1/10S122J R 470 RS1/10S332J R 471 RS1/10S512J R 472 RS1/10S683J R 473 RS1/10S122J R 474 RS1/10S332J R 475 RS1/10S332J R 476 RS1/10S683J R 477 RS1/10S132J R 478 RS1/10S332J R 479 RS1/10S122J R 480 RS1/10S823J R 481 RS1/10S122J R 482 RS1/10S332J R 483 RS1/10S332J R 484 RS1/10S683J R 485 RS1/10S132J R 486 RS1/10S332J R 487 RS1/10S122J R 488 RS1/10S823J R 489 RS1/10S122J R 490 RS1/10S332J R 501 RS1/10S103J R 502 RS1/10S473J R 503 RA3C102J R 504 RS1/10S102J R 505 RS1/10S473J R 506 RS1/10S104J R 507 CCN1121 R 508 RS1/10S104J R 509 RS1/10S102J R 510 RS1/10S473J R 511 RS1/10S473J R 512 RS1/10S472J R 513 RS1/10S102J R 514 CCN1121 R 515 RS1/10S102J R 516 RS1/10S102J R 517 RS1/10S102J R 521 RS1/10S681J R 522 RS1/10S681J R 523 RS1/10S681J R 531 RD1/4PU101J R 532 RD1/4PU101J R 533 RD1/4PU680J R 561 RS1/10S473J R 562 RS1/10S473J R 563 RS1/10S473J R 571 CCN1120 R 572 CCN1120 R 573 CCN1120 R 574 RS1/10S681J R 575 RA3C473J R 576 RA3C273J R 591 RS1/10S272J R 592 RS1/10S272J R 593 RS1/10S332J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 KEH-M8196ZT R 594 RS1/10S332J R 602 RS1/10S391J R 603 RS1/10S471J R 604 RS1/10S683J R 605 RS1/10S224J R 606 RS1/10S182J R 607 RS1/10S104J R 608 RS1/10S473J R 609 RS1/10S473J R 610 RS1/10S103J R 611 RS1/10S103J R 612 RS1/10S103J R 613 RS1/10S104J R 614 RS1/10S334J R 615 RS1/10S101J R 616 RS1/10S101J R 617 RS1/10S104J R 651 RS1/10S103J R 652 RS1/10S472J R 654 RS1/10S473J R 655 RS1/10S333J R 656 RS1/10S473J R 657 RS1/10S222J R 658 RS1/10S473J R 659 RS1/10S103J R 660 RS1/10S103J R 661 RS1/10S102J R 662 RS1/10S222J R 663 RS1/10S152J R 664 RS1/10S102J R 665 RS1/10S472J R 666 RS1/10S102J R 671 CCN1121 R 672 RS1/10S473J R 691 RS1/10S272J R 692 RS1/10S272J R 693 RS1/10S562J R 694 RS1/10S562J R 701 RS1/10S682J R 702 RS1/10S682J R 703 RS1/10S682J R 704 RS1/10S682J R 705 RS1/10S472J R 706 RS1/10S472J R 707 RS1/10S472J R 708 RS1/10S472J CAPACITORS C 301 3300µF/16V CCH1177 C 302 CEJA2R2M50 C 303 CKSQYB103K50 C 304 CKSQYB103K50 C 305 CKSQYB103K50 C 308 CKSQYB102K50 C 331 CEJA470M25 C 332 CEJA100M16 C 351 CEAS221M16 C 353 CEJA1R0M50 C 354 CKSQYB103K50 C 355 0.047F/5.5V CCL1040 C 356 CKSQYB103K50 C 357 CEJA101M6R3 C 381 CKSQYB102K50 C 382 CEJA1R0M50 C 383 CEAS470M10 C 384 CEAS470M10 C 385 CEAS470M10 C 386 CEAS470M10 C 401 CKSQYB104K16 C 402 CEJA470M10 C 403 CEJA1R0M50 C 404 CKSQYB472K50 C 405 CKSQYB472K50 C 406 CEJANP4R7M16 C 407 CEJANP4R7M16 C 408 CEJANP4R7M16 C 409 CEJANP4R7M16 C 410 CEJA1R5M50 C 411 CEJA1R5M50 C 412 CKSQYB153K25 C 413 CKSQYB153K25 C 414 CKSQYB104K16 C 415 CKSQYB104K16 C 416 CKSQYB474K16 C 417 CKSQYB474K16 C 418 CEJANP4R7M16 C 419 CEJANP4R7M16 C 420 CEJA2R2M50 C 421 CEJA100M16 C 422 CKSQYB473K16 C 423 CEJA101M6R3 C 424 CKSQYB102K50 C 425 CEJANP4R7M16 C 426 CEJANP4R7M16 C 427 CEJANP4R7M16 C 428 CEJANP4R7M16 C 429 CCSQCH101J50 C 430 CCSQCH101J50 C 431 CCSQCH101J50 C 432 CCSQCH101J50 C 433 CKSQYB103K50 C 434 CKSQYB103K50 C 435 CKSYB474K16 C 436 CKSYB474K16 C 437 CKSYB564K16 C 438 CKSYB564K16 C 439 CFTLA224J50 C 440 CFTLA224J50 C 441 CFTNA224J50 C 442 CFTNA224J50 C 443 CEHAS1R0M50 C 444 CFTNA224J50 C 445 CEHAS220M16 C 446 CKSQYB104K16 C 447 CEJA330M10 C 448 CKSQYB223K25 C 449 CKSQYB103K50 C 451 CKSQYB274K16 C 452 CKSQYB124K16 C 453 CKSQYB103K50 C 454 CKSQYB122K50 C 455 CKSQYB822K50 C 456 CKSQYB153K25 C 457 CKSQYB274K16 C 458 CKSQYB124K16 C 459 CKSQYB103K50 C 460 CKSQYB122K50 C 461 CKSQYB822K50 C 462 CKSQYB153K25 C 463 CKSQYB474K16 C 464 CKSQYB184K16 C 465 CKSQYB334K16 C 466 CKSQYB333K25 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 KEH-M8196ZT =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- C 467 CKSQYB474K16 C 468 CKSQYB184K16 C 469 CKSQYB334K16 C 470 CKSQYB333K25 C 481 CKSQYB272K50 C 482 CKSQYB272K50 C 483 CKSQYB272K50 C 484 CKSQYB272K50 C 485 CKSQYB272K50 C 486 CKSQYB272K50 C 487 CKSQYB272K50 C 488 CKSQYB272K50 C 501 CEJA100M16 C 502 CKSQYB103K50 C 503 CKSQYB102K50 C 504 CKSQYB102K50 C 505 CKSQYB102K50 C 506 CCSQCH330J50 C 507 CCSQCH330J50 C 508 CKSQYB102K50 C 509 CKSQYB103K50 C 510 CKSQYB104K16 C 511 CCSQCH101J50 C 531 CKSQYB103K50 C 532 CKSQYB221K50 C 533 CKSQYB221K50 C 591 CEJA1R0M50 C 592 CEJA1R0M50 C 601 CKSYB103K50 C 602 CCSQCH220J50 C 603 CCSQCH220J50 C 604 CCSQCH150J50 C 605 CCSQCH150J50 C 606 CCSQCH390J50 C 607 CKSQYB222K50 C 609 CKSQYB103K50 C 610 CKSQYB102K50 C 611 CEJA2R2M50 C 612 CKSQYB103K50 C 613 CKSQYB103K50 C 614 CKSQYB392K50 C 615 CKSQYB472K50 C 616 CEJA100M16 C 617 CKSQYB103K50 C 618 CKSQYB103K50 C 619 CKSQYB473K16 C 652 CKSQYB103K50 C 654 CKSQYB103K50 C 656 CKSQYB103K50 C 658 CKSQYB103K50 C 660 CKSQYB104K16 C 661 CKSQYB102K50 C 662 CKSQYB102K50 C 663 CCSQCH101J50 C 664 CCSQCH101J50 C 665 CEJA100M16 C 666 CKSQYB102K50 C 667 CKSQYB472K50 C 668 CGCYX103K25 C 669 CKSQYB103K50 C 670 4.7µF/16V CCH1165 C 671 CCSQCH120J50 C 672 CCSQCH120J50 C 673 CKSQYB102K50 C 674 CKSQYB102K50 C 675 CKSQYB102K50 C 676 CKSQYB103K50 C 677 CCSQCH101J50 C 691 CKSQYB223K25 C 692 CKSQYB223K25 C 693 CKSQYB682K50 C 694 CKSQYB682K50 C 695 CEJA1R0M50 C 696 CEJA1R0M50 C 701 CEJA4R7M35 C 702 CEJA4R7M35 C 703 CEJA4R7M35 C 704 CEJA4R7M35 C 705 CKSQYB221K50 C 706 CKSQYB221K50 C 707 CKSQYB221K50 C 708 CKSQYB221K50 Unit Number : CWM6231 Unit Name : Keyboard Unit MISCELLANEOUS IC 901 IC LC75853NW S 901 Switch CSG1041 S 902 Switch CSG1041 S 903 Switch CSG1041 S 904 Switch CSG1041 S 905 Switch CSG1041 S 906 Switch CSG1041 S 907 Switch CSG1041 S 908 Switch CSG1041 S 909 Switch CSG1041 S 910 Switch CSG1041 S 911 Switch CSG1041 S 912 Switch CSG1041 S 913 Switch CSG1041 S 914 Rotary switch CSD1037 IL 901 Lamp CEL1620 IL 902 Lamp 40mA 14V CEL1504 IL 903 Lamp 40mA 14V CEL1504 IL 904 Lamp 40mA 14V CEL1504 IL 905 Lamp 40mA 14V CEL1504 VR 901 Volume 50kΩ(B) CCS1264 LCD 901 LCD CAW1564 RESISTORS R 901 RS1/16S103J R 902 RS1/16S683J R 903 RS1/10S472J R 904 RS1/10S102J R 912 RS1/8S270J R 913 RS1/8S0R0J R 914 RS1/8S0R0J CAPACITORS C 901 CKSRYB821K50 C 902 CKSRYB473K16 C 903 CKSRYB473K16 C 904 CKSRYB103K50 C 905 CCSRCH101J50 C 906 CKSRYB102K50 C 907 CKSRYB102K50 C 908 CKSRYB102K50 C 909 CKSRYB102K50 C 910 CKSRYB102K50 C 911 CKSQYB102K50 C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 KEH-M8196ZT Unit Number : CWE1426 Unit Name : Tuner Unit MISCELLANEOUS IC 1 IC PA4023B IC 2 IC PA4024A Q 1 Transistor 2SC2712 Q 3 FET 3SK263 Q 31 Transistor 2SC2712 Q 201 Transistor FC12 Q 203 Transistor DTC124EU D 3 Diode 1SV251 D 4 Diode 1SV250 D 5 Diode KV1410-F1 D 6 Diode MA157 D 7 Diode KV1410-F1 D 8 Diode KV1410-F1 D 201 Diode MA157 D 202 Diode 1SV251 D 231 Diode SVC253 L 1 Inductor LCTBR12K2125 L 2 Coil CTC1145 L 3 Inductor LCTB4R7K2125 L 4 Coil CTC1131 L 5 Coil CTC1147 L 51 Ferri-Inductor LAU150K L 52 Coil CTC1136 L 201 Ferri-Inductor LAU4R7K L 202 Ferri-Inductor LAU330K L 203 Inductor CTF1371 L 208 Inductor LAU390K L 209 Ferri-Inductor LAU680K L 210 Coil CTB1103 L 231 Inductor LAU3R3J T 31 Coil CTE1116 CF 25 Ceramic Filter CTF1290 CF 51 Ceramic Filter CTF1290 CF 52 Ceramic Filter CTF1290 CF 53 Ceramic Filter CTF1290 CF 230 Crystal Filter CTF1262 CF 232 Ceramic Filter CTF1348 X 151 Radiator 918.5Hz CSS1365 X 231 Crystal Resonator 10.26MHz CSS1111 VR 101 Semi-fixed 15kΩ(B) CCP1230 VR 151 Semi-fixed 10kΩ(B) CCP1229 VR 154 Semi-fixed 150kΩ(B) CCP1236 VR 156 Semi-fixed 68kΩ(B) CCP1234 AR 1 Surge Protector DSP-201M RESISTORS R 3 RS1/16S223J R 4 RS1/16S101J R 5 RS1/16S181J R 6 RS1/16S101J R 7 RS1/10S331J R 8 RS1/16S473J R 9 RS1/16S473J R 10 RS1/16S223J R 11 RS1/16S124J R 12 RS1/16S474J R 15 RS1/16S271J R 16 RS1/16S104J R 17 RS1/16S473J R 18 RS1/16S473J R 19 RS1/16S154J R 27 RS1/16S0R0J R 31 RS1/16S470J R 32 RS1/16S912J R 33 RS1/16S912J R 34 RS1/16S331J R 35 RS1/16S331J R 39 RS1/16S0R0J R 51 RS1/16S331J R 55 RS1/16S102J R 56 RS1/16S823J R 61 RS1/16S392J R 62 RS1/16S273J R 103 RS1/16S333J R 104 RS1/16S334J R 105 RS1/16S683J R 107 RS1/16S222J R 152 RS1/16S393J R 155 RS1/16S563J R 157 RS1/10S183J R 160 RS1/16S222J R 161 RS1/16S563J R 162 RS1/16S225J R 163 RS1/16S222J R 165 RS1/16S102J R 202 RS1/16S223J R 203 RS1/16S225J R 204 RS1/16S103J R 205 RS1/16S471J R 206 RS1/16S220J R 207 RS1/16S101J R 208 RS1/16S102J R 209 RS1/16S0R0J R 214 RS1/16S563J R 215 RS1/16S473J R 217 RS1/16S393J R 220 RS1/10S0R0J R 231 RS1/16S242J R 232 RS1/16S473J R 233 RS1/16S0R0J R 234 RS1/16S0R0J R 237 RS1/16S103J R 238 RS1/16S104J R 239 RS1/16S104J R 240 RS1/16S472J R 241 RS1/16S202J R 243 RS1/16S123J R 244 RS1/16S103J R 247 RS1/10S153J CAPACITORS C 1 CCSRCH220J50 C 2 CKSRYB222K50 C 3 CCSRCH6R0D50 C 5 CKSRYB222K50 C 6 CKSQYB473K16 C 7 CKSQYB473K16 C 8 CKSQYB104K16 C 9 CCSRCJ3R0C50 C 10 CEJA1R0M50 C 11 CCSRCH470J50 C 12 CCSRCH820J50 C 13 CKSRYB222K50 C 14 CCSRCH4R0C50 C 15 CCSRCH7R0D50 C 16 CCSRCH120J50 C 17 CKSRYB222K50 C 18 CKSRYB103K25 C 19 CKSRYB222K50 C 20 CKSRYB222K50 C 21 CEJA100M16 C 22 CCSRRH100D50 C 23 CCSRRH120J50 C 24 CKSRYB103K25 C 30 CCSRRH201J50 C 31 CKSRYB103K25 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 KEH-M8196ZT C 32 CKSQYB473K16 C 33 CCSRCK2R0C50 C 35 CCSRCH270J50 C 36 CCSRCH120J50 C 40 CKSRYB222K50 C 41 CKSQYB104K16 C 51 CKSRYB223K25 C 52 CKSRYB103K25 C 54 CCSRCH470J50 C 55 CKSQYB223K25 C 56 CKSQYB104K16 C 57 CKSRYB472K50 C 58 CEJA330M10 C 59 CKSRYB103K25 C 60 CKSRYB102K50 C 61 CCSRCH270J50 C 62 CKSRYB103K25 C 63 CEJAR22M50 C 65 CKSQYB104K16 C 101 CEJANP100M10 C 102 CKSRYB182K50 C 103 CKSQYB682K50 C 104 CEJA2R2M50 C 105 CKSRYB103K25 C 106 CCSRCH151J50 C 107 CKSRYB103K25 C 151 CKSRYB472K50 C 152 CKSQYB104K16 C 153 CEJA3R3M50 C 154 CKSQYB104K16 C 157 CEJA3R3M50 C 158 CKSYB474K16 C 159 CEJA220M6R3 C 160 CKSQYB104K16 C 161 CKSQYB104K16 C 162 CEJA3R3M50 C 163 CKSRYB102K50 C 165 CCSRCH100D50 C 201 CKSRYB103K25 C 202 CCSRCH100D50 C 203 CKSRYB332K50 C 204 CKSQYB473K16 C 205 CKSQYB473K16 C 206 CKSQYB103K25 C 207 CCSRCH120J50 C 211 CCSRCH560J50 C 212 CEJA101M10 C 213 CKSRYB103K25 C 215 CCSRCH680J50 C 216 CCSRCH101J50 C 217 CEJAR47M50 C 219 CKSRYB223K25 C 220 CKSRYB103K25 C 221 CKSRYB103K25 C 230 CKSQYB104K16 C 231 CCSRCH330J50 C 232 CCSRCH150J50 C 233 CKSRYB103K25 C 234 CEJA330M10 C 235 CKSRYB332K50 C 236 CKSQYB473K16 C 237 CCSRTH180J50 C 239 CKSRYB103K25 C 240 CKSYB104K16 C 241 CKSQYB104K16 C 242 CEJAR47M50 C 243 CEJAR33M50 C 244 CKSQYB473K16 C 245 CKSQYB123K25 C 246 CKSQYB393K25 C 250 CCSRCJ3R0C50 Unit Number : EWM1016 Unit Name : Deck Unit MISCELLANEOUS IC 251 IC CXA2560Q IC 351 IC PA2020A Q 351 Transistor 2SB1260 Q 352 Transistor 2SC4102 D 351 Diode 1SS355 VR 301 Semi-fixed 33kΩ(B) CCP1280 VR 302 Semi-fixed 33kΩ(B) CCP1280 RESISTORS R 255 RS1/16S221J R 256 RS1/16S221J R 257 RS1/16S102J R 258 RS1/16S102J R 271 RS1/16S102J R 272 RS1/16S102J R 273 RS1/16S102J R 281 RS1/8S0R0J R 282 RS1/8S0R0J R 283 RS1/8S0R0J R 284 RS1/8S0R0J R 285 RS1/16S0R0J R 286 RS1/16S0R0J R 287 RS1/8S0R0J R 290 RS1/8S0R0J R 301 RS1/16S183J R 322 RS1/16S102J R 351 RS1/16S102J R 352 RS1/16S102J R 353 RS1/16S102J R 354 RS1/16S102J R 355 RS1/10S274J R 356 RS1/10S202J R 357 RS1/10S472J R 358 RS1/10S103J R 359 RS1/10S103J R 360 RS1/10S102J R 361 RS1/10S622J R 362 RS1/8S181J R 373 RS1/8S0R0J R 374 RS1/8S0R0J R 375 RS1/8S0R0J R 401 RS1/16S472J R 402 RS1/16S163J R 403 RS1/16S823J CAPACITORS C 251 CKSRYB331K50 C 252 CKSRYB331K50 C 253 CKSRYB331K50 C 254 CKSRYB331K50 C 255 CKSRYB103K25 C 256 CKSRYB103K25 C 272 CKSQYB104K16 C 273 CEJA220M16 C 301 CKSYB104K50 C 302 CKSYB104K50 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 KEH-M8196ZT C 309 CKSQYB104K16 C 310 CKSQYB104K16 C 313 CCSQCH101K50 C 351 CKSYB224K25 C 352 CKSQYB392K50 C 353 CKSQYB103K50 C 354 CKSQYB103K50 C 355 CKSYB104K50 C 356 CKSQYB103K50 C 401 CKSQYB334K16 C 402 CKSQYB472K50 C 403 CKSQYB683K16 Unit Number : Unit Name : PCB Unit S 1 Switch(LOAD) ESG1004 S 2 Switch(70µS) ESG1004 EGN 1 Photo-Interrupter EGN1005 Unit Number : Unit Name : Reel PCB EGN 2 Photo-Interrupter EGN1006 EGN 3 Photo-Interrupter EGN1006 MISCELLANEOUS M 1 Motor Unit(MAIN) EXA1499 M 2 Motor Unit(SUB) EXA1382 HD 1 Head Assy EXA1593 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 KEH-M8196ZT FM SSG Stereo Modulator 50Ω(37.5Ω) Antenna Plug Dummy Antenna 50Ω(75Ω) MAIN UNIT TUNER UNIT 4kΩ 4kΩ +13.2V Antenna Jack (Main) mV Meter (1) Oscilloscope DC Regulated Power Supply DECK UNIT DC V Meter(1) Center Meter Pin 19 TUNER UNIT (BOTTOM VIEW) C63 TUNER UNIT (TOP VIEW) L2 L5 T31 Pin1 Pin13 Pin14 Pin26 L4 VR156 DECK UNIT RR– RR+ RL+ RL– GND ACC VR154 VR101 L52 VR151 BU VR301 VR302 CN251 Pin2 Pin3 R-CH L-CH GGD1019 mV Meter(2) DC V Meter(2) Pin 6 L52 6. ADJUSTMENT - Connection Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 KEH-M8196ZT FM ADJUSTMENT Modulation M:MONO MOD., 400Hz 30%(22.5kHz Dev.) S1:STEREO MOD., 1kHz, L or R=30%(20.25kHz+7.5kHz Dev.) NOTE:Before proceeding to further adjustments after switching power ON, let the tuner run for ten minutes to allow the circuits to stabilize. FM SSG Displayed Adjustment Adjustment Method No. Frequency(MHz) Level(dBf) Frequency(MHz) Point (Switch Position) TUN Volt 1 ••••• ••••• 108.0 L5 DC V Meter(1) : 6.5V Center 1 98.1 M 65-85 98.1 L52 Center Meter : 0 Meter IFT 1 98.1 M 5-15 98.1 T31 mV Meter(1) : Maximum ANT 1 89.9 M 5-15 89.9 L2 mV Meter(1) : Maximum Coil RF Coil 1 89.9 M 5-15 89.9 L4 mV Meter(1) : Maximum Separation 1 98.1 S 65 98.1 VR101 mV Meter(1) : Maximum ARC 1 98.1 S 40 98.1 VR154 mV Meter(1) : Separation 5dB Separation Interstation 1 98.1 M 65 98.1 mV Meter(1) : AdB Noise 2 98.1 M -∞ 98.1 VR151 mV Meter(1) : A-20dB Search 1 98.1 M 27 98.1 VR156 DC V Meter(2) : more than 3.5V Sensitivity 2 98.1 M 26 98.1 VR156 DC V Meter(2) : 0 3 Repeat steps 1 and 2 until the adjustment standards are satisfied. DOLBY B NR ADJUSTMENT No. Test Tape Adjustment Point Adjustment Method (Switch Position) 1 NCT-150 VR301(Lch),VR302(Rch) mV Meter(2) : –6dBs±1dB (400Hz,200nwb/m) (DOLBY NR Switch : OFF) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 KEH-M8196ZT 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 TEST MODE Test mode is to be operated only when AVC-LAN CD changer is connected to this product. - Flow Chart 1 CD player select RPT Display Carriage shifted inwards while this key is pressed (Rough) CD Carriage move or T. jump 6 TRACK RPT SCAN SCAN SCAN SCAN SCAN RAND RPT Power OFF AGC AGC display select *1 Carriage move or T. jump *5 *3 *2 Display Regulator ON Power OFF Power OFF Power OFF Display Display example Carriage shifted outwards while this key is pressed Carriage shifted inwards while this key is pressed Carriage shifted outwards while this key is pressed Press the [CD] key three times, while holding down the [1] and [6] keys simultaneously. Diagnosis mode *2 Normal focus close 00 only. *3 Normal display Focus gain Track gain *5 In the case of 100TRK jump and C.MOVE mode only. *1 Press the DISP Key for change the display. CD test mode Press the [TRACK ] and [CD] keys simultaneously. CD 1-01 CD 1'50 *1 CD 1-11 CD 11'11 *1 CD 1- CD 0'00 *1 CD 1- CD ' Press the [CD] key two times. TRACK TRACK TRACK DISC TRACK TRACK DISC T.Jump mode serect *4 RAND Single 4TRK 10TRK 32TRK 100TRK C.MOVE *4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 KEH-M8196ZT 7.1.2 SELF-DIAGNOSTIC FUNCTION Normal mode System Check mode The system runs a self-diagnosis and displays the results (diagnostic codes). •Max. 6 Diagnostic codes for each physical address (for each connected device) •Displays the current status (past errors not displayed) Diagnosis Memory mode The system displays historical operational errors recorded for each physical address (for each device) during normal operation in the past. •Max. 6 Diagnostic codes for each physical address (for each connected device) LAN CHECK mode The system displays the physical address of each device connected to AVC-LAN. •The device's own physical address is included. Diagnosis Memory Clear The system clears Diagnosis Memory (the codes). •After completing clearing, the system goes to LAN CHECK mode. 6Memory Clear Complete clearing (automatic) 2End Diagnosis 3Go to System Check 4Return to LAN CHECK 5Go to Diagnosis Memory 4Return to LAN CHECK 2End Diagnosis 1Go to Diagnosis 2End Diagnosis - Flowchart and Functions - Operation Specifications KEH-M8196ZT/ES 1Go to Diagnosis Press the CD key three times, while holding down CH1 and CH6. 2End Diagnosis CD key (Press and hold for 1.7 seconds.) ACC OFF/ON 3Go to System Check CH1 4Return to LAN CHECK CH6 5Go to Diagnosis Memory CH2 6Memory Clear CH5 (Press and hold for 1.7 seconds.) •Page up TUNE + •Page down TUNE – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 KEH-M8196ZT 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 1 3 2 Display 1 — 123 Serial No. Physical address Example:2—190 II The second device connected is an “audio H/U.” 1Device groups 1 : Controllers 2 : Video output devices 3 : Audio output devices 4 : Audio processing devices 5 : Information output devices 6 : Vehicle devices - Physical Address Assignment M.DISP computer AV machine 1DIN -TV EMV CD-ROM navigation Audio ECU Audio H/U Rear seat TV Display with SW Rear control SW CD-CH commander MD-CH commander 0 8 1-8 A-F 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 2 Navigation computer ATIS FM multiple TV tuner CD-CH with video 0 1-F 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 3 Radio Cassette Radio/cas- sette without CH controller CD-P CD-CH MD-P MD-CH DAT DCC TEL ECU 0 8 1-7 9-F 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 4 Equalizer DSP H. W AMP 0 1-F 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 5 GPS receiver ATIS decoder FM multiplex decoder CD-CH MD-CH CD-ROM -CH MD-ROM -CH 0 1-F 1 0 1 2 3 4 5 6 7 8 9 A B C D E F 6 A/C computer Body computer 0 1-F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 KEH-M8196ZT 1 2 - Assignment of Diagnostic Codes Display 1 — 12 Serial No. Diagnostic code Example: 3—D2 II The third content of Diagnosis is "No response to periodical communications." NOTES: *1 Instruction to check for an error in periodical communications is interrupted. - Items corresponding each model • KEH-M8196ZT/ES D1, D2, D4, FF, 50 • KEH-M8196ZT/ES No Diagnostic code assigned 00 Common Diagnostic code among devices Diagnostic code specific to a particular device Diagnostic code for communications NO ERR +B error ACC error MUTE error Micropro- cessor error ROM error RAM error AM tuner error FM tuner error TV tuner error Cassette deck error Cassette deck EJT failure Tape entan- gled in the cassette deck Dirt in cassette deck head Broken cassette deck belt CD deck or CD-CH error CD, CH EJT failure Dirt, scar and upside- down in CD, CH Detected P.U tem- perature in CD, CH Detected overcur- rent in CD, CH CH tray error CH elevator error CD, CH clamp error MD deck or MD-CH error MD, CH r MD, CH r MD, CH r MD, CH r MD, CH recording function error CH r MD, CH r Amplifier error DSP error EQ error LCD error Switch error Antenna error Main antenna error Sub antenna error TV antenna error Antenna selector error AUDIO ECU error No response to commu- nications Commu- nications failure No response to periodical communica- tions *1 No response to Diagnosis 0 1 2 3 4 5 6 7 8 9 A B C D E F 0 1 2 3 4 5 6 7 8 9 A B C D/E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 KEH-M8196ZT LAN-CHECK mode System Check mode Diagnosis Memory mode Beep Display • The system displays the physical address of each device connected to AVC-LAN in sequence from the lowest address. Example: 1 — 1E0 Serial No. Physical address (CD commander) • When changing to another mode Lighting "SYS" is displayed. • After completing System Check Displays a physical address. ••Identifies the device. Example: H 150 Physical address (1DIN-TV) Distinguishes from LAN-CHECK. Displays a Diagnostic code. ••Identifies the type of error. Example: 1 — d2 Serial No. Diagnostic code (no response to periodical communications) Max. 6 for each physical address Displays an auxiliary code ••Identifies the device involved in the error. Example: 1 — 360 Serial No. Physical address (CD-CH) 1DIN-TV has recorded an error indicating there is no response to periodical communications in CD-CH. 1 — — — — When there is no physical address: Displays a physical address. The next lowest physical address • When there is no Diagnostic code after completion of System Check 00 The system changes as shown above, as this unit does not include System Check. • The system beeps three times when changing to another mode. • The system beeps once every time a physical address is displayed. • When changing to another mode Lighting "CODE" is displayed. • Then, "Latest periodical communications number" is displayed. ••Elapsed time at the current point is displayed. Example: 1F Elapsed time (31 minutes) • The system displays a number from 00 to FF (increases a digit every minute). • When 256 minutes are reached, the system returns to 00. • Displays the details of Diagnosis. Displays a physical address. (Same as the left.) Displays a periodical communications number. ••Displays the time when the error occurred. Example: 1 — 02 Serial No. Elapsed time (2 minutes) Displays Diagnostic code. (Same as the left.) Displays an auxiliary code. (Same as the left.) Displays a physical address. • When there is no Diagnostic data: 00 • The system beeps three times when changing to another mode. • The system beeps once every time a physical address is displayed. • The system beeps three times when starting up Diagnosis. - Go to Diagnosis (Beep and Display) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 KEH-M8196ZT - Remove the Main Unit(Fig.2) Remove the screw. Unbend the tabs at two locations indicated by arrow until straight. Remove the main unit. - Remove the Heat Sink(Fig.1) Remove the three screws. Remove the two screws and heat sink. Fig.2 Heat Sink Fig.1 7.1.3 DISASSEMBLY - Remove the Case(not shown) - Remove the Cassette Mechanism Module(not shown) 1. Remove the four screws. 2.Remove the connector and then remove the cassette mechanism module. - Remove the Grille Assy(not shown) 1. Disengage the stopper at four locations indicated remove the grille assy. Main Unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 KEH-M8196ZT 7.1.4 CONNECTOR FUNCTION DESCRIPTION BU MUT ACC NC TX+ TX- SGND GND L+ L- R- R+ BU ACC ILL NC NC GND FL+ FL- FR+ FR- RL+ RR+ RL- NC NC RR- ANTENNA JACK(MAIN) ANTENNA JACK(SUB) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 KEH-M8196ZT 7.2 PARTS 7.2.1 IC - Pin Functions(PE5033A) Pin No. Pin Name I/O Format Function and Operation 1 BL O C Back light control output 2 ILM O C Illumination control output 3 NC Not used 4 AVSS GND 5 ENC+ I Rotary encoder +Data input 6 ENC- I Rotary encoder -Data input 7 NC Not used 8 MUTE O C System mute output 9 AM/fm O C AM/FM select output 10 ANT O C Antenna control output 11 LDI I Key/LCD driver serial data input 12 LDO O C Key/LCD driver serial data output 13 LCK O C Key/LCD driver serial clock output 14 LCE O C Key/LCD driver chip select output 15 ECE O C ROM chip select output 16 PDI/TSI I PLL IC serial data input 17 PDO/TSO O C PLL IC serial data output 18 PCK/TCK O C PLL IC serial clock output 19 PCE O C PLL IC chip select output 20 SYSPW O C System power control output 21 stby O C Cassette mechanism stand-by control output 22 CM O C Cassette mechanism capstan motor control output 23 SC1 O C Cassette mechanism sub motor control output 1 24 SC2 O C Cassette mechanism sub motor control output 2 25,26 NC Not used 27 NES I Cassette mechanism forward end sense input 28 RES I Cassette mechanism reverse end sense input 29 POS I Cassette mechanism position sense input 30 LOAD I Cassette mechanism loading detection input 31 NR O C Cassette mechanism noise reduction output 32 mtl I Cassette mechanism tape select input 33 NC Not used 34 PLAY O C Tape MS filter select output 35 f/R O C Cassette mechanism forward/reverse select output 36 MS I Cassette mechanism MS sense input 37 LED O N LED control output 38–40 NC Not used 41–43 MODEL I Model select input 44 NC Not used 45 PEE O C Beep tone output 46 NC Not used 47 VST O C Strobe pulse output for electronic volume 48 VCK O C Clock output for electronic volume 49 VDT O C Data output for electronic volume 50–54 NC Not used 55 IPPOW O C IE-BUS power control output 56 IPDO O C IE-BUS driver data output 57 IPDI I IE-BUS driver data input 58,59 NC Not used 60 reset I Reset input 61 NC Open 62 csej I Cassette eject switch input 63 bsen I Back up sense input 64 isen I Illumination sense input 65 asen I ACC sense input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 KEH-M8196ZT Pin No. Pin Name I/O Format Function and Operation 66,67 NC Not used 68 VDD Power supply 69 X2 O Oscillator output 70 X1 I Oscillator input 71 IC Connect to GND 72 NC Not used 73 TEST/ten I Test mode/Test mode enable input 74 AVDD A/D converter analog power supply 75 AVREF2 A/D converter standard voltage 76 VOL I A/D input for VOL 77 SL I Signal level input from tuner 78 SD I SD input from tuner 79,80 NC Not used 80 1 20 21 40 41 60 61 *PE5033A IC's marked by* are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. Format Meaning C C MOS N N channel open drain www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 KEH-M8196ZT 7.2.2 DISPLAY - CAW1564 SEGMENT COMMON www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 KEH-M8196ZT 7.3 SYSTEM BLOCK DIAGRAM FR FL RR RL FOUR SPEAKERS MAIN UNIT MUSIC CD AUDIO SYSTEM MULTI-CD CDX-M9226ZT/ES ANT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 KEH-M8196ZT 8. OPERATIONS AND SPECIFICATIONS 8.1 OPERATIONS Listening to the Radio Band Power Volume Scan,Preset Scan Tuning Preset Fader Bass Treble Balance Listening to the Tape FF REW Eject Auto Program Search Dolby B NR Program Repeat Blank Skip Fader Bass Treble Balance Multi-CD Control CD Select Track Select Fast UP/Down Random Play Disc Random Disc Repeat Track Repeat Disc Scan Track Scan Display Change Power Volume Power Volume Fader Bass Treble Balance Disc Select www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEH-M8196ZT 8.2 SPECIFICATIONS Power source...............................................13.2V±0.2V DC Grounding system........................................Negative type Dimensions...............................180(W)x50(H)x165(D)mm Weight......................................................................1.210kg Amplifier Maximum power output ...............................20W or more Tone controls(bass) ........................................±9dB(100Hz) (treble) ....................................±10dB(10kHz) Loudness Contour .............5±3dB(100Hz),2.5±3dB(10kHz) Tape Tape................................Compact cassette tape(C30-C90) Tape speed ......4.76 cm/sec.(+0.14 cm/sec.,-0.05 cm/sec.) Crosstalk........................................................40dB or more Separation.....................................................35dB or more S/N .................................................................48dB or more Distortion.............................................................3% or less FM tuner Frequency...................................................87.5–108.0 MHz S/N .................................................................50dB or more Distortion..........................................................2.0% or less IF interference ...............................................84dB or more Image interference........................................46dB or more AM tuner Frequency ......................................................531–1602 kHz Selectivity .........................................55dB or more(±9kHz) S/N .................................................................40dB or more Distortion..........................................................2.0% or less IF interference ...............................................50dB or more Image interference........................................50dB or more www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
