TX-SR304(HT-S4100) SERVICE MANUAL SERVICE MANUAL AV RECEIVER Black and Silver models MODEL TX-SR304 Ref. No. 4059 042007 120V AC, 60Hz 120V AC, 60Hz B MDC S MDC For HT-S4100 TONE + STEREO LISTENING MODE DISPLAY DIGITAL INPUT DIMMER MEMORY TUNING MODE RETURN TUNING / PRESET ENTER SETUP STANDBY STANDBY/ON CLEAR PHONES MULTl CH DVD VIDEO 1/VCR VIDEO 2 VIDEO 3 TAPE TUNER CD MASTER VOLUME A SPEAKERS B RC-645S MUTING PREVIOUS MENU GUIDE TOP MENU SP A / B SETUP RETURN PLAYLIST PLAYLIST RANDOM SUBTITLE PLAY MODE AUDIO REPEAT RC-645S --/--- TAPE ON/STANDBY DIMMER SLEEP INPUT SELECTOR REMOTE MODE V1 V2 V3 C D TA PE TUNER DVD MULTI CH LISTENING MODE DISPLAY TEST TONE CH SEL SURROUND STEREO CINE FLTR LEVEL+ LEVEL- L NIGHT VOL HDD CDR MD DVD RECEIVER C D +10 0 CLR 1 2 3 4 5 6 7 8 9 ENTER CH DISC ALBUM SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER. Model:TX-SR304(HT-S4100) Ref No:4059 Component:HT-S4100 = TX-SR304 + HTP-460 + DS-A1XP Pri nt ed servi ce manual i s not prepared. Ti t l e Approve ( Dat e) At t ached f i l e Cover 2008/02/12 Speci f i cat i ons / Panel vi ew / Remot e cont rol l er - - - Ref er t o i nst ruct i on manual . Expl oded vi ew 2008/02/13 Bl ock di agrams - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) Schemat i c di agrams 2008/02/12 <- - - 2 Pages ( L/R) Audi o i nput sect i on <- - - Al l ( Tabl oi d si ze) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <- - - 2 Pages ( L/R) Power ampl i f i er sect i on <- - - Al l ( Tabl oi d si ze) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <- - - 2 Pages ( L/R) DSP & Mi croprocessor sect i on <- - - Al l ( Tabl oi d si ze) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <- - - 2 Pages ( L/R) Di spl ay sect i on / Power suppl y sect i on / Vi deo sect i on <- - - Al l ( Tabl oi d si ze) Packi ng procedure - - - Ref er t o servi ce manual of "HT- S4100" ( Ref . No. : 4058 ) Pri nt ed ci rcui t board vi ews - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) I C bl ock di agrams and Termi nal descri pt i ons - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) Mi croprocessor t ermi nal descri pt i ons - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) Servi ce procedure - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) Operat i on check - - - Ref er t o servi ce manual of "TX- SR304/304E" ( Ref . No. : 3925) Adj ust ment procedure - - - I dl i ng current adj ust ment : Unnecessary Expl oded vi ew part s l i st / Pri nt ed ci rcui t board part s l i st 2008/02/12 ( 1 sheet , about 23 Pages) Packi ng procedure part s l i st - - - Ref er t o servi ce manual of "HT- S4100" ( Ref . No. : 4058 ) Back cover 2008/04/03 TX-SR304(HT-S4100) TX-SR304(HT-S4100) EXPLODED VIEW A404 x 26 pcs. A002 x 5 pcs. A034 x 2 pcs. A051 x 6 pcs. A022 x 4 pcs. A020 x 3 pcs. A035 x 2 pcs. A037 x 4 pcs. A023 x 4 pcs. A021 x 2 pcs. A003 x 2 pcs. A015 x 3 pcs. A016 x 2 pcs. A055 x 4 pcs. A057 x 4 pcs. A056 x 4 pcs. A005 x 7 pcs. A026 x 2 pcs. A007 x 2 pcs. U12 P101 P7001 T901 P901 F901 F6001 F6001C F6002 F6002C A401 A028 A405 A050 A052 A413 U05 U08 U11 U09 U02 U01 U04 U06 U07 A001 A025 A412 A065 A406 A004 A420 A430 A411 A010 A042 A043 A043 A041 Q9006A A030 A421 x 3 pcs. A012 x 2 pcs. A040 A008 A008 TX-SR304/304E TX-SR304/304E BLOCK DIAGRAM AUDIO SECTION SPRLCS Z2RL HPIN MAIN L MAIN R SUB L SUB R REC L REC R HPRL SPRLF AMUT POWER AMPLIFIER CENTER SPEAKER SURROUND SPEAKERS CD IN SUBWOOFER SURROUND L DVD IN VIDEO 1 IN VIDEO 1 OUT VIDEO 2 IN VIDEO 3 IN TAPE IN TAPE OUT DIR AD R L PHONES SUBWOOFER PREOUT LPF LPF LPF LPF LPF LPF 6ch DAC TUNER UNIT +25dB +25dB +25dB +25dB +25dB R2S15211FP 17 19 20 9 10 16 4 5 2 1 12 11 6 7 14 15 53 70 69 67 66 65 62 64 63 60 59 58 57 56 55 54 52 51 50 49 48 47 45 68 40 72 71 61 39 38 32 33 78 77 74 34 30 75 28 79 29 80 76 73 35 31 46 + + + + + + + + To MICROPROCESSOR TONE TONE FRONT L FRONT R SURROUND R CENTER FRONT SPEAKERS A R L FRONT SPEAKERS B R L DIGITAL IN COAXIAL OPTICAL 2 1 STK-413-220A STK-412-220A FL FR C SL SR 8 ch Electronic Volume with Input Selector and Tone Control ADSP-21266 DSP CS-42516 6 ch Codec with S/P DIF Receiver A 1 2 3 4 B C D E SCHEMATIC DIAGRAMS-1(SD-1) AUDIO INPUT SECTION TX-SR304(HT-S4100) MULTI_C MULTI_SW MULTI_SR MULTI_SL AD_L AD_R VIDEO 1_OUT VIDEO 3_IN VIDEO 2_IN R L R L R L R L R L R L R L FRONT R FRONT L DVD_IN SURROUND R SURROUND L SUBWOOFER CENTER (Botom view) CD_IN DAC_SR DAC_SW DAC_SL DAC_C DAC_R DAC_L TAPE_IN V1_OUTR V1_OUTL TA_R TA_L V3_L V3_R V2_L V2_R V1_L V1_R DVD_L DVD_R TU_L TU_R CD_L CD_R TA_OUTL TA_OUTR NC NC SUBWOOFER PREOUT RI TAPE_OUT VIDEO 1_IN R5005 330 R5006 330 R5009 330 R5010 330 R5013 330 R5014 330 R5017 330 R5018 330 R5021 330 R5022 330 R5025 330 R5100 330 R5101 330 R5102 330 R5103 330 R5104 330 R5105 330 C5008 NC C5007 NC C5011 221J C5016 221J C5015 221J C5111 221J C5110 221J C5114 221J C5113 221J C5115 221J C5112 221J R5002 330 R5001 330 R5146 10K R5026 330 R5145 10K R5004 100K R5003 100K R5007 100K R5012 100K R5011 100K R5016 100K R5015 100K R5020 100K R5019 100K R5024 100K R5023 100K R5028 100K R5027 100K R5111 100K R5110 100K R5114 100K R5113 100K R5115 100K R5112 100K R5008 100K R5029 100K R5030 100K R5143 1.2K R5144 1.2K R5147 10K C5141 330J R5148 10K C5142 330J C5035 223J C5031 474J D5002 MTZJ6.8B C5200 47/25 + C5204 47/25 + C5203 47/25 + C5205 47/25 + C5202 47/25 + D5001 MTZJ6.8B C5032 474J C5134 47/16 + C5133 47/16 + C5135 47/16 + C5201 47/25 + Q5001 R2S15211FP 1 2 3 4 2-OUT 5 2-C 6 3-C 7 3-OUT 8 AGND 9 4-OUT 10 4-C 11 5-C 12 5-OUT 13 AGND 14 6-OUT 15 6-C 16 FLC 17 FLOUT 18 AGND 19 FROUT 20 FRC 21 22 BASS_L1 21 BASS_L2 22 TRE_L 23 AVCC 24 23 24 65 INRB/RECR2 66 INLB/RECL2 67 INR10/RECR4 68 INL10/RECL4 69 INR11/RECL5 70 INL11/RECL5 71 RECR3 72 RECL3 73 FLIN1 74 FRIN1 75 CIN1 76 SWIN1 77 SLIN1 78 SRIN1 79 SBLIN1 80 SBRIN1 41 42 43 44 45 INR1 46 INL1 47 INR2 48 INL2 49 INR3 50 INL3 51 INR4 52 INL4 53 INR5 54 INL5 55 INR6 56 INL6 57 INR7 58 INL7 59 INR8 60 INL8 61 62 63 64 25 BASS_R1 26 BASS_R2 27 TRE_R 28 SBLIN2 29 SBRIN2 30 CIN2 31 SWIN2 32 SLIN2 33 SRIN2 34 FLIN2 35 FRIN2 36 ADCL 37 ADCR 38 SUBR 39 SUBL 40 MONO Q5003:B NJM4580M-D 1 2 3 C5012 221J C5003 221J R5285 100 R5275 100K C5275 221J R5500 330 C5130 47/16 + C5132 47/16 + C5131 47/16 + R5901 R5902 C5027 221J C5028 221J C5023 NC C5024 NC C5020 221J C5019 221J C5302 470/25 + C5301 470/25 + C5304 C5303 D5500 1SS133 R5304 10K R5303 10K Q5003:A NJM4580M-D 7 4 5 6 8 R5141 10K R5142 10K C5033 823J C5036 223J C5034 823J R5041 1.8K R5042 1.8K C5004 221J R5301 100(1/2W) R5302 100(1/2W) P5001 P5002 P5005 P5006 P5500 3 2 1 C5051 C5052 P5003 P5004 C5053 C5054 473K -6.9V +6.9V NC NC NC 1-C 1 1-OUT 2 AGND 3 64 INL9 63 INR9 62 INLA/RECL1 63 INRA/RECR1 44 AVEE 43 CLOCK 42 DATA 41 DGND SELECTOR/VOLUME A 1 2 3 4 5 B C D TX-SR304(HT-S4100) COUT ROUT LOUT SROUT SLOUT A_+12V A_-12V L R C SL AMUTE S1_GND DAC_C DAC_SW DAC_SL DAC_SR DAC_L DAC_R AD_R AD_L TU_L TU_R VOL_CLK VOL_DAT SYS_IN SR_SW SR_SW TU_GND CODEC_GND S3_GND NC NC NC NC NC NC NC NC NC NC A_GND To NAAF-8745 (2/2) (SD-2 : F5) J6114 J6116 R5202 220K R5203 220K R5204 220K C5210 47/50 C5212 47/50 C5213 47/50 C5214 47/50 C5255 103K R5200 220K R5201 220K Q5201 RN1441 Q5203 RN1441 R5211 2.2K R5212 2.2K R5213 2.2K R5214 2.2K 5146 10K Q5202 RN1441 Q5204 RN1441 5145 10K 5143 1.2K 5144 1.2K R5149 470 R5150 470 Q5002:B NJM4580M-D 5 6 7 R5207 22 R5206 22 Q5200 RN1441 Q5210 Q5214 Q5212 Q5211 Q5213 Q5215 RN1441 R5225 100 R5210 2.2K R5220 R5221 R5222 R5223 R5224 C5211 47/50 C5206 220/25 + C5207 220/25 + R5216 220K R5235 47K R5245 1.2K R5255 15K R5265 10K C5245 221J Q5205 RN1441 Q5002:A NJM4580M-D 3 2 4 1 8 R5215 270 C5235 47/50 R5205 C5215 THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY REPLACE ONLY WITH PART NUMBER SPECIFIED. VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL). ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED. ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED. ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED. ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV. ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED. EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED. THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS. EX) PRINTING SIDE CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT. ! NOTE U01 AMPLIFER PC BOARD NAAF-8745 (1/2) +11.8V -11.8V 2.2/50 2.2K NC NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-1(SD-1) AUDIO INPUT SECTION COUT ROUT LOUT SROUT SLOUT A_+12V A_-12V L R C SL AMUTE S1_GND DAC_C DAC_SW DAC_SL DAC_SR DAC_L DAC_R AD_R AD_L TU_L TU_R VOL_CLK VOL_DAT SYS_IN MULTI_C MULTI_SW MULTI_SR MULTI_SL AD_L AD_R SR_SW SR_SW VIDEO 1_OUT VIDEO 3_IN VIDEO 2_IN R L R L R L R L R L R L R L FRONT R FRONT L DVD_IN SURROUND R SURROUND L SUBWOOFER CENTER (Botom view) CD_IN DAC_SR DAC_SW DAC_SL DAC_C DAC_R DAC_L TAPE_IN V1_OUTR V1_OUTL TA_R TA_L V3_L V3_R V2_L V2_R V1_L V1_R DVD_L DVD_R TU_GND CODEC_GND S3_GND TU_L TU_R CD_L CD_R TA_OUTL TA_OUTR NC NC NC NC NC NC NC NC NC NC NC NC A_GND SUBWOOFER PREOUT RI TAPE_OUT VIDEO 1_IN To NAAF-8745 (2/2) (SD-2 : F5) J6114 J6116 R5005 330 R5006 330 R5009 330 R5010 330 R5013 330 R5014 330 R5017 330 R5018 330 R5021 330 R5022 330 R5025 330 R5100 330 R5101 330 R5102 330 R5103 330 R5104 330 R5105 330 R5202 220K R5203 220K R5204 220K C5008 NC C5007 NC C5011 221J C5016 221J C5015 221J C5111 221J C5110 221J C5114 221J C5113 221J C5115 221J C5112 221J C5210 47/50 C5212 47/50 C5213 47/50 C5214 47/50 C5255 103K R5200 220K R5201 220K Q5201 RN1441 Q5203 RN1441 R5002 330 R5001 330 R5211 2.2K R5212 2.2K R5213 2.2K R5214 2.2K R5146 10K R5026 330 Q5202 RN1441 Q5204 RN1441 R5145 10K R5004 100K R5003 100K R5007 100K R5012 100K R5011 100K R5016 100K R5015 100K R5020 100K R5019 100K R5024 100K R5023 100K R5028 100K R5027 100K R5111 100K R5110 100K R5114 100K R5113 100K R5115 100K R5112 100K R5008 100K R5029 100K R5030 100K R5143 1.2K R5144 1.2K R5147 10K C5141 330J R5148 10K C5142 330J R5149 470 R5150 470 C5035 223J C5031 474J D5002 MTZJ6.8B C5200 47/25 + C5204 47/25 + C5203 47/25 + C5205 47/25 + C5202 47/25 + D5001 MTZJ6.8B C5032 474J C5134 47/16 + C5133 47/16 + C5135 47/16 + C5201 47/25 + Q5001 R2S15211FP 1 2 3 4 2-OUT 5 2-C 6 3-C 7 3-OUT 8 AGND 9 4-OUT 10 4-C 11 5-C 12 5-OUT 13 AGND 14 6-OUT 15 6-C 16 FLC 17 FLOUT 18 AGND 19 FROUT 20 FRC 21 22 BASS_L1 21 BASS_L2 22 TRE_L 23 AVCC 24 23 24 65 INRB/RECR2 66 INLB/RECL2 67 INR10/RECR4 68 INL10/RECL4 69 INR11/RECL5 70 INL11/RECL5 71 RECR3 72 RECL3 73 FLIN1 74 FRIN1 75 CIN1 76 SWIN1 77 SLIN1 78 SRIN1 79 SBLIN1 80 SBRIN1 41 42 43 44 45 INR1 46 INL1 47 INR2 48 INL2 49 INR3 50 INL3 51 INR4 52 INL4 53 INR5 54 INL5 55 INR6 56 INL6 57 INR7 58 INL7 59 INR8 60 INL8 61 62 63 64 25 BASS_R1 26 BASS_R2 27 TRE_R 28 SBLIN2 29 SBRIN2 30 CIN2 31 SWIN2 32 SLIN2 33 SRIN2 34 FLIN2 35 FRIN2 36 ADCL 37 ADCR 38 SUBR 39 SUBL 40 MONO Q5002:B NJM4580M-D 5 6 7 Q5003:B NJM4580M-D 1 2 3 C5012 221J C5003 221J R5285 100 R5275 100K C5275 221J R5207 22 R5500 330 R5206 22 Q5200 RN1441 Q5210 Q5214 Q5212 Q5211 Q5213 Q5215 RN1441 R5225 100 C5130 47/16 + C5132 47/16 + C5131 47/16 + R5901 R5902 R5210 2.2K R5220 R5221 R5222 R5223 R5224 C5027 221J C5028 221J C5023 NC C5024 NC C5020 221J C5019 221J C5302 470/25 + C5301 470/25 + C5211 47/50 C5206 220/25 + C5207 220/25 + C5304 C5303 D5500 1SS133 R5304 10K R5303 10K R5216 220K Q5003:A NJM4580M-D 7 4 5 6 8 R5141 10K R5142 10K C5033 823J C5036 223J C5034 823J R5041 1.8K R5235 47K R5245 1.2K R5255 15K R5265 10K C5245 221J Q5205 RN1441 Q5002:A NJM4580M-D 3 2 4 1 8 R5215 270 C5235 47/50 R5042 1.8K C5004 221J R5301 100(1/2W) R5302 100(1/2W) P5001 R5205 C5215 P5002 P5005 P5006 P5500 3 2 1 C5051 C5052 P5003 P5004 C5053 C5054 473K THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY REPLACE ONLY WITH PART NUMBER SPECIFIED. VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL). ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED. ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED. ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED. ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV. ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED. EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED. THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS. EX) PRINTING SIDE CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT. ! NOTE U01 AMPLIFER PC BOARD NAAF-8745 (1/2) -6.9V +6.9V +11.8V -11.8V NC NC NC 1-C 1 1-OUT 2 AGND 3 64 INL9 63 INR9 62 INLA/RECL1 63 INRA/RECR1 44 AVEE 43 CLOCK 42 DATA 41 DGND 2.2/50 2.2K NC NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. SELECTOR/VOLUME A 1 2 3 4 5 B C D E F G H SCHEMATIC DIAGRAMS-2(SD-2) POWER AMPLIFIER SECTION TX-SR304(HT-S4100) S2-1 S2-2 S3-1 S3-2 +12VD +10VS POFF POFF POFF2 -VP R C L S1H+ POWERD POW_RLY SR To TRANS (Sec.) (SD-4 : H2) RLY_GND +23V(RLY) AVR_GND(Audio) VIDEO_GND +23V(Audio) -23V(Audio) FAC1 D_GND FAC2 S3-G C R SL L B_GND SP_GND PH_GND NC P6006 NC F6002 NAAF-8745 (2/2) NAETC-8746 Connected to P.Trans pin (Crimp Assy) (Bus Bar) To NAPS-8769 (SD-4 : G2) F6001 102J C6080 - 6087 J6414 J6279 J6409 NF_GND J6415 J6413 G H J6410 R6905 J6279 J6410 J6411 J6411 J6416 J6408 J6412 R6075 22K R6105 33K D9007 RN1N4003 C6007 334J R6074 22K R9501 (1/2W) 22 R9502 330K C9506 10/50 + D9002 RN1N4003 C9051 104J R9503 1 D9010 1SS133 R9504 1 D9011 1SS133 C9001 4700/16 + C9504 220/63 + C9503 220/50 + C9002 22/50 + C9003 22/50 + C9004 22/50 + C9005 22/50 + D9001 D3SBA20 4 3 1 2 C6201 NC Q6023 2SC2240-GR C9505 10/50 + C9507 1/50+ C6202 NC D9009 RN1N4003 R9015 (1/2W) 4.7 R9505 2.2K R9054 (1/2W) 8.2 R9011 (1/2W) 0.22 JL9002A 7 6 5 4 3 2 1 R9004 47K R9005 47K JL9003A 5 4 3 2 1 JL9001B 1 2 3 4 5 6 7 8 JL9001A 1 2 3 4 5 6 7 8 Q9002 TA79012S 2 I 3 O 1 G C6040 300D C6042 300D C6041 300D R6010 1K R6012 1K R6011 1K R6020 56K R6022 56K R6021 56K R6040 56K R6042 56K R6041 56K R6071 22K R6073 22K R6100 33K R6102 33K R6101 33K R6103 33K R6072 22K R6070 22K R6204 (1W) 100 R6205 (1W) 100 C6010 47/25 + C6012 47/25 + C6011 47/25 + C6020 471J C6022 471J C6021 471J C6103 47/50 + R6090 NC R6092 NC R6091 NC R6060 R6062 R6061 C6102 100/63 + D6001 D5SBA20 4 3 1 2 D6010 NC D6012 NC D6011 NC Q9006 AN34060A 1 MODE 2 5V 3 VCC 4 GND 5 3.3V 6 NC 7 2.5V R6052 1K R6030 1.5K R6032 1.5K C6120 NC C6122 NC C6121 NC C6101 100/63 + R6082 5.6K R6081 5.6K R6083 5.6K R6084 5.6K Q9001 TA7812S 1 I 2 G 3 O Q9003 2SA1930 D9012 MTZJ4.7C R9009 (1/2W) 15 R9012 (2W) 220 R9013 (2W) 220 R9006 (2W) 220 R9007 (2W) 220 R9008 (2W) 270 P6005 C6030 220/35 + C6032 220/35 + C6031 220/35 + R9003 (2W) 12 R9002 (1W) 56 C6004 5600/35 + C6003 5600/35 + D9008 MTZJ36D C9010 10/50 + C9012 10/50 + C9011 10/50 + C9013 10/50 + D9004 RN1N4003 C9502 470/35 + R9001 (1W) 6.8 C6001 + C6002 + D6002 D5SBA20 4 3 1 2 C6009 NC D6008 NC D6007 NC D9013 RN1N4003 D9006 RN1N4003 R9508 100K R6080 5.6K R6050 1K Q6012 Q6011 Q6013 Q6015 Q6014 JL9002B 1 2 3 4 5 6 7 R9051 (1/2W) 0.22 C6005 C6006 C6008 334J R9052 (1W) 1 R9053 (1W) 1 C6016 NC Q9501 2SA970-GR/BL Q6010 Q9502 KRC105M R6502 220K R6501 220K D6006 R6207 R6206 (1W) 3.3k D6005 MTZJ15C R6403 1K R6404 10K Q6101 2SA970-GR/BL R6402 10K R6903 Q6102 2SC2240-GR Q6104 RN2402 Q6105 2SA970 GR/BL Q6106 2SC2240-GR R6407 10K R6410 10K R6409 1K R6408 10K R6031 1.5K R6401 10K R6405 56K C6050 472K C6051 472K C6053 472K R6085 5.6K C6055 472K C6054 472K R6412 47K R6901 R6902 R6051 1K R6414 220 C6052 472K Q6109 RN1401 R6413 33K Q6110 PC817X C9501 1000/35 + D9005 RN1N4003 D9003 RN1N4003 C6401 103J R6905 R6406 47K Q6103 RN1402 R6201 (1W) 3.3K R6202(1W) 3.3K R6203 33K D6003 MTZJ15C D6004 MTZJ15C C6402 101J C6403 101J Q6107 RN1402 Q6001 STK413-220A +VH +VL COMP+ COMP- -VL 6 -VH 7 SUB_G 8 OUT1+ 9 OUT1- 10 OUT2- 11 OUT2+ 12 -VA 13 +VA 14 IN1 15 FB1 16 BIAS 17 FB2 18 IN2 19 IN3 20 FB3 21 OUT3+ 22 OUT3- E6001 1 +VH +VL 3 COMP+ 4 COMP- Q6108 RN2402 R6411 56K U01 AMPLIFIER PC BOARD U02 TRANS SEC. TERMINAL PC BOARD +1 -12 -26.0V +24.7V -36.7V ! ! ! ! +11.0V +2.5V +5.1V +3.3V ! ! ! ! ! ! +47.8V -47.8V +23.5V -23.5V 5 4 3 2 1 Q6010 - Q6014 : 2SC2240-GR 0.22 (2W)x2 0.22 (2W)x2 0.22 (2W)x2 +46.0V -46.0V 0V 8200/56 8200/56 8A/125V 8A/125V Refer to following table about the parts displayed by mark " ". MDC G H 000J 4.20Vac None None Yes POWER AMP. NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. NC NC A 1 2 3 4 5 B C D TX-SR304(HT-S4100) SL HP_RLY F_RLY S_RLY THERMAL SPB_RLY S1_GND L C R SL AD_L AD_R DAC_R DAC_SR DAC_SL DAC_SW DAC_C TU_R TU_L DAC_L VOL_CLK VOL_DAT AMUTE SYS_IN A_-12V A_+12V SL_OUT L_OUT C_OUT SR_SW SR_SW SR_SW R_OUT C SL SR SW R L L(SPB) R(SPB) HP_L HP_R D_GND VIDEO_12V -VP HP_L HP_R HP_G SYS_IN VOL_DAT VOL_CLK A_MUTE F_RLY S_RLY SPB_RLY CODEC_GND DAC_SR DAC_SL DAC_SW DAC_C DAC_R DAC_L EVOL_GND A_-12V A_+12V AD_R AD_L TU_+12V TU_R TU_L D_GND S3_GND D_+3.3V D_+5V D_+2.5V D_+3.3V D_+5V FAC2 FAC1 D_+2.5V A_GND(EVOL_GND) TU_GND CODEC_GND TU_GND D_GND D_GND +10VS VIDEO_+12V VIDEO_GND VIDEO_GND POFF2 POFF TERMAL VOLH PROTECT HP_RLY APOWER NC NC NC NC NC NC NC NC NC NC NC NC J6176 J6190 NC NC P6500 P6501 NC To NADG-8756 (SD-3 : A3) FRONT SPEAKERS A FRONT SPEAKERS B To NAAF-8745 (1/2) (SD-1 : H3) J6411 C6045 300D R6013 1K R6045 56K R6131 4.7 R6133 4.7 R6216 220K R6111 47K R6112 47K R6113 47K R6115 47K R6209 (1W) 100 R6210 (1W) 100 C6105 100/63 + R6043 56K C6043 300D R6044 56K R6023 56K R6025 56K R6024 56K C6015 47/25 + C6014 47/25 + C6025 471J C6024 471J C6044 300D R6104 33K R6211 33K R6213 10K C6093 104Z R6214 47K C6091 1/50 + R6134 4.7 R6135 4.7 RL6002 RL6003 RL6005 RL6004 R6251 (1/2W) 390 R6252 (1/2W) 390 C6090 100/16 + R6215 NC D6052 1SS133 C6106 47/50 + D6056 1SS133 R6063 0.22 (2W)x2 R6065 R6064 0.22(2W) x 2 C6080 C6081 C6082 C6083 C6084 C6086 C6087 RL6001 RL6006 R6132 4.7 L6000 3uH L6001 3uH L6002 3uH L6003 3uH L6004 3uH L6005 3uH D6033 MTZJ5.1B D6055 1SS133 D6031 1SS133 D6032 1SS133 3 -GR Q6022 2SC2240-GR JL6001B 1 2 3 4 5 6 JL6001A 1 2 3 4 5 6 C6902 NC Q6004 LM61CIZ 1 G 2 O 3 V P302 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 P303 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C6903 NC C6109 100/50 + C6070 103J C6071 103J C6072 103J C6073 103J C6074 103J C6075 NC R6054 1K R6053 1K R6055 1K R6033 1.5K R6035 1.5K R6034 1.5K C6085 D6051 1SS133 C6123 NC C6125 NC C6124 NC C6060 473J C6061 473J C6062 473J C6063 473J C6064 473J C6065 473J R6140 (1W) 8.2 R6141 (1W) 8.2 R6142 (1W) 8.2 R6143 (1W) 8.2 R6144 (1W) 8.2 R6145 (1W) 8.2 D6024 R6124 D6025 R6125 D6023 R6123 D6022 R6122 D6021 R6121 D6020 R6120 R6015 1K R6014 1K Q6052 DTC123JKA Q6051 DTC123JKA Q6054 DTC123JS C6115 103J C6112 103J C6111 103J C6116 103K R6114 47K C6107 100/63 + C6108 100/63 + C6110 100/50 + R6110 47K C6013 47/25 + C6104 100/63 + C6034 220/35 + C6035 220/35 + C6033 220/35 + R6302 (1W) 27 R6301 (1/2W) 56 R6130 4.7 P301 6 5 4 3 2 1 P6002 L R P6001 L L R CENTER SPEAKER R Q6021 2SA1163-BL D6006 MTZJ15C Q6053 DTC123JKA R6207 (1W) 3.3k R6208 33K C6023 471J Q6002 4 COMP- 5 -VL 6 -VH 7 SUB_G 8 OUT1+ 9 OUT1- 10 OUT2- 11 OUT2+ 12 -VA 13 +VA 14 IN1 15 FB1 16 BIAS 17 FB2 18 IN2 19 IN3 20 FB3 21 OUT3+ 22 OUT3- SURROUND SPEAKERS +12V -12V To NADG-8756 (SD-3 : A2) To NADG-8756 (SD-3 : A1) 0.22 (2W)x2 +47.8V +46.0V -46.0V +5V 0V V STK412-220A POWER AMP. SR_OUT NC E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-2(SD-2) POWER AMPLIFIER SECTION SL HP_RLY F_RLY S_RLY THERMAL SPB_RLY S2-1 S2-2 S3-1 S3-2 +12VD +10VS S1_GND L C R SL AD_L AD_R DAC_R DAC_SR DAC_SL DAC_SW DAC_C TU_R TU_L DAC_L POFF POFF POFF2 VOL_CLK VOL_DAT AMUTE SYS_IN A_-12V -VP A_+12V SL_OUT R C L S1H+ L_OUT C_OUT SR_SW SR_SW SR_SW POWERD POW_RLY R_OUT C SL SR SW R L L(SPB) R(SPB) SR To TRANS (Sec.) (SD-4 : H2) HP_L HP_R RLY_GND +23V(RLY) AVR_GND(Audio) D_GND VIDEO_12V -VP HP_L HP_R HP_G SYS_IN VOL_DAT VOL_CLK A_MUTE F_RLY S_RLY SPB_RLY CODEC_GND DAC_SR DAC_SL DAC_SW DAC_C DAC_R DAC_L EVOL_GND A_-12V A_+12V AD_R AD_L TU_+12V TU_R TU_L VIDEO_GND +23V(Audio) -23V(Audio) D_GND S3_GND D_+3.3V D_+5V D_+2.5V D_+3.3V D_+5V FAC2 FAC1 FAC1 D_+2.5V A_GND(EVOL_GND) TU_GND CODEC_GND TU_GND D_GND FAC2 S3-G D_GND D_GND +10VS VIDEO_+12V VIDEO_GND VIDEO_GND POFF2 POFF TERMAL VOLH PROTECT HP_RLY APOWER NC NC NC NC NC NC NC NC NC NC NC NC C R SL L B_GND SP_GND PH_GND J6176 J6190 NC NC NC P6006 P6500 P6501 NC NC F6002 To NADG-8756 (SD-3 : A3) FRONT SPEAKERS A FRONT SPEAKERS B NAAF-8745 (2/2) NAETC-8746 Connected to P.Trans pin (Crimp Assy) (Bus Bar) To NAPS-8769 (SD-4 : G2) To NAAF-8745 (1/2) (SD-1 : H3) F6001 102J C6080 - 6087 J6414 J6279 J6409 NF_GND J6415 J6413 G H J6410 R6905 J6279 J6410 J6411 J6411 J6416 J6408 J6412 C6045 300D R6013 1K R6045 56K R6075 22K R6105 33K R6131 4.7 R6133 4.7 R6216 220K R6111 47K R6112 47K R6113 47K R6115 47K D9007 RN1N4003 C6007 334J R6209 (1W) 100 R6210 (1W) 100 C6105 100/63 + R6043 56K C6043 300D R6044 56K R6023 56K R6025 56K R6024 56K C6015 47/25 + C6014 47/25 + C6025 471J C6024 471J C6044 300D R6104 33K R6074 22K R6211 33K R6213 10K C6093 104Z R6214 47K C6091 1/50 + R6134 4.7 R6135 4.7 RL6002 RL6003 RL6005 RL6004 R6251 (1/2W) 390 R6252 (1/2W) 390 R9501 (1/2W) 22 R9502 330K C9506 10/50 + D9002 RN1N4003 C9051 104J R9503 1 D9010 1SS133 R9504 1 D9011 1SS133 C6090 100/16 + R6215 NC D6052 1SS133 C9001 4700/16 + C9504 220/63 + C9503 220/50 + C6106 47/50 + C9002 22/50 + C9003 22/50 + C9004 22/50 + C9005 22/50 + D6056 1SS133 R6063 0.22 (2W)x2 R6065 R6064 0.22(2W) x 2 C6080 C6081 C6082 C6083 C6084 C6086 C6087 D9001 D3SBA20 4 3 1 2 RL6001 RL6006 R6132 4.7 L6000 3uH L6001 3uH L6002 3uH L6003 3uH L6004 3uH L6005 3uH C6201 NC D6033 MTZJ5.1B D6055 1SS133 D6031 1SS133 D6032 1SS133 Q6023 2SC2240-GR Q6022 2SC2240-GR C9505 10/50 + C9507 1/50+ JL6001B 1 2 3 4 5 6 JL6001A 1 2 3 4 5 6 C6902 NC Q6004 LM61CIZ 1 G 2 O 3 V P302 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 P303 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C6903 NC C6202 NC D9009 RN1N4003 C6109 100/50 + C6070 103J C6071 103J C6072 103J C6073 103J C6074 103J C6075 NC R6054 1K R6053 1K R6055 1K R6033 1.5K R6035 1.5K R6034 1.5K R9015 (1/2W) 4.7 R9505 2.2K R9054 (1/2W) 8.2 C6085 D6051 1SS133 C6123 NC C6125 NC C6124 NC C6060 473J C6061 473J C6062 473J C6063 473J C6064 473J C6065 473J R6140 (1W) 8.2 R6141 (1W) 8.2 R6142 (1W) 8.2 R6143 (1W) 8.2 R6144 (1W) 8.2 R6145 (1W) 8.2 R9011 (1/2W) 0.22 D6024 R6124 D6025 R6125 D6023 R6123 D6022 R6122 D6021 R6121 D6020 R6120 R6015 1K R6014 1K JL9002A 7 6 5 4 3 2 1 Q6052 DTC123JKA Q6051 DTC123JKA Q6054 DTC123JS C6115 103J C6112 103J C6111 103J C6116 103K R6114 47K C6107 100/63 + C6108 100/63 + C6110 100/50 + R6110 47K R9004 47K R9005 47K JL9003A 5 4 3 2 1 JL9001B 1 2 3 4 5 6 7 8 JL9001A 1 2 3 4 5 6 7 8 Q9002 TA79012S 2 I 3 O 1 G C6040 300D C6042 300D C6041 300D R6010 1K R6012 1K R6011 1K R6020 56K R6022 56K R6021 56K R6040 56K R6042 56K R6041 56K R6071 22K R6073 22K R6100 33K R6102 33K R6101 33K R6103 33K R6072 22K R6070 22K R6204 (1W) 100 R6205 (1W) 100 C6010 47/25 + C6012 47/25 + C6011 47/25 + C6020 471J C6022 471J C6021 471J C6103 47/50 + R6090 NC R6092 NC R6091 NC R6060 R6062 R6061 C6102 100/63 + D6001 D5SBA20 4 3 1 2 D6010 NC D6012 NC D6011 NC Q9006 AN34060A 1 MODE 2 5V 3 VCC 4 GND 5 3.3V 6 NC 7 2.5V R6052 1K R6030 1.5K R6032 1.5K C6120 NC C6122 NC C6121 NC C6101 100/63 + C6013 47/25 + C6104 100/63 + R6082 5.6K R6081 5.6K R6083 5.6K R6084 5.6K Q9001 TA7812S 1 I 2 G 3 O Q9003 2SA1930 D9012 MTZJ4.7C R9009 (1/2W) 15 R9012 (2W) 220 R9013 (2W) 220 R9006 (2W) 220 R9007 (2W) 220 R9008 (2W) 270 P6005 C6030 220/35 + C6032 220/35 + C6031 220/35 + C6034 220/35 + C6035 220/35 + C6033 220/35 + R9003 (2W) 12 R9002 (1W) 56 C6004 5600/35 + C6003 5600/35 + D9008 MTZJ36D C9010 10/50 + C9012 10/50 + C9011 10/50 + C9013 10/50 + D9004 RN1N4003 C9502 470/35 + R9001 (1W) 6.8 R6302 (1W) 27 R6301 (1/2W) 56 R6130 4.7 C6001 + C6002 + D6002 D5SBA20 4 3 1 2 P301 6 5 4 3 2 1 P6002 L R C6009 NC D6008 NC D6007 NC D9013 RN1N4003 D9006 RN1N4003 R9508 100K R6080 5.6K R6050 1K Q6012 Q6011 Q6013 Q6015 Q6014 P6001 L L R CENTER SPEAKER R JL9002B 1 2 3 4 5 6 7 R9051 (1/2W) 0.22 C6005 C6006 C6008 334J R9052 (1W) 1 R9053 (1W) 1 C6016 NC Q9501 2SA970-GR/BL Q6010 Q6021 2SA1163-BL Q9502 KRC105M R6502 220K R6501 220K D6006 MTZJ15C Q6053 DTC123JKA R6207 (1W) 3.3k R6206 (1W) 3.3k D6005 MTZJ15C R6403 1K R6404 10K Q6101 2SA970-GR/BL R6402 10K R6903 Q6102 2SC2240-GR R6208 33K Q6104 RN2402 Q6105 2SA970 GR/BL Q6106 2SC2240-GR R6407 10K R6410 10K R6409 1K R6408 10K R6031 1.5K R6401 10K R6405 56K C6050 472K C6051 472K C6053 472K R6085 5.6K C6055 472K C6054 472K R6412 47K R6901 R6902 R6051 1K R6414 220 C6052 472K Q6109 RN1401 R6413 33K Q6110 PC817X C9501 1000/35 + D9005 RN1N4003 D9003 RN1N4003 C6023 471J C6401 103J R6905 R6406 47K Q6103 RN1402 R6201 (1W) 3.3K R6202(1W) 3.3K R6203 33K D6003 MTZJ15C D6004 MTZJ15C C6402 101J C6403 101J Q6107 RN1402 Q6001 STK413-220A +VH +VL COMP+ COMP- -VL 6 -VH 7 SUB_G 8 OUT1+ 9 OUT1- 10 OUT2- 11 OUT2+ 12 -VA 13 +VA 14 IN1 15 FB1 16 BIAS 17 FB2 18 IN2 19 IN3 20 FB3 21 OUT3+ 22 OUT3- E6001 Q6002 1 +VH +VL 3 COMP+ 4 COMP- 5 -VL 6 -VH 7 SUB_G 8 OUT1+ 9 OUT1- 10 OUT2- 11 OUT2+ 12 -VA 13 +VA 14 IN1 15 FB1 16 BIAS 17 FB2 18 IN2 19 IN3 20 FB3 21 OUT3+ 22 OUT3- Q6108 RN2402 R6411 56K U01 AMPLIFIER PC BOARD U02 TRANS SEC. TERMINAL PC BOARD SURROUND SPEAKERS +12V -12V -26.0V +24.7V -36.7V ! ! ! ! +11.0V +2.5V +5.1V +3.3V ! ! ! ! ! ! +47.8V -47.8V +23.5V -23.5V 5 4 3 2 1 To NADG-8756 (SD-3 : A2) To NADG-8756 (SD-3 : A1) Q6010 - Q6014 : 2SC2240-GR 0.22 (2W)x2 0.22 (2W)x2 0.22 (2W)x2 0.22 (2W)x2 +46.0V -46.0V +47.8V +46.0V -46.0V +5V 0V 0V STK412-220A 8200/56 8200/56 8A/125V 8A/125V Refer to following table about the parts displayed by mark " ". MDC G H 000J 4.20Vac None None Yes POWER AMP. POWER AMP. SR_OUT NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. NC NC NC A 1 2 3 4 5 B C D E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-3(SD-3) DSP & MICROPROCESSOR SECTION RTAD LTAD +10VS DSPCLK_3.3V DSPSDI_3.3V DSPSDO_3.3V DIRCS_3.3V DIRINT0_3.3V DIRRST_3.3V BCK DIRSDO ADCSDO DSPMCK COAX DSPSDO3 DSPSDO1 DSPSDO2 TU_R TU_L GNDTU +12V_TU +2.5V_DSP +3.3V_DSP +5V_DSP GND_DAC RTAD LTAD -12V +12V SYSIN VOLDAT VOLCLK AMUT SPRLB SPRLCS SPRLF DAC_FL DAC_FR DAC_C DAC_SW DAC_SL DAC_SR +10VS +12V_VIDEO GND_VIDEO THERMAL PROTECT VOLH APOWER POFF2 POFFV HPRL KEY3 KEY1 KEY0 REMIN FLDSDO FLDCLK FLDCS FLDRST KEY2 KEYINT0 KEYINT1 KEYINT2 KEYINT3 VOLA VOLB LEDSTBY GND_HP HPIN +5.6S FAC1 FAC2 -VP HP_L HP_R FAC1 FAC2 -VP GND_HP HP_L HP_R TU_L TU_R STEREO SD RDSDAT RDSCLK PLLSCL PLLSDA OPT2 OPT1 COAX VMUTV1 VCTRLB VMUT VMUTV3 +12V_VIDEO GND_VIDEO VCTRLA +9V_TUNER GNDTU LRCK +5V_DSP To NAVD-8768 (SD-4 : E5) To NAAF-8745 (SD-2 : H5) To NAAF-8745 (SD-2 : H4) To NAAF-8745 (SD-2 : H3) NC NC To NADIS-8767 (SD-4 : E1) C312 473K C313 104Z R313 220 R314 220 R315 220 R316 220 R317 220 C415 681J C425 681J R445 180 R446 180 R448 180 R447 180 C405 472J R421 470 R422 470 R424 470 R423 470 R409 3.3K R410 3.3K R412 3.3K R411 3.3K C413 681J C423 681J R441 180 R442 180 R444 180 R443 180 C403 472J R417 470 R418 470 R420 470 R419 470 R405 3.3K R406 3.3K R408 3.3K R407 3.3K C411 681J C421 681J C422 681J C412 681J R437 180 R438 180 R440 180 R439 180 C402 472J R413 470 R414 470 R416 470 R415 470 R402 3.3K R404 3.3K R403 3.3K C310 104Z R318 220 C304 100/16 + C307 104Z C337 222J C338 222J Q331:B NJM4580M-D 2 3 1 R401 3.3K C401 472J Q402:A 7 4 5 6 8 Q403:B 1 2 3 Q402:B 1 2 3 Q401:B 1 2 3 C323 330J R451 4.7 R452 4.7 Q401:A 7 4 5 6 8 C301 470/6.3 + R322 220 C321 330J C322 330J R321 220 Q403:A 7 4 5 6 8 C414 153J C424 103J C404 333J C416 681J C426 681J C406 472J R323 220 Q331:A NJM4580M-D 5 6 8 7 4 P2011 1 2 3 4 5 6 7 8 9 10 11 R312 33 R308 33 R309 33 R307 33 R303 33 R342 0 R341 0 C451 220/16 + C452 220/16 + C332 101J C311 222K Q301 CS42516 17 18 19 REFGND 20 AOUTB4- 21 AOUTB4+ 22 AOUTA4+ 23 AOUTA4- 24 VA 25 AGND1 26 AOUTB3- 27 AOUTB3+ 28 AOUTA3+ 29 AOUTA3- 30 AOUTB2- 31 31 AOUTB2 32 32 AOUTA2 33 AOUTA2- 34 AOUTB1- 35 AOUTB1+ 36 AOUTA1+ 37 AOUTA1- 38 MUTEC 39 LPFLT 40 AGND2 41 VARX 42 RXP7/GP7 43 RXP6/GP6 44 RXP5/GP5 45 RXP4/GP4 46 RXP3/GP3 47 RXP2/GP2 48 RXP1/GP1 49 RXP0 49 50 TXP 50 51 VD2 52 DGND2 53 VLS 54 SAI_SDOUT 55 RMCK 56 CX_SDOUT 57 ADCIN2 58 ADCIN1 59 OMCK 60 SAI_LRCK 61 SAI_SLCK 62 CX_SDIN4 62 63 CX_SDIN3 63 64 CX_SDIN2 64 1 CX_SDIN1 2 CX_SCLK 3 CX_LRCK 4 VD1 5 DGND1 6 VLC 7 CCLK/SCL 8 CDOUT/SAD 9 CDIN/AD1 10 CS/AD0 11 INT1 12 _RST 13 AINR- 14 AINR+ 15 AINL+ 16 AINL- R332 10K R333 10K R334 10K R436 4.7K R435 4.7K R434 4.7K R433 4.7K R432 4.7K R431 4.7K R430 4.7K R429 4.7K R428 4.7K R427 4.7K R426 4.7K R425 4.7K P302A 20 1 P303A 20 1 E151 NC P301A 6 1 P7001A 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 P101A 1 2 3 4 5 6 7 8 9 10 11 12 13 C331 101J C308 104Z C335 22/50 + R337 0 C334 22/50 + C336 22/50 + R338 0 R336 56 C333 22/50 + R335 56 C104 104Z C103 100/16 + R191 39K R192 39K R194 0 R193 33K C192 100/16 + C191 100/16 + D192 NC Q191 BD7820 1 _SHUT 2 INPUT 3 GND 4 OUTPUT 5 DAJ Q101 2SC1815 2 1 3 R101 330 D101 UDZS10B C101 100/16 + C306 104Z R301 33 R304 33 R305 33 R310 33 L301 BLM21PG221 SN1 BL SN R325 2.7K L303 L302 C302 470/6.3 + C303 470/6.3 + C309 NC D336 D334 D338 D332 D335 D333 D337 D331 R340 3.9K R339 3.9K R331 10K L311 LM182 R311 33 L306 LM182 R306 33 R302 33 L305 LM182 C305 100/10(VX) + 17 VQ 18 FLT To TUNER UNIT +1.2V + +3.3V -12V +12V Q401 - Q403 : NJM4580M-D L302, 303 : BLM21PG221SN1 +2.5V +5V +8.9V DIR/DAC/ADC NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. FR FL SW C SR SL A 1 2 3 4 5 B C D TX-SR304(HT-S4100) FLAG0_3.3V DSPSDO_3.3V DSPCLK_3.3V DSPCS_3.3V DSPRST_3.3V DSPSDI_3.3V FLDCS FLDSDO LEDSTBY FLDRST FLDCLK KEYINT3 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 KEY1 KEY0 DSPINT0 PLLSDA RESET VMUT STEREO SD REMIN PROTECT THERMAL INT3 DIGCLK DIGSDI DIGSDO DSPRST DIRCS DIRPDN DSPCS BAND INT1 INT2 AMUTB PLLSCL VCTRLA VCTRLB CNVSS POFF VMUTB APOWER HPIN RDSDAT HPIN VMUTV1 DIRINT0_3.3V HPRL SPRLB SPRLCS VMUTV3 VMUTV1B VMUTV3B DIRPDN DIRCS DIRRST_3.3V DIRCS_3.3V DSPCS DSPCS_3.3V DSPRST_3.3V DSPRST DSPSDO_3.3V DSPCLK_3.3V DIGCLK DIGSDO DIRINT0 DSPINT0 DIGSDI SD VOLH OPT2 OPT1 RDSCLK DIRINT0 ROMSDA ROMSCL +VCC FBUSY FCLK FRXD FTXD CNVSS RESET APOWER ROMSDA ROMSCL VOLDAT VOLCLK SPRLF STEREO VOLB VOLA SYSOUT SYSIN DIRINT0_3.3V FLAG0_3.3V DSPSDI_3.3V AMUT 2 1 DIGITAL IN To FLASH WRITER NC NADG-8756 C220 104Z C241 102K R205 0 R203 0 R207 0 C228 104Z C235 104Z C211 104Z C212 104Z C215 104Z C214 104Z R213 220 R210 220 R209 220 C224 104Z C238 104Z C239 104Z R223 220 R224 220 R222 220 C244 101J R251 1M C243 104Z C703 100/16 + R776 220 R777 220 R775 220 R738 220 R739 220 R740 220 R730 0 R729 0 C798 104Z R610 0 R620 0 C716 104Z Q728 RN1404 2 3 1 C730 101J C729 101J Q747 RN1404 3 1 2 Q748 RN2402 2 1 3 D747 1SS355 C767 104Z Q772 RN2402 1 2 3 D772 1SS355 C778 102K C712 104Z D712 1SS355 C702 100/16 + C223 104Z R201 0 R225 220 C271 104Z X201 24.576MHz C748 1/50 + R744 220 R743 220 R745 220 C232 104Z C242 103Z Q705 RN1404 2 3 1 C718 104Z R131 220 C131 100/16 + C133 104Z C132 104Z R132 220 C272 104Z D718 1SS355 C213 104Z C209 120J C210 120J C217 104Z C218 104Z C219 104Z C227 104Z C230 104Z C231 104Z C236 104Z C713 4.7/50+ Q712 RN1404 1 2 3 R733 33 R732 33 R731 33 R734 33 D773 HZU5.1B C790 NC C791 NC C792 NC C789 NC C795 102K C797 102K C793 102K C794 102K L701 NCH-1479 Q701 M30622MGP 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 98 VREF 99 AVCC 100 NC 100 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 Q271 TC74VHC541FT 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 _G2 20 VCC 1 _G1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND Q272 TC74HCT7007AF 1 2 3 4 5 6 7 GND 8 OUT4 9 IN4 10 OUT5 11 IN5 12 OUT6 13 IN6 14 VCC Q702 S-812C50AUA-C3E 2 I 3 O 1 G R612 47K R677 27K R676 27K R678 10K R609 10K R221 1K R704 1K R703 1K R710 NC R721 NC X701 CSTCR6M0055 -R0 R618 220K R790 4.7K R791 4.7K R792 4.7K R793 4.7K R794 4.7K R795 4.7K R789 4.7K R797 4.7K R781 1K R695 2.7K R694 2.7K R696 2.7K R693 2.7K R673 220K R778 1K R779 1K R780 1K R773 47K R770 NC R769 NC R768 NC R670 0 R748 1K R750 1K R617 10K R718 10K R720 NC R723 1K R621 10K R727 1K R629 2.2K R630 2.2K R208 10K R206 10K R204 10K R202 10K R211 10K R212 10K R647 10K R226 10K R671 33K R771 56K R742 220 R741 10K P701A 1 2 3 4 5 6 7 8 9 C720 NC R669 0 R668 0 R643 NC R774 NC R735 100 R736 100 R636 2.2K C735 104 R635 2.2K L131 L131 : BLM21PG221SN1 U132 GP1FAV51RKF5 1 OUT 3 VCC 2 GND U131 GP1FAV51RKF5 1 OUT 3 VCC 2 GND R766 NC R765 1K R666 10K C762 104Z R767 1K R753 220 R754 220 R751 1K R631 10K R632 10K R646 10K D720 NC Q706 NC 3 2 1 C204 220/6.3 2 + Q201 ADSP-21266SKSTZ 73 73 VDDEXT 74 74 GND 75 VDDINT 76 GND 77 DAI_P10 78 DAI_P11 79 DAI_P12 80 DAI_P13 81 DAI_P14 82 DAI_P15 83 VDDINT 84 GND 85 GND 86 DAI_P16 87 DAI_P17 88 DAI_P18 89 DAI_P19 90 VDDINT 91 GND 92 GND 93 VDDEXT 94 DAI_P20 95 GND 96 VDDINT 97 FLAG2 98 FLAG3 99 VDDINT 100 GND 101 VDDINT 102 GND 103 VDDINT 104 GND 105 VDDINT 106 GND 107 107 VDDINT 108 108 DDINT 109 GND 110 VDDINT 111 GND 112 VDDINT 113 GND 114 VDDINT 115 GND 116 VDDEXT 117 GND 118 VDDINT 119 GND 120 VDDINT 121 RESET 122 SPIDS 123 GND 124 VDDINT 125 SPICLK 126 MISO 127 MOSI 128 GND 129 VDDINT 130 VDDEXT 131 AVDD 132 AVSS 133 GND 134 CLKOUT 135 EMU 136 TDO 137 TDI 138 TRST 139 TCK 140 TMS 141 GND 142 CLKIN 143 XTAL 144 VDDEXT 1 VDDINT 1 2 CLKCFG0 2 3 CLKCFG1 4 BOOTCFG0 5 BOOTCFG1 6 GND 7 VDDEXT 8 GND 9 VDDINT 10 GND 11 VDDINT 12 GND 13 VDDINT 14 GND 15 FLAG0 16 FLAG1 17 AD7 18 GND 19 VDDINT 20 GND 21 VDDEXT 22 GND 23 VDDINT 24 AD6 25 AD5 26 AD4 27 VDDINT 28 GND 29 AD3 30 AD2 31 VDDEXT 32 GND 33 AD1 34 AD0 35 WR 35 36 VDDINT 36 37 VDDINT 38 GND 39 RD 40 ALE 41 AD15 42 AD14 43 AD13 44 GND 45 VDDEXT 46 AD12 47 VDDINT 48 GND 49 AD11 50 AD10 51 AD9 52 AD8 53 DAI_P1 54 VDDINT 55 GND 56 DAI_P2 57 DAI_P3 58 GND 59 VDDEXT 60 VDDINT 61 GND 62 DAI_P4 63 DAI_P5 64 DAI_P6 65 DAI_P7 66 VDDINT 67 GND 68 VDDINT 69 GND 70 DAI_P8 71 DAI_P9 72 VDDINT L201 BLM21PG221SN1 C704 100/16 + L202 BLM21PG221 SN1 R747 2.2K C750 474K Q735 S-24CS16A0I-J8V1G 1 A0 2 A1 3 A2 4 GND 5 SDA 6 SCL 7 WP 8 VCC R749 1K P201 JTAGNC 1 3 5 7 9 11 13 14 12 10 8 6 4 2 R231 56 L231 LM182 C749 474K OPTICAL U04 DSP & MICROPROCESSOR PC BOARD HPIN VOLB VOLA STEREO SD REMIN SYSOUT SYSIN PROTECT THERMAL VOLH APOWER VOLDAT VOLCLK SPRLF VCTRLA VCTRLB VMUTV1B VMUTV3B CNVSS RDSDAT DSPINT0 PLLSDA PLLSCL VMUTB DIGCLK DIGSDI DIGSDO DSPRST DIRCS DIRPDN DSPCS ROMSDA ROMSCL AMUTB FLDCS FLDSDO LEDSTBY FLDRST FLDCLK KEYINT3 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 KEY1 KEY0 AVSS 81 HPRL 82 NC 83 NC NC VSS NC NC NC NC NC VCC2 NC NC NC FCE SPRLCS 50 NC 49 SPRL B 48 DSPINT2 DSPINT3/DIRINT1 DSPINT1 NC NC NC NC NC NC XOUT VSS XIN VCC1 NC NC NC FCLK 33 FRXD 32 FTXD 31 NC HOLD +5V +5V +5V +5V +5V +3.3V +3.3V +1.2V +3.3V +1.2V +5V +10V MICROPROCESSOR DSP E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-3(SD-3) DSP & MICROPROCESSOR SECTION FLAG0_3.3V DSPSDO_3.3V DSPCLK_3.3V DSPCS_3.3V DSPRST_3.3V DSPSDI_3.3V FLDCS FLDSDO LEDSTBY FLDRST FLDCLK KEYINT3 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 KEY1 KEY0 DSPINT0 PLLSDA RESET VMUT STEREO SD REMIN PROTECT THERMAL INT3 DIGCLK DIGSDI DIGSDO DSPRST DIRCS DIRPDN DSPCS BAND INT1 INT2 AMUTB PLLSCL VCTRLA VCTRLB CNVSS POFF VMUTB APOWER HPIN RDSDAT RTAD LTAD +10VS HPIN DSPCLK_3.3V DSPSDI_3.3V DSPSDO_3.3V DIRCS_3.3V DIRINT0_3.3V DIRRST_3.3V VMUTV1 DIRINT0_3.3V BCK DIRSDO ADCSDO DSPMCK HPRL SPRLB SPRLCS COAX VMUTV3 VMUTV1B VMUTV3B DSPSDO3 DIRPDN DIRCS DIRRST_3.3V DIRCS_3.3V DSPCS DSPCS_3.3V DSPRST_3.3V DSPRST DSPSDO1 DSPSDO2 DSPSDO_3.3V DSPCLK_3.3V DIGCLK DIGSDO DIRINT0 DSPINT0 DIGSDI SD VOLH TU_R TU_L GNDTU +12V_TU +2.5V_DSP +3.3V_DSP +5V_DSP GND_DAC RTAD LTAD -12V +12V SYSIN VOLDAT VOLCLK AMUT SPRLB SPRLCS SPRLF DAC_FL DAC_FR DAC_C DAC_SW DAC_SL DAC_SR +10VS +12V_VIDEO GND_VIDEO THERMAL PROTECT VOLH APOWER POFF2 POFFV HPRL KEY3 KEY1 KEY0 REMIN FLDSDO FLDCLK FLDCS FLDRST KEY2 KEYINT0 KEYINT1 KEYINT2 KEYINT3 VOLA VOLB LEDSTBY GND_HP HPIN +5.6S FAC1 FAC2 -VP HP_L HP_R FAC1 FAC2 -VP GND_HP HP_L HP_R TU_L TU_R STEREO SD RDSDAT RDSCLK PLLSCL PLLSDA OPT2 OPT1 OPT2 OPT1 RDSCLK DIRINT0 COAX VMUTV1 VCTRLB VMUT VMUTV3 +12V_VIDEO GND_VIDEO VCTRLA +9V_TUNER ROMSDA ROMSCL +VCC FBUSY FCLK FRXD FTXD CNVSS RESET APOWER ROMSDA ROMSCL VOLDAT VOLCLK SPRLF STEREO VOLB VOLA SYSOUT SYSIN GNDTU LRCK +5V_DSP DIRINT0_3.3V FLAG0_3.3V DSPSDI_3.3V AMUT To NAVD-8768 (SD-4 : E5) 2 1 DIGITAL IN To NAAF-8745 (SD-2 : H5) To NAAF-8745 (SD-2 : H4) To NAAF-8745 (SD-2 : H3) To FLASH WRITER NC NADG-8756 NC NC To NADIS-8767 (SD-4 : E1) C220 104Z C241 102K R205 0 R203 0 R207 0 C228 104Z C235 104Z C211 104Z C212 104Z C215 104Z C214 104Z R213 220 R210 220 R209 220 C224 104Z C238 104Z C239 104Z R223 220 R224 220 R222 220 C244 101J R251 1M C243 104Z C312 473K C313 104Z R313 220 R314 220 R315 220 R316 220 R317 220 C703 100/16 + R776 220 R777 220 R775 220 R738 220 R739 220 R740 220 R730 0 R729 0 C798 104Z C415 681J C425 681J R445 180 R446 180 R448 180 R447 180 C405 472J R421 470 R422 470 R424 470 R423 470 R409 3.3K R410 3.3K R412 3.3K R411 3.3K C413 681J C423 681J R441 180 R442 180 R444 180 R443 180 C403 472J R417 470 R418 470 R420 470 R419 470 R405 3.3K R406 3.3K R408 3.3K R407 3.3K C411 681J C421 681J C422 681J C412 681J R437 180 R438 180 R440 180 R439 180 C402 472J R413 470 R414 470 R416 470 R415 470 R402 3.3K R404 3.3K R403 3.3K C310 104Z R318 220 C304 100/16 + R610 0 R620 0 C716 104Z Q728 RN1404 2 3 1 C730 101J C729 101J Q747 RN1404 3 1 2 Q748 RN2402 2 1 3 D747 1SS355 C767 104Z Q772 RN2402 1 2 3 D772 1SS355 C778 102K C712 104Z D712 1SS355 C702 100/16 + C223 104Z R201 0 R225 220 C271 104Z C307 104Z C337 222J C338 222J Q331:B NJM4580M-D 2 3 1 R401 3.3K C401 472J Q402:A 7 4 5 6 8 Q403:B 1 2 3 Q402:B 1 2 3 Q401:B 1 2 3 X201 24.576MHz C323 330J R451 4.7 R452 4.7 Q401:A 7 4 5 6 8 C748 1/50 + R744 220 R743 220 R745 220 C301 470/6.3 + C232 104Z C242 103Z R322 220 C321 330J C322 330J R321 220 Q705 RN1404 2 3 1 C718 104Z R131 220 C131 100/16 + C133 104Z C132 104Z R132 220 Q403:A 7 4 5 6 8 C414 153J C424 103J C404 333J C416 681J C426 681J C406 472J C272 104Z R323 220 D718 1SS355 Q331:A NJM4580M-D 5 6 8 7 4 P2011 1 2 3 4 5 6 7 8 9 10 11 C213 104Z C209 120J C210 120J C217 104Z C218 104Z C219 104Z C227 104Z C230 104Z C231 104Z C236 104Z R312 33 R308 33 R309 33 R307 33 R303 33 C713 4.7/50+ Q712 RN1404 1 2 3 R342 0 R341 0 C451 220/16 + C452 220/16 + R733 33 R732 33 R731 33 R734 33 D773 HZU5.1B C790 NC C791 NC C792 NC C789 NC C795 102K C797 102K C793 102K C794 102K C332 101J L701 NCH-1479 Q701 M30622MGP 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 98 VREF 99 AVCC 100 NC 100 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 Q271 TC74VHC541FT 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 _G2 20 VCC 1 _G1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND Q272 TC74HCT7007AF 1 2 3 4 5 6 7 GND 8 OUT4 9 IN4 10 OUT5 11 IN5 12 OUT6 13 IN6 14 VCC C311 222K Q301 CS42516 17 18 19 REFGND 20 AOUTB4- 21 AOUTB4+ 22 AOUTA4+ 23 AOUTA4- 24 VA 25 AGND1 26 AOUTB3- 27 AOUTB3+ 28 AOUTA3+ 29 AOUTA3- 30 AOUTB2- 31 31 AOUTB2 32 32 AOUTA2 33 AOUTA2- 34 AOUTB1- 35 AOUTB1+ 36 AOUTA1+ 37 AOUTA1- 38 MUTEC 39 LPFLT 40 AGND2 41 VARX 42 RXP7/GP7 43 RXP6/GP6 44 RXP5/GP5 45 RXP4/GP4 46 RXP3/GP3 47 RXP2/GP2 48 RXP1/GP1 49 RXP0 49 50 TXP 50 51 VD2 52 DGND2 53 VLS 54 SAI_SDOUT 55 RMCK 56 CX_SDOUT 57 ADCIN2 58 ADCIN1 59 OMCK 60 SAI_LRCK 61 SAI_SLCK 62 CX_SDIN4 62 63 CX_SDIN3 63 64 CX_SDIN2 64 1 CX_SDIN1 2 CX_SCLK 3 CX_LRCK 4 VD1 5 DGND1 6 VLC 7 CCLK/SCL 8 CDOUT/SAD 9 CDIN/AD1 10 CS/AD0 11 INT1 12 _RST 13 AINR- 14 AINR+ 15 AINL+ 16 AINL- Q702 S-812C50AUA-C3E 2 I 3 O 1 G R612 47K R677 27K R676 27K R678 10K R609 10K R332 10K R333 10K R334 10K R436 4.7K R435 4.7K R434 4.7K R433 4.7K R432 4.7K R431 4.7K R430 4.7K R429 4.7K R428 4.7K R427 4.7K R426 4.7K R425 4.7K R221 1K R704 1K R703 1K R710 NC R721 NC X701 CSTCR6M0055 -R0 R618 220K R790 4.7K R791 4.7K R792 4.7K R793 4.7K R794 4.7K R795 4.7K R789 4.7K R797 4.7K R781 1K R695 2.7K R694 2.7K R696 2.7K R693 2.7K R673 220K R778 1K R779 1K R780 1K R773 47K R770 NC R769 NC R768 NC R670 0 R748 1K R750 1K R617 10K R718 10K R720 NC R723 1K R621 10K R727 1K R629 2.2K R630 2.2K R208 10K R206 10K R204 10K R202 10K R211 10K R212 10K R647 10K R226 10K R671 33K R771 56K R742 220 R741 10K P302A 20 1 P303A 20 1 E151 NC P301A 6 1 P7001A 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 P701A 1 2 3 4 5 6 7 8 9 P101A 1 2 3 4 5 6 7 8 9 10 11 12 13 C720 NC R669 0 R668 0 C331 101J C308 104Z C335 22/50 + R337 0 C334 22/50 + C336 22/50 + R338 0 R336 56 C333 22/50 + R335 56 R643 NC R774 NC C104 104Z C103 100/16 + R735 100 R736 100 R636 2.2K C735 104 R635 2.2K L131 L131 : BLM21PG221SN1 U132 GP1FAV51RKF5 1 OUT 3 VCC 2 GND U131 GP1FAV51RKF5 1 OUT 3 VCC 2 GND R766 NC R765 1K R666 10K C762 104Z R767 1K R753 220 R754 220 R751 1K R631 10K R632 10K R646 10K D720 NC Q706 NC 3 2 1 C204 220/6.3 2 + Q201 ADSP-21266SKSTZ 73 73 VDDEXT 74 74 GND 75 VDDINT 76 GND 77 DAI_P10 78 DAI_P11 79 DAI_P12 80 DAI_P13 81 DAI_P14 82 DAI_P15 83 VDDINT 84 GND 85 GND 86 DAI_P16 87 DAI_P17 88 DAI_P18 89 DAI_P19 90 VDDINT 91 GND 92 GND 93 VDDEXT 94 DAI_P20 95 GND 96 VDDINT 97 FLAG2 98 FLAG3 99 VDDINT 100 GND 101 VDDINT 102 GND 103 VDDINT 104 GND 105 VDDINT 106 GND 107 107 VDDINT 108 108 DDINT 109 GND 110 VDDINT 111 GND 112 VDDINT 113 GND 114 VDDINT 115 GND 116 VDDEXT 117 GND 118 VDDINT 119 GND 120 VDDINT 121 RESET 122 SPIDS 123 GND 124 VDDINT 125 SPICLK 126 MISO 127 MOSI 128 GND 129 VDDINT 130 VDDEXT 131 AVDD 132 AVSS 133 GND 134 CLKOUT 135 EMU 136 TDO 137 TDI 138 TRST 139 TCK 140 TMS 141 GND 142 CLKIN 143 XTAL 144 VDDEXT 1 VDDINT 1 2 CLKCFG0 2 3 CLKCFG1 4 BOOTCFG0 5 BOOTCFG1 6 GND 7 VDDEXT 8 GND 9 VDDINT 10 GND 11 VDDINT 12 GND 13 VDDINT 14 GND 15 FLAG0 16 FLAG1 17 AD7 18 GND 19 VDDINT 20 GND 21 VDDEXT 22 GND 23 VDDINT 24 AD6 25 AD5 26 AD4 27 VDDINT 28 GND 29 AD3 30 AD2 31 VDDEXT 32 GND 33 AD1 34 AD0 35 WR 35 36 VDDINT 36 37 VDDINT 38 GND 39 RD 40 ALE 41 AD15 42 AD14 43 AD13 44 GND 45 VDDEXT 46 AD12 47 VDDINT 48 GND 49 AD11 50 AD10 51 AD9 52 AD8 53 DAI_P1 54 VDDINT 55 GND 56 DAI_P2 57 DAI_P3 58 GND 59 VDDEXT 60 VDDINT 61 GND 62 DAI_P4 63 DAI_P5 64 DAI_P6 65 DAI_P7 66 VDDINT 67 GND 68 VDDINT 69 GND 70 DAI_P8 71 DAI_P9 72 VDDINT L201 BLM21PG221SN1 C704 100/16 + R191 39K R192 39K R194 0 R193 33K C192 100/16 + C191 100/16 + D192 NC Q191 BD7820 1 _SHUT 2 INPUT 3 GND 4 OUTPUT 5 DAJ Q101 2SC1815 2 1 3 R101 330 D101 UDZS10B C101 100/16 + C306 104Z R301 33 R304 33 R305 33 R310 33 L301 BLM21PG221 SN1 L202 BLM21PG221 SN1 R325 2.7K L303 L302 C302 470/6.3 + C303 470/6.3 + C309 NC D336 D334 D338 D332 D335 D333 D337 D331 R340 3.9K R339 3.9K R331 10K R747 2.2K C750 474K Q735 S-24CS16A0I-J8V1G 1 A0 2 A1 3 A2 4 GND 5 SDA 6 SCL 7 WP 8 VCC R749 1K P201 JTAGNC 1 3 5 7 9 11 13 14 12 10 8 6 4 2 R231 56 L231 LM182 L311 LM182 R311 33 L306 LM182 R306 33 R302 33 L305 LM182 C749 474K C305 100/10(VX) + 17 VQ 18 FLT OPTICAL U04 DSP & MICROPROCESSOR PC BOARD HPIN VOLB VOLA STEREO SD REMIN SYSOUT SYSIN PROTECT THERMAL VOLH APOWER VOLDAT VOLCLK SPRLF VCTRLA VCTRLB VMUTV1B VMUTV3B CNVSS RDSDAT DSPINT0 PLLSDA PLLSCL VMUTB DIGCLK DIGSDI DIGSDO DSPRST DIRCS DIRPDN DSPCS ROMSDA ROMSCL AMUTB FLDCS FLDSDO LEDSTBY FLDRST FLDCLK KEYINT3 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 KEY1 KEY0 AVSS 81 HPRL 82 NC 83 NC NC VSS NC NC NC NC NC VCC2 NC NC NC FCE SPRLCS 50 NC 49 SPRL B 48 DSPINT2 DSPINT3/DIRINT1 DSPINT1 NC NC NC NC NC NC XOUT VSS XIN VCC1 NC NC NC FCLK 33 FRXD 32 FTXD 31 NC HOLD +5V +5V +5V +5V To TUNER UNIT +5V +3.3V +3.3V +1.2V +1.2V +3.3V +3.3V +1.2V +5V -12V +12V Q401 - Q403 : NJM4580M-D L302, 303 : BLM21PG221SN1 +10V +2.5V +5V +8.9V MICROPROCESSOR DSP DIR/DAC/ADC NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. FR FL SW C SR SL A 1 2 3 4 5 B C D E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-4(SD-4) DISPLAY SECTION / POWER SUPPLY SECTION / VIDEO SECTION FLDRST FLDCS FLDCLK FLDSDO HP_L HPIN HP_R GND_HP LEDSTBY KEYINT0 KEY0_2 GNDTACT HPIN HP_L HP_R GND_HP KEYINT0 STANDBY CD TUNER TAPE VIDEO 3 VIDEO 2 VIDEO 1/ VCR DVD MEMORY DIGITAL INPUT DISPLAY LISTENNG MODE> LISTENIG MODE< STEREO TONE+ TONE- TONE TUNING UP TUNING DOWN PRESET UP PRESET DOWN ENTER SETUP RETURN TUNING MODE MULTI CH NADIS-8767 STANDBY/ON SPEAKERS A SPEAKERS B NASW-8770 NAETC-8771 S7318 S7317 S7316 S7315 S7312 S7328 S7327 S7326 S7325 S7324 S7323 S7322 S7329 S7338 S7337 S7336 S7335 S7334 S7333 S7332 S7313 S7319 C7009 223Z C7005 101J C7006 101J C7007 101J C7008 101J C7004 101J C7012 223Z C7213 102K R7402 10K R7403 10K R7404 10K R7005 3.3K R7332 470 R7333 560 R7334 820 R7335 1.2K R7336 2.2K R7337 3.9K R7338 12K R7322 470 R7323 560 R7324 820 R7325 1.2K R7326 2.2K R7327 3.9K R7328 12K R7312 470 R7313 560 R7314 820 R7315 1.2K R7316 2.2K R7317 3.9K Q7002 M66005 49 SEG2 50 SEG1 51 SEG0 52 VCC2 53 DIG15/SEG39 54 DIG14/SEG38 55 DIG13/SEG37 56 DIG12/SEG36 57 DIG11 58 DIG10 59 DIG9 60 DIG8 61 DIG7 62 DIG6 63 DIG5 64 DIG4 1 DIG03 2 DIG02 3 DIG01 4 DIG00 5 _RESET 6 _CS 7 SCK 8 SDATA 9 P1 10 P0 11 VCC1 12 XOUT 13 XIN 14 VSS 15 SEG35 16 SEG34 17 SEG33 18 SEG32 19 SEG31 20 SEG30 21 SEG29 22 SEG28 23 SEG27 24 VP 25 SEG26 26 SEG25 27 SEG24 28 SEG23 29 SEG22 30 SEG21 31 SEG20 32 SEG19 33 SEG18 34 SEG17 35 SEG16 36 SEG15 37 SEG14 38 SEG13 39 SEG12 40 SEG11 41 SEG10 42 SEG9 43 SEG8 44 SEG7 45 SEG6 46 SEG5 47 SEG4 48 SEG3 R7001 100K R7008 220 R7006 3.3K R7007 220 R7004 27K C7402 103Z R7201 2.2K R7211 100 R7301 330 R7311 330 R7321 330 R7331 330 S7311 S7321 S7331 R7401 10K S7401 4 2 5 3 1 C7401 103Z R7212 1.2K C7002 104J C7211 100/16 + C7001 100/16 + C7019 NC C7018 NC C7017 NC C7015 NC C7020 NC R7011 220 R7012 220 Q7001 16BT128 1 F21 2 F22 5 1G 6 2G 7 3G 8 4G 9 5G 10 6G 11 7G 12 8G 13 9G 14 10G 15 11G 16 12G 17 13G 18 14G 19 15G 20 16G 21 P1 22 P2 23 P3 24 P4 25 P5 26 P6 27 P7 28 P8 29 P9 30 P10 31 P11 32 P12 33 P13 34 P14 35 P15 36 P16 37 P17 38 P18 39 P19 40 P20 41 P21 42 P22 43 P23 44 P24 45 P25 46 P26 47 P27 48 P28 49 P29 50 P30 51 P31 52 P32 53 P33 54 P34 55 P35 58 F11 59 F12 JL7101A 1 2 3 4 5 6 7 C7013 223Z C7014 223Z C7051 104J C7052 104J D7011 MTZJ8.2C D7201 Q7003 2SC2458-GR 2 1 3 C7011 223Z L7011 220K L7012 220K C7003 1/50 + C7010 220/50 + U7212 3 2 1 C7016 220/50 + JL7101B 1 JL7102A 5 4 3 2 1 S7303 S7304 S7307 R7302 470 R7303 560 C7053 104J E7501 C7501 102K C7502 102K P7501 1 8 7 3 2 4 5 JL7102B 1 2 3 4 5 C7503 102K C7504 102K L7503 022M L7501 022M L7502 022M To NADG (SD-3 : PHONES AGAINST FIRE HAZARD, REPLACE V A FOR CONTINUED PROTECTION AND RATING INDICATED. ONLY WITH FUSE OF SAME TYPE CAUTION ATTENTION ET CALIBRATION COMME INDIQUE. D'INCENDIE, REMPLACER UNIQUEMENT PERMANENTE CONTRE LES RISQUES AFIN D'ASSURER UNE PROTECTION PAR UN FUSIBLE DE MEME TYPE V A E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE. QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST FOR CONTINUED PROTECTION AGAINST FIRE RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL. HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE THIS SYMBOL LOCATED NEAR THE FUSE INDICATES THAT THE FUSE USED IS SLOW OPERATING TYPE THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY REPLACE ONLY WITH PART NUMBER SPECIFIED. VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL). ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED. ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED. ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED. ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV. ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED. EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED. THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS. EX) PRINTING SIDE CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT. ! NOTE U05 DISPLAY PC BOARD U09 HEADPHONE JACK PC BOARD U08 SWITCH PC BOARD MASTER VOLUME +5V +5V -36.7V S7739 DIMMER NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. FL DRIVER FL TUBE A 1 2 3 4 5 B C D TX-SR304(HT-S4100) COAX VMUTMON VMUTV1 VCTRLA VCTRLB VMUTV3 GND_DSP +5V_DSP GND_VIDEO +12V_VIDEO -VP FLDRST FLDCS FLDCLK FLDSDO REMIN KEY1 KEY0 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 +5.6S FAC1 FAC2 KEYINT3 VOLA VOLB GNDCPU +5VDIS LEDSTBY HP_L GND_HP HP_R HPIN +10VS POFF +12VD POWERD GNDDG AC-G AC-H 10 11 12 13 16 17 18 19 14 15 8 9 1 3 7 5 MONITOR OUT VIDEO 1 IN VIDEO 1 OUT VIDEO 2 IN VIDEO 3 IN DVD IN Y PR PB DIGITAL IN NAVD-8768 NC NC NAPS-8769 F902 NC F901 8A 125V T901 To NAETC-8476 (SD-2 : A5) C2013 2.2/50 + C2012 2.2/50 + Q2002 RN1241 3 1 2 C2014 470/16 + C2015 2.2/50 + C2016 2.2/50 + C2116 1/50 + C2115 1/50 + R2004 75 R2003 75 R2002 75 R2006 75 R2007 75 R2122 NC R2123 560 R2105 75 R2106 75 R2005 75 R2014 220 C2022 223Z C2021 47/25 + R2121 56 C2011 470/16 + C2123 47/25 + C1004 080D R1005 NC C1002 101J R1002 10 C1001 223Z C1003 103J C2124 100/16 + C2119 1/50 + C2118 1/50 + R2107 75 R2108 75 R2109 75 C2117 2.2/50 + C2122 1/50 + C2121 1/50 + R2110 75 R2111 75 R2112 75 C2120 2.2/50 + P1001 Q2021 LA7956 1 VIDEO OUT 2 A 3 B 4 VIN1 5 GND 6 VIN2 7 VCC 8 VIN3 9 VIN4 Q2121 NJM2585L 1 CH1IN1 2 SW1 3 CH1IN2 4 SW2 5 CH1IN3 6 V+ 7 CH2IN1 8 GND 9 CH2IN2 10 GND 11 CH2IN3 12 CH3IN3 13 GND 14 CH3IN2 15 GND 16 CH3IN1 17 GND 18 CH3OUT 19 V+ 20 CH2OUT 21 PS 22 CH1OUT C1012 223Z Q2122 2SC1815 2 1 3 R1001 75 R2114 75 R2115 75 R2116 75 R2104 75 C2114 2.2/50 + P2101 C2111 470/6.3 + J2113 J2112 J2111 Q2113 NC 3 1 2 Q2111 NC 3 1 2 Q2112 NC 3 1 2 R2117 NC Q2001 RN1241 3 1 2 Q2114 NC 3 1 2 Q2003 DTA114ES 3 1 2 Q2004 DTA114ES 3 1 2 C2125 223Z P2011A 11 1 P2001 D2001 D2002 C2001 102K C2002 102K C2101 102K C2102 102K D2121 MTZJ9.1C Q1001 TC74HCU04A 1 2 3 4 5 6 7 GND 8 OUT4 9 IN4 10 OUT5 11 IN5 12 OUT6 13 IN6 14 VCC Q2005 KTA1267-GR 1 2 3 R1003 100K R1004 10K P2002 R2001 100K R2008 680K R2009 680K R2010 680K R2011 680K R2012 100K R2013 100K P2102 R2101 100K R2102 100K R2103 100K C1011 220/6.3 + L1011 220K L1001 022M C2112 470/6.3 + C2113 470/6.3 + P7001B 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 R7013 100 T902 1 2 3 4 5 6 7 8 9 C921 NC D933 1SS133 D935 1SS133 C933 4.7/50 + R901 56(1/2W) E901 D952 1SS133 C905 10/50 + C907 100/16 + R934 100K R905 100K R906 100K R908 10K R907 82K D951 1SS133 C930 33/35 + P906A P905A P904A JL9003B 1 2 3 4 5 RL901 3 1 4 2 D925 1SS133 C902 103Z C901 103M/275 D921 1SS133 D922 1SS133 D923 1SS133 D924 1SS133 P901A 2 1 D931 1SS133 D930 1SS133 C922 2200/16 + J906 J907 D934 MTZJ5.1B Q901 SI-3010KF 1 Vc 2 Vin 3 GND 4 Vout 5 ADJ D932 1SS133 C951 101J P902 1 2 P902 2 1 To NADG-8756 (SD-3 : B1) G-8756 : C1) . COAXIAL U07 POWER SUPPLY PC BOARD U06 VIDEO PC BOARD ! ! ! ! ! ! ! +12V +12V +5V ! COMPONENT VIDEO VIDEO 2 IN Y PR PB Y PR PB Y PR PB VIDEO 1 IN DVD IN OUT ! To NAAF-8475 (SD-2 : B4) +8.4V NPT-1514D T902 MDC : NPT-1520JQ AC IN MDC : 120V, 60z NC NC NC VIDEO SWITCH T901 E F G H TX-SR304(HT-S4100) SCHEMATIC DIAGRAMS-4(SD-4) DISPLAY SECTION / POWER SUPPLY SECTION / VIDEO SECTION COAX VMUTMON VMUTV1 VCTRLA VCTRLB VMUTV3 GND_DSP +5V_DSP GND_VIDEO +12V_VIDEO FLDRST FLDCS FLDCLK FLDSDO HP_L HPIN HP_R GND_HP -VP LEDSTBY KEYINT0 FLDRST FLDCS FLDCLK FLDSDO REMIN KEY1 KEY0 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 +5.6S FAC1 FAC2 KEYINT3 VOLA VOLB GNDCPU +5VDIS LEDSTBY HP_L GND_HP HP_R HPIN KEY0_2 GNDTACT HPIN HP_L HP_R GND_HP KEYINT0 +10VS POFF +12VD POWERD GNDDG AC-G AC-H 10 11 12 13 16 17 18 19 14 15 8 9 1 3 7 5 MONITOR OUT VIDEO 1 IN VIDEO 1 OUT VIDEO 2 IN VIDEO 3 IN DVD IN Y PR PB DIGITAL IN NAVD-8768 STANDBY CD TUNER TAPE VIDEO 3 VIDEO 2 VIDEO 1/ VCR DVD MEMORY DIGITAL INPUT DISPLAY LISTENNG MODE> LISTENIG MODE< STEREO TONE+ TONE- TONE TUNING UP TUNING DOWN PRESET UP PRESET DOWN ENTER SETUP RETURN TUNING MODE MULTI CH NADIS-8767 STANDBY/ON SPEAKERS A SPEAKERS B NASW-8770 NAETC-8771 NC NC NAPS-8769 F902 NC F901 8A 125V T901 To NAETC-8476 (SD-2 : A5) C2013 2.2/50 + C2012 2.2/50 + Q2002 RN1241 3 1 2 C2014 470/16 + C2015 2.2/50 + C2016 2.2/50 + C2116 1/50 + C2115 1/50 + R2004 75 R2003 75 R2002 75 R2006 75 R2007 75 R2122 NC R2123 560 R2105 75 R2106 75 R2005 75 R2014 220 C2022 223Z C2021 47/25 + R2121 56 C2011 470/16 + C2123 47/25 + C1004 080D R1005 NC C1002 101J R1002 10 C1001 223Z C1003 103J C2124 100/16 + C2119 1/50 + C2118 1/50 + R2107 75 R2108 75 R2109 75 C2117 2.2/50 + C2122 1/50 + C2121 1/50 + R2110 75 R2111 75 R2112 75 C2120 2.2/50 + P1001 Q2021 LA7956 1 VIDEO OUT 2 A 3 B 4 VIN1 5 GND 6 VIN2 7 VCC 8 VIN3 9 VIN4 Q2121 NJM2585L 1 CH1IN1 2 SW1 3 CH1IN2 4 SW2 5 CH1IN3 6 V+ 7 CH2IN1 8 GND 9 CH2IN2 10 GND 11 CH2IN3 12 CH3IN3 13 GND 14 CH3IN2 15 GND 16 CH3IN1 17 GND 18 CH3OUT 19 V+ 20 CH2OUT 21 PS 22 CH1OUT C1012 223Z Q2122 2SC1815 2 1 3 R1001 75 R2114 75 R2115 75 R2116 75 R2104 75 C2114 2.2/50 + P2101 C2111 470/6.3 + J2113 J2112 J2111 Q2113 NC 3 1 2 Q2111 NC 3 1 2 Q2112 NC 3 1 2 R2117 NC Q2001 RN1241 3 1 2 Q2114 NC 3 1 2 Q2003 DTA114ES 3 1 2 Q2004 DTA114ES 3 1 2 C2125 223Z P2011A 11 1 P2001 D2001 D2002 C2001 102K C2002 102K C2101 102K C2102 102K D2121 MTZJ9.1C Q1001 TC74HCU04A 1 2 3 4 5 6 7 GND 8 OUT4 9 IN4 10 OUT5 11 IN5 12 OUT6 13 IN6 14 VCC Q2005 KTA1267-GR 1 2 3 R1003 100K R1004 10K P2002 R2001 100K R2008 680K R2009 680K R2010 680K R2011 680K R2012 100K R2013 100K P2102 R2101 100K R2102 100K R2103 100K C1011 220/6.3 + L1011 220K L1001 022M C2112 470/6.3 + C2113 470/6.3 + S7318 S7317 S7316 S7315 S7312 S7328 S7327 S7326 S7325 S7324 S7323 S7322 S7329 S7338 S7337 S7336 S7335 S7334 S7333 S7332 S7313 S7319 C7009 223Z C7005 101J C7006 101J C7007 101J C7008 101J C7004 101J C7012 223Z C7213 102K R7402 10K R7403 10K R7404 10K R7005 3.3K R7332 470 R7333 560 R7334 820 R7335 1.2K R7336 2.2K R7337 3.9K R7338 12K R7322 470 R7323 560 R7324 820 R7325 1.2K R7326 2.2K R7327 3.9K R7328 12K R7312 470 R7313 560 R7314 820 R7315 1.2K R7316 2.2K R7317 3.9K P7001B 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 Q7002 M66005 49 SEG2 50 SEG1 51 SEG0 52 VCC2 53 DIG15/SEG39 54 DIG14/SEG38 55 DIG13/SEG37 56 DIG12/SEG36 57 DIG11 58 DIG10 59 DIG9 60 DIG8 61 DIG7 62 DIG6 63 DIG5 64 DIG4 1 DIG03 2 DIG02 3 DIG01 4 DIG00 5 _RESET 6 _CS 7 SCK 8 SDATA 9 P1 10 P0 11 VCC1 12 XOUT 13 XIN 14 VSS 15 SEG35 16 SEG34 17 SEG33 18 SEG32 19 SEG31 20 SEG30 21 SEG29 22 SEG28 23 SEG27 24 VP 25 SEG26 26 SEG25 27 SEG24 28 SEG23 29 SEG22 30 SEG21 31 SEG20 32 SEG19 33 SEG18 34 SEG17 35 SEG16 36 SEG15 37 SEG14 38 SEG13 39 SEG12 40 SEG11 41 SEG10 42 SEG9 43 SEG8 44 SEG7 45 SEG6 46 SEG5 47 SEG4 48 SEG3 R7001 100K R7008 220 R7006 3.3K R7007 220 R7004 27K R7013 100 C7402 103Z R7201 2.2K R7211 100 R7301 330 R7311 330 R7321 330 R7331 330 S7311 S7321 S7331 R7401 10K S7401 4 2 5 3 1 C7401 103Z R7212 1.2K C7002 104J C7211 100/16 + C7001 100/16 + C7019 NC C7018 NC C7017 NC C7015 NC C7020 NC R7011 220 R7012 220 Q7001 16BT128 1 F21 2 F22 5 1G 6 2G 7 3G 8 4G 9 5G 10 6G 11 7G 12 8G 13 9G 14 10G 15 11G 16 12G 17 13G 18 14G 19 15G 20 16G 21 P1 22 P2 23 P3 24 P4 25 P5 26 P6 27 P7 28 P8 29 P9 30 P10 31 P11 32 P12 33 P13 34 P14 35 P15 36 P16 37 P17 38 P18 39 P19 40 P20 41 P21 42 P22 43 P23 44 P24 45 P25 46 P26 47 P27 48 P28 49 P29 50 P30 51 P31 52 P32 53 P33 54 P34 55 P35 58 F11 59 F12 JL7101A 1 2 3 4 5 6 7 C7013 223Z C7014 223Z C7051 104J C7052 104J D7011 MTZJ8.2C D7201 Q7003 2SC2458-GR 2 1 3 C7011 223Z L7011 220K L7012 220K C7003 1/50 + C7010 220/50 + U7212 3 2 1 C7016 220/50 + JL7101B 1 JL7102A 5 4 3 2 1 S7303 S7304 S7307 R7302 470 R7303 560 C7053 104J E7501 C7501 102K C7502 102K P7501 1 8 7 3 2 4 5 JL7102B 1 2 3 4 5 C7503 102K C7504 102K L7503 022M L7501 022M L7502 022M T902 1 2 3 4 5 6 7 8 9 C921 NC D933 1SS133 D935 1SS133 C933 4.7/50 + R901 56(1/2W) E901 D952 1SS133 C905 10/50 + C907 100/16 + R934 100K R905 100K R906 100K R908 10K R907 82K D951 1SS133 C930 33/35 + P906A P905A P904A JL9003B 1 2 3 4 5 RL901 3 1 4 2 D925 1SS133 C902 103Z C901 103M/275 D921 1SS133 D922 1SS133 D923 1SS133 D924 1SS133 P901A 2 1 D931 1SS133 D930 1SS133 C922 2200/16 + J906 J907 D934 MTZJ5.1B Q901 SI-3010KF 1 Vc 2 Vin 3 GND 4 Vout 5 ADJ D932 1SS133 C951 101J P902 1 2 P902 2 1 To NADG-8756 (SD-3 : B1) To NADG-8756 (SD-3 : C1) PHONES AGAINST FIRE HAZARD, REPLACE V A FOR CONTINUED PROTECTION AND RATING INDICATED. ONLY WITH FUSE OF SAME TYPE CAUTION ATTENTION ET CALIBRATION COMME INDIQUE. D'INCENDIE, REMPLACER UNIQUEMENT PERMANENTE CONTRE LES RISQUES AFIN D'ASSURER UNE PROTECTION PAR UN FUSIBLE DE MEME TYPE V A E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE. QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST FOR CONTINUED PROTECTION AGAINST FIRE RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL. HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE THIS SYMBOL LOCATED NEAR THE FUSE INDICATES THAT THE FUSE USED IS SLOW OPERATING TYPE THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY REPLACE ONLY WITH PART NUMBER SPECIFIED. VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL). ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED. ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED. ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED. ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV. ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED. EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED. THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS. EX) PRINTING SIDE CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT. ! NOTE COAXIAL U05 DISPLAY PC BOARD U07 POWER SUPPLY PC BOARD U06 VIDEO PC BOARD U09 HEADPHONE JACK PC BOARD U08 SWITCH PC BOARD ! ! ! ! ! ! ! MASTER VOLUME +12V +12V +5V +5V +5V ! COMPONENT VIDEO VIDEO 2 IN Y PR PB Y PR PB Y PR PB VIDEO 1 IN DVD IN OUT -36.7V ! To NAAF-8475 (SD-2 : B4) +8.4V S7739 DIMMER NPT-1514D T902 MDC : NPT-1520JQ AC IN MDC : 120V, 60z NC NC NC NC = No mount of parts. SD-Z : XY Location of connected terminal in schematic diagrams. SD-Z = Schematic diagrams-Z. X = A to H, Y = 1 to 5. VIDEO SWITCH FL DRIVER FL TUBE T901 A 1 2 3 4 5 B C D E F G H PRINTED CIRCUIT BOARD VIEWS-1 TX-SR304/304E U01 AMPLIFIER PC BOARD (NAAF-8745) Component side A 1 2 3 4 5 B C D TX-SR304/304E E F G H TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-1 U01 AMPLIFIER PC BOARD (NAAF-8745) Component side A 1 2 3 4 5 B C D E F G H PRINTED CIRCUIT BOARD VIEWS-2 TX-SR304/304E U01 AMPLIFIER PC BOARD (NAAF-8745) Soldering side A 1 2 3 4 5 B C D TX-SR304/304E E F G H TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-2 U01 AMPLIFIER PC BOARD (NAAF-8745) Soldering side A 1 2 3 4 5 B C D E F G H TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-3 U02 SEC. TERMINAL PC BOARD (NAETC-8746) Component side Soldering side A 1 2 3 4 5 B C D TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-4 U04 DSP & MICROPROCESSOR PC BOARD (NADG-8756) Component side A 1 2 3 4 5 B C D PRINTED CIRCUIT BOARD VIEWS-5 TX-SR304/304E U05 DISPLAY PC BOARD (NADIS-8767) Component side A 1 2 3 4 5 B C D TX-SR304/304E E F G H TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-5 U05 DISPLAY PC BOARD (NADIS-8767) Component side A 1 2 3 4 5 B C D E F G H TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-6 U06 VIDEO PC BOARD (NAVD-8768) Component side U07 POWER SUPPLY PC BOARD (NAPS-8769) Component side A 1 2 3 4 5 B C D TX-SR304/304E PRINTED CIRCUIT BOARD VIEWS-7 U08 SWITCH PC BOARD (NASW-8770) Component side U09 HEADPHONE JACK PC BOARD (NAETC-8771) Component side A 1 2 3 4 5 B C D TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-1 Q201 : ADSP-21266(32 bit, Floating-point SHARC DSP)-1/5 BLOCK DIAGRAM ADDR DATA PX REGISTER 6 JTAG TEST & EMULATION 20 3 SERIAL PORTS (6) INPUT DATA PORTS (8) PARALLEL DATA ACQUISITION PORT TIMERS (3) SIGNAL ROUTING UNIT PRECISION CLOCK GENERATORS (2) DIGITAL AUDIO INTERFACE 3 16 ADDRES S/ DA TA BUS / GPIO CONTROL/GP IO PARALLEL PORT IOP REGISTERS (MEMORY MAPPED) CONTROL, STATUS, DATA BUFFERS 4 SPI PORT (1) DMA CONTROLLER 22 CHANNE LS 4 GPIO FLAGS/ IRQ/TIMEXP I/O PROCESSOR PROCESSING ELEMENT (PEY) PROCESSING EL EMENT (PEX) TIMER INSTRUCTION CACHE 32 48-BIT DAG1 8 4 32 DAG2 8 4 32 32 PM ADDRESS BUS DM ADDRESS BUS PM DATA BUS DM DATA BUS 64 64 CORE PROCESSOR PROGRAM SEQUENCER ADDR DATA SRAM 1 MBIT ROM 2 MBIT DUAL PORTED MEMORY BLOCK 0 SRAM 1 MBIT ROM 2 MBIT DUAL PORTED MEMORY BLOCK 1 IOD (32) IOA (18) 32 TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-2 Q201 : ADSP-21266(32 bit, Floating-point SHARC DSP)-2/5 TERMINAL DESCRIPTION(1/3) Parallel Port Address/Data. The ADSP-21266 parallel port and its corresponding DMA unit output addresses and data for peripherals on these multiplexed pins. The multiplex state is determined by the ALE pin. The parallel port can operate in either 8-bit or 16-bit mode. Each AD pin has a 22.5 k ohms internal pull-up resistor. See Address Data Modes on Page 14 for details of the AD pin operation. For 8-bit mode: ALE is automatically asserted whenever a change occurs in the upper 16 external address bits, A23–8; ALE is used in conjunction with an external latch to retain the values of the A23–8. For 16-bit mode: ALE is automatically asserted whenever a change occurs in the address bits, A15–0; ALE is used in conjunction with an external latch to retain the values of the A15–0. To use these pins as flags (FLAG15–0) set (=1) Bit 20 of the SYSCTL register and disable the parallel port. See Table 4 on Page 14 for a list of how the AD15–0 pins map to the flag pins. When configured in the IDP_PDAP_CTL register, the IDP Channel 0 can use these pins for parallel input data. Parallel Port Read Enable. RD is asserted low whenever the DSP reads 8-bit or 16-bit data from an external memory device. When AD15–0 are flags, this pin remains deasserted. Parallel Port Write Enable. WR is asserted low whenever the DSP writes 8-bit or 16-bit data to an external memory device. When AD15–0 are flags, this pin remains deasserted. Parallel Port Address Latch Enable. ALE is asserted whenever the DSP drives a new address on the parallel port address pin. On reset, ALE is active high. However, it can be reconfigured using software to be active low. When AD15–0 are flags, this pin remains deasserted. Flag Pins. Each FLAG pin is configured via control bits as either an input or output. As an input, it can be tested as a condition. As an output, it can be used to signal external peripherals. These pins can be used as an SPI interface slave select output during SPI mastering. These pins are also multiplexed with the IRQx and the TIMEXP signals. In SPI master boot mode, FLAG0 is the slave select pin that must be connected to an SPI EPROM. FLAG0 is configured as a slave select during SPI master boot. When Bit 16 is set (=1) in the SYSCTL register, FLAG0 is configured as IRQ0. When Bit 17 is set (=1) in the SYSCTL register, FLAG1 is configured as IRQ1. When Bit 18 is set (=1) in the SYSCTL register, FLAG2 is configured as IRQ2. When Bit 19 is set (=1) in the SYSCTL register, FLAG3 is configured as TIMEXP, which indicates that the system timer has expired. Digital Audio Interface Pins. These pins provide the physical interface to the SRU. The SRU configuration registers define the combination of on-chip peripheral inputs or outputs connected to the pin and to the pin’s output enable. The configuration registers of these peripherals then determine the exact behavior of the pin. Any input or output signal present in the SRU may be routed to any of these pins. The SRU provides the connection from the serial ports, input data port, precision clock generators, and timers to the DAI_P20–1 pins. These pins have internal 22.5 k ohms pull-up resistors which are enabled on reset. These pull-ups can be disabled in the DAI_PIN_PULLUP register. I/O/T O O O I/O/A I/O/T AD15–0 RD WR ALE FLAG3–0 DAI_P20–1 Pin Type Function IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-3 Q201 : ADSP-21266(32 bit, Floating-point SHARC DSP)-3/5 TERMINAL DESCRIPTION(2/3) TX-SR304/304E Serial Peripheral Interface Clock Signal. Driven by the master, this signal controls the rate at which data is transferred. The master may transmit data at a variety of baud rates. SPICLK cycles once for each bit transmitted. SPICLK is a gated clock that is active during data transfers, only for the length of the transferred word. Slave devices ignore the serial clock if the slave select input is driven inactive (HIGH). SPICLK is used to shift out and shift in the data driven on the MISO and MOSI lines. The data is always shifted out on one clock edge and sampled on the opposite edge of the clock. Clock polarity and clock phase relative to data are programmable into the SPICTL control register and define the transfer format. SPICLK has a 22.5 k ohms internal pull-up resistor. If SPI master boot mode is selected, MOSI and SPICLK pins are driven during reset. These pins are not three-stated during reset in SPI master boot mode. Serial Peripheral Interface Slave Device Select. An active low signal used to select the DSP as an SPI slave device. This input signal behaves like a chip select, and is provided by the master device for the slave devices. In multimaster mode the DSP’s SPIDS signal can be driven by a slave device to signal to the DSP (as SPI master) that an error has occurred, as some other device is also trying to be the master device. If asserted low when the device is in master mode, it is considered a multimaster error. For a single master, multiple-slave configuration where flag pins are used, this pin must be tied or pulled high to VDDEXT on the master device. For ADSP-21266 to ADSP-21266 SPI interaction, any of the master ADSP-21266’s flag pins can be used to drive the SPIDS signal on the ADSP-21266 SPI slave device. SPI Master Out Slave In. If the ADSP-21266 is configured as a master, the MOSI pin becomes a data transmit (output) pin, transmitting output data. If the ADSP-21266 is configured as a slave, the MOSI pin becomes a data receive (input) pin, receiving input data. In an ADSP-21266 SPI interconnection, the data is shifted out from the MOSI output pin of the master and shifted into the MOSI input(s) of the slave(s). MOSI has a 22.5 k OHMS internal pull-up resistor. If SPI master boot mode is selected, MOSI and SPICLK pins are driven during reset. These pins are not three-stated during reset in SPI master boot mode. SPI Master In Slave Out. If the ADSP-21266 is configured as a master, the MISO pin becomes a data receive (input) pin, receiving input data. If the ADSP-21266 is configured as a slave, the MISO pin becomes a data transmit (output) pin, transmitting output data. In an ADSP-21266 SPI interconnection, the data is shifted out from the MISO output pin of the slave and shifted into the MISO input pin of the master. MISO has a 22.5 k ohms internal pull-up resistor. MISO can be configured as O/D by setting the OPD bit in the SPICTL register. Note: Only one slave is allowed to transmit data at any given time. To enable broadcast transmission to multiple SPI slaves, the DSP’s MISO pin may be disabled by setting (=1) Bit 5 (DMISO) of the SPICTL register. Boot Configuration Select. Selects the boot mode for the DSP. The BOOTCFG pins must be valid before reset is asserted. See Table 5 on Page 14 for a description of the boot modes. I/O I I/O (O/D) I/O (O/D) I SPICLK SPIDS MOSI MISO BOOTCFG1–0 Pin Type Function TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-4 Q201 : ADSP-21266(32 bit, Floating-point SHARC DSP)-4/5 TERMINAL DESCRIPTION(3/3) Local Clock In. Used in conjunction with XTAL. CLKIN is the ADSP-21266 clock input. It configures the ADSP-21266 to use either its internal clock generator or an external clock source. Connecting the necessary components to CLKIN and XTAL enables the internal clock generator. Connecting the external clock to CLKIN while leaving XTAL unconnected configures the ADSP-21266 to use the external clock source such as an external clock oscillator. The core is clocked either by the PLL output or this clock input depending on the CLKCFG1–0 pin settings. CLKIN may not be halted, changed, or operated below the specified frequency. Crystal Oscillator Terminal. Used in conjunction with CLKIN to drive an external crystal. Core/CLKIN Ratio Control. These pins set the start up clock frequency. See Table 6 for a description of the clock configuration modes. Note that the operating frequency can be changed by programming the PLL multiplier and divider in the PMCTL register at any time after the core comes out of reset. Reset Out/Local Clock Out. Drives out the core reset signal to an external device. CLKOUT can also be configured as a reset out pin (RSTOUT). The functionality can be switched between the PLL output clock and reset out by setting Bit 12 of the PMCTL register. The default is reset out. Processor Reset. Resets the ADSP-21266 to a known state. Upon deassertion, there is a 4096 CLKIN cycle latency for the PLL to lock. After this time, the core begins program execution from the hardware reset vector address. The RESET input must be asserted (low) at power-up. Test Clock (JTAG). Provides a clock for JTAG boundary scan. TCK must be asserted (pulsed low) after power-up or held low for proper operation of the ADSP-21266. Test Mode Select (JTAG). Used to control the test state machine. TMS has a 22.5 k ohms internal pull-up resistor. Test Data Input (JTAG). Provides serial data for the boundary scan logic. TDI has a 22.5 k ohms internal pull-up resistor. Test Data Output (JTAG). Serial scan output of the boundary scan path. Test Reset (JTAG). Resets the test state machine. TRST must be asserted (pulsed low) after power-up or held low for proper operation of the ADSP-21266. TRST has a 22.5 k ohms internal pull-up resistor. Emulation Status. Must be connected to the ADSP-21266 Analog Devices DSP Tools product line of JTAG emulators target board connector only. EMU has a 22.5 k ohms internal pull-up resistor. Core Power Supply. Nominally +1.2 V dc and supplies the DSP’s core processor (13 pins on the BGA package, 32 pins on the LQFP package). I/O Power Supply. Nominally +3.3 V dc (6 pins on the BGA package, 10 pins on the LQFP package). Analog Power Supply. Nominally +1.2 V dc and supplies the DSP’s internal PLL (clock generator). This pin has the same specifications as VDDINT, except that added filtering circuitry is required. For more information, see Power Supplies on Page 8. Analog Power Supply Return. Power Supply Return. (54 pins on the BGA package, 39 pins on the LQFP package). I O I O I/A I I/S I/S O I/A O (O/D) P P P G G CLKIN XTAL CLKCFG1–0 RSTOUT/ CLKOUT RESET TCK TMS TDI TDO TRST EMU VDDINT VDDEXT AVDD AVSS GND Pin Type Function TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-5 Q201 : ADSP-21266(32 bit, Floating-point SHARC DSP)-5/5 PIN CONFIGURATION 1 36 37 72 73 108 109 144 ADSP-21266 VDDINT CLKCFG0 CLKCFG1 BOOTCFG0 BOOTCFG1 GND VDDEXT GND VDDINT GND VDDINT GND VDDINT GND FLAG0 FLAG1 AD7 GND VDDINT GND VDDEXT GND VDDINT AD6 AD5 AD4 VDDINT GND AD3 AD2 VDDINT GND AD1 AD0 WR VDDINT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 VDDINT GND RD ALE AD15 AD14 AD13 GND VDDEXT AD12 VDDINT GND AD11 AD10 AD9 AD8 DAI_P1(SD0A) VDDINT GND DAI_P2(SD0B) DAI_P3(SCLK0) GND VDDEXT VDDINT GND DAI_P4(SFS0) DAI_P5(SD1A) DAI_P6(SD1B) DAI_P7(SCLK1) VDDINT GND VDDINT GND DAI_P8(SFS1) DAI_P9(SD2A) VDDINT 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 VDDEXT GND VDDINT GND DAI_P10(SD2B) DAI_P11(SD3A) DAI_P12(SD3B) DAI_P13(SCLK23) DAI_P14(SFS23) DAI_P15(SD4A) VDDINT GND GND DAI_P16(SD4B) DAI_P17(SD5A) DAI_P18(SD5B) DAI_P19(SCLK45) VDDINT GND GND VDDEXT DAI_P20(SFS45) GND VDDINT FLAG2 FLAG3 VDDINT GND VDDINT GND VDDINT GND VDDINT GND VDDINT VDDINT GND VDDINT GND VDDINT GND VDDINT GND VDDEXT GND VDDINT GND VDDINT RESET SPIDS GND VDDINT SPICLK MISO MOSI GND VDDINT VDDEXT AVDD AVSS GND CLKOUT EMU TDO TDI TRST TCK TMS GND CLKIN XTAL VDDEXT Pin No. Pin Name Pin No. Pin Name Pin No. Pin Name Pin No. Pin Name TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-6 Q301 : CS42516-CQZ (192 kHz, 6-Ch Codec with S/PDIF Receiver)-1/3 BLOCK DIAGRAM PIN CONFIGURATION TXP VARX AGND LPFLT DGND DGND VD VD INT RST AD0/CS AD1/CDIN SDA/CDOUT SCL/CCLK VLC OMCK RMCK SAI_LRCK SAI_SCLK SAI_SDOUT VLS ADCIN1 ADCIN2 CX_SDOUT CX_LRCK CX_SCLK CX_SDIN1 CX_SDIN2 CX_SDIN3 RXP0 RXP1/GPO1 RXP7/GPO7 RXP4/GPO4 RXP5/GPO5 RXP6/GPO6 RXP3/GPO3 RXP2/GPO2 MUTEC FILT+ VQ REFGND VA AGND AINL+ AINL- AINR+ AINR- AOUTA1+ AOUTA1- AOUTA3+ AOUTA3- AOUTB2+ AOUTB2- AOUTA2+ AOUTA2- AOUTB1+ AOUTB1- AOUTB3+ AOUTB3- DAC#1 DAC#2 DAC#3 DAC#4 DAC#5 DAC#6 Analog Filter ADC#1 ADC#2 Digital Filter Digital Filter Gain & Clip Gain & Clip DEM Digital Filter ADC Serial Data Serial Audio Interface Port Mult/Div Internal MCLK Control Port C&U Bit Data Buffer Format Detector S/PDIF Decoder Clock/Data Recovery Rx GPO MUTE Ref Volume Control CODEC Serial Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 CX_SDIN1 CX_SCLK CX_LRCK VD DGND VLC SCL/CCLK SDA/CDOUT AD1/CDIN AD0/CS INT RST AINR- AINR+ AINL+ AINL- 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 RXP1/GPO1 RXP2/GPO2 RXP3/GPO3 RXP4/GPO4 RXP5/GPO5 RXP6/GPO6 RXP7/GPO7 VARX AGND LPFLT MUTEC AOUTA1- AOUTA1+ AOUTB1+ AOUTB1- AOUTA2- CS42516 CX_SDIN2 CX_SDIN3 TEST SAI_SCLK SAI_LRCK OMCK ADCIN1 ADCIN2 CX_SDOUT RMCK SAI_SDOUT VLS DGND VD TXP RXP0 VQ FILT+ REFGND NC NC NC NC VA AGND AOUTB3- AOUTB3+ AOUTA3+ AOUTA3- AOUTB2- AOUTB2+ AOUTA2+ IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-7 Q301 : CS42516-CQZ (192 kHz, 6-Ch Codec with S/PDIF Receiver)-2/3 TERMINAL DESCRIPTION(1/2) TX-SR304/304E Pin Name # Pin Description TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-8 Q301 : CS42516-CQZ (192 kHz, 6-Ch Codec with S/PDIF Receiver)-3/3 TERMINAL DESCRIPTION(2/2) Pin Name # Pin Description TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-9 Q2021 : LA7956 (Video Switch) BLOCK DIAGRAM and PIN CONFIGURATION TERMINAL DESCRIPTION (I/O Logic) Driver Control 6dB amp. Video switch (4 input 1 output) 1 2 3 4 5 6 7 8 9 VIDEO OUT A B VIN1 GND VIN2 VCC VIN3 VIN4 S2 (2 pin) H L H L S3 (3 pin) H H L L VIN1 (4 pin) ON OFF OFF OFF VIN2 (6 pin) OFF ON OFF OFF VIN3 (8 pin) OFF OFF ON OFF VIN4 (9 pin) OFF OFF OFF ON (S2) (S3) I/O Pin I/O Logic TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-10 Q5001 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Lout REC Lch Rout Input ATT Out L for ADC REC AGND Out R for ADC Rch AVCC Multi Rin Multi Lin 3 4 5 6 7 8 9 1 2 Tone Rch Tone Bass & Lch Tone 10 11 3 4 5 6 7 8 9 1 2 10 11 SLout Multi SLin Multi SRin Cout SWout Multi Cin Multi SWin SBLout Multi SBLin Multi SBRin AVEE SUB SUB MCU I/F CLOCK DATA Bass & Volume Volume Input ATT mono SBRout SRout Volume Volume Volume Volume Volume Volume Volume Volume Input selector Input selector Volume Volume Treble Treble Treble TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-11 Q5001 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-2/3 BLOCK DIAGRAM AND PIN CONFIGURATION AGND 5-C AGND 3-C AGND 1-C CLOCK AVCC INLB/RECL2 INRB/RECR2 INR11/RECR5 INL10/RECL4 RECR3 INL11/RECL5 FLIN1 RECL3 CIN1 FRIN1 SLIN1 SWIN1 ADCL ADCR FLIN2 FRIN2 SLIN2 SRIN2 CIN2 SWIN2 SBLIN2 SBRIN2 BASSR 2 TRER BASSR 1 TREL BASSL1 BASSL2 FLOUT 6-C FLC FROUT AGND FRC DATA SBLIN1 SRIN1 SBRIN1 1-OUT (SBL OUT) DGND 2-OUT (SBR OUT) 3-OUT (C OUT) 2-C 4-OUT (SW OUT) 5-OUT (SL OUT) 4-C 6-OUT (SR OUT) INL5 INL1 INR1 INL2 INR2 INL3 INR3 INL4 INR4 INR5 INL6 INR6 INL7 INR7 INL8 INR8 INLA/RECL1 INRA/RECR1 INL9 INR9 AVEE SUBR SUBL MONO INR10/RECR4 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 64 63 62 61 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 AVCC MCU I/F MAIN SUB REC ATT 0/-6/-12/-18dB Bass/ Treble -14~+14dB (2dB step) +16~-95dB (1dBstep) +16~-95dB (1dBstep) +16~-95dB (1dBstep) +16~-95dB (1dBstep) +16~-95dB (1dBstep) +16~-95dB (1dBstep) Tone +16~0dB (1dBstep) Tone Bass/ Treble -14~+14dB (2dB step) 0~-95dB (1dBstep) +16~0dB (1dBstep) 0~-95dB, (1dBstep) TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-12 Q5001 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-3/3 TERMINAL DESCRIPTION PIN No. Name Function 42 DATA 43 CLOCK 35,34, 33,32, 31,30, 29,28 71 RECR3 23,27 21,22, 25,26 19,17, 14,12, 9,7, 4,2 FROUT,FLOUT, 6-OUT,5-OUT, 4-OUT, 3-OUT, 2-OUT,1-OUT 73,74, 75,76, 77,78, 79,80 20,16, 15,11, 10,6, 5,1 46,48,50, 52,54,56, 58,60,64 45,47,49, 51,53,55, 57,59,63 36,37 ADCL, ADCR 72 3,8, 13,18 AGND 24 AVCC 41 DGND 44 AVEE 38,39 RECL3 40 MONO 61,62, 65,66, 67,68, 69,70 Input pin of L/R/C/SW/SL/SR/SBL/SBR channel (Multi IN 1/2) Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel Input pin of monaural (Input Selector) Output pin for L/R channel SUB Output Output pin for L/R channel ADC Output pin for L/R channel REC Output Input pin of L/R channel (Input Selector)/ Output pin for L/R channel REC Output Connects capacitor for reducing click noise of L/R/C/SW/SL/SR/SBL/SBR channel volume Analog ground of internal circuit Frequency characteristic setting pin of L/R channel tone control(Treble) Frequency characteristic setting pin of L/R channel tone control(Bass) Positive power supply to internal circuit Input pin of L/R channel (Input Selector) Digital ground of internal circuit Input pin of control data Input pin of control clock Negative power supply to internal circuit FLIN1, FRIN1, CIN1,SWIN1, SLIN1,SRIN1, SBLIN1,SBRIN1 TREL, TRER FRIN2, FLIN2, SRN2,SLIN2, SWIN2,CIN2, SBRIN2,SBLIN2 INRA/RECR1,INLA/RECL1, INRB/RECR2,INLB/RECL2, INR10/RECR4,INL10/RECL4, INR11/RECR5,INL11/RECL5 FRC,FLC, 6-C,5-C, 4-C,3-C, 2-C,1-C BASSL1, BASSL2 BASSR1, BASSR2 SUBL,SUBR INL1, INL2, INL3, INL4, INL5, INL6, INL7, INL8, INL9 INR1, INR2, INR3, INR4, INR5, INR6, INR7, INR8, INR9 TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-13 Q6001 : STK413-220 (3-channel AF power amplifier)-1/2 BLOCK DIAGRAM 3 1 2 7 5 4 6 10 11 22 21 17 18 19 20 13 8 9 12 14 15 16 Comparator Comparator TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-14 Q6001 : STK413-220 (3-channel AF power amplifier)-2/2 +VH +VL -VL -VH SUB GND Ch1 OUT Ch2 OUT Ch3 OUT Ch1 IN Ch2 IN Ch3 IN -VH2 +VH2 NF1 IN NF2 IN NF3 IN 1 22 PIN CONFIGRATION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 STK-413-220A-E STK-413-220A-E TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-15 Q6002 : STK412-220 (2-channel AF power amplifier) BLOCK DIAGRAM 3 1 2 7 5 4 6 17 18 13 8 9 12 14 15 16 10 11 Comparator Comparator TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-16 Q6002 : STK412-220 (2-channel AF power amplifier) +VH +VL -VL -VH SUB GND Ch1 OUT Ch2 OUT Ch1 IN Ch2 IN -VH2 +VH2 NF1 IN NF2 IN 1 18 PIN CONFIGRATION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 STK-412-220A-E STK-412-220A TX-SR304/304E IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-17 Q7002 : M66005 (FL Tube Driver) BLOCK DIAGRAM TERMINAL DESCRIPTION These pins are used to connect to digit pins of VFD. RESET Reset input This pin is used to initialize the internal state of the M66004. CS Chip select input "L" : Communication with the MCU is possible. "H" : Any instruction from the MCU is neglected. SCK Shift clock input At the rising edge from "L" to "H", input data is shifted. SDATA Serial data input Character code or command data to display is input from MSB. XIN, XOUT Clock input Clock output This pin is used to connect a resister and a capacitor externally to set oscillation frequency. DIG00 ~ DIG15 Digit output SEG00 ~ SEG39 Segment output P0, P1 Output port (static operation) VSS GND VP Negative power supply for VFD drive. VCC1 VCC2 Positive power supply for internal logic. Positive power supply for high-pressure-resistant output port. SYMBOL PIN NAME DESCRIPTION PIN NO. 13 14 15 16 21, 20 1~12 61~64 23~31 33~59 17, 18 19 60 22 32 These pins are used to connect to segment pins of VFD. 14 15 16 CG ROM (35bit x 160) CG RAM (35bit x 16) code write data dot data write code select 12 1 DIG00 DIG11 scan pulse CS SCK SDATA 21 20 XIN XOUT 13 RESET 18 17 2 P0 P1 19 60 22 32 Vcc1 Vcc2 Vss Vp Code/ command control circuit Bank 1 : 8bit x 16 Bank 2 : 8bit x 64 Segment output circuit Segment/ Digit select/ output circuit Clock generator timing clock Display controller Serial receive circuit Display code RAM Digit output circuit 59 33 31 23 64 63 62 61 DIG12/SEG36 DIG13/SEG37 DIG14/SEG38 DIG15/SEG39 SEG00 SEG26 SEG27 SEG35 24 SEG34 TX-SR304/304E FL TUBE VIEW Q7001 : 16BT128GNYK (1G-15G) 1-1 15G 14G 13G 12G 11G 10G 9G 16G 8G 7G 6G 5G 4G 3G 2G 1G 2-1 3-1 4-1 5-1 1-2 2-2 3-2 4-2 5-2 1-3 2-3 3-3 4-3 5-3 1-4 2-4 3-4 4-4 5-4 1-5 2-5 3-5 4-5 5-5 1-6 2-6 3-6 4-6 5-6 1-7 2-7 3-7 4-7 5-7 P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 1-1 2-1 3-1 4-1 5-1 1-2 2-2 3-2 4-2 5-2 1-3 2-3 3-3 4-3 5-3 1-4 2-4 3-4 15G-1G 16G P19 P20 P21 P22 P23 P24 P25 P26 P27 P28 P29 P30 P31 P32 P33 P34 P35 4-4 5-4 1-5 2-5 3-5 4-5 5-5 1-6 2-6 3-6 4-6 5-6 1-7 2-7 3-7 4-7 5-7 15G-1G 16G TX-SR304/304E MICROPROCESSOR TERMINAL DESCRIPTIONS-1 Q701 : M30622MGP-A98FP Pin No. Pin name I/O Description 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 NU NU VCTRLA VCTRLB VMUTV1 VMUTV3 NU NU CNVSS NU NU RESET XOUT VSS XIN VCC1 NU POFF NU NU NU NU DIRINT0 DSPINT3/DIRINT1 DSPINT2 DSPINT1 DSPINT0 VMUT PLLSCL PLLSDA FTXD FRXD FCLK FBUSY ROMSDA ROMSCL NU DIRCS DIRRST DSPCS FEPM DSPRST DIGCLK DIGSDI DIGSDO FCE AMUT SPRLB NU SPRLCS --- --- O O O O --- --- --- --- --- I O --- I --- --- I --- --- --- --- I I I I I O O O O I O O I/O O --- O O O O O O I O I O O --- O --- --- H H L L --- --- --- --- --- L H --- H --- --- H --- --- --- --- H L L L L L CLK H H H CLK H H CLK --- L L L H L CLK H H H H H --- H Act. Not used. Not used. Video selector switch control output. Video selector switch control output. Video mute (video 1) control output. Video mute (component video) control output. Not used. Not used. Not used. Not used. Not used. System reset input. Crystal oscillation circuit output. Ground. Crystal oscillation circuit input. Power supply. Not used. Power failure detection input. Not used. Not used. Not used. Not used. Interrupt request signal input from DIR. Interrupt request signal input from DSP/DIR. Interrupt request signal input from DSP. Interrupt request signal input from DSP C. Interrupt request signal input from DSP. Video mute (monitor out) control output. Serial clock output to PLL. Serial data output for PLL. For writing of flash microprocessor. For writing of flash microprocessor. For writing of flash microprocessor. For writing of flash microprocessor. E2PROM IIC data input/output. E2PROM IIC clock output. Not used. Chip select signal output to DIR/CODEC. Reset signal output to DIR/CODEC. DSP C chip select signal output. For writing of flash microprocessor. Reset signal output to DSP. Serial communication clock output to DIR/CODEC/DSP. Serial communication signal input from DIR/CODEC/DSP. Serial communication signal output to DIR/CODEC/DSP. For writing of flash microprocessor. Audio mute control output. Front speaker-B relay control output. Not used. Center/Surround speaker relay control output. TX-SR304/304E MICROPROCESSOR TERMINAL DESCRIPTIONS-2 Q701 : M30622MGP-A98FP Pin No. Pin name I/O Description 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 SPRLF NU VOLDAT VOLCLK VOLSTB NU APOWER NU NU NU NU VCC2 SEC1H VSS PROTECT VOLH THERMAL INIT3 INIT2 INIT1 BAND SYSOUT SYSIN NU REMIN STEREO TUNED HPDET VOLB VOLA HPRL NU NU LEDSTBY FLDSDO FLDCLK FLDCS FLDRST KEYINT3 KEYINT2 KEYINT1 KEYINT0 KEY3 KEY2 KEY1 AVSS KEY0 VREF AVCC NU O --- O O O --- O --- --- --- --- --- O --- I I I I I I I O I --- I I I I I I O --- --- O O O O O I I I I I I I --- I --- --- --- H --- H H H --- H --- --- --- --- --- H --- H A/D A/D A/D A/D A/D A/D L H --- L L L H H H H --- --- L H CLK H L L L L L A/D A/D A/D --- A/D --- --- --- Act. Front speaker relay control output. Not used. Serial data output to volume IC. Serial clock output to volume IC. Strobe output to volume IC. Not used. Main power supply control output. Not used. Not used. Not used. Not used. Power supply. Amplifier power supply control output. Ground. Over current detection input for speaker protect. Speaker output level detection input. Thermal sensor detection input. Initial setting-3. Initial setting-2. Initial setting-1. Tuner band setting. System control (RI) signal output. System control (RI) signal input. Not used. Signal input form remote sensor. FM stereo signal detection input. Tuning signal detection input. Phones detection signal input. Data input from rotary encoder (master volume). Data input from rotary encoder (master volume). Headphone relay control output. Not used. Not used. Standby LED control output. Serial data output to FL driver. Serial clock output to FL driver. Chip select output to FL driver. Reset output to FL driver. Key input-3 (interrupt). Key input-2 (interrupt). Key input-1 (interrupt). Key input-0 (interrupt). Key input-3. Key input-2. Key input-1. Ground. Key input-0 A/D reference voltage power supply. A/D Power supply. Not used. 1/40 PAGE TX-SR304(HT-S4100) Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. (B) : Black model (S) : Silver model EXPLODED VIEW PARTS LIST REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS EV A001 RETAINER (F) 1 27141972A EV A002 SCREW 3TTB+10B(3CM) 5 838130108GR EV A003 SCREW 3TTB+8B(3CM)SR 3 801637 EV A004 SCREW 3TTB+8B(3CM)SR 1 801637 EV A005 SCREW 3TTB+10B(3CM) 7 838130108GR EV A007 SCREW 3TTB+10B(3CM) 2 838130108GR EV A008 CUSHION (DAC) 2 28141438 EV A010 CHASSIS --- 1 --- NSP EV A012 WIRE TIE BINDER(CLAMPER)UL 2 260258 EV A013 WIRE TIE BSK-1 1 260208 EV A015 HOLDER KGLS-14RT 3 27190524 EV A016 HOLDER KGPS-16RF 2 27190991 EV A020 SCREW 3TTB+8B(3CM)SR 3 801637 EV A021 SCREW 3TTB+8B(3CM)SR 2 801637 EV A022 SCREW 3TTB+8B(3CM)SR 4 801637 EV A023 SCREW 4TTC+8C(3BC) 4 830440089GR NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED. 2/40 PAGE EV A025 TAPE TAPE(CLOTH-16U) (1) 29110083 EV A026 IB CUSHION W15*3t TAPE 1 28141585 EV A028 BUSHING S-RELIEF #2271 1 27300750 ! EV A030 HEAT SINK AS 1 27160586 EV A034 SCREW 3TTB+8B(3CM)SR 2 801637 EV A035 SCREW 3TTB+8B(3CM)SR 2 801637 EV A037 SCREW 3SMS8WSW+18B3CM 4 801636 EV A040 RETAINER (TR-NEW) 1 27142081 EV A041 SCREW 3TTB+8B(3CM)SR 1 801637 EV A042 RETAINER (FR) 1 27142029 EV A043 SCREW 3TTB+8B(3CM)SR 2 801637 EV A050 COVER (Bent) 1 28184831 (B) EV A050 COVER (Bent) 1 28184906 (S) EV A050 COVER (Not bent) 1 28184831Z (B) EV A050 COVER (Not bent) 1 28184906Z (S) EV A051 SCREW 3TTB+8B(3BC) 6 838430088GR (B) EV A051 SCREW 3TTB+8B(3CM) 6 838130088GR (S) EV A052 LABEL (COVER) 1 29364123 EV A055 BOTTOM LEG --- 4 27175432B EV A056 CUSHION --- 4 28141664 EV A057 SCREW 3TTB+8B(3CM)SR 4 801637 EV A065 CLEAR PLT --- 1 28192064A (B) EV A065 CLEAR PLT --- 1 28192065A (S) EV A401 REAR PANEL TXSR304MDD 1 27123527A EV A404 SCREW 3TTB+8B(3BC) 26 838430088GR EV A405 F PANEL --- 1 27213025 (B) EV A405 F PANEL --- 1 27212862A (S) EV A406 FACET (ST) 1 28198998A EV A411 KNOB (POW) 1 28326298 (B) EV A411 KNOB (POW) 1 28326299 (S) EV A412 KNOB (SEL) 1 28326302 (B) 3/40 PAGE EV A412 KNOB (SEL) 1 28326303 (S) EV A413 KNOB (PRE) 1 28326306 EV A420 BADGE --- 1 28135244 (B) EV A420 BADGE --- 1 28135298 (S) EV A421 SCREW 3TTB+8B(3BC) 3 838430088GR EV A430 KNOB (VOL)AS 1 28326318 (B) EV A430 KNOB (VOL)AS 1 28326319 (S) EV F6001 FUSE 8A-T/UL-ST2 1 252261GR ! EV F6001C LABEL LABEL 1 29360842 EV F6002 FUSE 8A-T/UL-ST2 1 252261GR ! EV F6002C LABEL LABEL 1 29360842 EV F901 FUSE 8A-UL/T-233 1 252329GR ! EV F901 or FUSE 8A-T/UL-ST2 (1) 252261GR ! EV P101 FFC NCFC7-131012 1 2047131012 EV P7001 FFC NCFC5-292522 1 2045292522 EV Q9006A ISO SHEET AC238 1 223024 EV T901 P TRANS NPT-1514D 1 2301793 ! EV P901 AC CORD AS-UC-2 1 253368BLTK ! EV P901 or AC CORD AS-UC-2 (1) 253333VOL ! EV P901 or AC CORD AS-UC-2 (1) 253368AYUN ! EV P901 or AC CORD AS-UC-2 (1) 253368HSN ! EV U01 AMPLIFIER PC board ass'y NAAF-8745-1E 1 1B130545-1E EV U02 TRANS SEC. TERMINAL PC board ass'y NAETC-8746-1E 1 --- NSP EV U04 DSP & MICROPROCESSOR PC board ass'y NADG-8756-1E 1 1B130556-1E EV U05 DISPLAY PC board ass'y NADIS-8767-1A 1 1B130567-1A EV U06 VIDEO PC board ass'y NAVD-8768-1A 1 1B130568-1A EV U07 POWER SUPPLY PC board ass'y NAPS-8769-1A 1 1B130569-1A EV U08 SWITCH PC board ass'y NASW-8770-1A 1 1B130570-1A EV U09 HEADPNOHE JACK PC board ass'y NAETC-8771-1A 1 --- NSP EV U11 HOLDER PC board NAETC-8773-1A 1 --- NSP EV U12 TUNER UNIT ENG06507QFUS 1 240156 4/40 PAGE EV U12 or TUNER UNIT FAE385-A11US (1) 240152 TX-SR304(HT-S4100) PC BOARD PARTS LIST PCB1 U01 AMPLIFIER PC BOARD (NAAF-8745-1E) PCB1 U02 TRANS SEC. TERMINAL PC BOARD (NAETC-8746-1E) PCB1 PCB1 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB1 Q5001 IC R2S15211FP 1 22242297R3 PCB1 Q5002 IC NJM4580M-D 1 22241448R2 PCB1 Q5003 IC NJM4580M-D 1 22241448R2 PCB1 Q5200 TR RN1441 1 2215410R2 PCB1 Q5201 TR RN1441 1 2215410R2 PCB1 Q5202 TR RN1441 1 2215410R2 PCB1 Q5203 TR RN1441 1 2215410R2 PCB1 Q5204 TR RN1441 1 2215410R2 PCB1 Q5205 TR KRC283S 1 2217220R2 PCB1 Q5205 or TR RN1441 (1) 2215410R2 PCB1 Q5215 TR KRC283S 1 2217220R2 PCB1 Q5215 or TR RN1441 (1) 2215410R2 PCB1 Q6001 IC STK413-220A 1 222139 PCB1 Q6002 IC STK412-220A 1 222140 PCB1 Q6004 IC LM61CIZ 1 22242212 PCB1 Q6010 TR 2SC2240-GR 1 2211405T PCB1 Q6011 TR 2SC2240-GR 1 2211405T PCB1 Q6012 TR 2SC2240-GR 1 2211405T PCB1 Q6013 TR 2SC2240-GR 1 2211405T PCB1 Q6015 TR 2SC2240-GR 1 2211405T PCB1 Q6021 TR 2SA1163-BL(TE85L_F) 1 2216756R2 PCB1 Q6022 TR 2SC2240-GR 1 2211405T 5/40 PAGE PCB1 Q6023 TR 2SC2240-GR 1 2211405T PCB1 Q6051 TR KRC105S 1 2217290R2 PCB1 Q6051 or TR DTC123JKA (1) 2216690R2 PCB1 Q6051 or TR RN1405 (1) 2214500R2 PCB1 Q6052 TR KRC105S 1 2217290R2 PCB1 Q6052 or TR DTC123JKA (1) 2216690R2 PCB1 Q6052 or TR RN1405 (1) 2214500R2 PCB1 Q6053 TR KRC105S 1 2217290R2 PCB1 Q6053 or TR DTC123JKA (1) 2216690R2 PCB1 Q6053 or TR RN1405 (1) 2214500R2 PCB1 Q6054 TR KRC105M 1 2215830T PCB1 Q6054 or TR DTC123JS (1) 2213640T PCB1 Q6054 or TR RN1205 (1) 2214660T PCB1 Q9001 IC 7812HF(TA7812S) 1 222780124TOS PCB1 Q9001 or IC 78M12HF (1) 222780125 PCB1 Q9002 IC 79012HF(TA79012S) 1 222790124TOS PCB1 Q9002 or IC 79M12HF (1) 222790125 PCB1 Q9003 TR 2SA1930(ONK_Q) 1 2203000 PCB1 Q9006 IC AN34060A 1 22242205 PCB1 Q9501 TR 2SA970-BL(TPE2_F) 1 2211396T PCB1 Q9502 TR KRC105M 1 2215830T PCB1 Q9502 or TR DTC123JS (1) 2213640T PCB1 Q9502 or TR RN1205 (1) 2214660T PCB1 D5001 ZENER D MTZJ6.8B 1 224470682T PCB1 D5001 or ZENER D DZ-6.8BSB (1) 224850682T PCB1 D5002 ZENER D MTZJ6.8B 1 224470682T PCB1 D5002 or ZENER D DZ-6.8BSB (1) 224850682T PCB1 D5500 DIODE 1SS133(DS) 1 223280T PCB1 D5500 or DIODE 1SS133 (1) 223163T PCB1 D6001 DIODE D5SBA20 1 22380130F PCB1 D6001 or DIODE RS603M-B42 (1) 22380274F 6/40 PAGE PCB1 D6001A SCREW 3P+10FN(3BC) 1 82143010GR PCB1 D6001B HEAT SINK(S) RAD-155 1 27160486 PCB1 D6002 DIODE D5SBA20 1 22380130 PCB1 D6002 or DIODE DIODE RS603M (1) 22380274 PCB1 D6002A SCREW 3P+10FN(3BC) 1 82143010GR PCB1 D6002B HEAT SINK RAD-141 1 27160472 PCB1 D6003 ZENER D MTZJ15C 1 224471503T PCB1 D6003 or ZENER D DZ-15BSC (1) 224851503T PCB1 D6004 ZENER D MTZJ15C 1 224471503T PCB1 D6004 or ZENER D DZ-15BSC (1) 224851503T PCB1 D6005 ZENER D MTZJ15C 1 224471503T PCB1 D6005 or ZENER D DZ-15BSC (1) 224851503T PCB1 D6006 ZENER D MTZJ15C 1 224471503T PCB1 D6006 or ZENER D DZ-15BSC (1) 224851503T PCB1 D6031 DIODE 1SS133(DS) 1 223280T PCB1 D6031 or DIODE 1SS133 (1) 223163T PCB1 D6032 DIODE 1SS133(DS) 1 223280T PCB1 D6032 or DIODE 1SS133 (1) 223163T PCB1 D6033 ZENER D MTZJ5.1B 1 224470512T PCB1 D6033 or ZENER D DZ-5.1BSB (1) 224850512T PCB1 D6051 DIODE 1SS133(DS) 1 223280T PCB1 D6051 or DIODE 1SS133 (1) 223163T PCB1 D6052 DIODE 1SS133(DS) 1 223280T PCB1 D6052 or DIODE 1SS133 (1) 223163T PCB1 D6055 DIODE 1SS133(DS) 1 223280T PCB1 D6055 or DIODE 1SS133 (1) 223163T PCB1 D6056 DIODE 1SS133(DS) 1 223280T PCB1 D6056 or DIODE 1SS133 (1) 223163T PCB1 D9001 DIODE D3SBA20 1 22380271F PCB1 D9002 DIODE RL1N4003 1 22380260T PCB1 D9002 or DIODE GP104003E (1) 22380035T 7/40 PAGE PCB1 D9003 DIODE RL1N4003 1 22380260T PCB1 D9003 or DIODE GP104003E (1) 22380035T PCB1 D9004 DIODE RL1N4003 1 22380260T PCB1 D9004 or DIODE GP104003E (1) 22380035T PCB1 D9005 DIODE RL1N4003 1 22380260T PCB1 D9005 or DIODE GP104003E (1) 22380035T PCB1 D9006 DIODE RL1N4003 1 22380260T PCB1 D9006 or DIODE GP104003E (1) 22380035T PCB1 D9007 DIODE RL1N4003 1 22380260T PCB1 D9007 or DIODE GP104003E (1) 22380035T PCB1 D9008 ZENER D MTZJ36D 1 224473604T PCB1 D9008 or ZENER D DZ-36BSD (1) 224853604T PCB1 D9009 DIODE RL1N4003 1 22380260T PCB1 D9009 or DIODE GP104003E (1) 22380035T PCB1 D9013 DIODE RL1N4003 1 22380260T PCB1 D9013 or DIODE GP104003E (1) 22380035T PCB1 L6000 S COIL PB9510 1 231361 PCB1 L6001 S COIL PB9510 1 231361 PCB1 L6002 S COIL PB9510 1 231361 PCB1 L6003 S COIL PB9510 1 231361 PCB1 L6004 S COIL PB9510 1 231361 PCB1 C5003 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5004 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5011 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5012 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5015 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5016 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5019 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5020 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5027 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5028 C-CERA C CC725CH1H-221J1 1 342102214R1 8/40 PAGE PCB1 C5031 MMT C MMT50V-474J 1 375524744T PCB1 C5032 MMT C MMT50V-474J 1 375524744T PCB1 C5033 MMT C MMT50V-823J 1 375528234T PCB1 C5034 MMT C MMT50V-823J 1 375528234T PCB1 C5035 MMT C MMT50V-223J 1 375522234T PCB1 C5036 MMT C MMT50V-223J 1 375522234T PCB1 C5054 C-CERA C CK725B1H-473K1 1 332104735R1 PCB1 C5110 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5111 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5112 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5113 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5114 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5115 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5130 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5131 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5132 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5133 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5134 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5135 VX C CE04W16V 47M(VX_BLK) 1 397344707T PCB1 C5141 C-CERA C CC725CH1H-330J1 1 342103304R1 PCB1 C5142 C-CERA C CC725CH1H-330J1 1 342103304R1 PCB1 C5200 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5201 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5202 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5203 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5204 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5205 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C5206 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C5207 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C5210 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5211 VX C CE04W50V 47M(VX_BLK) 1 397384707T 9/40 PAGE PCB1 C5212 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5213 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5214 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5215 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5235 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C5245 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5255 C-CERA C CK725B1H-103K1 1 332101035R1 PCB1 C5275 C-CERA C CC725CH1H-221J1 1 342102214R1 PCB1 C5301 VX C CE04W25V-470M(VX_BLK) 1 397354717T PCB1 C5302 VX C CE04W25V-470M(VX_BLK) 1 397354717T PCB1 C6001 ELECT C CE69W56V-8200MB 1 3504416 PCB1 C6002 ELECT C CE69W56V-8200MB 1 3504416 PCB1 C6003 ELECT C CE69W35V-5600MB 1 3504443 PCB1 C6004 ELECT C CE69W35V-5600MB 1 3504443 PCB1 C6007 TF C ECQ-V50V-334J 1 374723344T PCB1 C6008 TF C ECQ-V50V-334J 1 374723344T PCB1 C6009 TF C ECQ-V50V-273J 1 374722734T PCB1 C6010 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C6011 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C6012 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C6013 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C6015 VX C CE04W25V-47M(VX_BLK) 1 397354707T PCB1 C6020 TF C ECQ-B50V-471J 1 374724714T PCB1 C6021 TF C ECQ-B50V-471J 1 374724714T PCB1 C6022 TF C ECQ-B50V-471J 1 374724714T PCB1 C6023 TF C ECQ-B50V-471J 1 374724714T PCB1 C6025 TF C ECQ-B50V-471J 1 374724714T PCB1 C6030 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C6031 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C6032 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C6033 VX C CE04W25V-220M(VX_BLK) 1 397352217T 10/40 PAGE PCB1 C6035 VX C CE04W25V-220M(VX_BLK) 1 397352217T PCB1 C6040 CERA C CC45CH50V-030D 1 345340302T PCB1 C6041 CERA C CC45CH50V-030D 1 345340302T PCB1 C6042 CERA C CC45CH50V-030D 1 345340302T PCB1 C6043 CERA C CC45CH50V-030D 1 345340302T PCB1 C6045 CERA C CC45CH50V-030D 1 345340302T PCB1 C6050 C-CERA C CK725B1H-472K1 1 332104725R1 PCB1 C6051 C-CERA C CK725B1H-472K1 1 332104725R1 PCB1 C6052 C-CERA C CK725B1H-472K1 1 332104725R1 PCB1 C6053 C-CERA C CK725B1H-472K1 1 332104725R1 PCB1 C6055 C-CERA C CK725B1H-472K1 1 332104725R1 PCB1 C6060 TF C ECQ-V50V-473J 1 374724734T PCB1 C6061 TF C ECQ-V50V-473J 1 374724734T PCB1 C6062 TF C ECQ-V50V-473J 1 374724734T PCB1 C6063 TF C ECQ-V50V-473J 1 374724734T PCB1 C6064 TF C ECQ-V50V-473J 1 374724734T PCB1 C6070 TF C ECQ-B50V-103J 1 374721034T PCB1 C6071 TF C ECQ-B50V-103J 1 374721034T PCB1 C6072 TF C ECQ-B50V-103J 1 374721034T PCB1 C6073 TF C ECQ-B50V-103J 1 374721034T PCB1 C6074 TF C ECQ-B50V-103J 1 374721034T PCB1 C6080 TF C ECQ-B50V-102J 1 374721024T PCB1 C6081 TF C ECQ-B50V-102J 1 374721024T PCB1 C6082 TF C ECQ-B50V-102J 1 374721024T PCB1 C6083 TF C ECQ-B50V-102J 1 374721024T PCB1 C6084 TF C ECQ-B50V-102J 1 374721024T PCB1 C6086 TF C ECQ-B50V-102J 1 374721024T PCB1 C6087 TF C ECQ-B50V-102J 1 374721024T PCB1 C6090 VX C CE04W25V-100M(VX_BLK) 1 397351017T PCB1 C6091 VX C CE04W50V-1M(VX_BLK) 1 397380107T PCB1 C6093 C-CERA C CK725F1E-104Z1 1 332161040R1 11/40 PAGE PCB1 C6101 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6102 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6103 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C6104 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6105 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6106 VX C CE04W50V 47M(VX_BLK) 1 397384707T PCB1 C6107 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6108 VX C CE04W63V-100M(VX_BLK) 1 397371017T PCB1 C6109 VX C CE04W50V 100M(VX_BLK) 1 397381017T PCB1 C6110 VX C CE04W50V 100M(VX_BLK) 1 397381017T PCB1 C6111 TF C ECQ-B50V-103J 1 374721034T PCB1 C6112 TF C ECQ-B50V-103J 1 374721034T PCB1 C6115 TF C ECQ-B50V-103J 1 374721034T PCB1 C6116 C-CERA C CK725B1H-103K1 1 332101035R1 PCB1 C9001 VR C CE04W16V-4700M(VR) 1 394644727S PCB1 C9002 VR C CE04W50V-22M(VR) 1 394682207T PCB1 C9003 VR C CE04W50V-22M(VR) 1 394682207T PCB1 C9004 VR C CE04W50V-22M(VR) 1 394682207T PCB1 C9005 VR C CE04W50V-22M(VR) 1 394682207T PCB1 C9010 VR C CE04W50V-10M(VR) 1 394681007T PCB1 C9011 VR C CE04W50V-10M(VR) 1 394681007T PCB1 C9012 VR C CE04W50V-10M(VR) 1 394681007T PCB1 C9013 VR C CE04W50V-10M(VR) 1 394681007T PCB1 C9051 TF C ECQ-V50V-104J 1 374721044T PCB1 C9501 VR C CE04W35V-1000M(VR) 1 394661027S PCB1 C9502 VR C CE04W35V-470M(VR) 1 394664717T PCB1 C9503 VR C CE04W50V-220M(VR) 1 394682217T PCB1 C9504 VR C CE04W63V-470M(VR) 1 394674717S PCB1 C9505 VR C CE04W50V-10M(VR) 1 394681007T PCB1 C9506 VR C CE04W50V-10M(VR) 1 394681007T PCB1 R5001 C-CARBON R RN72K1J-331JE 1 435033314R1 12/40 PAGE PCB1 R5002 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5003 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5004 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5005 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5006 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5007 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5008 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5009 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5010 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5011 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5012 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5013 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5014 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5015 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5016 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5017 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5018 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5019 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5020 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5021 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5022 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5023 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5024 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5025 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5026 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5027 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5028 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5029 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5030 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5041 C-CARBON R RN72K1J-182JE 1 435031824R1 PCB1 R5042 C-CARBON R RN72K1J-182JE 1 435031824R1 13/40 PAGE PCB1 R5100 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5101 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5102 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5103 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5104 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5105 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5110 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5111 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5112 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5113 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5114 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5115 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5141 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5142 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5143 C-CARBON R RN72K1J-122JE 1 435031224R1 PCB1 R5144 C-CARBON R RN72K1J-122JE 1 435031224R1 PCB1 R5145 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5146 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5147 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5148 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5149 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB1 R5150 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB1 R5200 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5201 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5202 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5203 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5204 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5205 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5206 CARBON R R16J-22 1 417342204T PCB1 R5207 CARBON R R16J-22 1 417342204T PCB1 R5210 C-CARBON R RN72K1J-222JE 1 435032224R1 14/40 PAGE PCB1 R5211 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB1 R5212 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB1 R5213 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB1 R5214 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB1 R5215 C-CARBON R RN72K1J-271JE 1 435032714R1 PCB1 R5216 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R5225 C-CARBON R RN72K1J-101JE 1 435031014R1 PCB1 R5235 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R5245 C-CARBON R RN72K1J-122JE 1 435031224R1 PCB1 R5255 C-CARBON R RN72K1J-153JE 1 435031534R1 PCB1 R5265 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5275 C-CARBON R RN72K1J-104JE 1 435031044R1 PCB1 R5285 C-CARBON R RN72K1J-101JE 1 435031014R1 PCB1 R5301 METAL O R RS1/2WBJ-100 1 443521014T PCB1 R5302 METAL O R RS1/2WBJ-100 1 443521014T PCB1 R5303 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5304 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R5500 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB1 R5901 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB1 R5902 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB1 R6010 CARBON R R16J-1K 1 417341024T PCB1 R6011 CARBON R R16J-1K 1 417341024T PCB1 R6012 CARBON R R16J-1K 1 417341024T PCB1 R6013 CARBON R R16J-1K 1 417341024T PCB1 R6015 CARBON R R16J-1K 1 417341024T PCB1 R6020 CARBON R R16J-56K 1 417345634T PCB1 R6021 CARBON R R16J-56K 1 417345634T PCB1 R6022 CARBON R R16J-56K 1 417345634T PCB1 R6023 CARBON R R16J-56K 1 417345634T PCB1 R6025 CARBON R R16J-56K 1 417345634T PCB1 R6030 CARBON R R16J-1.5K 1 417341524T 15/40 PAGE PCB1 R6031 CARBON R R16J-1.5K 1 417341524T PCB1 R6032 CARBON R R16J-1.5K 1 417341524T PCB1 R6033 CARBON R R16J-1.5K 1 417341524T PCB1 R6035 CARBON R R16J-1.5K 1 417341524T PCB1 R6040 CARBON R R16J-56K 1 417345634T PCB1 R6041 CARBON R R16J-56K 1 417345634T PCB1 R6042 CARBON R R16J-56K 1 417345634T PCB1 R6043 CARBON R R16J-56K 1 417345634T PCB1 R6045 CARBON R R16J-56K 1 417345634T PCB1 R6050 CARBON R R16J-1K 1 417341024T PCB1 R6051 CARBON R R16J-1K 1 417341024T PCB1 R6052 CARBON R R16J-1K 1 417341024T PCB1 R6053 CARBON R R16J-1K 1 417341024T PCB1 R6055 CARBON R R16J-1K 1 417341024T PCB1 R6060 CEMENT R RSS2WK-0.22 1 4800071 PCB1 R6060 or METAL PR MPR2W+2W 0R22 (1) 4000234 PCB1 R6060 or OTHER R RGC22-0.22 OHMK (1) 4000131 PCB1 R6060 or METAL PR MPC708-2WK-0.22 (1) 4500027 PCB1 R6061 CEMENT R RSS2WK-0.22 1 4800071 PCB1 R6061 or METAL PR MPR2W+2W 0R22 (1) 4000234 PCB1 R6061 or OTHER R RGC22-0.22 OHMK (1) 4000131 PCB1 R6061 or METAL PR MPC708-2WK-0.22 (1) 4500027 PCB1 R6062 CEMENT R RSS2WK-0.22 1 4800071 PCB1 R6062 or METAL PR MPR2W+2W 0R22 (1) 4000234 PCB1 R6062 or OTHER R RGC22-0.22 OHMK (1) 4000131 PCB1 R6062 or METAL PR MPC708-2WK-0.22 (1) 4500027 PCB1 R6063 CEMENT R RSS2WK-0.22 1 4800071 PCB1 R6063 or METAL PR MPR2W+2W 0R22 (1) 4000234 PCB1 R6063 or OTHER R RGC22-0.22 OHMK (1) 4000131 PCB1 R6063 or METAL PR MPC708-2WK-0.22 (1) 4500027 PCB1 R6065 CEMENT R RSS2WK-0.22 1 4800071 16/40 PAGE PCB1 R6065 or METAL PR MPR2W+2W 0R22 (1) 4000234 PCB1 R6065 or OTHER R RGC22-0.22 OHMK (1) 4000131 PCB1 R6065 or METAL PR MPC708-2WK-0.22 (1) 4500027 PCB1 R6070 C-CARBON R RN72K1J-223JE 1 435032234R1 PCB1 R6071 C-CARBON R RN72K1J-223JE 1 435032234R1 PCB1 R6072 C-CARBON R RN72K1J-223JE 1 435032234R1 PCB1 R6073 C-CARBON R RN72K1J-223JE 1 435032234R1 PCB1 R6075 C-CARBON R RN72K1J-223JE 1 435032234R1 PCB1 R6080 C-CARBON R RN72K1J-562JE 1 435035624R1 PCB1 R6081 C-CARBON R RN72K1J-562JE 1 435035624R1 PCB1 R6082 C-CARBON R RN72K1J-562JE 1 435035624R1 PCB1 R6083 C-CARBON R RN72K1J-562JE 1 435035624R1 PCB1 R6085 C-CARBON R RN72K1J-562JE 1 435035624R1 PCB1 R6100 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6101 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6102 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6103 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6105 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6110 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6111 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6112 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6113 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6115 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6130 CARBON R R16J-4.7 1 417340474T PCB1 R6131 CARBON R R16J-4.7 1 417340474T PCB1 R6132 CARBON R R16J-4.7 1 417340474T PCB1 R6133 CARBON R R16J-4.7 1 417340474T PCB1 R6134 CARBON R R16J-4.7 1 417340474T PCB1 R6140 METAL R RNU1WCJ-8.2 1 453630824T PCB1 R6141 METAL R RNU1WCJ-8.2 1 453630824T PCB1 R6142 METAL R RNU1WCJ-8.2 1 453630824T 17/40 PAGE PCB1 R6143 METAL R RNU1WCJ-8.2 1 453630824T PCB1 R6144 METAL R RNU1WCJ-8.2 1 453630824T PCB1 R6201 METAL O R RS1WBJ-3.3K 1 441623324F PCB1 R6202 METAL O R RS1WBJ-3.3K 1 441623324F PCB1 R6203 CARBON R R16J-33K 1 417343334T PCB1 R6204 METAL O R RS1WBJ-100 1 441621014F PCB1 R6205 METAL O R RS1WBJ-100 1 441621014F PCB1 R6206 METAL O R RS1WBJ-3.3K 1 441623324F PCB1 R6207 METAL O R RS1WBJ-3.3K 1 441623324F PCB1 R6208 CARBON R R16J-33K 1 417343334T PCB1 R6209 METAL O R RS1WBJ-100 1 441621014F PCB1 R6210 METAL O R RS1WBJ-100 1 441621014F PCB1 R6211 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB1 R6213 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB1 R6214 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R6216 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R6251 METAL O R RS1/2WBJ-390 1 443523914T PCB1 R6252 METAL O R RS1/2WBJ-390 1 443523914T PCB1 R6301 METAL O R RS1/2WBJ-56 1 443525604T PCB1 R6302 METAL O R RS1/2WBJ-27 1 443522704T PCB1 R6501 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R6502 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB1 R6905 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB1 R9001 METAL R RNU1WCJ-6.8 1 453630684T ! PCB1 R9002 METAL O R RS1WBJ-56 1 441625604F ! PCB1 R9003 METAL O R RS2WBJ-12 1 441721204F ! PCB1 R9004 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R9005 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB1 R9006 METAL O R RS2WBJ-220 1 441722214F PCB1 R9007 METAL O R RS2WBJ-220 1 441722214F PCB1 R9008 METAL O R RS2WBJ-270 1 441722714F 18/40 PAGE PCB1 R9009 METAL R RNU1/2WCJ-15 1 453531504T PCB1 R9011 METAL R RNU1/2WCJ-0.22 1 453532294T PCB1 R9012 METAL O R RS2WBJ-220 1 441722214F PCB1 R9013 METAL O R RS2WBJ-220 1 441722214F PCB1 R9015 METAL R RNU1/2WCJ-4.7 1 453530474T PCB1 R9051 METAL R RNU1/2WCJ-0.22 1 453532294T ! PCB1 R9052 METAL R RNU1WCJ-1 1 453630104T ! PCB1 R9053 METAL R RNU1WCJ-1 1 453630104T ! PCB1 R9054 METAL R RNU1/2WCJ-8.2 1 453530824T ! PCB1 R9501 METAL O R RS1/2WBJ-22 1 443522204T ! PCB1 R9502 CARBON R R16J-330K 1 417343344T PCB1 R9505 CARBON R R16J-2.2K 1 417342224T PCB1 RL6001 RELAY NRL-2P5A-DC24-158 1 25065618 PCB1 RL6001 or RELAY NRL-2P5A-DC24-129 (1) 25065563A PCB1 RL6002 RELAY NRL-2P5A-DC24-158 1 25065618 PCB1 RL6002 or RELAY NRL-2P5A-DC24-129 (1) 25065563A PCB1 RL6003 RELAY NRL-2P5A-DC24-158 1 25065618 PCB1 RL6003 or RELAY NRL-2P5A-DC24-129 (1) 25065563A PCB1 RL6005 RELAY NRL-2P5A-DC24-158 1 25065618 PCB1 RL6005 or RELAY NRL-2P5A-DC24-129 (1) 25065563A PCB1 RL6006 RELAY NRL-2P5A-DC24-095 1 25065510 PCB1 P301 PLUG NPLG-6P0961 1 25056011 PCB1 P302 PLUG NPLG-20P0975 1 25056025 PCB1 P303 PLUG NPLG-20P0975 1 25056025 PCB1 P5001 TRM(SCREW) NEJITANSI M3 1 25065425 PCB1 P5002 PIN JACK NPJ-6PDWWWRRR561 1 25045779 PCB1 P5002 or PIN JACK NPJ-6PDBL159 (1) 25045300 PCB1 P5003 PIN JACK NPJ-4PDWWRR624 1 25045845 PCB1 P5003 or PIN JACK NPJ-4PDBL162 (1) 25045303 PCB1 P5004 PIN JACK NPJ-4PDWWRR624 1 25045845 PCB1 P5004 or PIN JACK NPJ-4PDBL162 (1) 25045303 19/40 PAGE PCB1 P5005 PIN JACK NPJ-6PDWLGREP562 1 25045780 PCB1 P5005 or PIN JACK NPJ-6PWRLGGP493 (1) 25045697 PCB1 P5006 PIN JACK NPJ-1PDP555 1 25045773 PCB1 P5006 or PIN JACK NPJ-1PDP510 (1) 25045720 PCB1 P5500 ST JACK LGY2502-0200FC 1 25045696 PCB1 P6001 TRM NTM-10PDML363 1 25060434 PCB1 P6001 or TRM NTM-10PDML354 (1) 25060425 PCB1 P6002 TRM NTM-4PDML364 1 25060435 PCB1 P6002 or TRM NTM-4PDML357 (1) 25060428 PCB1 P6005 BUS BAR BBL30 1 27141791 PCB1 P6006 CRIMP AS CRIMP AS 1 20799165UL PCB1 P6500 WS CLAMP CB-71683(L=50) 1 260261 PCB1 P6501 WS CLAMP CB-71683(L=50) 1 260261 PCB1 E6001 RETAINER MET37-0002 1 27142009T PCB1 F6001A FUSE HOL NSCT-1P2031 1 25052133T ! PCB1 F6001B FUSE HOL NSCT-1P2031 1 25052133T ! PCB1 F6002A FUSE HOL NSCT-1P2031 1 25052133T ! PCB1 F6002B FUSE HOL NSCT-1P2031 1 25052133T ! PCB1 JL6001 JUMPER LEAD JL6 200 H 1 --- NSP PCB1 JL6001A WIRE HOL NSCT-6P897 1 25051110 PCB1 JL6001B WIRE HOL NSCT-6P897 1 25051110 PCB1 JL9001 JUMPER LEAD JL8 200 H 1 --- NSP PCB1 JL9001A WIRE HOL NSCT-8P899 1 25051112 PCB1 JL9001B WIRE HOL NSCT-8P899 1 25051112 PCB1 JL9002 JUMPER LEAD JL7 200 H 1 --- NSP PCB1 JL9002A WIRE HOL NSCT-7P898 1 25051111 PCB1 JL9002B WIRE HOL NSCT-7P898 1 25051111 PCB1 JL9003 JUMPER LEAD JL5 150 H 1 --- NSP PCB1 JL9003A WIRE HOL NSCT-5P896 1 25051109 PCB2 U04 DSP & MICROPROCESSOR PC BOARD (NADG-8756-1E) 20/40 PAGE PCB2 PCB2 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB2 U131 PHT CP GP1FAV51RK0F 1 24120129 PCB2 U131 or PHT CP JSR1165-001recieving (1) 24120143 PCB2 U132 PHT CP GP1FAV51RK0F 1 24120129 PCB2 U132 or PHT CP JSR1165-001recieving (1) 24120143 PCB2 Q101 TR 2SC1815-GR 1 2211255T PCB2 Q191 IC BD7820 1 22242300R2 PCB2 Q201 IC ADSP-21266SKSTZ-1C-1113 1 22242301R3 PCB2 Q271 IC TC74VHC541FT 1 22274541ER2TO PCB2 Q271 or IC SN74AHC541PWR (1) 22274541IR2TI PCB2 Q271 or IC TC74VHC541FT(EKJ) (1) 22274541E1R2TO PCB2 Q272 IC TC74HCT7007AF(EL_F) 1 222740077R2TO PCB2 Q301 IC CS42516-CQZ(R)-D 1 22242294R2 PCB2 Q401 IC NJM4580M-D 1 22241448R2 PCB2 Q402 IC NJM4580M-D 1 22241448R2 PCB2 Q403 IC NJM4580M-D 1 22241448R2 PCB2 Q701 IC (MICROPROCESSOR) M30622MGP-395FP 1 22242461R3 PCB2 Q702 IC S-812C50AUA-C3E 1 22242240R2 PCB2 Q705 TR KRC104S 1 2216210R2 PCB2 Q705 or TR RN1404 (1) 2214490R2 PCB2 Q712 TR KRC104S 1 2216210R2 PCB2 Q712 or TR RN1404 (1) 2214490R2 PCB2 Q728 TR KRC104S 1 2216210R2 PCB2 Q728 or TR RN1404 (1) 2214490R2 PCB2 Q735 IC S-24CS16A0I-J8V1G 1 22242326R2 PCB2 Q747 TR KRC104S 1 2216210R2 PCB2 Q747 or TR RN1404 (1) 2214490R2 PCB2 Q748 TR KRA102S 1 2216220R2 PCB2 Q748 or TR RN2402 (1) 2214530R2 PCB2 Q772 TR KRA102S 1 2216220R2 21/40 PAGE PCB2 Q772 or TR RN2402 (1) 2214530R2 PCB2 D101 ZENER D UDZS10B 1 224551000R2 PCB2 D712 C-DIODE KDS4148U 1 223283R2 PCB2 D712 or C-DIODE 1SS352 (1) 223234R2 PCB2 D712 or C-DIODE MA2J111 (1) 223279R2 PCB2 D712 or C-DIODE 1SS355 (1) 223269R2 PCB2 D718 C-DIODE KDS4148U 1 223283R2 PCB2 D718 or C-DIODE 1SS352 (1) 223234R2 PCB2 D718 or C-DIODE MA2J111 (1) 223279R2 PCB2 D718 or C-DIODE 1SS355 (1) 223269R2 PCB2 D747 C-DIODE KDS4148U 1 223283R2 PCB2 D747 or C-DIODE 1SS352 (1) 223234R2 PCB2 D747 or C-DIODE MA2J111 (1) 223279R2 PCB2 D747 or C-DIODE 1SS355 (1) 223269R2 PCB2 D772 C-DIODE KDS4148U 1 223283R2 PCB2 D772 or C-DIODE 1SS352 (1) 223234R2 PCB2 D772 or C-DIODE MA2J111 (1) 223279R2 PCB2 D772 or C-DIODE 1SS355 (1) 223269R2 PCB2 D773 ZENER D UDZS5.1B 1 224550510R2 PCB2 X201 CRYSTAL HC-49US24.576MHz 1 3010423T PCB2 X201 or CRYSTAL HC-49/U03-24.576M (1) 3010314T PCB2 X701 CERA LOCK CSTCR6M0055-R0 1 3010397R2 PCB2 L131 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L201 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L202 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L231 EMIFIL BK1608LM182-T 1 230958R1 PCB2 L301 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L302 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L303 CHOKE COIL BLM21PG221SN1 1 230949R2 PCB2 L305 EMIFIL BK1608LM182-T 1 230958R1 PCB2 L306 EMIFIL BK1608LM182-T 1 230958R1 22/40 PAGE PCB2 L311 EMIFIL BK1608LM182-T 1 230958R1 PCB2 L701 CHOKE COIL NCH-1479 1 231237K470R2 PCB2 C101 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C103 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C104 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C131 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C132 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C133 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C191 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C192 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C204 VR C CE04W6.3V-220M(VR) 1 394622217T PCB2 C209 C-CERA C CC725CH1H-120J1 1 342101204R1 PCB2 C210 C-CERA C CC725CH1H-120J1 1 342101204R1 PCB2 C211 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C212 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C213 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C214 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C215 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C217 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C218 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C219 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C220 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C223 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C224 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C227 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C228 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C230 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C231 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C232 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C235 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C236 C-CERA C CK725F1E-104Z1 1 332161040R1 23/40 PAGE PCB2 C238 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C239 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C241 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C242 C-CERA C CK725F1H-103Z1 1 332151030R1 PCB2 C243 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C244 C-CERA C CC725CH1H-101J1 1 342101014R1 PCB2 C271 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C272 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C301 VR C CE04W6.3V-470M(VR) 1 394624717T PCB2 C302 VR C CE04W6.3V-470M(VR) 1 394624717T PCB2 C303 VR C CE04W6.3V-470M(VR) 1 394624717T PCB2 C304 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C305 VX C CE04W10V-100M(VX_BLK) 1 397331017T PCB2 C306 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C307 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C308 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C310 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C311 C-CERA C CK725B1H-222K1 1 332102225R1 PCB2 C312 C-CERA C CK725B1H-473K1 1 332104735R1 PCB2 C313 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C321 C-CERA C CC725CH1H-330J1 1 342103304R1 PCB2 C322 C-CERA C CC725CH1H-330J1 1 342103304R1 PCB2 C323 C-CERA C CC725CH1H-330J1 1 342103304R1 PCB2 C333 VX C CE04W50V-22M(VX_BLK) 1 397382207T PCB2 C334 VX C CE04W50V-22M(VX_BLK) 1 397382207T PCB2 C335 VX C CE04W50V-22M(VX_BLK) 1 397382207T PCB2 C336 VX C CE04W50V-22M(VX_BLK) 1 397382207T PCB2 C337 TF C ECQ-B50V-222J 1 374722224T PCB2 C338 TF C ECQ-B50V-222J 1 374722224T PCB2 C401 TF C ECQ-B50V-472J 1 374724724T PCB2 C402 TF C ECQ-B50V-472J 1 374724724T 24/40 PAGE PCB2 C403 TF C ECQ-B50V-472J 1 374724724T PCB2 C404 TF C ECQ-V50V-333J 1 374723334T PCB2 C405 TF C ECQ-B50V-472J 1 374724724T PCB2 C406 TF C ECQ-B50V-472J 1 374724724T PCB2 C411 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C412 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C413 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C414 TF C ECQ-B50V-153J 1 374721534T PCB2 C415 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C416 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C421 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C422 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C423 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C424 TF C ECQ-B50V-103J 1 374721034T PCB2 C425 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C426 C-CERA C CC725CH1H-681J1 1 342106814R1 PCB2 C451 VR C CE04W16V-220M(VR) 1 394642217T PCB2 C452 VR C CE04W16V-220M(VR) 1 394642217T PCB2 C702 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C703 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C704 VR C CE04W16V-100M(VR) 1 394641017T PCB2 C712 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C713 VR C CE04W50V-4.7M(VR) 1 394680477T PCB2 C716 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C718 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C729 C-CERA C CC725CH1H-101J1 1 342101014R1 PCB2 C730 C-CERA C CC725CH1H-101J1 1 342101014R1 PCB2 C735 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C748 VR C CE04W50V-1M(VR) 1 394680107T PCB2 C749 C-CERA C CK732B1C-474K 1 337394745R1 PCB2 C750 C-CERA C CK732B1C-474K 1 337394745R1 25/40 PAGE PCB2 C762 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C767 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 C778 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C793 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C794 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C795 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C797 C-CERA C CK725B1H-102K1 1 332101025R1 PCB2 C798 C-CERA C CK725F1E-104Z1 1 332161040R1 PCB2 R101 C-CARBON R RN72K1J-331JE 1 435033314R1 PCB2 R131 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R132 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R191 C-CARBON R RN72K1J-393JE 1 435033934R1 PCB2 R192 C-CARBON R RN72K1J-393JE 1 435033934R1 PCB2 R193 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB2 R194 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R201 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R203 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R205 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R207 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R209 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R210 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R211 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R212 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R213 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R214 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R221 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R222 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R223 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R224 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R225 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R226 C-CARBON R RN72K1J-103JE 1 435031034R1 26/40 PAGE PCB2 R231 C-CARBON R RN72K1J-560JE 1 435035604R1 PCB2 R251 C-CARBON R RN72K1J-105JE 1 435031054R1 PCB2 R301 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R302 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R303 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R304 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R305 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R306 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R307 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R308 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R309 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R310 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R311 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R312 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R313 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R314 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R315 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R316 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R317 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R318 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R321 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R322 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R323 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R325 C-CARBON R RN72K1J-272JE 1 435032724R1 PCB2 R335 C-CARBON R RN72K1J-560JE 1 435035604R1 PCB2 R336 C-CARBON R RN72K1J-560JE 1 435035604R1 PCB2 R337 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R338 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R339 C-CARBON R RN72K1J-392JE 1 435033924R1 PCB2 R340 C-CARBON R RN72K1J-392JE 1 435033924R1 PCB2 R341 C-CARBON R RN72K1J-000JE 1 435030004R1 27/40 PAGE PCB2 R342 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R401 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R402 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R403 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R404 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R405 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R406 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R407 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R408 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R409 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R410 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R411 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R412 C-CARBON R RN72K1J-332JE 1 435033324R1 PCB2 R413 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R414 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R415 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R416 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R417 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R418 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R419 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R420 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R421 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R422 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R423 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R424 C-CARBON R RN72K1J-471JE 1 435034714R1 PCB2 R425 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R426 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R427 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R428 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R429 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R430 C-CARBON R RN72K1J-472JE 1 435034724R1 28/40 PAGE PCB2 R431 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R432 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R433 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R434 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R435 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R436 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R437 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R438 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R439 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R440 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R441 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R442 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R443 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R444 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R445 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R446 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R447 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R448 C-CARBON R RN72K1J-181JE 1 435031814R1 PCB2 R451 C-CARBON R RN72K1J-047JE 1 435030474R1 PCB2 R452 C-CARBON R RN72K1J-047JE 1 435030474R1 PCB2 R609 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R610 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R612 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB2 R617 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R618 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB2 R620 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R629 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB2 R630 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB2 R631 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R632 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R635 C-CARBON R RN72K1J-222JE 1 435032224R1 29/40 PAGE PCB2 R636 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB2 R646 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R647 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R666 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R668 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R669 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R670 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R671 C-CARBON R RN72K1J-333JE 1 435033334R1 PCB2 R673 C-CARBON R RN72K1J-224JE 1 435032244R1 PCB2 R676 C-CARBON R RN72K1J-273JE 1 435032734R1 PCB2 R677 C-CARBON R RN72K1J-273JE 1 435032734R1 PCB2 R678 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R693 C-CARBON R RN72K1J-272JE 1 435032724R1 PCB2 R694 C-CARBON R RN72K1J-272JE 1 435032724R1 PCB2 R695 C-CARBON R RN72K1J-272JE 1 435032724R1 PCB2 R696 C-CARBON R RN72K1J-272JE 1 435032724R1 PCB2 R703 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R704 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R718 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R723 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R727 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R729 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R730 C-CARBON R RN72K1J-000JE 1 435030004R1 PCB2 R731 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R732 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R733 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R734 C-CARBON R RN72K1J-330JE 1 435033304R1 PCB2 R735 C-CARBON R RN72K1J-101JE 1 435031014R1 PCB2 R736 C-CARBON R RN72K1J-101JE 1 435031014R1 PCB2 R738 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R739 C-CARBON R RN72K1J-221JE 1 435032214R1 30/40 PAGE PCB2 R740 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R741 C-CARBON R RN72K1J-103JE 1 435031034R1 PCB2 R742 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R743 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R744 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R745 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R747 C-CARBON R RN72K1J-222JE 1 435032224R1 PCB2 R748 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R749 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R750 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R751 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R753 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R754 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R765 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R767 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R771 C-CARBON R RN72K1J-563JE 1 435035634R1 PCB2 R773 C-CARBON R RN72K1J-473JE 1 435034734R1 PCB2 R775 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R776 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R777 C-CARBON R RN72K1J-221JE 1 435032214R1 PCB2 R778 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R779 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R780 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R781 C-CARBON R RN72K1J-102JE 1 435031024R1 PCB2 R789 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R790 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R791 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R792 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R793 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R794 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 R795 C-CARBON R RN72K1J-472JE 1 435034724R1 31/40 PAGE PCB2 R797 C-CARBON R RN72K1J-472JE 1 435034724R1 PCB2 P101A SOCKET NSCT-13P2106 1 25052209 PCB2 P301A SOCKET NSCT-6P2186 1 25052289 PCB2 P302A SOCKET NSCT-20P2200 1 25052303 PCB2 P303A SOCKET NSCT-20P2200 1 25052303 PCB2 P2011 PLUG NPLG-11P0966 1 25056016 PCB2 P7001A SOCKET NSCT-29P2263 1 25052366 PCB2 P7001A or SOCKET NSCT-29P2447 (1) 25052550 PCB3 U05 DISPLAY PC BOARD (NADIS-8767-1A) PCB3 U06 VIDEO PC BOARD (NAVD-8768-1A) PCB3 U07 POWER SUPPLY PC BOARD (NAPS-8769-1A) PCB3 U08 SWITCH PC BOARD (NASW-8770-1A) PCB3 U09 HEADPHONE JACK PC BOARD (NAETC-8771-1A) PCB3 PCB3 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB3 U7212 REMO SENS NJL34H380A 1 241365 PCB3 Q1001 IC TC74HCU04AP 1 222740046TOS PCB3 Q2001 TR RN1241-A(TPE4_F) 1 2213631T PCB3 Q2001 or TR RN1241-B (1) 2213632T PCB3 Q2002 TR RN1241-A(TPE4_F) 1 2213631T PCB3 Q2002 or TR RN1241-B (1) 2213632T PCB3 Q2003 TR KRA102M 1 2215770T PCB3 Q2003 or TR DTA114ES (1) 2213510T PCB3 Q2004 TR KRA102M 1 2215770T PCB3 Q2004 or TR DTA114ES (1) 2213510T PCB3 Q2005 TR KTA1267-GR 1 2215995T PCB3 Q2005 or TR 2SA933S-R (1) 2213354T PCB3 Q2005 or TR 2SA933S-S (1) 2213355T PCB3 Q2021 IC LA7956-E 1 22241759 PCB3 Q2121 IC NJM2585L 1 22242243 32/40 PAGE PCB3 Q2122 TR 2SC1815-GR 1 2211255T PCB3 Q7001 FL TUBE 16-BT-128GNYK 1 212258A PCB3 Q7001A HOLDER (FL) 1 27191222C PCB3 Q7002 IC M66005-0001AHP 1 22242208R3 PCB3 Q7003 TR 2SC2458-GR 1 2212115T PCB3 Q7003 or TR KTC3199-GR (1) 2215864T PCB3 Q7003 or TR 2SC1740S-R (1) 2213284T PCB3 Q7003 or TR 2SC1740S-S (1) 2213285T PCB3 D921 DIODE 1SS133(DS) 1 223280T PCB3 D921 or DIODE 1SS133 (1) 223163T PCB3 D922 DIODE 1SS133(DS) 1 223280T PCB3 D922 or DIODE 1SS133 (1) 223163T PCB3 D923 DIODE 1SS133(DS) 1 223280T PCB3 D923 or DIODE 1SS133 (1) 223163T PCB3 D924 DIODE 1SS133(DS) 1 223280T PCB3 D924 or DIODE 1SS133 (1) 223163T PCB3 D925 DIODE 1SS133(DS) 1 223280T PCB3 D925 or DIODE 1SS133 (1) 223163T PCB3 D930 DIODE 1SS133(DS) 1 223280T PCB3 D930 or DIODE 1SS133 (1) 223163T PCB3 D931 DIODE 1SS133(DS) 1 223280T PCB3 D931 or DIODE 1SS133 (1) 223163T PCB3 D932 DIODE 1SS133(DS) 1 223280T PCB3 D932 or DIODE 1SS133 (1) 223163T PCB3 D933 DIODE 1SS133(DS) 1 223280T PCB3 D933 or DIODE 1SS133 (1) 223163T PCB3 D934 ZENER D MTZJ5.1B 1 224470512T PCB3 D934 or ZENER D DZ-5.1BSB (1) 224850512T PCB3 D935 DIODE 1SS133(DS) 1 223280T PCB3 D935 or DIODE 1SS133 (1) 223163T PCB3 D951 DIODE 1SS133(DS) 1 223280T 33/40 PAGE PCB3 D951 or DIODE 1SS133 (1) 223163T PCB3 D952 DIODE 1SS133(DS) 1 223280T PCB3 D952 or DIODE 1SS133 (1) 223163T PCB3 D2001 DIODE 1SS133(DS) 1 223280T PCB3 D2001 or DIODE 1SS133 (1) 223163T PCB3 D2002 DIODE 1SS133(DS) 1 223280T PCB3 D2002 or DIODE 1SS133 (1) 223163T PCB3 D2121 ZENER D MTZJ9.1C 1 224470913T PCB3 D2121 or ZENER D DZ-9.1BSC (1) 224850913T PCB3 D7011 ZENER D MTZJ8.2C 1 224470823T PCB3 D7011 or ZENER D DZ-8.2BSC (1) 224850823T PCB3 D7201 LED SLI-343URC-TE7 1 225449T PCB3 T902 P TRANS NPT-1520JQ 1 2301812A ! PCB3 L1001 CHOKE COIL NCH-1452 022M 1 233454M022T PCB3 L1001 or CHOKE COIL NCH-1561 022K (1) 233526K022T PCB3 L1011 CHOKE COIL NCH-1452 220K 1 233454K220T PCB3 L1011 or CHOKE COIL NCH-1561 220K (1) 233526K220T PCB3 L7011 CHOKE COIL NCH-1452 220K 1 233454K220T PCB3 L7011 or CHOKE COIL NCH-1561 220K (1) 233526K220T PCB3 L7012 CHOKE COIL NCH-1452 220K 1 233454K220T PCB3 L7012 or CHOKE COIL NCH-1561 220K (1) 233526K220T PCB3 L7501 CHOKE COIL NCH-1452 022M 1 233454M022T PCB3 L7501 or CHOKE COIL NCH-1561 022K (1) 233526K022T PCB3 L7502 CHOKE COIL NCH-1452 022M 1 233454M022T PCB3 L7502 or CHOKE COIL NCH-1561 022K (1) 233526K022T PCB3 L7503 CHOKE COIL NCH-1452 022M 1 233454M022T PCB3 L7503 or CHOKE COIL NCH-1561 022K (1) 233526K022T PCB3 C901 IS C LE103-C3.5 1 3800042S ! PCB3 C901 or IS C RE275V-103M (1) 3500196S ! PCB3 C902 CERA C CK45F50V-103Z 1 335621030T PCB3 C922 VR C CE04W16V-2200M(VR) 1 394642227S 34/40 PAGE PCB3 C930 VR C CE04W35V-33M(VR) 1 394663307T PCB3 C933 VR C CE04W50V-4.7M(VR) 1 394680477T PCB3 C951 CERA C CC45SL50V-101J 1 345021014T PCB3 C1001 CERA C CK45F50V-223Z 1 335622230T PCB3 C1002 CERA C CC45SL50V-101J 1 345021014T PCB3 C1003 TF C ECQ-B50V-103J 1 374721034T PCB3 C1004 CERA C CC45SL50V-080D 1 345020802T PCB3 C1011 VR C CE04W6.3V-220M(VR) 1 394622217T PCB3 C1012 CERA C CK45F50V-223Z 1 335622230T PCB3 C2001 CERA C CK45B50V-102K 1 335321025T PCB3 C2002 CERA C CK45B50V-102K 1 335321025T PCB3 C2011 VR C CE04W16V-470M(VR) 1 394644717T PCB3 C2012 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2013 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2014 VR C CE04W16V-470M(VR) 1 394644717T PCB3 C2015 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2016 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2021 VR C CE04W35V-47M(VR) 1 394664707T PCB3 C2022 CERA C CK45F50V-223Z 1 335622230T PCB3 C2101 CERA C CK45B50V-102K 1 335321025T PCB3 C2102 CERA C CK45B50V-102K 1 335321025T PCB3 C2111 VR C CE04W6.3V-470M(VR) 1 394624717T PCB3 C2112 VR C CE04W6.3V-470M(VR) 1 394624717T PCB3 C2113 VR C CE04W6.3V-470M(VR) 1 394624717T PCB3 C2114 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2115 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2116 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2117 VR C CE04W50V-2.2M(VR) 1 394680227T PCB3 C2118 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2119 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2120 VR C CE04W50V-2.2M(VR) 1 394680227T 35/40 PAGE PCB3 C2121 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2122 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C2123 VR C CE04W35V-47M(VR) 1 394664707T PCB3 C2124 VR C CE04W16V-100M(VR) 1 394641017T PCB3 C2125 CERA C CK45F50V-223Z 1 335622230T PCB3 C7001 VR C CE04W16V-100M(VR) 1 394641017T PCB3 C7002 MMT C MMT50V-104J 1 375521044T PCB3 C7003 VR C CE04W50V-1M(VR) 1 394680107T PCB3 C7004 CERA C CC45SL50V-101J 1 345021014T PCB3 C7005 CERA C CC45SL50V-101J 1 345021014T PCB3 C7006 CERA C CC45SL50V-101J 1 345021014T PCB3 C7007 CERA C CC45SL50V-101J 1 345021014T PCB3 C7008 CERA C CC45SL50V-101J 1 345021014T PCB3 C7009 CERA C CK45F50V-223Z 1 335622230T PCB3 C7010 VR C CE04W50V-220M(VR) 1 394682217T PCB3 C7011 CERA C CK45F50V-223Z 1 335622230T PCB3 C7012 CERA C CK45F50V-223Z 1 335622230T PCB3 C7013 CERA C CK45F50V-223Z 1 335622230T PCB3 C7014 CERA C CK45F50V-223Z 1 335622230T PCB3 C7016 VR C CE04W50V-220M(VR) 1 394682217T PCB3 C7051 MMT C MMT50V-104J 1 375521044T PCB3 C7052 MMT C MMT50V-104J 1 375521044T PCB3 C7053 MMT C MMT50V-104J 1 375521044T PCB3 C7211 VR C CE04W16V-100M(VR) 1 394641017T PCB3 C7213 CERA C CK45B50V-102K 1 335321025T PCB3 C7401 CERA C CK45F50V-103Z 1 335621030T PCB3 C7402 CERA C CK45F50V-103Z 1 335621030T PCB3 C7501 CERA C CK45B50V-102K 1 335321025T PCB3 C7502 CERA C CK45B50V-102K 1 335321025T PCB3 C7503 CERA C CK45B50V-102K 1 335321025T PCB3 C7504 CERA C CK45B50V-102K 1 335321025T 36/40 PAGE PCB3 R901 METAL O R RS1/2WBJ-56 1 443525604T PCB3 R934 CARBON R R16J-100K 1 417341044T PCB3 R1001 CARBON R R16J-75 1 417347504T PCB3 R1002 CARBON R R16J-10 1 417341004T PCB3 R1003 CARBON R R16J-100K 1 417341044T PCB3 R1004 CARBON R R16J-10K 1 417341034T PCB3 R2001 CARBON R R16J-100K 1 417341044T PCB3 R2002 CARBON R R16J-75 1 417347504T PCB3 R2003 CARBON R R16J-75 1 417347504T PCB3 R2004 CARBON R R16J-75 1 417347504T PCB3 R2005 CARBON R R16J-75 1 417347504T PCB3 R2006 CARBON R R16J-75 1 417347504T PCB3 R2007 CARBON R R16J-75 1 417347504T PCB3 R2008 CARBON R R16J-680K 1 417346844T PCB3 R2009 CARBON R R16J-680K 1 417346844T PCB3 R2010 CARBON R R16J-680K 1 417346844T PCB3 R2011 CARBON R R16J-680K 1 417346844T PCB3 R2012 CARBON R R16J-100K 1 417341044T PCB3 R2013 CARBON R R16J-100K 1 417341044T PCB3 R2014 CARBON R R16J-220 1 417342214T PCB3 R2101 CARBON R R16J-100K 1 417341044T PCB3 R2102 CARBON R R16J-100K 1 417341044T PCB3 R2103 CARBON R R16J-100K 1 417341044T PCB3 R2104 CARBON R R16J-75 1 417347504T PCB3 R2105 CARBON R R16J-75 1 417347504T PCB3 R2106 CARBON R R16J-75 1 417347504T PCB3 R2107 CARBON R R16J-75 1 417347504T PCB3 R2108 CARBON R R16J-75 1 417347504T PCB3 R2109 CARBON R R16J-75 1 417347504T PCB3 R2110 CARBON R R16J-75 1 417347504T PCB3 R2111 CARBON R R16J-75 1 417347504T 37/40 PAGE PCB3 R2112 CARBON R R16J-75 1 417347504T PCB3 R2114 CARBON R R16J-75 1 417347504T PCB3 R2115 CARBON R R16J-75 1 417347504T PCB3 R2116 CARBON R R16J-75 1 417347504T PCB3 R2121 CARBON R R16J-56 1 417345604T PCB3 R2123 CARBON R R16J-560 1 417345614T PCB3 R7001 CARBON R R16J-100K 1 417341044T PCB3 R7004 CARBON R R16J-27K 1 417342734T PCB3 R7005 CARBON R R16J-3.3K 1 417343324T PCB3 R7006 CARBON R R16J-3.3K 1 417343324T PCB3 R7007 CARBON R R16J-220 1 417342214T PCB3 R7008 CARBON R R16J-220 1 417342214T PCB3 R7011 CARBON R R16J-220 1 417342214T PCB3 R7012 CARBON R R16J-220 1 417342214T PCB3 R7013 CARBON R R16J-100 1 417341014T PCB3 R7201 CARBON R R16J-2.2K 1 417342224T PCB3 R7211 CARBON R R16J-100 1 417341014T PCB3 R7212 CARBON R R16J-1.2K 1 417341224T PCB3 R7301 CARBON R R16J-330 1 417343314T PCB3 R7302 CARBON R R16J-470 1 417344714T PCB3 R7303 CARBON R R16J-560 1 417345614T PCB3 R7311 CARBON R R16J-330 1 417343314T PCB3 R7312 CARBON R R16J-470 1 417344714T PCB3 R7313 CARBON R R16J-560 1 417345614T PCB3 R7314 CARBON R R16J-820 1 417348214T PCB3 R7315 CARBON R R16J-1.2K 1 417341224T PCB3 R7316 CARBON R R16J-2.2K 1 417342224T PCB3 R7317 CARBON R R16J-3.9K 1 417343924T PCB3 R7321 CARBON R R16J-330 1 417343314T PCB3 R7322 CARBON R R16J-470 1 417344714T PCB3 R7323 CARBON R R16J-560 1 417345614T 38/40 PAGE PCB3 R7324 CARBON R R16J-820 1 417348214T PCB3 R7325 CARBON R R16J-1.2K 1 417341224T PCB3 R7326 CARBON R R16J-2.2K 1 417342224T PCB3 R7327 CARBON R R16J-3.9K 1 417343924T PCB3 R7328 CARBON R R16J-12K 1 417341234T PCB3 R7331 CARBON R R16J-330 1 417343314T PCB3 R7332 CARBON R R16J-470 1 417344714T PCB3 R7333 CARBON R R16J-560 1 417345614T PCB3 R7334 CARBON R R16J-820 1 417348214T PCB3 R7335 CARBON R R16J-1.2K 1 417341224T PCB3 R7336 CARBON R R16J-2.2K 1 417342224T PCB3 R7337 CARBON R R16J-3.9K 1 417343924T PCB3 R7338 CARBON R R16J-12K 1 417341234T PCB3 R7401 CARBON R R16J-10K 1 417341034T PCB3 R7402 CARBON R R16J-10K 1 417341034T PCB3 R7403 CARBON R R16J-10K 1 417341034T PCB3 R7404 CARBON R R16J-10K 1 417341034T PCB3 RL901 RELAY NRL-1P5A-DC9-179 1 25065669 ! PCB3 RL901A TAPE TAPE(CLOTH-16U) (1) 29110083 PCB3 S7303 PUSH SW NPS-111-S681 1 25035718T PCB3 S7304 PUSH SW NPS-111-S681 1 25035718T PCB3 S7307 PUSH SW NPS-111-S681 1 25035718T PCB3 S7311 PUSH SW NPS-111-S681 1 25035718T PCB3 S7312 PUSH SW NPS-111-S681 1 25035718T PCB3 S7313 PUSH SW NPS-111-S681 1 25035718T PCB3 S7315 PUSH SW NPS-111-S681 1 25035718T PCB3 S7316 PUSH SW NPS-111-S681 1 25035718T PCB3 S7317 PUSH SW NPS-111-S681 1 25035718T PCB3 S7318 PUSH SW NPS-111-S681 1 25035718T PCB3 S7319 PUSH SW NPS-111-S681 1 25035718T PCB3 S7321 PUSH SW NPS-111-S681 1 25035718T 39/40 PAGE PCB3 S7322 PUSH SW NPS-111-S681 1 25035718T PCB3 S7323 PUSH SW NPS-111-S681 1 25035718T PCB3 S7324 PUSH SW NPS-111-S681 1 25035718T PCB3 S7325 PUSH SW NPS-111-S681 1 25035718T PCB3 S7326 PUSH SW NPS-111-S681 1 25035718T PCB3 S7327 PUSH SW NPS-111-S681 1 25035718T PCB3 S7328 PUSH SW NPS-111-S681 1 25035718T PCB3 S7329 PUSH SW NPS-111-S681 1 25035718T PCB3 S7331 PUSH SW NPS-111-S681 1 25035718T PCB3 S7332 PUSH SW NPS-111-S681 1 25035718T PCB3 S7333 PUSH SW NPS-111-S681 1 25035718T PCB3 S7334 PUSH SW NPS-111-S681 1 25035718T PCB3 S7335 PUSH SW NPS-111-S681 1 25035718T PCB3 S7336 PUSH SW NPS-111-S681 1 25035718T PCB3 S7337 PUSH SW NPS-111-S681 1 25035718T PCB3 S7338 PUSH SW NPS-111-S681 1 25035718T PCB3 S7339 PUSH SW NPS-111-S681 1 25035718T PCB3 S7401 R ENCODE EC12E2425 1 25065655 PCB3 P901A PLUG 1-1123724-2 1 25056402 ! PCB3 P901A or PLUG NPLG-2P631 (1) 25055675 ! PCB3 P902 PLUG 1-1123724-2 1 25056402 PCB3 P902 or PLUG NPLG-2P631 (1) 25055675 PCB3 P1001 PIN JACK NPJ-1PDO554 1 25045772 PCB3 P1001 or PIN JACK NPJ-1PDBL291 (1) 25045473 PCB3 P2001 PIN JACK NPJ-3PDYYY560 1 25045778 PCB3 P2001 or PIN JACK NPJ-3PDYE158 (1) 25045299 PCB3 P2002 PIN JACK NPJ-3PDYYY560 1 25045778 PCB3 P2002 or PIN JACK NPJ-3PDYE158 (1) 25045299 PCB3 P2011A SOCKET NSCT-11P2191 1 25052294 PCB3 P2101 PIN JACK NPJ-9PDGLRGLRGLR563 1 25045781 PCB3 P2102 PIN JACK NPJ-3PDGLR623 1 25045844 40/40 PAGE PCB3 P7001B SOCKET NSCT-29P2263 1 25052366 PCB3 P7001B or SOCKET NSCT-29P2447 (1) 25052550 PCB3 P7501 ST JACK MSJ-064-05A SR 1 25045783 PCB3 E901 RETAINER MET37-0002 1 27142009T PCB3 E7501 RETAINER MET37-0002 1 27142009T PCB3 F901A FUSE HOL NSCT-1P2031 1 25052133T ! PCB3 F901B FUSE HOL NSCT-1P2031 1 25052133T ! PCB3 JL7101 JUMPER LEAD JL7 150 H 1 --- NSP PCB3 JL7101A WIRE HOL NSCT-7P898 1 25051111 PCB3 JL7101B WIRE HOL NSCT-7P898 1 25051111 PCB3 JL7102 JUMPER LEAD JL5 100 H 1 --- NSP PCB3 JL7102A WIRE HOL NSCT-5P896 1 25051109 PCB3 JL7102B WIRE HOL NSCT-5P896 1 25051109 PCB3 JL9003B SOCKET NSCT-5P97 1 25050269 TX-SR304(HT-S4100) ONKYO EUROPE UK Office Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/ Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO CORPORATION http://www.onkyo.com/ HOMEPAGE ONKYO CHINA LIMITED Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.ch.onkyo.com/
