SERVICE MANUAL DATA BASIC TAPE MECHANISM : TN-21ZSC-2003 BASIC CD MECHANISM : DA-11T3C COMPACT DISC STEREO SYSTEM LCX-K277 S/M Code No. 09-007-347-4N2 HC(S) MODEL CODE : 86HR8-0117(B) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -2- SPECIFICATIONS • Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -3- PROTECTION OF EYES FROM LASER BEAM DURING SERVICING VAROITUS! Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit- ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit- tävälle näkymättömälle lasersäteilylle. VARNING! Om apparaten används på annat sätt än vad som specificeras i denna bruksanvising, kan användaren utsättas för osynling laserstrålning, som överskrider gränsen för laserklass 1. Caution: Invisible laser radiation when open and interlocks defeated avoid expo- sure to beam. Advarsel:Usynling laserståling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsættelse for stråling. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. ATTENTION L'utilisation de commandes, réglages ou procédures autres que ceux spécifiés peut entraîner une dangereuse exposition aux radiations. ADVARSEL! Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude af funktion. Undgå udsættelse for stråling. This Compact Disc player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the rear exterior. This set employs laser. Therefore, be sure to follow carefully the instructions below when servicing. WARNING! WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN 30cm FROM THE SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK. CLASS 1 KLASSE 1 LUOKAN 1 KLASS 1 LASER PRODUCT LASER PRODUKT LASER LAITE LASER APPARAT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -4- Precaution to replace Optical block (SF-P101NR) 1) After the connection, remove solder shown in the right figure. Body or clothes electrostatic potential could ruin laser diode in the optical block. Be sure ground body and workbench, and use care the clothes do not touch the diode. Solder PICK-UP Assy P.W.B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -5- REF. NO PART NO. KANRI DESCRIPTION NO. REF. NO PART NO. KANRI DESCRIPTION NO. ELECTRICAL MAIN PARTS LIST-1/4 IC 87-A20-547-010 C-IC,CXA1992AR 87-A21-368-010 IC,NJM7812FA(A) 87-A20-919-040 C-IC,BA5915FP 87-002-849-080 IC,NJM78L06A 87-A20-917-010 C-IC,CXD2540Q-1/2 87-A21-443-040 C-IC,M62495AFP 8A-CGC-606-010 C-IC,UPD78016FGC 87-A21-020-010 IC,TA8223K 87-A20-993-040 C-IC,PST9121NL 87-A20-602-040 C-IC,M5291FP 87-A21-431-010 IC,BA4560N 87-A20-925-040 C-IC,BA05FP 87-A20-905-040 C-IC,BA033FP 87-A20-920-010 C-IC,CL680-D1 87-A20-921-040 C-IC,SN74LVU04APW 87-A20-962-040 C-IC,MSM54V16258B/BSL 84-ZG1-695-040 C-IC,LH5V2RN1 87-A20-975-040 C-IC,SN74LV74APW 87-A20-974-040 C-IC,LC74781M-9017 8A-CGC-605-010 C-IC,LC877248A 87-A20-918-040 C-IC,SM5878AM 87-070-127-110 IC,LC72131 D 87-A20-913-010 IC,LA1837NL 87-A21-482-010 IC,RPM6938-H4 TRANSISTOR 87-026-463-080 TR,2SA933S (0.3W) 89-213-703-010 TR,2SB1370F 87-026-237-080 CHIP-TR,DTC124XK 87-026-610-080 TR,KTC3198GR 89-327-125-080 CHIP TR,2SC2712GR 87-026-580-080 C-TR,DTA123JK 87-026-235-080 CHIP-TR,DTC114EK 87-026-231-080 CHIP-TRANSISTER,DTA124XK 89-406-555-080 TR,2SD655 (0.5W) 89-109-521-080 TR,2SA952 (0.6W) 87-A30-117-010 TR,2SA1357 89-111-625-080 TR,2SA1162 (0.15W) 87-026-263-080 C-TR,RN1410 87-026-470-080 TR,HN1C03F (0.3W) 89-320-011-080 TR,2SC2001 (15W) 87-A30-072-080 C-TR,RT1P 144C 87-026-215-080 TR,DTC114YS 89-327-143-080 TR,2SC2714 (0.1W) DIODE 87-020-027-080 CHIP-DIODE 1SS184 87-070-178-090 DIODE,1N5402-BD54 87-020-465-080 DIODE,1SS133 (110MA) 87-017-024-040 C-DIODE,DA204K 87-017-092-080 ZENER,HZS5C2 87-A40-180-040 C-DIODE,SB07-015C 87-A40-189-080 DIODE,1SR139-400 87-020-330-080 DIODE,DAP202K 87-A40-246-080 DIODE,1N4148T-77 87-017-781-080 DIODE,IN4004G 87-017-149-080 ZENER,HZS6A2L MAIN C.B C109 87-016-658-090 CAP,E 4700-35 SMG C111 87-010-196-080 CHIP CAPACITOR,0.1-25 C112 87-010-401-080 CAP, ELECT 1-50V C113 87-010-401-080 CAP, ELECT 1-50V C114 87-010-101-080 CAP, ELECT 220-16 C115 87-010-101-080 CAP, ELECT 220-16 C117 87-010-403-080 CAP, ELECT 3.3-50V C118 87-010-101-080 CAP, ELECT 220-16 C119 87-010-196-080 CHIP CAPACITOR,0.1-25 C120 87-010-263-080 CAP, ELECT 100-10V C201 87-010-248-080 CAP, ELECT 220-10V C203 87-010-248-080 CAP, ELECT 220-10V C204 87-010-197-080 CAP, CHIP 0.01 DM C213 87-016-669-080 C-CAP,S 0.1-25 K B C214 87-016-669-080 C-CAP,S 0.1-25 K B C223 87-A11-123-080 CAP,TC U 1800P C224 87-A11-123-080 CAP,TC U 1800P C225 87-010-401-080 CAP, ELECT 1-50V C226 87-010-401-080 CAP, ELECT 1-50V C227 87-018-208-080 CAP 0.047-50F C228 87-018-208-080 CAP 0.047-50F C229 87-018-132-080 CAP, CER 2200P-16V C230 87-018-132-080 CAP, CER 2200P-16V C231 87-010-406-080 CAP, ELECT 22-50 C232 87-010-406-080 CAP, ELECT 22-50 C233 87-010-260-080 CAP, ELECT 47-25V C234 87-010-404-080 CAP, ELECT 4.7-50V C235 87-010-112-080 CAP, ELECT 100-16V C236 87-010-112-080 CAP, ELECT 100-16V C237 87-010-237-080 CAP, ELECT 1000-16V C238 87-010-237-080 CAP, ELECT 1000-16V C241 87-018-209-080 CAP, CER 0.1-50V C243 87-010-387-080 CAP,E 470-25 SME C244 87-010-248-080 CAP, ELECT 220-10V C250 87-010-401-080 CAP, ELECT 1-50V C251 87-010-401-080 CAP, ELECT 1-50V C255 87-010-401-080 CAP, ELECT 1-50V C256 87-010-401-080 CAP, ELECT 1-50V C257 87-010-401-080 CAP, ELECT 1-50V C258 87-010-401-080 CAP, ELECT 1-50V C259 87-010-401-080 CAP, ELECT 1-50V C260 87-010-401-080 CAP, ELECT 1-50V C270 87-010-322-080 C-CAP,S 100P-50 CH C271 87-010-322-080 C-CAP,S 100P-50 CH C301 87-010-322-080 C-CAP,S 100P-50 CH C302 87-010-401-080 CAP, ELECT 1-50V C305 87-010-374-080 CAP, ELECT 47-10V C307 87-010-405-080 CAP, ELECT 10-50V C308 87-010-248-080 CAP, ELECT 220-10V C309 87-010-405-080 CAP, ELECT 10-50V C310 87-010-322-080 C-CAP,S 100P-50 CH C312 87-010-374-080 CAP, ELECT 47-10V C313 87-010-401-080 CAP, ELECT 1-50V C315 87-010-426-080 C-CAP,S 0.012-25 B C318 87-010-426-080 C-CAP,S 0.012-25 B C319 87-A11-098-080 CAP,270PF-50 CH C320 87-010-197-080 CAP, CHIP 0.01 DM C321 87-A11-114-080 CAP,TC U 1200P-50 J CH C322 87-010-248-080 CAP, ELECT 220-10V C324 87-010-186-080 CAP,CHIP 4700P C327 87-010-405-080 CAP, ELECT 10-50V C328 87-010-405-080 CAP, ELECT 10-50V C329 87-010-178-080 CHIP CAP 1000P C330 87-010-178-080 CHIP CAP 1000P C331 87-010-178-080 CHIP CAP 1000P C332 87-010-263-080 CAP, ELECT 100-10V C334 87-010-401-080 CAP, ELECT 1-50V C335 87-010-260-080 CAP, ELECT 47-25V C341 87-010-197-080 CAP, CHIP 0.01 DM C700 87-018-209-080 CAP, CER 0.1-50V C701 87-010-381-080 CAP, ELECT 330-16V C702 87-010-404-080 CAP, ELECT 4.7-50V C703 87-012-286-080 CAP, U 0.01-25 C704 87-012-286-080 CAP, U 0.01-25 C705 87-A10-592-080 C-CAP,S 0.015-50 J B C706 87-A10-592-080 C-CAP,S 0.015-50 J B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -6- REF. NO PART NO. KANRI DESCRIPTION NO. REF. NO PART NO. KANRI DESCRIPTION NO. ELECTRICAL MAIN PARTS LIST-2/4 C709 87-012-195-080 C-CAP,U 100P-50CH C711 87-010-260-080 CAP, ELECT 47-25V C712 87-010-831-080 C-CAP,U,0.1-16F C714 87-012-286-080 CAP, U 0.01-25 C717 87-012-286-080 CAP, U 0.01-25 C719 87-012-286-080 CAP, U 0.01-25 C720 87-012-195-080 C-CAP,U 100P-50CH C721 87-012-176-080 CAP 15P C722 87-012-176-080 CAP 15P C723 87-012-274-080 CHIP CAP,U 1000P-50B C725 87-012-274-080 CHIP CAP,U 1000P-50B C727 87-010-196-080 CHIP CAPACITOR,0.1-25 C728 87-010-248-080 CAP, ELECT 220-10V C729 87-012-274-080 CHIP CAP,U 1000P-50B C731 87-012-286-080 CAP, U 0.01-25 C733 87-010-987-080 C-CAP,S 1500P-50 CH C734 87-010-987-080 C-CAP,S 1500P-50 CH C735 87-010-987-080 C-CAP,S 1500P-50 CH C736 87-010-987-080 C-CAP,S 1500P-50 CH C737 87-A10-592-080 C-CAP,S 0.015-50 J B C738 87-A10-592-080 C-CAP,S 0.015-50 J B C751 87-010-220-080 C-CAP,S 0.018-25 B C752 87-010-220-080 C-CAP,S 0.018-25 B C756 87-012-286-080 CAP, U 0.01-25 C757 87-012-188-080 C-CAP,U 47P-50 CH C758 87-012-167-080 C-CAP,U 5P-50 CH C763 87-010-829-080 CAP, U 0.047-16 C764 87-012-337-080 C-CAP,U 56P-50 CH C765 87-012-286-080 CAP, U 0.01-25 C768 87-012-286-080 CAP, U 0.01-25 C769 87-010-260-080 CAP, ELECT 47-25V C770 87-010-829-080 CAP, U 0.047-16 C771 87-010-383-080 CAP, ELECT 33-25V C772 87-010-829-080 CAP, U 0.047-16 C773 87-010-196-080 CHIP CAPACITOR,0.1-25 C774 87-010-263-080 CAP, ELECT 100-10V C775 87-010-404-080 CAP, ELECT 4.7-50V C776 87-012-286-080 CAP, U 0.01-25 C777 87-010-400-080 CAP, ELECT 0.47-50V C778 87-010-401-080 CAP, ELECT 1-50V C779 87-010-401-080 CAP, ELECT 1-50V C780 87-010-196-080 CHIP CAPACITOR,0.1-25 C781 87-010-405-080 CAP, ELECT 10-50V C782 87-010-405-080 CAP, ELECT 10-50V C783 87-012-286-080 CAP, U 0.01-25 C784 87-012-286-080 CAP, U 0.01-25 C785 87-016-279-080 CAP,E 1-50 BP C786 87-016-279-080 CAP,E 1-50 BP C789 87-012-275-080 C-CAP,U 1200P-50 B C790 87-012-275-080 C-CAP,U 1200P-50 B C791 87-010-405-080 CAP, ELECT 10-50V C793 87-012-273-080 C-CAP,U 820P-50 B C794 87-010-406-080 CAP, ELECT 22-50 C795 87-010-596-080 CAP, S 0.047-16 C796 87-010-403-080 CAP, ELECT 3.3-50V C799 87-010-829-080 CAP, U 0.047-16 C812 87-012-286-080 CAP, U 0.01-25 C820 87-010-260-080 CAP, ELECT 47-25V C821 87-012-286-080 CAP, U 0.01-25 C822 87-012-286-080 CAP, U 0.01-25 C823 87-012-286-080 CAP, U 0.01-25 C828 87-010-196-080 CHIP CAPACITOR,0.1-25 C829 87-010-196-080 CHIP CAPACITOR,0.1-25 C959 87-010-196-080 CHIP CAPACITOR,0.1-25 C960 87-010-196-080 CHIP CAPACITOR,0.1-25 C961 87-012-170-080 C-CAP,U 8P-50 CH C963 87-010-196-080 CHIP CAPACITOR,0.1-25 CF801 87-008-261-010 FILTER, SFE10.7MA5-A CF802 87-008-261-010 FILTER, SFE10.7MA5-A CN101 87-049-919-010 CONN,3P EH V WHT CN201 87-099-719-010 CONN,30P TYK-B(X) CN203 87-A60-060-010 CONN,07P V 9604S-07C CN301 87-A60-627-010 CONN,10P V 2MM JMT FB701 87-008-372-080 FILTER, EMI BL OIRNI FB702 87-008-372-080 FILTER, EMI BL OIRNI FB703 87-008-372-080 FILTER, EMI BL OIRNI FB704 87-008-372-080 FILTER, EMI BL OIRNI FB705 87-008-372-080 FILTER, EMI BL OIRNI FFE801 A8-8ZA-193-070 8ZA-1 YFEUNC !ICP203 87-001-132-080 ICP-N38 J201 87-A60-420-010 JACK,3.5 ST (MSC) J202 87-A60-754-010 TERMINAL,SPK 4P MSP-154V-05 J203 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN J204 87-099-801-010 JACK,PIN 1P BLK J801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 L204 87-005-239-080 COIL,100UH L205 87-005-239-080 COIL,100UH L301 87-007-342-010 COIL,OSC 85K BIAS L771 87-A50-266-010 COIL,FM DET-2N(TOK) L772 87-A91-110-010 FLTR,PCFJZH-450 (TOK) L981 8Z-ZA1-667-010 COIL,AM PACK 4F(TOK) R251 87-029-124-010 RES,FUSE 2.2-1/4 R252 87-029-124-010 RES,FUSE 2.2-1/4 S301 8Z-CL8-668-010 SW,RP ZCL8 X721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 MICON C.B C601 87-010-196-080 CHIP CAPACITOR,0.1-25 C602 87-010-248-080 CAP, ELECT 220-10V C606 87-010-178-080 CHIP CAP 1000P C607 87-010-317-080 C-CAP,S 39P-50 CH C608 87-010-312-080 C-CAP,S 15P-50 CH C609 87-010-315-080 C-CAP,S 27P-50 CH C610 87-010-452-080 CAPACITOR,1-16 C613 87-010-196-080 CHIP CAPACITOR,0.1-25 C614 87-010-196-080 CHIP CAPACITOR,0.1-25 C618 87-012-156-080 C-CAP,S 220P-50 CH C619 87-010-196-080 CHIP CAPACITOR,0.1-25 C621 87-010-196-080 CHIP CAPACITOR,0.1-25 C622 87-010-401-080 CAP, ELECT 1-50V C641 87-010-248-080 CAP, ELECT 220-10V CN601 87-099-720-010 CONN,30P TYK-B(P) CN602 87-A60-059-010 CONN,08P V 9604S-08C CN604 87-A60-060-010 CONN,07P V 9604S-07C L601 87-003-098-080 COIL,2.2UH L603 87-003-098-080 COIL,2.2UH LCD601 8A-CJB-630-010 LCD,AIW4214-30P1N ACJ-11 X601 87-030-376-080 VIB,CER CSA5.76MG200 VCD C.B C101 87-010-182-080 C-CAP,S 2200P-50 B C102 87-016-669-080 C-CAP,S 0.1-25 K B C103 87-016-669-080 C-CAP,S 0.1-25 K B C104 87-016-669-080 C-CAP,S 0.1-25 K B C105 87-010-404-040 CAP,E 4.7-50 SME C106 87-016-369-080 C-CAP,S 0.033-25 B K C107 87-010-197-080 CAP, CHIP 0.01 DM C108 87-010-546-080 CAP, ELECT 0.33-50V C109 87-010-382-040 CAP,E 22-25 SME C110 87-010-213-080 C-CAP,S 0.015-50 B C111 87-010-263-040 CAP,E 100-10 C112 87-010-197-080 CAP, CHIP 0.01 DM C113 87-016-369-080 C-CAP,S 0.033-25 B K C114 87-016-369-080 C-CAP,S 0.033-25 B K C115 87-016-369-080 C-CAP,S 0.033-25 B K C116 87-012-158-080 C-CAP,S 390P-50 CH C117 87-010-318-080 C-CAP,S 47P-50 CH C118 87-010-494-040 CAP,E 1-50 GAS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -7- REF. NO PART NO. KANRI DESCRIPTION NO. REF. NO PART NO. KANRI DESCRIPTION NO. ELECTRICAL MAIN PARTS LIST-3/4 C119 87-010-313-080 CAP, CHIP 18P C120 87-010-992-080 C-CAP,S 0.047-25 B C121 87-010-992-080 C-CAP,S 0.047-25 B C123 87-016-669-080 C-CAP,S 0.1-25 K B C125 87-010-198-080 CAP, CHIP 0.022 C126 87-016-669-080 C-CAP,S 0.1-25 K B C127 87-010-112-040 CAP,E 100-16 C130 87-010-112-040 CAP,E 100-16 C131 87-010-112-040 CAP,E 100-16 C132 87-010-178-080 CHIP CAP 1000P C133 87-010-112-040 CAP,E 100-16 C134 87-010-196-080 CHIP CAPACITOR,0.1-25 C135 87-010-196-080 CHIP CAPACITOR,0.1-25 C136 87-010-196-080 CHIP CAPACITOR,0.1-25 C137 87-010-196-080 CHIP CAPACITOR,0.1-25 C138 87-010-184-080 CHIP CAPACITOR 3300P(K) C139 87-010-197-080 CAP, CHIP 0.01 DM C140 87-010-112-040 CAP,E 100-16 C141 87-010-196-080 CHIP CAPACITOR,0.1-25 C143 87-010-992-080 C-CAP,S 0.047-25 B C151 87-010-263-040 CAP,E 100-10 C152 87-010-197-080 CAP, CHIP 0.01 DM C153 87-A10-893-040 CAP,E 220-10 M PW C154 87-010-190-080 S CHIP F 0.01 C155 87-010-184-080 CHIP CAPACITOR 3300P(K) C156 87-010-992-080 C-CAP,S 0.047-25 B C157 87-010-992-080 C-CAP,S 0.047-25 B C158 87-012-156-080 C-CAP,S 220P-50 CH C159 87-016-526-080 C-CAP,S 0.47-16 BK C160 87-010-314-080 C-CAP,S 22P-50V C161 87-010-182-080 C-CAP,S 2200P-50 B C162 87-010-178-080 CHIP CAP 1000P C201 87-016-669-080 C-CAP,S 0.1-25 K B C206 87-010-322-080 C-CAP,S 100P-50 CH C207 87-010-322-080 C-CAP,S 100P-50 CH C208 87-010-322-080 C-CAP,S 100P-50 CH C209 87-010-322-080 C-CAP,S 100P-50 CH C210 87-016-669-080 C-CAP,S 0.1-25 K B C211 87-010-263-040 CAP,E 100-10 C213 87-010-190-080 S CHIP F 0.01 C214 87-010-196-080 CHIP CAPACITOR,0.1-25 C301 87-016-251-040 CAP,E 220-16 SMG C302 87-012-140-080 CAP 470P C303 87-010-178-080 CHIP CAP 1000P C304 87-010-384-040 CAP,E 100-25 SME C305 87-010-982-040 CAP,E 33-25 GAS C306 87-010-112-040 CAP,E 100-16 C307 87-010-196-080 CHIP CAPACITOR,0.1-25 C308 87-010-263-040 CAP,E 100-10 C309 87-010-196-080 CHIP CAPACITOR,0.1-25 C310 87-010-263-040 CAP,E 100-10 C311 87-010-196-080 CHIP CAPACITOR,0.1-25 C312 87-010-178-080 CHIP CAP 1000P C321 87-010-992-080 C-CAP,S 0.047-25 B C322 87-010-197-080 CAP, CHIP 0.01 DM C501 87-010-197-080 CAP, CHIP 0.01 DM C502 87-010-197-080 CAP, CHIP 0.01 DM C503 87-010-197-080 CAP, CHIP 0.01 DM C504 87-010-154-080 CAP CHIP 10P C505 87-010-154-080 CAP CHIP 10P C506 87-010-197-080 CAP, CHIP 0.01 DM C508 87-010-263-040 CAP,E 100-10 C509 87-016-669-080 C-CAP,S 0.1-25 K B C510 87-010-263-040 CAP,E 100-10 C511 87-010-196-080 CHIP CAPACITOR,0.1-25 C512 87-010-197-080 CAP, CHIP 0.01 DM C513 87-010-197-080 CAP, CHIP 0.01 DM C514 87-010-197-080 CAP, CHIP 0.01 DM C518 87-010-322-080 C-CAP,S 100P-50 CH C519 87-012-145-080 CAP, CHIP S 270P CH C520 87-012-157-080 C-CAP,S 330P-50 CH C521 87-012-154-080 C-CAP,S 150P-50 CH C522 87-010-371-080 CAP, ELECT 470-6.3V C523 87-010-197-080 CAP, CHIP 0.01 DM C524 87-010-197-080 CAP, CHIP 0.01 DM C525 87-010-197-080 CAP, CHIP 0.01 DM C526 87-010-197-080 CAP, CHIP 0.01 DM C527 87-010-197-080 CAP, CHIP 0.01 DM C528 87-010-197-080 CAP, CHIP 0.01 DM C529 87-010-197-080 CAP, CHIP 0.01 DM C530 87-010-197-080 CAP, CHIP 0.01 DM C531 87-010-197-080 CAP, CHIP 0.01 DM C532 87-010-374-040 CAP,E 47-10 C533 87-010-197-080 CAP, CHIP 0.01 DM C534 87-010-112-040 CAP,E 100-16 C535 87-010-197-080 CAP, CHIP 0.01 DM C536 87-010-078-040 CAP,E 47-6.3 5L C537 87-010-190-080 S CHIP F 0.01 C538 87-010-196-080 CHIP CAPACITOR,0.1-25 C539 87-010-196-080 CHIP CAPACITOR,0.1-25 C540 87-010-078-040 CAP,E 47-6.3 5L C541 87-010-197-080 CAP, CHIP 0.01 DM C542 87-010-318-080 C-CAP,S 47P-50 CH C543 87-010-322-080 C-CAP,S 100P-50 CH C544 87-010-197-080 CAP, CHIP 0.01 DM C546 87-010-197-080 CAP, CHIP 0.01 DM C547 87-010-322-080 C-CAP,S 100P-50 CH C548 87-018-134-080 CAP,TC U 0.01-16 NY UP050 C549 87-010-494-040 CAP,E 1-50 GAS C551 87-012-153-080 C-CAP,S 120P-50 CH C552 87-016-526-080 C-CAP,S 0.47-16 BK C554 87-010-197-080 CAP, CHIP 0.01 DM C556 87-010-197-080 CAP, CHIP 0.01 DM C557 87-A11-167-080 C-CAP,S 27P-50 F CH C558 87-A11-167-080 C-CAP,S 27P-50 F CH C559 87-010-197-080 CAP, CHIP 0.01 DM C560 87-010-197-080 CAP, CHIP 0.01 DM C601 87-010-197-080 CAP, CHIP 0.01 DM C602 87-010-197-080 CAP, CHIP 0.01 DM C603 87-010-112-040 CAP,E 100-16 C604 87-010-196-080 CHIP CAPACITOR,0.1-25 C605 87-010-197-080 CAP, CHIP 0.01 DM C606 87-010-197-080 CAP, CHIP 0.01 DM C607 87-010-313-080 CAP, CHIP 18P C608 87-010-313-080 CAP, CHIP 18P C609 87-010-178-080 CHIP CAP 1000P C610 87-010-178-080 CHIP CAP 1000P C611 87-010-178-080 CHIP CAP 1000P C612 87-010-178-080 CHIP CAP 1000P C613 87-010-403-040 CAP,E 3.3-50 SME C614 87-010-403-040 CAP,E 3.3-50 SME C615 87-010-318-080 C-CAP,S 47P-50 CH C616 87-010-318-080 C-CAP,S 47P-50 CH CN101 87-A60-424-010 CONN,16P V TOC-B CN403 87-A60-079-010 CONN,08P H 9604S-08F CN405 87-A60-060-010 CONN,07P V 9604S-07C CN406 87-A60-619-010 CONN,2P V 2MM JMT CNA102 8A-CJB-623-010 CONN ASSY,6P CD MOTOR J501 87-009-502-010 JACK,PIN 1P Y EARTH L101 87-005-196-080 COIL,10UH L301 87-A50-095-010 COIL,68UH RCR875D L302 87-005-426-080 COIL,3.3UH K FLR50 L502 87-005-204-080 COIL,47UH L503 87-005-189-080 COIL 2.7UH L504 87-005-187-080 COIL,1.8UH L505 87-005-204-080 COIL,47UH L506 87-005-204-080 COIL,47UH L507 87-005-204-080 COIL,47UH L508 87-005-817-080 C-COIL, 33UH J FLC32 L509 87-005-270-080 COIL,4.7UH K LAL03 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -8- 8 8 A Resistor Code Chip Resistor Part Coding Figure Value of resistor Chip resistor Wattage Type Tolerance 1/16W 1/10W 1/8W 1608 2125 3216 5% 5% 5% CJ CJ CJ Form L W t 1.6 0.8 0.45 2 1.25 0.45 3.2 1.6 108 118 128 : A : A CHIP RESISTOR PART CODE 0.55 Resistor Code Dimensions (mm) Symbol 1/16W 1005 5% CJ 1.0 0.5 0.35 104 L t W • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. ELECTRICAL MAIN PARTS LIST-4/4 L510 87-005-270-080 COIL,4.7UH K LAL03 R109 87-022-364-080 C-RES,S 82K-1/10W F R507 87-A00-408-080 C-RES,S 2K-1/10W D S201 88-CDV-607-010 SW,SL 2-2-3 SK23D02G9 X201 87-A70-124-080 VIB,CER 8.0MHZ X501 87-A70-125-080 VIB,XTAL 27MHZ 50PPM X601 87-030-270-080 VIB,XTAL 16.9344MHZ KEY C.B C901 87-010-196-080 CHIP CAPACITOR,0.1-25 C902 87-010-196-080 CHIP CAPACITOR,0.1-25 C903 87-010-197-080 CAP, CHIP 0.01 DM C904 87-010-197-080 CAP, CHIP 0.01 DM C905 87-010-405-080 CAP, ELECT 10-50V C906 87-010-178-080 CHIP CAP 1000P CN901 87-A60-080-010 CONN,07P H 9604S-07F S901 87-A91-024-180 SW,TACT KSH0611BT S902 87-A91-024-180 SW,TACT KSH0611BT S904 87-A91-024-180 SW,TACT KSH0611BT S905 87-A91-024-180 SW,TACT KSH0611BT S906 87-A91-024-180 SW,TACT KSH0611BT S907 87-A91-024-180 SW,TACT KSH0611BT S908 87-A91-024-180 SW,TACT KSH0611BT S909 87-A91-024-180 SW,TACT KSH0611BT S910 87-A91-024-180 SW,TACT KSH0611BT S911 87-A91-024-180 SW,TACT KSH0611BT S913 87-A91-024-180 SW,TACT KSH0611BT S915 87-A91-024-180 SW,TACT KSH0611BT S916 87-A91-024-180 SW,TACT KSH0611BT S917 87-A91-024-180 SW,TACT KSH0611BT S920 87-A91-385-010 SW,RTRY EC12E12504-15MM LED C.B CN606 87-A61-297-010 CONN,5P TKX-P05P-A1 D621 87-A40-821-080 LED,SMLS1BE16C BLU/UMB D622 87-A40-821-080 LED,SMLS1BE16C BLU/UMB PT C.B C100 87-010-398-010 CAP ELECT 2200 C101 87-010-198-080 CAP, CHIP 0.022 C102 87-010-198-080 CAP, CHIP 0.022 C103 87-010-198-080 CAP, CHIP 0.022 C104 87-010-198-080 CAP, CHIP 0.022 CNA101 8A-CLC-610-010 CONN ASSY,3P POWER !F101 87-035-367-010 FUSE, 3.15A 250V FC101 87-A90-160-080 FUSE CLAMP FC102 87-A90-160-080 FUSE CLAMP !PT101 8A-CLC-609-010 PT,ACL-12 H !S101 87-A90-234-010 SW,SL 1-2-2 SW2201 !T1 87-A60-317-010 TERMINAL, 1P MSC !T2 87-A60-317-010 TERMINAL, 1P MSC MOTOR C.B M2 S0-M10-A09-700 MOTOR SLED ASSY PIN3 S2-369-750-000 PLUG,6P SW1 S4-S13-A01-600 SW,LEAF REF. NO PART NO. KANRI DESCRIPTION NO. REF. NO PART NO. KANRI DESCRIPTION NO. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -9- 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 A B C D E F G H I J K L M N O P Q R S T U 1 2 3 4 5 6 7 8 9 25 26 27 28 29 30 31 32 WIRING-1/5 (MAIN) C965 C810 C743 C741 C742 C700 FB703 FB702 1 2 3 4 5 6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -10- SCHEMATIC DIAGRAM-1/5 (MAIN1/2) TAPE DECK (TN-21ZSC-2003) TO VCD C.B CN405 TO VCD C.B (1/2) 12V FB701 S101 AC VOLTAGE FB704 FB703 FB702 FB705 IC102 NJM7812FA 1800p 1800p GND L202 JW J203 JW w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -11- SCHEMATIC DIAGRAM-2/5 (MAIN2/2: TUNER) C700 0.1 12V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -12- 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 A B C D E F G H I J K L M N O P Q R S T U 1 2 3 4 5 6 7 8 9 25 26 27 28 29 30 31 32 WIRING-2/5 (MICON/KEY/LED) 30 31 1 100 80 81 50 51 TO VCD C.B CN403 S920 VOLUME/ MULTI JOG CD/PBC SELECT CLEAR/ RETURN PREVIOUS NEXT w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -13- SCHEMATIC DIAGRAM-3/5 (MICON) XBUSY COMMAND STATUS XBUSY COMMAND STATUS SCK SCK N.C N.C TO VCD C.B CN403 XBUSY COMMAND STATUS I-STATUS SCK I/O-XBUSY O-COMMAND O-SCK IC601 LC877248A-5R97 DESTINATION CD/PBC PRESET/ SELECT CLEAR/ RETURN UP/ NEXT DOWN/ PREVIOUS w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -14- WIRING-3/5 (VCD: COMPONENT SIDE) 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 A B C D E F G H I J K L M N O P Q R S T U 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -15- WIRING-4/5 (VCD: CONDUCTOR SIDE) 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 A B C D E F G H I J K L M N O P Q R S T U 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 C605 J501 CN203 PIN3 CN405 CN101 CN602 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -16- SCHEMATIC DIAGRAM-4/5 (VCD1/2) PIN3 R140 5.6k C320 0.1 FZ , w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -17- SCHEMATIC DIAGRAM-5/5 (VCD2/2) J501 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -18- 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 A B C D E F G H I J K L M N O P Q R S T U 1 2 3 4 5 6 7 8 9 25 26 27 28 29 30 31 32 WIRING-5/5 (PT/MOTOR) MOTOR C.B PIN3 M3 SW1 _ + M2 M3 (SPINDLE MOTOR) SW1 (INSIDE LIMIT SW) TO MAIN C.B CNA102 M2 (SLED MOTOR) _ + 1 6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -19- ELECTRICAL ADJUSTMENT-1/1 IC404 SFR430 6 MICON C.B L301 L981 3 2 (RED) (YELLOW) IC721 IC772 L772 L771 5 1 4 J201 PHONS MAIN C.B w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -20- VOLTAGE CHART-1/1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -21- FL (AIW4214-30PIN ACJ-11) GRID ASSIGNMENT/ANODE CONNECTION-1/1 ANODE CONNECTION GRID ASSIGNMENT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -22- TRANSISTOR ILLUSTRATION-1/1 KTC3198 DTC114YS 2SC2001 2SD655 2SA952 E C B E C B E C B 2SB1370F 2SA1162 2SC2712 2SC2714 DTA123JK DTA124XK DTC114EK RT1P144C DTC124XK RN1410 B E C E C B 2SA933S C1B2 E2 E1B1 C2 E C B 2SA1357 HN1C03F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -23- IC BLOCK DIAGRAM-1/1 IC, M62495AFP IC, LA1837NL IC, LC72131D IC, BA4560N Switch collector Driver Peak currect detection Power supply Comparator input Switch emitter External capacitance for oscillation Ground 1.17V REF. VOL OSC IC, M5291FP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -24- 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39-53 54 55 Pin No. Pin Name I/O Description IC DESCRIPTION-1/7 (LC877248A-5R97)-1/2 O-ARDY O-SREQ O-SOUT I-SIN I-ACLK I-MREQ NC (SELECT) O-PCONT ___________ I-HOLD O-CLKSFT I-RESET XT1 XT2 VSS1 CF1 CF2 VDD1 I-JOGA I-JOGB I-KEY1 I-KEY I-RDSIG I-CTON I-RDDT I-COLOR I-TMBASE I-INIT I-RDCL I-RMC I-CTPLAY I-CTREC O-TUCONT O-TUCE O-TUDI O-TUCL I-TUDO _________________ I-STEREO NC S9-S23 VDD2 VCC2 O O O I I I O O I O I I O — I O — I I I I I I I I I I I I I I O O O O I I — O — — Not connected. Pull down. Main power control. Hold status detection. Clock shift control. Reset terminal. Connected to VDD. Not connected. GND. External ceramics oscillator (5.76 MHz) is connected to this pin. (input) External ceramics oscillator (5.76 MHz) is connected to this pin. (output) Power supply positive polarity (+) terminal. Jog dial detection A. Jog dial detection B. Tact key, AD input detection. RDS signal level input, AD input. (Not connected) CT DECK power supply detection. RDS data input. (Not connected) LCD back light initial setting input. 8Hz clock reference frequency input. Tuner destination, initial setting input. RDS clock input. (Not connected) Remote controller receptor signal input. CT DECK PLAY detection. CT DECK REC detection. Tuner power supply control. Tuner, Chip enable output for PLL communication. Tuner, Serial data output for PLL communication. Tuner, Clock output for PLL communication. Tuner, Serial data input for PLL communication. Tuner stereo reception detection. Not connected. LCD SEG terminal initial setting output. (No.43-29) Power supply positive polarity (+) terminal. GND. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -25- Pin No. Pin Name I/O Description 56-79 80 81 82 83-86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 S24-S47 I-DOOR I-WRQ I-DRF COM0-COM3 O-CDCONT I-STATUS VSS3 VDD3 I/O-XBUSY O-SCK O-COMMAND O-LIGHT1 O-JOGLED O-SCONTM O-SCONTL O-MUTE O-LIGHT2 O-SRST O I I I O O I — — I/O O O O O O O O O O LCD SEG terminal initial setting output. (No.28-5) CD door detection. Sub-code Q reading stand-by for CD LSI communication. RF level detection input. LCD common output. (No.4-1) CD/VCD power supply control. STATUS from VCD MICON. GND. Power supply terminal. READY/BUSY I/O from VCD MICON. SCK to VCD MICON. COMMAND to VCD MICON. Control output 1 of LCD back light. Not connected. Sound processor control. Audio signal mute output. Control output 2 of LCD back light. Not connected. IC DESCRIPTION-1/7 (LC877248A-5R97)-2/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -26- Output terminal for focus error amplifier. Internally connected to window comparator input for bias condition. Input terminal for focus error. Capacitor connection terminal for time constant used when there is defect. This pin is connected to GND via capacitor when high frequency gain of the focus servo is attenuated. This is a pin where the time constant is externally connected to raise the low frequency gain of the focus servo. Focus drive output. Focus amplifier inverted input pin. This is a pin where the time constant is externally connected to generate the focus search waveform. This is a pin where the selection time constant is externally connected to set the tracking servo the high frequency gain. This is a pin where the selection time constant is externally connected to set the tracking high frequency gain. Pin for setting peak of the phase compensator of the focus tracking. Tracking amplifier inverted input pin. Tracking drive output. Sled amplifier non-inverted input pin. Sled amplifier inverted input pin. Sled drive output. The current which determines height of the focus search, track jump and sled kick is input with external resistance connected. Power supply. “L” setting starts sled disorder-prevention circuit. (Not pull-up resistance) Clock input for serial data transfer from CPU. (No pull-up resistance) Latch input from CPU. (No pull-up resistance) Serial data input from CPU. (No pull-up resistance) Reset system at “L” setting. (No pull-up resistance) Signal output for track number counting. FZC, DFCT1, TZC, BALH, TGH, FOH, or ATSC is output depending on the command from CPU. DFCT2, MIRR, BALL, TGL or FOL is output depending on the command from CPU. Output terminal for focus OK comparator. Input pin where the DEFECT bottom hold output is capacitance coupled. DEFECT bottom-hold output terminal. Internally connected to interruption comparator input. Connection terminal for DEFECT bottom-hold capacitor. Connection terminal for MIRR hold-capacitor. Anti-reverse input terminal for MIRR comparator. Input terminal by capacity combination of RF summing amplifier. FEO FEI FDFCT FGD FLB FE_O FEM SRCH TGU TG2 FSET TA_M TA_O SL_P SL_M SL_O ISET Vcc LOCK CLK XLT DATA XRST C_OUT SENS1 SENS2 FOK CC2 CC1 CB CP RF_I Pin No. Pin Name I/O Description 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 O I I I I O I I I I I I O I I O I I I I I I I O O O O I O I I I IC DESCRIPTION-2/7 (CXA1992AR)-1/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -27- RF_O RF_M RFTC LD PD PD1, PD2 FEBIAS F, E EI VEE TEO LPFI TEI ATSC TZC TDFCT VC FZC Pin No. Pin Name I/O Description 33 34 35 36 37 38, 39 40 41, 42 43 44 45 46 47 48 49 50 51 52 O I I O I I I/O I — — O I I I I I O I Output terminal of RF summing amplifier. Checkpoint of Eye pattern. Anti-reverse input terminal for RF summing amplifier. The gain of RF amplifier is decided by the connection resistance between RF_M and RFO terminals. This is a pin where the selection time constant is externally connected to control the RF level. APC amplifier output terminal. APC amplifier input terminal. RFI-V amplifier inverted input pin. These pins are connected to the A+C and B+C pins of the optical pickup, receiving by currents input. Bias adjustment pin of the focus error amplifier. (Not connected) F and EIV amplifier inverted input pins. These pins are connected to the F and E of the optical pickup, receiving by current input. Gain adjustment pin of the I-V amplifier E. (When not in use of BAL automatic adjustment) GND connection pin. Output terminal for tacking-error amplifier. Output E-F signal. BAL adjustment comparator input pin. (Input through LPF from TEO) Input terminal for tracking error. Window-comparator input terminal for detecting ATSC. Input terminal for tracking-zero cross comparator. Capacitor connection pin for the time constant used when there is defect. Output terminal for DC voltage reduced to half of VCC+VEE. Input terminal for focus-zero cross comparator. IC DESCRIPTION-2/7 (CXA1992AR)-2/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -28- FOK FSW MON MDP MDS LOCK NC VCOO VCOI TEST PDO VSS PWMI V16M VCTL VPCO VCKI FILO FILI PCO AVSS CLTV AVDD RF BIAS ASYI ASYO ASYE NC PSSL WDCK LRCK VDD DATA BCK DATA64 BCK64 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 Pin No. Pin Name I/O Description I O O O O O — O I I O — I O I O I O I O — I — I I I O I — I O O — O O O O Focus OK input. Used for SENS output and the servo auto sequencer. Spindle motor output filter switching output. (Not connected) Spindle motor on/off control output. (Not connected) Spindle motor servo control. (Pin 5 is not connected) High, when sampled value of GFS at 460Hz is high. Low, when sampled value of GFS at 460Hz is low by 8 times successively. Not used. Analog EFM PLL oscillation circuit output. (Not connected) Analog EFM PLL oscillation circuit input. fLOCK=8.6436MHz. (Connected to GND) TEST pin. (Connected to GND) Analog EFM PLL charge pump output. GND. Spindle motor external control input. VCO2 oscillation output for the wide-band EFM PLL. VCO2 control voltage input for the wide-band EFM PLL. Wide-band EFM PLL charge pump output. VCO2 oscillation input for the wide-band EFM PLL. Multiplier PLL (slave=digital PLL) filter output. Multiplier PLL filter input. Multiplier PLL charge pump output. Analog GND. Multiplier VCO1 control voltage input. Analog power supply. (5V) EFM signal input. Constant current input of the asymmetry circuit. Asymmetry comparator voltage input. EFM full-swing output. Low: asymmetry circuit off; high: asymmetry circuit on. Not connected. Audio data output mode switching input. Low: serial output; high: parallel output. (Connected to GND) D/A interface for 48-bit slot. Word clock f=2Fs. (Not connected) D/A interface for 48-bit slot. LR clock f=Fs. Power supply. (5V) DA16 (MSB) output when PSSL=1. 48-bit slot serial data (two’s complement, MSB first) when PSSL=0. DA15 output when PSSL=1. 48-bit slot bit clock when PSSL=0. DA14 output when PSSL=1. 64-bit slot serial data (two’s complement, LSB first) when PSSL=0. (Not connected) DA13 output when PSSL=1. 64-bit slot bit clock when PSSL=0. (Not connected) IC DESCRIPTION-3/7 (CXD2540Q)-1/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -29- LRCK64 GTOP XVCF XPCLK GFS RFCK C2PO XRAOF MNT3 MNT2 MNT1 MNT0 APTR APTL VSS XTAI XTAO XTSL FSTT FSOF C16M MD2 DOUT EMPH WFCK SCOR SBSO EXCK SQSO SQCK MUTE SENS XRST DATA XLAT VDD CLOK SEIN Pin No. Pin Name I/O Description 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 O O O O O O O O O O O O O O — I O I O O O I O O I O O I O I I — I O O O I DA12 output when PSSL=1. 64-bit slot LR clock when PSSL=0. (Not connected) DA11 output when PSSL=1. GTOP output when PSSL=0. (Not connected) DA10 output when PSSL=1. XUGF output when PSSL=0. (Not connected) DA09 output when PSSL=1. XPLCK output when PSSL=0. (Not connected) DA08 output when PSSL=1. GFS output when PSSL=0. DA07 output when PSSL=1. RFCK output when PSSL=0. (Not connected) DA06 output when PSSL=1. C2PO output when PSSL=0. DA05 output when PSSL=1. XRAOF output when PSSL=0. (Not connected) DA04 output when PSSL=1. MNT3 output when PSSL=0. (Not connected) DA03 output when PSSL=1. MNT2 output when PSSL=0. (Not connected) DA02 output when PSSL=1. MNT1 output when PSSL=0. (Not connected) DA01 output when PSSL=1. MNT0 output when PSSL=0. (Not connected) Aperture compensation control output. This pin outputs a high signal when the right channel is used. (Not connected) Aperture compensation control output. This pin outputs a high signal when the left channel is used. (Not connected) GND. Crystal oscillation circuit input. Crystal oscillation circuit output. (Not connected) Crystal selector input. 2/3 frequency divider output for Pins 53 and 54. (Not connected) 1/4 frequency divider output for Pins 53 and 54. (Not connected) 16.9344MHz output. (V16M output in CLV-W and CAV-W modes) (Not connected) Digital-out on/off control. High: on; low: off Digital-out output. Outputs a high signal when the playback disc has emphasis, and a low signal when there is no emphasis. WFCK (write frame clock) output. Outputs a high signal when either subcode sync S0 or S1 is detected. Sub P to W serial output. SBSO readout clock input. Sub Q 80-bit and PCM peak, level metter and internal status outputs. SQSO readout clock input. High: mute; low: release SENS output to CPU. System reset. Reset when low. Serial data input from CPU. Latch input from CPU. Serial data is latched at the falling edge. Power supply. (5V) Serial data transfer clock input from CPU. SENS input from SSP. IC DESCRIPTION-3/7 (CXD2540Q)-2/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -30- Track jump count signal input. Serial data output to SSP. Serial data latch output to SSP. Latched at the falling edge. Serial data transfer clock output to SSP. Mirror signal input. Used when the number of tracks is 128 or more for the 2N-track jump and M track move of the auto sequencer. Pin No. Pin Name I/O Description 76 77 78 79 80 CNIN DATO XLTO CLKO MIRR I O O O I Notes) • The 64-bit slot is an LSB first, two’s complement output, and the 48-bit slot is an MSB first, two’s complement output. • GTOP is used to monitor the frame sync protection status. (High: sync protection window open.) • XUGF is the negative pulse for the frame sync obtained from the EFM signal. It is the signal before sync protection. • XPLCK is the inverse of the EFM PLL clock. The PLL is designed so that the falling edge and the EFM signal transition point coincide. • GFS goes high when the frame sync and the insertion protection timing match. • RFCK is derived from the crystal accuracy, and has a cycle of 136µ. • C2PO represents the data error status. • XRAOF is generated when the 32K RAM exceeds the ±28F jitter margin. IC DESCRIPTION-3/7 (CXD2540Q)-3/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -31- 1 2 3 4 5 6 7-9 10-15 16 17 18 19 20 21 22 23-29 30-36 37 38 39 40 41 42 43 44-46 47 48 49 50-52 53 54 55 56-58 59 60 61 62-64 65 66 67 68 Pin No. Pin Name I/O Description IC DESCRIPTION-4/7 (CL680)-1/3 NC VSS CD BCK CD DATA CD LRCK CD C2PO NC MD0-MD5 VSS MD6 VDD3 MD7 VSS MD8 VDD3 MD9-MD15 NC ________ MCE __________ MWE VSS ________ CAS VDD3 ___________ RASO ___________ RASI MA10-MA8 VSS MA7 VDD3 MA6-MA4 VSS MA3 VDD3 MA2-MA0 PGIO7 ______________ RESET VDD MAX IN NC AGND DAC A DAC COMP OUT AGND DAC — — I I I I — I/O — I/O — I/O — I/O — I/O — — O — O — O O O — O — O — O — O I/O I — — — — O — No connection. GND. Bit clock input from CD DSP. Data input from CD DSP. LRCK input from CD DSP. C2 pointer input from CD DSP. No connection. DRAM/ROM interface. (DATA) Ground. DRAM/ROM interface. (DATA) Power supply 3.3V. DRAM/ROM interface. (DATA) Ground. DRAM/ROM interface. (DATA) Power supply 3.3V. DRAM/ROM interface. (DATA) No connection. ROM chip enable. DRAM write enable. Ground. DRAM/ROM interface. Power supply 3.3V. DRAM/ROM interface. (Pin 43 is no connection) DRAM/ROM interface. (Address) Ground. DRAM/ROM interface. (Address) Power supply 3.3V. DRAM/ROM interface. (Address) Ground. DRAM/ROM interface. (Address) Power supply 3.3V. DRAM/ROM interface. (Address) Programmable I/O. (No connection) Reset input. Power supply - VDDMAX. (5.0V) No connection. Analog ground. Analog power supply (DAC) : 3.3V. Composite out. Analog ground. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -32- Video signal “Y” OUT. (No connection) Analog power supply (DAC) 3.3V. Analog ground. Reference resistor input. Voltage reference input. Analog power supply (DAC) : 3.3V. Video signal “C” out. (No connection) Analog ground. Clock selection input. Ground. Clock selection input. Power supply 3.3V. Clock selection input. Analog ground. DA XCK (16.933MHz) input. Analog power supply 3.3V. DAC-emphasis output. Programmable I/O. (No connection) ______________ ______________ VSYNC/CSYNC output. Analog power supply (PLL) 3.3V. Video DAC clock. Processor clock. (No connection) Audio XCK. (No connection) Analog ground. Ground. No connection. ______________ HSYNC output. Power supply 3.3V. VCK out. Ground. Global clock signal input. (42.3MHz) (No connection) Video clock signal input. (27.0MHz) Global clock signal output. (27.0MHz) DAC-LRCK output. Power supply (VDD MAX) : 5.0V. DAC-PCM data output. DAC-BIT clock output. Micon interface. (Data out) Micon interface. (Host ready) O — — I I — O — I — I — I — I — O I/O I/O I/O O — O O O — — — O — O — I I O O — O O O O Y OUT AVDD DAC AGND DAC R REF V REF AVDD DAC C OUT AGND DAC CLK SEL0-2 VSS CLK SEL3 VDD3 CLK SEL4, 5 AGND PLL DA XCK AVDD PLL DA EMP PGIO5, O6 PGIO0 PGIO8 ______________ ______________ VSYNC/CSYNC AVDD PLL VID_DAC_CK PROC_CK AUD_XCK AGND PLL VSS NC ______________ HSYNC VDD3 VCK OUT VSS GCK VCK IN GCK OUT DA LRCK VDD MAX OUT DA DATA DA BCK HD OUT HRDY Pin No. Pin Name I/O Description 69 70 71 72 73 74 75 76 77-79 80 81 82 83, 84 85 86 87 88 89, 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 IC DESCRIPTION-4/7 (CL680)-2/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -33- __________ HINT CDG SCK VSS HCK VDD3 HD IN VDD3 HSEL CDG SDATA CDG VFSY CDG SOSI DSP-XCK NC Pin No. Pin Name I/O Description 114 115 116 117 118 119 120 121 122 123 124 125 126-128 Micon interface. (Host interrupt) CD-G serial clock input. Ground. Micon interface. (Host clock) Power supply 3.3V. Micon interface. (Host data in) Power supply 3.3V. Micon interface. (Host select in) CD-G data input. CD-G VFSY input. CD-G SOSI input. DSP-XCK output. (No connection) No connection. O I — I — I — I I I I O — IC DESCRIPTION-4/7 (CL680)-3/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -34- GND connection terminal. (Digital ground terminal) External X’tal and capacitor for internal sync generator, or the external clock are connected to this terminal. (2fsc or 4fsc) Either the external clock input mode or the X’tal generator mode is selected by this selector terminal. L: X’tal generator mode, H: External clock input. Blank signal (character and the green ORed signal) is output from this terminal. (MODE 0: ________ composite sync signal is output at H) When reset (RST terminal = L), the X’tal clock signal is output. (It is not output when reset by the reset command) External coil and capacitor for the character output dot clock generator are connected to this terminal. The character signal is output from this terminal. (MOD 0: when H, the external sync signal identification signal is output from this terminal. This output signal tells whether the external ________ sync signal is present or not. When external sync signal is present, H is output) When reset (RST terminal = L), the dot clock signal (LC oscillator) is output. (It is not output when reset by the reset command) Enable signal for the serial data input is input to this terminal. The serial data input is enabled at L. Pull-up resistor is built-in. (Hysteresis input) Clock of the serial data input is input to this terminal. Pull-up resistor is built-in. (Hysteresis input) Serial data input terminal. Pull-up resistor is built-in. (Hysteresis input) Power supply for the composite video signal level adjustment. (Analog power supply) Composite video signal output terminal. Connected to GND or not connected. Composite video signal input terminal. Power supply. (+5V digital power supply) Video signal for the internal sync separator circuit is input to this terminal. (When the internal sync separator circuit is not used, the horizontal sync signal or composite sync signal is input to this terminal) Internal sync separator circuit bias voltage monitoring terminal. The composite sync output signal of the internal sync separator circuit is output from this terminal. (H: MOD 1. H: during internal sync mode. L: during external sync mode) (When internal sync separator circuit is not used, the SYN IN input signal is output from this terminal) The output signal of the SEP OUT terminal is integrated so that the vertical sync signal is input to this terminal. An integrator circuit must be connected between the SEP OUT terminal and this terminal. When this terminal is not used, it must be connected to VDD1. When selecting any of the NTSC or PAL or PAL-M or PAL-N system, the pin setting has priority. When L, the NTSC system is selected after resetting. Selection of either NTSC or PAL or PAL-M or PAL-N system by the command becomes effective. H: PAL-M system. ______________ ______________ Controls whether or not to input the VSYNC signal to the SEPIN input. L: to input the VSYNC ______________ signal. H: not to input the VSYNC signal. System reset input terminal. Pull-up resistor is built-in. (Hysteresis input) VSS1 Xtal IN Xtal OUT CTRL1 BLANK OSC IN OSC OUT CHARA ______ CS SCLK SIN VDD2 CV OUT NC CV IN VDD1 SYN IN SEP C SEP OUT SEP IN CTRL2 CTRL3 ________ RST 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 IC DESCRIPTION-5/7 (LC74781M)-1/2 — I O I O I O O I I I — O — I — I — O I I I I Pin No. Pin Name I/O Description www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -35- 24 Pin No. Pin Name I/O Description VDD1 — Power supply. (+5V digital power supply) IC DESCRIPTION-5/7 (LC74781M)-2/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -36- 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 IC DESCRIPTION-6/7 (µPD78016FGC-578-AB8)-1/2 RBPLS AMUTE GFS XVCDMD MD2 EMPH SQSO SQCK VSS SWNT SWAUTO SWPAL EMERG MJSW NC LPCSEL LOCK DMUTE SENS XCDRST DATA XLAT CLOK VSS FOK SENS2 XBUSY MPGON AC/DC CDLID TST0 TST1 TST2 TST3 RESET HRDY XHINT RWSEL SCOR VDD XO RADIAL BALANCE PLUS. AUDIO ANALOG MUTE. (H=MUTE ON) GFS. AUDIO/VIDEO CD MODE. (L=VCD=SPINDLE GAIN UP) DOUT MUTE CONT. EMPHASIS. SQDATA FROM CD. SQCLK TO CD. GND. SW TV OUT MODE. (L=NTSC) SW TV OUT MODE. (L=NTSC/PAL AUTO) SW TV OUT MODE. (L=PAL) POWER EMERGENCY STOP. (Ln3sec=STOP) MIC DETECTION INPUT. (L=MIC IN) Not used. (Connected to GND) “LPC ON/OFF (H=ON, NORMAL)”. GFS (FRAME SYNC) LOCK. (NO USE=H) (Not connected) DIGITAL DATA OUT MUTE. DSP SENS1 FROM CD. CD RESET. DATA TO CD. XLT TO CD. CLK TO CD. GND. FOCUS OK. SSP SENS2 FROM CD. READY/BUSY I/O TO HOST OD. MPEG POWER CONTROL OUTPUT. H=VCD. (Not connected) AC/DC DETECTION INPUT. H=AC. CD LID SWITCH STATUS INPUT. H=OPEN. CHECK LAND. RESET. HRDY FROM CL680. XHINT FROM CL680. CD-RW SELECT1. L=CD-RW. SCOR FROM CD. 5.0VDD. 8.0MHz CERALOCK. O O I O O I I O — I I I I I I I O O I O O O O — I I I/O O I I I/O I/O I/O I/O I I I O I/O — O Pin No. Pin Name I/O Description www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -37- XI VSS XT2 XT1 AVSS XMPGRST HSEL INLSW NC OSDXCS ABSEL CLVSEL AADSEL AVDD AVREF HDOUT HDIN HCK OSDDATA OSDCLK COMMAND STATUS SCK 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 8.0MHz CERALOCK. GND. Not connected. 5.0VDD. GND. MPEG BLOCK IC RESET. ADDRESS/DATA SEL TO CL680. INSIDE LIMIT SW. Not connected. OSD CHIP SELECT. CXA1992A/B SELECT. (L=CXA1992A) CLV MODE SELECT. (H=CLV-N) (Not connected) AUTO ADJUST SELECT. (H=AUTO ON) (Not connected) 5.0VDD. HD-OUT FROM CL680. HD-IN FROM CL680. HCK TO CL680. OSD DATA. OSD CLOCK. COMMAND FROM HOST. STATUS TO HOST. SCK FROM HOST. I — — I — O O I — O I I I — — I O O O O I O I Pin No. Pin Name I/O Description IC DESCRIPTION-6/7 (µPD78016FGC-578-AB8)-2/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -38- MUTE DEEM CKO DVSS BCKI DI DVDD LRCI TSTN TO1 AVDDL LO AVSS RO AVDDR MUTEO XVDD XTI XTO XVSS DS RSTN MODE ATCK Pin No. Pin Name I/O Description 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 I I O — I I — I I O — O — O — O — I O — I I I I MODE = H: Soft mute ON/OFF terminal. (Mute at H) MODE = L: Attenuator level DOWN/UP terminal. (DOWN at H) De-emphasis ON/OFF terminal. (De-emphasis ON at H) Oscillator clock output. (16.9344 MHz) Digital VSS terminal. Bit clock input terminal. Serial data input terminal. Digital VDD terminal. Sample rate clock (fs) input terminal. (H = L ch/L = R ch) Test input. (“H” or open during normal operation) (Not connected) Test output 1. (Normally low level output) (Not connected) Analog VDD terminal. (For L ch) Left channel analog output terminal. Analog VSS terminal. Right channel analog output terminal. Analog VDD terminal. (For R ch) Infinity zero detection output. X’tal system VDD terminal. X’tal oscillator terminal. (Or external clock input terminal of 16.9344 MHz) X’tal oscillator terminal. X’tal system VSS terminal. Double-speed/normal playback selection. (Double-speed at H) Reset terminal. (Reset at L) Soft mute/Attenuator mode selection. (Soft mute at H) (Not connected) Attenuator level setup clock (Ignored when MODE = H) (Not connected) IC DESCRIPTION-7/7 (SM5878AM)-1/1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -39- MECHANICAL EXPLODED VIEW-1/1 A A E D D A A A B G A H A A A F F A E C A E E E E G B A A 17 18 15 13 6 PWB PWB PWB PWB PWB 16 19 11 50 10 21 35 28 30 31 39 38 a a 32 25 26 53 34 36 33 20 24 SH, DIFFUSION SH, REFRECTOR 12 5 2 7 3 8 9 49 51 48 22 46 1 4 LCD BINDER WIRE BINDER WIRE TN-21ZSC CHAS, MAIN HT-SINK HT-SINK, RIG 30 43 42 41 40 37 45 44 27 52 23 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -40- REF. NO PART NO. KANRI DESCRIPTION NO. REF. NO PART NO. KANRI DESCRIPTION NO. MECHANICAL PARTS LIST-1/1 1 8A-CJB-044-010 WINDOW,CASS (S) 2 8A-CGC-005-010 LID,CASS 3 8A-CJB-221-010 SPR-T,CASS 4 8A-CJB-020-010 KNOB,RTRY JOG 5 8A-CLC-028-010 WINDOW,DISP (DS) 6 8A-CGC-004-010 CABI,FRONT 7 8A-CJB-061-010 CUSH,FOOT MAIN 8 8A-CJB-019-010 KEY,CASS 9 8A-CJB-207-010 HLDR,KEY CASS 10 86-NFZ-231-010 DMPR,70 11 8A-CLC-207-010 SPR-P,REC 12 8A-CJB-012-010 WINDOW,RC 13 8A-CJB-210-010 COVER,LED 15 8A-CJB-218-010 PLATE,REFRECTOR 16 8A-CJB-208-010 GUIDE,LCD 17 88-908-101-110 FF-CABLE, 8P 1.25 10MM 18 88-907-121-110 FF-CABLE, 7P 1.25 120MM 19 8A-CGC-009-010 COVER, KEY FUNC 20 8A-CLC-002-010 KEY,CONT A 21 8A-CGC-014-010 KEY,CONT B MASK 22 8A-CJB-625-010 CONN ASSY,10P DECK 23 8A-CLC-610-010 CONN ASSY,3P POWER 24 8A-CJB-003-010 PANEL,L 25 8A-CJB-626-010 CONN ASSY,2P CD DOOR 26 8A-CGC-609-010 FF-CABLE,7P 1.25 250MM 27 8A-CGC-608-010 FF-CABLE,16P 1.0 150MM 28 8A-CJB-623-010 CONN ASSY,6P CD MOTOR 30 88-CH6-220-010 CUSHION,CD A 31 M8-ZZK-E90-070 DA11T3C 32 8Z-CDB-169-010 PANEL,CD SANYO 33 8A-CJB-206-010 HLDR,CHAS CD R 34 87-036-389-010 SW,PUSH LOCK 35 8A-CJB-205-010 HLDR,CHAS CD L 36 8Z-NF6-210-010 DMPR,150 N 37 8A-CLC-206-010 SPR-T,CD 38 88-CD9-211-210 RING,CHUCK 39 8Z-CDB-170-010 BASE,CHUCK 40 8A-CLC-026-010 LID,CD (DS) 41 87-036-368-010 MAGNET 42 84-CT5-209-010 PLATE,MAGNET 43 8A-CJB-042-010 WINDOW,CD (S) 44 8A-CJB-005-010 CHAS,CD 45 8A-CGC-003-010 PANEL,REAR H 46 8A-CJB-004-010 PANEL,R ! 48 87-A80-083-010 AC CORD,HC BLK ! 49 87-085-185-010 BUSHING, AC CORD (E) 50 87-A90-193-010 HLDR,CV100 (B) 51 8Z-NB8-240-010 COVER, PL 52 87-A91-894-010 F-BEAD, E2010JET 53 8A-CGC-201-010 HLDR,SW SL A 87-067-703-010 TAPPING SCREW, BVT2+3-10 B 87-723-095-410 QT2+3-8 BLK C 87-253-033-110 SCREW,U+2-4 D 8A-CK4-223-010 S-SCREW,CD E 87-B10-230-010 BVT2+3-10 W/O SLOT SILVER CR F 87-067-586-010 TAPPING SCREW, BVT2+4-8 G 87-078-150-010 BVT2+3-6 SIL H 87-571-032-410 VIT+2-3 NOTE: No.14, 29 and 47 are not used. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -41- COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange GM Metallic Green YM Metallic Yellow DM Metallic Orange PT Transparent Pink LA Aqua Blue GL Light Green www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -42- TAPE MECHANISM EXPLODED VIEW-1/1 (TN21ZSC) b c a a b c J L F G E LUG PLATE 6 2 1 3 4 5 11 10 8 9 46 47 21 20 18 19 22 23 24 26 27 28 29 14 15 16 17 49 34 35 36 51 13 C C 30 7 25 37 38 48 B 50 45 44 K I D D 39 40 41 42 43 B H A 32 31 33 12 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -43- REF. NO PART NO. KANRI DESCRIPTION NO. TAPE MECHANISM PARTS LIST-1/1 (TN21ZSC) 1 S1-921-030-4A0 HEAD BASE 2 S1-821-030-070 AZIMUTH SPRING 3 S1-921-030-090 PANEL P SPRING 4 S1-921-260-050 GEAR PLATE SPRING 5 S1-921-265-020 GEAR PLATE ASSY 6 S6-201-011-110 HEAD,RP7442ES-0951 7 S1-921-015-010 CHASSIS ASSY 8 S1-921-030-110 HEAD PANEL 9 S1-921-143-160 BASE ASSY 10 S1-921-141-8A0 M CONTROL SPRING 11 S1-921-260-4A0 SENSING LEVER 12 S1-921-043-100 PINCH ROLLER ARM ASSY 13 S1-921-130-020 EJECT SLIDE LEVER 14 S1-921-141-3A0 P CONTROL SPRING 15 S1-921-140-550 PAUSE LEVER(E) 16 S1-921-140-120 PAUSE LEVER SPRING 17 S1-921-140-110 PAUSE STOPPER 18 S1-921-140-150 BUTTON LEVER SPRING(B) 19 S1-821-011-590 E KICK LEVER 20 S1-921-141-070 BUTTON LEVER SPRING(A) 21 S6-401-011-490 LEAF SW MSW-1541T 22 S1-921-140-090 SWITCH ACTUATOR 23 S1-921-140-080 PUSH BUTTON ACTUATOR 24 S1-921-140-230 PLAY BUTTON LEVER 25 S6-401-011-610 LEAF SW MSW-17820MVEI 26 S1-921-140-240 REW BUTTON LEVER 27 S1-921-140-250 FF BUTTON LEVER 28 S1-921-140-260 STOP BUTTON LEVER 29 S1-921-140-610 PAUSE BUTTON LEVER 30 S1-821-100-700 FF GEAR 31 S1-921-050-060 SENSER 32 S1-921-053-100 TAKE UP REEL ASSY 33 S1-829-100-010 PACK SPRING 34 S1-921-050-150 S REEL HUB 35 S1-921-050-220 BACK TENSION SPRING REF. NO PART NO. KANRI DESCRIPTION NO. 36 S1-921-140-220 REC BUTTON LEVER 37 S1-921-140-170 P.S.LEVER SPRING 38 S1-921-073-040 RF CLUTCH ASSY 39 S1-921-070-030 RF BELT 40 S1-921-260-020 CAM GEAR 41 S1-921-140-160 E ACTUATOR SPRING 42 S1-921-093-210 FLYWHEEL ASSY 43 S1-921-090-380 MAIN BELT 44 S1-921-120-590 MOTOR PULLEY 45 S6-002-030-220 MOTOR EG530AD-2B 46 S6-209-100-100 E HEAD PH-K380-MS1 47 S1-921-030-050 MG ARM 48 S1-921-140-210 REC BUTTON LEVER SPRING 49 S1-821-100-690 RECORD SAFETY LEVER 50 S1-821-128-9A0 MOTOR BRACKET 51 S1-821-010-500 PLAY BUTTON LEVER SPRING A S9-P04-200-310 C TAPPING SCREW 2-3 B S1-921-120-020 MOTOR COLLER SCREW C S9-B10-200-510 P TAPPING BIND SCREW M2-5 D S9-C07-204-510 SCREW,TAPPING(CAMERA)M2-4.5 E S9-P01-200-610 SCREW,M2-6 F S9-B01-200-310 (+)BIND SCREW M2-3 G S9-F08-200-710 AZIMUTH SCREW M2-7 H S1-921-120-030 MB SCREW I S9-W02-300-100 P WASHER CUT 1.2-3.8-0.3 J S9-W02-500-100 P WASHER CUT 1.45-3.8-0.5 K S9-W01-400-100 P WASHER 2-3.5-0.4 L S9-W01-130-200 P WASHER 2.1-4-0.13 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -44- CD MECHANISM EXPLODED VIEW-1/1 (DTA11T3C) A M2 PIN 3 SW1 MOTOR C.B 4 3 2 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -45- REF. NO PART NO. KANRI DESCRIPTION NO. CD MECHANISM PARTS LIST-1/1 (DTA11T3C) 1 M8-ZZK-E90-070 DA11T3C 2 S2-121-A28-400 COVER GEAR 3 S2-511-A21-000 GEAR MIDDLE 4 S2-511-A21-100 GEAR,DRIVE A S1-PN2-03R-OSE SCR PAN PCS 2-3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -46- REF. NO PART NO. KANRI DESCRIPTION NO. SPEAKER PARTS LIST-1/1 1 8A-CJB-632-010 SPKR,100MM 4OHM 2 8A-CJB-021-010 CABI,SPKR FR 3 8A-CJB-023-110 PANEL,SPKR 4 8A-CJB-220-010 HLDR,SPKR REAR 5 8A-CJB-204-010 HLDR,SPKR WIRE 6 8A-CJB-627-010 CORD,SPKR 7 8A-CJB-027-010 CUSH,FOOT A 87-067-698-010 BVT2+3-18(W/O,SLOT) B 87-067-703-010 TAPPING SCREW, BVT2+3-10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com -47- REF. NO PART NO. KANRI DESCRIPTION NO. ACCESSORIES/PACKAGE LIST-1/1 1 8A-CGC-911-010 IB,H(EC-K)B 2 87-A90-030-010 ANT,LOOP AM-NC C 3 87-043-115-010 ANT,FEEDER FM 4 8Z-CG8-952-010 RC UNIT,RC-ZAT05 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 737004 Printed in Singapore www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
