SERVICE MANUAL DATA BASIC TAPE MECHANISM : OVD-6S STEREO VIDEO CASSETTE RECORDER HV-FX8100 S/M Code No. 09-004-344-7N1 U 120V AC, 60Hz 12W TYP 2.5W (standby mode) 3.2kg (7.1lbs.) 360mm (W) x 232.5mm (D) x 94mm(H) (14 1/4 x 13 1/8 x 3 3/4 in.) 5°C to 40°C Rotary 2 head helical scanning system NTSC color system, 525 lines, 60 fields Double azimuth 4 heads VHS video cassette VHF: 2 to 13 UHF: 14 to 69 CATV: 5A, A-5 to A-1, A to W, W+1 to W-84 VHF channel 3 or 4 (switchable), 66dBµ 230 lines (at SP) Frequency synthesized tuner M Approx.110 seconds with T-120 tape More than 90dB (at SP) SPECIFICATIONS SP: 33.35 mm/sec LP: 16.67 mm/sec SLP: 11.12 mm/sec SP: 3.5 hours with T-210 tape LP: 7 hours with T-210 tape SLP: 10.5 hours with T-210 tape 1.0Vp-p, 75ohm, unbalanced 1.0Vp-p, 75ohm, unbalanced 50dB (nominal) –8dBs, 50K ohm –8dBs, less than 1K ohm 3 tracks (Hi-Fi sound 2 tracks, Normal sound 1 track) Normal: 100Hz-10kHz (at SP) Hi-Fi: 20Hz-20kHz (at SP) Normal: more than 42 dB (at SP) TAPE SPEED ...................................... RECORDING/PLAYBACK TIME ........ VIDEO INPUT...................................... VIDEO OUTPUT ................................. VIDEO S/N .......................................... AUDIO INPUT ..................................... AUDIO OUTPUT ................................. AUDIO TRACK .................................... AUDIO FREQUENCY RESPONSE .... AUDIO S/N .......................................... POWER REQUIREMENTS ................. POWER CONSUMPTION ................... WEIGHT .............................................. DIMENSIONS ...................................... OPERATING TEMPERATURE ........... VIDEO RECORDING SYSTEM .......... VIDEO SIGNAL SYSTEM ................... VIDEO HEAD ...................................... USABLE CASSETTES ........................ CHANNEL COVERAGE ...................... RF OUTPUT ........................................ HORIZONTAL RESOLUTION ............ TUNER SYSTEM ................................ TV SYSTEM ........................................ FAST-FORWARD/REWIND TIME ...... HI-FI DYNAMIC RANGE ..................... Design and specifications are subject to change without notice. • www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TABLE OF CONTENTS SPECIFICATIONS .............................................................................................................................................................. TABLE OF CONTENTS ..................................................................................................................................................... SERVICING NOTICES ON CHECKING ............................................................................................................................. IMPORTANT NOTICE ........................................................................................................................................................ DISASSEMBLY INSTRUCTIONS REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS ........................................................................................... REMOVAL OF DECK PARTS .......................................................................................................................................... KEY TO ABBREVIATIONS ................................................................................................................................................. SERVICE MODE LIST ....................................................................................................................................................... PREVENTIVE CHECKS AND SERVICE INTERVALS ....................................................................................................... NOTE FOR THE REPLACING OF MEMORY IC ................................................................................................................ SERVICING FIXTURES AND TOOLS ................................................................................................................................ PREPARATION FOR SERVICING ..................................................................................................................................... VCR TEST TAPE INTERCHANGEABILITY TABLE ........................................................................................................... MECHANICAL ADJUSTMENTS CONFIRMATION AND ADJUSTMENT............................................................................................................................ CONFIRMATION AND ADJUSTMENT OF TAPE RUNNING MECHANISM .................................................................. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE ............................................................................................. ELECTRICAL ADJUSTMENTS BASIC ADJUSTMENTS ................................................................................................................................................... ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE ............................................................................................. TROUBLESHOOTING GUIDES.......................................................................................................................................... IC DESCRIPTIONS ............................................................................................................................................................ SERVO TIMING CHART .................................................................................................................................................... SYSTEM SWITCH MODE ................................................................................................................................................... SEMICONDUCTOR BASE CONNECTIONS ...................................................................................................................... BLOCK DIAGRAMS Y/C/AUDIO/CCD/HEAD AMP .......................................................................................................................................... TUNER ............................................................................................................................................................................ SYSTEM CONTROL ....................................................................................................................................................... HIFI/DEMODULATOR ..................................................................................................................................................... DISPLAY/OPERATION ................................................................................................................................................... POWER ........................................................................................................................................................................... DECK SCHEMATIC DIAGRAM........................................................................................................................................... OPERATION SCHEMATIC DIAGRAM ............................................................................................................................... PRINTED CIRCUIT BOARDS (OPERATION1/2/DECK) .................................................................................................... PRINTED CIRCUIT BOARDS (SYSCON) .......................................................................................................................... Y/C/AUDIO/CCD/HEAD AMP SCHEMATIC DIAGRAM ..................................................................................................... SYSTEM CONTROL SCHEMATIC DIAGRAM ................................................................................................................... TUNER SCHEMATIC DIAGRAM ........................................................................................................................................ HIFI/DEMODULATOR SCHEMATIC DIAGRAM ................................................................................................................ POWER SCHEMATIC DIAGRAM ....................................................................................................................................... DISPLAY SCHEMATIC DIAGRAM ..................................................................................................................................... INTERCONNECTION DIAGRAM ........................................................................................................................................ WAVEFORMS .................................................................................................................................................................... MECHANICAL EXPLODED VIEW ...................................................................................................................................... MECHANICAL REPLACEMENT PARTS LIST ................................................................................................................... ACCESSORY REPLACEMENT PARTS LIST .................................................................................................................... CHASSIS EXPLODED VIEW (TOP VIEW) ......................................................................................................................... CHASSIS EXPLODED VIEW (BOTTOM VIEW) ................................................................................................................. CHASSIS REPLACEMENT PARTS LIST ........................................................................................................................... ELECTRICAL REPLACEMENT PARTS LIST .................................................................................................................... A1-1 COVER A1-1 A2-1 A2-1 B1-1 B2-1~B2-5 C1-1, C1-2 C2-1 C3-1, C3-2 C4-1 C5-1 C5-1 C6-1 D1-1, D1-2 D1-2, D1-3 D1-4 D2-1 D2-2 E-1~E-28 F1-1~F1-3 F2-1 F2-2 G-1, G-2 H-1 H-2 H-3 H-4 H-5 H-6 I-1 I-2 I-3 I-4~I-6 I-7 I-8 I-9 I-10 I-11 I-12 I-13 J-1 K1-1 K1-2 K1-2 K2-1 K2-2 K2-3 K3-1, K3-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis and parts. Make sure to keep the indications and notices in the operation manual. 2. USE THE DESIGNATED PARTS The parts in this equipment have the specific characters of incombustibility and withstand voltage for safety. Therefore, the part which is replaced should be used the part which has the same character. Especially as to the important parts for safety which is indicated in the circuit diagram or the table of parts as a mark, the designated parts must be used. 3. PUT PARTS AND WIRES IN THE ORIGINAL POSITION AFTER ASSEMBLING OR WIRING There are parts which use the insulation material such as a tube or tape for safety, or which are assembled in the condition that these do not contact with the printed board. The inside wiring is designed not to get closer to the pyrogenic parts and high voltage parts. Therefore, put these parts in the original positions. PERFORM A SAFETY CHECK AFTER SERVICING 4. Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the portions which are deteriorated around the serviced places serviced or not. Check the insulation between the antenna terminal or external metal and the AC cord plug blades. And be sure the safety of that. A2-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS 1-1: TOP CABINET, FRONT CABINET AND OPERATION PCB (Refer to Fig. 1-1) 1. 2. 3. 4. 5. 6. 7. Remove the 4 screws 1. Remove the Top Cabinet in the direction of arrow (A). Disconnect the following connectors: (CP651 and CP652). Unlock the 7 supports 2. Remove the Front Cabinet in the direction of arrow (B). Remove the 4 screws 3 and remove the Operation 1 PCB. Remove the 4 screws 3 and remove the Operation 2 PCB. 1-3: DECK CHASSIS (Refer to Fig. 1-3) Remove the 3 screws 1. Remove the screw 2. Disconnect the following connectors: (CP1001, CP1002, CP1003, CP4001, CP4002 and CP4003). Remove the Deck Chassis in the direction of arrow. 1. 2. 3. 4. Bottom Plate Deck Chassis 1-4: SYSCON PCB AND JACK PLATE (Refer to Fig. 1-4) Remove the screw 1. Remove the Syscon PCB in the direction of arrow (A). Unlock the 2 supports 2. Remove the Jack Plate in the direction of arrow (B). 1. 2. 3. 4. Fig. 1-3 1 2 1 1 B1-1 1-2: FLAP (Refer to Fig. 1-2) 1. 2. Open Flap to 90˚ and flex in direction of arrow (A), at the same time slide in direction of arrow (B). Then lift in direction of arrow (C). (A) (C) (B) Flap Fig. 1-2 1 1 1 1 (A) 2 2 44 4 4 (B) 3 3 3 3 2 2 2 2 2 Operation 2 PCB Operation 1 PCB Top Cabinet Front Cabinet Fig. 1-1 Fig. 1-4 Syscon PCB (A) Jack Plate (B) Bottom Plate 1 2 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 2. REMOVAL OF DECK PARTS 2-1: TOP BRACKET (Refer to Fig. 2-1) Remove the 2 screws 1. Slide the 2 supports 2 and remove the Top Bracket. 1. 2. NOTE When you install the Top Bracket, install the screw (1) first, then install the screw (2). 1 (2) Top Bracket Top Bracket Main Chassis Main Chassis 2 1 (1) 2 Fig. 2-1 NOTE When you install the Tape Guide L, install as shown in the circle of Fig. 2-3-B. (Refer to Fig. 2-3-B) REC Lever Tape Guide L • The REC Lever is not installed on the Video Cassette Player. Fig. 2-3-B 2-4: CASSETTE HOLDER ASS'Y (Refer to Fig. 2-4) Move the Cassette Holder Ass'y to the front side. Push the Locker R to remove the Cassette Side R. Remove the Cassette Side L. 1. 2. 3. Main Chassis Main Chassis Cassette Side L Cassette Side R Locker R Fig. 2-4 2-5: CASSETTE SIDE L/R (Refer to Fig. 2-5) Unlock the 4 supports 1 and then remove the Cassette Side L/R. 1. • Screw Torque: 5 ± 0.5kgf•cm B2-1 2-2: FLAP LEVER/TAPE GUIDE R (Refer to Fig. 2-2) NOTE When you install the Cassette Side R, be sure to move the Locker R after installing. Cassette Side L Cassette Side R 1 1 1 Locker R 1 Fig. 2-5 Move the Cassette Holder Ass'y to the back side. Remove the Polyslider Washer 1. Remove the Flap Lever. Unlock the 3 supports 2 and remove the Tape Guide R. 1. 2. 3. 4. Fig. 2-2 2-3: TAPE GUIDE L (Refer to Fig. 2-3-A) Move the Cassette Holder Ass'y to the back side. Unlock the 2 supports 1 and remove the Tape Guide L. Remove the REC Lever. (Recorder only) 1. 2. 3. 1 Main Chassis Tape Guide L REC Lever Fig. 2-3-A • The REC Lever is not installed on the Video Cassette Player. 1 1 2 2 2 Tape Guide R Flap Lever Main Chassis www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 2-6: LINK ASS'Y (Refer to Fig. 2-6) Set the Link Ass'y to the Eject position. Remove the (A) side of the Link Ass'y first, then remove the (B) side. 1. 2. Main Chassis (A) Main Chassis Link Ass'y Fig. 2-6 2-7: LOADING MOTOR ASS'Y (Refer to Fig. 2-7) Remove the Link Lever. Remove the Dumper Spring. Remove the 2 screws 1. Unlock the support 2 and remove the Loading Motor Ass'y. Unlock the 2 supports 3 and remove the Deck PCB (BOT). 1. 2. 3. 4. 5. 2-9: TENSION ASS'Y (Refer to Fig. 2-9-A) Move the Inclined S Ass'y to the back side. Remove the Tension Spring. Unlock the support 1 and remove the Tension Arm Ass'y. Remove the Tension Adjust. Unlock the 2 supports 2 and remove the Tension Band Ass'y. Unlock the support 3 and remove the Tension Holder. Remove the SS Brake Spring. Remove the SS Arm Brake. 1. 2. 3. 4. 5. 6. 7. 8. 1 2 1 Loading Motor Ass'y Link Lever Main Chassis • Screw Torque: 5 ± 0.5kgf•cm Fig. 2-7 2-8: SENSOR COVER L3 (Refer to Fig. 2-8) Unlock the support 1 and remove the Sensor Cover L3. 1. Deck PCB (BOT) Link Ass'y (B) Dumper Spring 3 3 1 2 2 Tension Adjust Tension Band Ass'y Tension Spring Tension Arm Ass'y Tension Holder Inclined S Ass'y Fig. 2-9-A SS Brake Spring SS Arm Brake NOTE When you install the Tension Adjust, install as shown in Fig. 2-9-B. (Refer to Fig. 2-9-B) Fig. 2-9-B 2-10: T BRAKE ASS'Y (Refer to Fig. 2-10) Remove the T Brake Spring. Remove the T Brake Ass'y. 1. 2. T Brake Ass'y Fig. 2-10 Adjust the direction of the Marker to inside. T Brake Spring B2-2 Main Chassis Sensor Cover L3 1 Fig. 2-8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 2-11: S REEL/T REEL (Refer to Fig. 2-11) Remove the S Reel and T Reel. Remove the 2 Polyslider Washers 1. 1. 2. NOTE Do not touch the Pinch Roller. (Use gloves.) When you install the Pinch Roller Block, install as shown in the circle of Fig. 2-12-B. (Refer to Fig. 2-12-B) 1. 2. NOTE Take care not to damage the gears of the S Reel and T Reel. The Polyslider Washer may be remained on the back of the reel. Take care not to damage the shaft. Do not touch the section "A" of S Reel and T Reel. (Use gloves.) (Refer to Fig. 2-11) Do not adhere the stains on it. When you install the reel, clean the shaft and oil it (FL OIL #6115). (If you do not oil, noise may be heard in FF/ REW mode.) After installing the reel, adjust the height of the reel. (Refer to MECHANICAL ADJUSTMENT) 1. 2. 3. 4. 5. 6. S Reel 1 (A) T Reel (A) 1 Fig. 2-11 2-12: PINCH ROLLER BLOCK/P5-3 ARM ASS'Y (Refer to Fig. 2-12-A) Remove the P5 Spring. Remove the screw 1. Unlock the 2 supports 2 and remove the Cassette Opener. Remove the Pinch Roller Block, Pinch Roller Arm Spring, Pinch Roller Lever Ass'y and P5-3 Arm Ass'y. 1. 2. 3. 4. 1 2 2 P5 Spring Cassette Opener P5-3 Arm Ass'y Pinch Roller Block Pinch Roller Lever Ass'y Main Chassis Fig. 2-12-A Pinch Roller Arm Spring • Screw Torque: 5 ± 0.5kgf•cm B2-3 Fig. 2-12-B 2-13: A/C HEAD (Refer to Fig. 2-13-A) Remove the screw 1. Remove the A/C Head Base. Remove the 3 screws 2. Remove the A/C Head and A/C Head Spring. 1. 2. 3. 4. NOTE Do not touch the A/C Head. (Use gloves.) When you install the A/C Head Spring, install as shown in Fig. 2-13-B. (Refer to Fig. 2-13-B) When you install the A/C Head, tighten the screw (1) first, then tighten the screw (2), finally tighten the screw (3). 1. 2. 3. A/C Head 2 2 A/C Head Spring 1 (3) (1) 2 (2) A/C Head Base Spring Position Fig. 2-13-B 2-14: FE HEAD (RECORDER ONLY) (Refer to Fig. 2-14) Remove the screw 1. Remove the FE Head. 1. 2. 1 FE Head • The FE Head is not installed on the Video Cassette Player. • Screw Torque: 4 ± 0.5kgf•cm Fig. 2-13-A • Screw Torque: 4 ± 0.5kgf•cm (Screw 1) Fig. 2-14 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 1 2 E-Ring Middle Gear Main Cam Pinch Roller Cam Joint Gear P5 Cam Fig. 2-17-A NOTE When you install the Pinch Roller Cam, P5 Cam and Main Cam, align each marker. (Refer to Fig. 2-17-B) Pinch Roller Cam P5 Cam Main Cam Marker Check the hole of Main Chassis can be seen. Fig. 2-17-B 2-18: CLUTCH ASS'Y (Refer to Fig. 2-18) Remove the Polyslider Washer 1. Remove the Clutch Ass'y, Ring Spring and Coupling Gear. Unlock the 2 supports 2 and remove the Clutch Lever. 1. 2. 3. 2-16: CAPSTAN DD UNIT (Refer to Fig. 2-16) Remove the Capstan Belt. Remove the 3 screws 1. Remove the Capstan DD Unit. 1. 2. 3. • Screw Torque: 5 ± 0.5kgf•cm Fig. 2-16 2-17: MIDDLE GEAR/MAIN CAM (Refer to Fig. 2-17-A) Remove the Polyslider Washer 1, then remove the Middle Gear. Remove the E-Ring, then remove the Main Cam, P5 Cam and Pinch Roller Cam. Remove the Polyslider Washer 2, then remove the Joint Gear. 1. 2. 3. Capstan DD Unit Capstan Belt 1 1 1 Fig. 2-18 1 Clutch Ass'y Ring Spring Coupling Gear Clutch Lever 2 2 B2-4 2-15: AHC ASS'Y/CYLINDER UNIT ASS'Y (Refer to Fig. 2-15) Unlock the support 1 and remove the AHC Ass'y. Remove the 3 screws 2. Remove the Cylinder Unit Ass'y. 1. 2. 3. When you install the Cylinder Unit Ass'y, tighten the screws from (1) to (3) in order while pulling the Ass'y toward the left front direction. NOTE 1 AHC Ass'y Cylinder Unit Ass'y 2 2 2 • Screw Torque: 3 ± 0.5kgf•cm Fig. 2-15 (1) (3) (2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS 2-19: LOADING GEAR S/T ASS'Y (Refer to Fig. 2-19-A) 1. 2. 3. 4. 5. 6. 7. 8. 9. 1 2 Capstan Brake Spring Capstan Brake Ass'y Main Rod Main Loading Gear Tension Lever Loading Gear T Loading Gear Spring Loading Arm T Ass'y Loading Gear S Loading Gear Spring Loading Arm S Ass'y LED Reflecter Idler Arm Ass'y Clutch Actuator Remove the E-Ring 1 and remove the Main Loading Gear. Remove the Capstan Brake Spring. Slide the Main Rod and remove the Capstan Brake Ass'y. Remove the Main Rod, Tension Lever, Clutch Actuator, Idler Arm Ass'y. Remove the screw 2. Remove the LED Reflecter. Remove the Loading Arm S Ass'y and Loading Arm T Ass'y. Remove the Loading Gear S and Loading Gear T. Remove the Loading Gear Spring. 2. When you install the Clutch Actuator, install as shown in the circle of Fig. 2-19-C. (Refer to Fig. 2-19-C) Fig. 2-19-C Clutch Actuator NOTE Do not touch the roller of Guide Roller. B2-5 Fig. 2-20 Loading Gear Holder Inclined T P4 Cover Guide Roller Inclined S 1 2 3 4 4 Guide Roller 2-20: INCLINED S/T ASS'Y (Refer to Fig. 2-20) Unlock the support 1 and remove the P4 Cover. Remove the screw 2. Unlock the support 3 and remove the Loading Gear Holder. Remove the Inclined S. Remove the Inclined T. Remove the 2 screws 4, then remove the Guide Roller. 1. 2. 3. 4. 5. 6. • Screw Torque: 5 ± 0.5kgf•cm Fig. 2-19-A NOTES Loading Arm T Ass'y Main Loading Gear Marker Marker Loading Arm S Ass'y 1. When you install the Loading Arm S Ass'y, Loading Arm T Ass'y and Main Loading Gear, align each marker. (Refer to Fig. 2-19-B) Fig. 2-19-B • Screw Torque: 5 ± 0.2kgf•cm (Screw 2) • Screw Torque: 0.7 ± 0.2kgf•cm (Screw 4) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEY TO ABBREVIATIONS A B C D E F G H A/C ACC AE AFC AFT AFT DET AGC AMP ANT A.PB APC ASS'Y AT AUTO A/V BGP BOT BPF BRAKE SOL BUFF B/W C CASE CAP CARR CH CLK CLOCK (SY-SE) COMB CONV CPM CTL CYL CYL-M CYL SENS DATA (SY-CE) dB DC DD Unit DEMOD DET DEV E EF EMPH ENC ENV EOT EQ EXT F FBC FE FF FG FL SW FM FSC FWD GEN GND H.P.F : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Audio/Control Automatic Color Control Audio Erase Automatic Frequency Control Automatic Fine Tuning Automatic Fine Tuning Detect Automatic Gain Control Amplifier Antenna Audio Playback Automatic Phase Control Assembly All Time Automatic Audio/Video Burst Gate Pulse Beginning of Tape Bandpass Filter Brake Solenoid Buffer Black and White Capacitance, Collector Cassette Capstan Carrier Channel Clock Clock (Syscon to Servo) Combination, Comb Filter Converter Capstan Motor Control Cylinder Cylinder-Motor Cylinder-Sensor Data (Syscon to Servo) Decibel Direct Current Direct Drive Motor Unit Demodulator Detector Deviation Emitter Emitter Follower Emphasis Encoder Envelope End of Tape Equalizer External Fuse Feed Back Clamp Full Erase Fast Forward, Flipflop Frequency Generator Front Loading Switch Frequency Modulation Frequency Sub Carrier Forward Generator Ground High Pass Filter I K L M N O P R S H.SW Hz IC IF IND INV KIL L LED LIMIT AMP LM, LDM LP L.P.F LUMI. M MAX MINI MIX MM MOD MPX MS SW NC NR OSC OPE PB PB CTL PB-C PB-Y PCB P. CON PD PG P-P R REC REC-C REC-Y REEL BRK REEL S REF REG REW REV, RVS RF RMC RY S. CLK S. COM S. DATA SEG SEL SENS SER SI SIF SO SOL SP STB SW : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Head Switch Hertz Integrated Circuit Intermediate Frequency Indicator Inverter Killer Left Light Emitting Diode Limiter Amplifier Loading Motor Long Play Low Pass Filter Luminance Motor Maximum Minimum Mixer, mixing Monostable Multivibrator Modulator, Modulation Multiplexer, Multiplex Mecha State Switch Non Connection Noise Reduction Oscillator Operation Playback Playback Control Playback-Chrominance Playback-Luminance Printed Circuit Board Power Control Phase Detector Pulse Generator Peak-to Peak Right Recording Recording-Chrominance Recording-Luminance Reel Brake Reel Sensor Reference Regulated, Regulator Rewind Reverse Radio Frequency Remote Control Relay Serial Clock Sensor Common Serial Data Segment Select, Selector Sensor Search Mode Serial Input Sound Intermediate Frequency Serial Output Solenoid Standard Play Serial Strobe Switch C1-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEY TO ABBREVIATIONS S T U V X Y SYNC SYNC SEP TR TRAC TRICK PB TP UNREG V VCO VIF VP V.PB VR V.REC VSF VSR VSS V-SYNC VT X'TAL Y/C : : : : : : : : : : : : : : : : : : : : : Synchronization Sync Separator, Separation Transistor Tracking Trick Playback Test Point Unregulated Volt Voltage Controlled Oscillator Video Intermediate Frequency Vertical Pulse, Voltage Display Video Playback Variable Resistor Video Recording Visual Search Fast Forward Visual Search Rewind Voltage Super Source Vertical-Synchronization Voltage Tuning Crystal Luminance/Chrominance C1-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com C2-1 SERVICE MODE LIST This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. Method Operations Press both PLAY button and CH UP button on the set for more than 2 seconds. Initialization of the factory. NOTE: Do not use this for the normal servicing. PLAY/REC total hours are displayed on the FIP. Refer to the "PREVENTIVE CHECKS AND SERVICE INTERVALS" (CONFIRMATION OF USING HOURS). Can be checked of the INITIAL DATA of MEMORY IC. Refer to the "NOTE FOR THE REPLACING OF MEMORY IC". Adjusting of the Tracking to the center position. Refer to the "MECHANICAL ADJUSTMENT" (GUIDE ROLLER) and "ELECTRICAL ADJUSTMENT" (PG SHIFTER). Press the ATR button on the remote control for more than 2 seconds during PLAY. While pressing the CH UP button on the set, press the STOP button on the set for more than 2 seconds during PLAY. Make the short circuit between the test point of SERVICE and the GND. The EOT/BOT/Reel sensor do not work at this moment. Refer to the "PREPARATION FOR SERVICING" Adjust the PG SHIFTER automatically. Refer to the "ELECTRICAL ADJUSTMENT" (PG SHIFTER). While pressing the CH UP key on the set, press the FF key on the set for more than 2 seconds. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com C3-1 PREVENTIVE CHECKS AND SERVICE INTERVALS The following standard table depends on environmental conditions and usage. Unless maintenance is properly carried out, the following service intervals may be quite shortened as harmful effects may be had on other parts. Also, long term storage or misuse may cause transformation and aging of rubber parts. Parts Name Audio Control Head Notes Time 500 hours 1,000 hours 1,500 hours 2,000 hours 3,000 hours : Clean : Replace Full Erase Head (Recorder only) Capstan Belt Pinch Roller Capstan DD Unit Loading Motor Tension Band Capstan Shaft Tape Running Guide Post Cylinder Unit Clean those parts in contact with the tape. Clean the rubber, and parts which the rubber touches. Replace when rolling becomes abnormal. Clean the Head CONFIRMATION OF USING HOURS PLAY/REC total hours can be checked on the FIP. Total hours are displayed in 16 system of notation. (16 x 16 x 16 x thousands digit value) + (16 x 16 x hundreds digit value) + (16 x tens digit value) + (ones digit value) ADDRESS DATA 1. 2. 3. 4. 5. Turn on the POWER. While pressing the CH UP button on the set, press the FF button on the set for more than 2 seconds. Adjust the ADDRESS to "20" by SET +/- button and read the DATA. (This DATA becomes the thousands digit and hundreds digit value of the following formula.) Adjust the ADDRESS to "21" by SET +/- button and read the DATA. (This DATA becomes the tens digit and ones digit value of the following formula.) After the confirmation of using hours, turn off the power. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PREVENTIVE CHECKS AND SERVICE INTERVALS CLEANING NOTE After cleaning the heads with isopropyl alcohol, do not run a tape until the heads dry completely. If the heads are not completely dry and alcohol gets on the tape, damage may occur. 1. AUDIO CONTROL HEAD Wrap a piece of chamois around your finger. Dip it in isopropyl alcohol and clean the audio control head by wiping it horizontally. Clean the full erase head in the same manner. (Refer to the figure below.) Audio Control Head 2. TAPE RUNNING SYSTEM When cleaning the tape transport system, use the gauze moistened with isopropyl alcohol. 3. CYLINDER Wrap a piece of chamois around your finger. Dip it in isopropyl alcohol. Hold it to the cylinder head softly. Turn the cylinder head counterclockwise to clean it (in the direction of the arrow). (Refer to the figure below.) NOTE Do not exert force against the cylinder head. Do not move the chamois upward or downward on the head. Use the chamois one by one. Cylinder Head C3-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com NOTE FOR THE REPLACING OF MEMORY IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. C4-1 0A 54 43 00 64 64 4A 06 0B 37 86 33 08 08 0C 0C 00 +0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F INI 8C 68 5C 53 20 45 31 04 88 A5 9F 3A 00 10 BF 00 10 Table 1 1. 2. Turn on the POWER. While pressing the CH UP key on the set, press the FF key on the set for more than 2 seconds. ADDRESS and DATA should appear as FIG 1. ADDRESS DATA 3. 4. 5. 6. 7. 8. The unit will now have the correct DATA for the new MEMORY IC. Fig. 1 ADDRESS is now selected and should "blink". Using the SET + or - keys on the remote, step through the ADDRESS until required ADDRESS to be changed is reached. Press ENTER to select DATA. When DATA is selected, it will "blink". Again, step through the DATA using SET + or - until required DATA value has been selected. Pressing ENTER will take you back to ADDRESS for further selection if necessary. Repeat steps 3 to 6 until all data has been checked. When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SERVICING FIXTURES AND TOOLS C5-1 (For 2 heads model) VHS Alignment Tape JG001 JG001A JG001T JG100A Torque Tape (VHT-063) JG024A JG022 Master Plane JG153 X Value Adjustment Screwdriver JG005 Post Adjustment Screwdriver Part No. SV-TG0-030-000 (small) JG002B JG002E JG002F Adapter Dial Torque Gauge (10~90gf•cm) (60~600gf•cm) (For 4 heads model) VHS Alignment Tape JG001B JG001I JG001S (TTV-N2) (TTV-N12) (VN S-X6 ) 2 (TTV-N2) (TTV-N12) (VN S-X6 ) 1 Reel Disk Height Adjustment Jig Part No. Remarks JG001 Stair Steps, 7KHz (For 2 heads model) JG001A Color Bar, 1KHz (For 2 heads model) JG154 Cable Parts No. SJ-G15-400-000 3 3 JG001T X Value Adjustment (For 2 heads model) JG001B Stair Steps, 7KHz (For 4 heads model) JG001I Color Bar, 1KHz (For 4 heads model) JG001S X Value Adjustment (For 4 heads model) JG002B VSR Torque, Brake Torque (S Reel/T Reel Ass'y) JG002E Brake Torque (T Reel Ass'y) JG002F VSR Torque, Brake Torque (S Reel) JG005 Guide Roller Adjustment JG153 X Value Adjustment JG022/JG024A Reel Disk Height Adjustment Used to connect the test point of SERVICE and GROUND JG154 JG100A Playback Torque, Back Tension Torque During Playback Tentelometer PREPARATION FOR SERVICING Short circuit between TP1001 and Ground with the cable JG154. (Refer to MAJOR COMPONENTS LOCATION GUIDE) The EOT, BOT and Reel Sensor do not work at this moment. At that time, the STOP/EJECT button is available to insert and eject the Cassette Tape. 1. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TTV-P16 TTV-P7 TTV-P2 TTV-P1L TTV-P1 TTV-N7A TTV-N2 TTV-N1E TTV-N1 NTSC NTSC, Color, 1kHz, SP NTSC, Color, 1kHz, EP NTSC, Color, 1kHz, SP PAL, Color, 1kHz, SP PAL, Color, 1kHz, LP PAL, Stairsteps, 1kHZ, SP, HiFi, 1kHz NTSC, Stairsteps, 7kHz, SP NTSC, Stairsteps, 1kHz, SP, HiFi 400Hz TTV-N12 (SCV-1998) CH-2(3) CH-2(1) CH-2(4) CH-1B(3) CH-1B(4) CH-1B(1) CH-1B(4) *2 CH-1B(2) NTSC, Stairsteps, 1kHz, SP NTSC, Color, 1kHz, EP NTSC, Stairsteps, 7kHz, SP NTSC, Color, 1kHz, EP PAL, Stairsteps, 1kHz, SP CH-2(2) *3 PAL, Color, 1kHz, LP PAL, Stairsteps, 6kHz, SP PAL, Stairsteps, 6kHz, SP PAL, Color, No sound SP, HiFi 400Hz *1. Described in the order of color format. Video signal. Linear audio. Tape speed and Hi-Fi audio. *2. Use CH-1B (1) - (3) with models used exclusively in the SP mode. *3. Use CH-2 (3) and (4) when it is necessary to observe the chroma signal. There are two types of the new alignment tape CH-1B (for NTSC) and CH-2 (for PAL). On each tape four signals (1) - (4) are recorded for the times and in the order shown below. The TTV-MP1 (for M-PAL), TTV-MS1 (for MESECAM) and TTV-S1 (for SECAM) alignment tapes have the same contents as the previous tapes. (1) : 8min. ---> (2) : 2min. ---> (3) : 5min. ---> (4) : 5min. Method Contents*1 Model Model Contents*1 Application Now in use TYPE New TYPE No Changed. PB-Y Level/General electrical ADJ. Head ACE Height/Tilt ADJ. HiFi Audio PB Level ADJ. Switching position. (LP Model) FM Envelope ADJ. (LP Model) X-Value ADJ. (LP Model) Head ACE Azimuth ADJ. FM Envelope ADJ. (SP Model) X-Value ADJ. (SP Model) HiFi Audio PB Level ADJ. FM Filter ADJ. FM envelope ADJ. X-Value ADJ. Head ACE Azimuth ADJ. Switching position ADJ. PAL VCR TEST TAPE INTERCHANGEABILITY TABLE Switching position ADJ. PB-Y Level/General electrical ADJ. Head ACE Height/Tilt ADJ. PAL, Color, 400Hz, SP, HiFi 1kHz NTSC, Color, No sound SP, HiFi 400Hz C6-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D1-1 MECHANICAL ADJUSTMENTS 1. CONFIRMATION AND ADJUSTMENT Read the following NOTES before starting work. • • Place an object which weighs between 450g~500g on the Cassette Tape to keep it steady when you want to make the tape run without the Cassette Holder. (Do not place an object which weighs over 500g.) When you activate the deck without the Cassette Holder, short circuit between TP1001 and GND. (Refer to ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE) In this condition the BOT/EOT/Reel Sensor will not function. CONFIRMATION AND ADJUSTMENT OF REEL DISK HEIGHT 1-1: 1. 2. 3. 4. Turn on the power and set to the STOP mode. Set the master plane (JG022) and reel disk height adjustment jig (JG024A) on the mechanism framework, taking care not to scratch the drum, as shown in Fig. 1- 1-A. Confirm that "A" of the reel disk is lower than "B" of the reel disk height adjustment jig (JG024A) , and is higher than "C". If it is not enough height, adjust to 10(+0.2, -0) mm with the height adjustment washer. Adjust the other reel in the same way. Reel Disk Height Adjustment Jig (JG024A) Fig. 1-1-A Reel Disk Height Adjustment Washer 2.6x4.7xT0.13 2.6X4.7xT0.25 (B) (C) Master Plane (JG022) Fig. 1-1-B (A) 10(+0.2, -0)mm Master Plane (JG022) Reel Disk Height Adjustment Jig (JG024A) (A) Cut Position Fig. 1-2-B (B) Tension Adjust 1-3: CONFIRMATION OF PLAYBACK TORQUE AND BACK TENSION TORQUE DURING PLAYBACK Load a video tape (T-120) recorded in standard speed mode. Set the unit to the PLAY mode. Install the tentelometer as shown in Fig. 1-3. Confirm that the meter indicates 20 ± 2gf in the beginning of playback. 1. 2. • USING A CASSETTE TYPE TORQUE TAPE (JG100A) 1. 2. 3. After confirmation and adjustment of Tension Post position (Refer to item 1-2), load the cassette type torque tape (JG100A) and set to the PLAY mode. Confirm that the right meter of the torque tape indicates 60~110gf•cm during playback in SP mode. Confirm that the left meter of the torque tape indicates 25~40gf•cm during playback in SP mode. Tentelometer Video Tape Guide Roller P1 Post Fig. 1-3 1-2: CONFIRMATION AND ADJUSTMENT OF TENSION POST POSITION 1. 2. 3. Set to the PLAY mode. Adjust the Tension Adjust until the edge of the Tension Arm is positioning within 0.5mm range from the standard line center of Main Chassis. After this adjustment, confirm that the cut position is located in "A" area as shown in Fig. 1-2-B. If it is located in "B" area, adjust again. While turning the S Reel clockwise, confirm that the edge of the Tension Arm is located in the position described above. Fig. 1-2-A Standard line of Main Chassis Tension Adjust Tension Arm 0.5mm (Adjusting range) Standard line center of Main Chassis www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D1-2 MECHANICAL ADJUSTMENTS 1-4: CONFIRMATION OF VSR TORQUE Operate within 4~5 seconds after the reel disk begins to turn. Install the Torque Gauge (JG002F) and Adapter (JG002B) on the S Reel. Set to the Rewind mode. (Refer to Fig.1-4) Then, confirm that it indicates 120~180gf•cm. 1. 2. 3. NOTE Install the Torque Gauge on the reel disk firmly. Press the REW button to turn the reel disk. 1-5: CONFIRMATION OF REEL BRAKE TORQUE (S Reel Brake) (Refer to Fig. 1-4) Set to the STOP mode. Move the Idler Ass'y from the S Reel. Install the Torque Gauge (JG002F) and Adapter (JG002B) on the S Reel. Turn the Torque Gauge (JG002F) clockwise. Then, confirm that it indicates 60~100gf•cm. 1. 2. 3. 4. (T Reel Brake) (Refer to Fig. 1-4) Set to the STOP mode. Move the Idler Ass'y from the T Reel. Install the Torque Gauge (JG002E) and Adapter (JG002B) on the T reel. Turn the Torque Gauge (JG002E) counterclockwise. Then, confirm that it indicates 45~70gf•cm. 1. 2. 3. 4. Fig. 1-4 NOTE If the torque is out of the range, replace the following parts. Check item 1-4 1-5 Replacement Part Idler Ass'y/Clutch Ass'y T Brake Spring/Tension Spring 2. CONFIRMATION AND ADJUSTMENT OF TAPE RUNNING MECHANISM Tape Running Mechanism is adjusted precisely at the factory. Adjustment is not necessary as usual. When you replace the parts of the tape running mechanism because of long term usage or failure, the confirmation and adjustment are necessary. 2-1: GUIDE ROLLER Playback the VHS Alignment Tape (JG001 or JG001B). (Refer to SERVICING FIXTURE AND TOOLS) Connect CH-1 of the oscilloscope to TP4001 (Envelope) and CH-2 to TP1002 (SW Pulse). Press and hold the Tracking-Auto button on the remote control more than 2 seconds to set tracking to center. Trigger with SW Pulse and observe the envelope. (Refer to Fig. 2-1-A) When observing the envelope, adjust the Adjusting Driver (JG005) slightly until the envelope will be flat. Even if you press the Tracking Button, adjust so that flatness is not moved so much. Adjust so that the A : B ratio is better than 3 : 2 as shown in Fig. 2-1-B, even if you press the Tracking Button to move the envelope (The envelope waveform will begin to decrease when you press the Tracking Button). Adjust the PG shifter during playback. (Refer to the ELECTRICAL ADJUSTMENTS) 1. 2. 3. 4. 5. 6. 7. Torque Gauge/Adapter (JG002F/JG002B) T Reel S Reel Torque Gauge/Adapter (JG002E/JG002B) NOTE After adjustment, confirm and adjust A/C head. (Refer to item 2-2) Fig. 2-1-A Max A : B = 3 : 2 A Entrance Exit Max B Fig. 2-1-B CH-2 SW Pulse (TP1002) CH-1 Track CH-2 Track CH-1 Envelope (TP4001) Envelope CH-3 Audio (1) (2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D1-3 MECHANICAL ADJUSTMENTS 2-3: 2-2: When the Tape Running Mechanism does not work well, adjust the following items. CONFIRMATION AND ADJUSTMENT OF AUDIO/ CONTROL HEAD 1. 2. 3. 4. When the height is not correct, turn the screw 3 to adjust the height. Then, adjust the 1~3 again. Playback the VHS Alignment Tape (JG001 or JG001B). (Refer to SERVICING FIXTURE AND TOOLS) Confirm that the reflected picture of stamp mark is appeared on the tape prior to P4 Post as shown in Fig. 2-2-A. a) b) Turn the screw 2 to set the audio level to maximum. Confirm that the bottom of the Audio/ Control Head and the bottom of the tape is shown in Fig. 2-2-C. c) When the reflected picture is distorted, turn the screw 1 clockwise until the distortion is disappeared. When the reflected picture is not distorted, turn the screw 1 counterclockwise until little distortion is appeared, then adjust the a). Reflected picture of Stamp Mark Stamp Mark Audio/Control Head P4 Post Fig. 2-2-A Audio/Control Head 1 3 2 Fig. 2-2-B Tape Audio/Control Head Fig. 2-2-C 0.25±0.05mm TAPE RUNNING ADJUSTMENT (X VALUE ADJUSTMENT) Confirm and adjust the height of the Reel Disk. (Refer to item 1-1) Confirm and adjust the position of the Tension Post. (Refer to item 1-2) Adjust the Guide Roller. (Refer to item 2-1) Confirm and adjust the Audio/Control Head. (Refer to item 2-2) Connect CH-1 of the oscilloscope to TP4001, CH-2 to TP1002 and CH-3 to HOT side of Audio Out Jack. Playback the VHS Alignment Tape (JG001S or JG001T). (Refer to SERVICING FIXTURE AND TOOLS) Press and hold the Tracking-Auto button on the remote control more than 2 seconds to set tracking to center. Set the X Value adjustment driver (JG153) to the 4 of Fig. 2-2-B. Adjust X value so that the envelope waveform output becomes maximum. Check if the relation between Audio and Envelope waveform becomes (1) or (2) of Fig. 2-1-A. 1. 2. 3. 4. 5. 6. 7. 8. 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D1-4 MECHANICAL ADJUSTMENTS 3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE 5 6 7 8 9 10 1 2 3 4 1. Tension Adjust 2. Tension Arm 3. Guide Roller 4. P1 Post 5. Audio/Control Head 6. 7. 8. 9. 10. X value adjustment driver hole P4 Post T Brake Spring T Reel S Reel www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ELECTRICAL ADJUSTMENTS 1-1: PG SHIFTER Read and perform this adjustment when repairing the circuits or replacing electrical parts or PCB assemblies. D2-1 1. BASIC ADJUSTMENT CAUTION When replacing IC's or transistors, use only specified silicon grease (G746). (To prevent the damage to IC's and transistors.) CONDITIONS MODE-PLAYBACK Input Signal-Alignment Tape (JG001B) INSTRUCTIONS 1. 2. 3. 4. Connect CH-1 on the oscilloscope to TP1002 and CH-2 to TP4201. Playback the alignment tape. (JG001B) Press and hold the Tracking-Auto button on the remote control more than 2 seconds to set tracking to center. While pressing the CH UP button on the set, press the STOP button on the set for more than 2 seconds. If the indicator ATR disappear's, the adjustment is finished. (Refer to Fig. 1-1-A, B) 6.5H CH-1 CH-2 6.5H CH-2 CH-1 Fig. 1-1-A Fig. 1-1-B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D2-2 2. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE SYSCON PCB TU6001 T501 ELECTRICAL ADJUSTMENTS TP1001 J4201 TP4201 TP1002 TP4001 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-1 POWER DOES NOT TURN ON NO YES NO YES YES NO CHECK THE AROUND OF T501 AT PIN 11. CHECK IC1001. CHECK IC1001. CHECK Q509 AND Q513. IS COLLECTOR OF Q509 6V ? IS PIN 50 OF IC1001 0V ? DOES DISPLAY LIGHT ? www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-2 THE POWER SUPPLY CUTS INSERTING A CASSETTE AND PUSH PLAY BUTTON. YES NO YES NO NO YES DOES THE POWER CUT AFTER THREE SECONDS ? CHECK A TAPE LOADING, LOADING BELT, CAPSTAN DD UNIT AND CYLINDER UNIT. DOES THE POWER CUT AFTER ABOUT SIX SECONDS ? CHECK REEL SENSOR AND REEL BELT. DOES INTERMITTENTLY THE POWER CUT ? CHECK SAG OF REEL BELT, REEL SENSOR AND IC1001. CHECK THE POWER BLOCK. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-3 NO NO YES YES IN PLAYBACK, IS AT PIN 4 OF CP1001 ABOUT DC 12.6V ? CHECK AT 12.6V LINE, POWER BLOCK. IN PLAYBACK, IS AT PIN 7 OF CP1001 ABOUT DC 2.6V ? CHECK IC1001. CHANGE CYLINDER MOTOR. AT PLAYBACK AND RECORDING, CYLINDER MOTOR UNLOAD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-4 YES NO NO YES NO YES AUDIO SHAKES CHANGE AUDIO HEAD. AT PLAYBACK, IS INPUT ABOUT 0.4V AT PIN 9 OF IC1001 ? CHANGE CAPSTAN DD UNIT. AT PLAYBACK, IS PIN 3 OF CP1002 3V ? CHECK IC1001. CHECK AUDIO BLOCK. IS AUDIO HEAD SCRATCHED ? www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-5 NO YES NO YES NO YES YES NO THE CASSETTE TAPE CAN NOT BE INSERTED DOES WORM GEAR OF CASSETTE LOADING BLOCK MOVE ? CHECK WORM GEAR OF CASSETTE LOADING BLOCK. WHEN A CASSETTE CAN NOT INSERTED, IS PIN 25 OF IC1001 5V ? CHECK LED OF DECK, PHOTO SENSOR. WHEN A CASSETTE IS INSERTED, IS THE VOLTAGE BETWEEN PIN 3 AND PIN 4 OF CP1003 12V ? CHANGE LOADING MOTOR. WHEN A CASSETTE IS INSERTED, IS THE VOLTAGE AT PIN 67 OF IC1001 5V ? CHANGE IC1001. CHECK CIRCUIT OF LOADING MOTOR. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-6 YES NO NO YES NO YES WHEN INSERTING A CASSETTE, IT EJECTS IMMEDIATELY DOES ANOTHER CASSETTE INSERT ? DEFECTIVE CASSETTE OR CASSETTE LOADING BLOCK. DO SW1001 AND REC LEVER CORRECTLY SET ? CORRECTLY SW1001 AND REC LEVER SET. AFTER INSERTING CASSETTE, IS PIN 53 OF IC1001 0V ? CHECK SW1001. NO YES WHEN A CASSETTE IS INSERTED, IS THE VOLTAGE AT PIN 25 OF IC1001 5V ? CHECK IC1001. CHECK LOADING GEAR. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-7 NO YES CAN NOT FF/REW AT FF/REW ,DOES VOLTAGE AT PIN 71 OF IC1001 CHANGE ? CHECK DECK MECHANISM. CHECK LINE OF IC1001 AT PIN 29 AND PIN 30. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-8 NO NO YES YES NO YES NO YES NO YES TAPE LOADING IS OK, BUT UNLOADS IMMEDIATELY DOES CYLINDER ROTATE ? IS THE VOLTAGE AT PIN 4 OF CP1001 12.6V ? CHECK POWER BLOCK. AT PLAY, IS THE VOLTAGE AT PIN 7 OF CP1001 2.6 ? CHANGE CYLINDER UNIT. IS THERE HEAD SW PULSE AT TP1002 ? IS PG PULSE SIGNAL INPUTTED TO PIN 103 OF IC1001 ? CHANGE IC1001. CHECK REEL SENSOR. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-9 AT PLAY, THE PICTURE JITTERS VERTICAL MINUTELY IS FG WAVE OF CP1001 AT PIN 5 5V ? 5V YES NO NO YES CHANGE CYLINDER MOTOR. IS PIN 7 OF CP1001 2.6V ? CHANGE IC1001. CHANGE CYLINDER MOTOR. NO NO YES YES AT PLAY, THE PICTURE JITTERS IS FG WAVE OF CP1001 AT PIN 5 5V ? 5V CHANGE CYLINDER MOTOR. IS PIN 7 OF CP1001 2.6V ? CHANGE CYLINDER MOTOR. CHANGE IC1001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-10 AUTO TRACKING DOES NOT OPERATE IN AUTO TRACKING, IS THE VOLTAGE AT PIN 24 OF IC1001 MORE THAN DC 1.56V ? DOES THE CTL PULSE SIGNAL (ABOUT 1.0Vp-p) APPEAR AT PIN 7 OF IC1001 ? 1.0Vp-p NO NO YES YES CHECK CONTROL HEAD. CHANGE IC1001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-11 DOES CAPSTAN DD MOTOR ROTATE ? WHEN PLAYBACK, FF OR REW MODE IS ACTIVE ,UNIT STOPS IMMEDIATELY NO NO YES YES REFER TO SECTION "CAPSTAN DD MOTOR NOT ROTATING". IS THERE REEL SENSOR PULSE SIGNAL AT PIN 69 AND PIN 70 OF IC1001 ? CHECK Q1001 AND Q1002. CHANGE IC1001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-12 AT PLAY, PICTURE JITTERS HORIZONTALLY DOES A NOISE ON THE PICTURE APPEAR ? NO NO NO NO YES YES YES YES YES NO BY ADJUSTING THE MANUAL TRACKING UP/ DOWN BUTTONS, WILL THE LINE DISAPPEAR ? CHECK P/B ENVELOPE. IS A HEIGHT OF GUIDE POST MAXIMUM ? THE HEIGHT OF GUIDE POST READJUST. IS PG SHIFTER ADJUSTMENT 6.5H ? ADJUST PG SHIFTER. IS A WAVE OF PB-Y UNUSUAL ? CHECK THE CIRCUIT OF PB-Y. CHANGE IC1001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-13 NO YES NO YES NO YES NO NO YES YES NO AT PLAYBACK, THE PICTURE DOES NOT APPEAR DOES E-E PICTURE APPEAR ? IS THE VOLTAGE OF IC4001 AT PIN 21, 54, 56, 57, 75 AND 87 5V ? CHECK POWER BLOCK. CHECK IC4001. IS THERE VIDEO SIGNAL OF IC4001 AT PIN 35 ? YES IS THERE VIDEO SIGNAL OF IC1001 AT PIN 17 ? IS THERE VIDEO SIGNAL OF IC1001 AT PIN 19 ? IS THERE VIDEO SIGNAL EMITTER OF Q4201 ? CHECK JACK J4201. CHANGE Q4201. CHANGE IC1001. CHECK IC4001. CHANGE IC4001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-14 NO YES NO AT PLAYBACK ,THE COLOR DOES NOT APPEAR IS THERE VIDEO SIGNAL AT PIN 35 OF IC4001 ? CHECK IC4001. IS THERE COLOR SIGNAL IN VIDEO SIGNAL AT PIN 35 OF IC4001 ? CHECK IC4001. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-15 NO YES YES YES NO NO YES NO PLAYBACK PICTURE IS NOISY (EVEN AFTER CLEANING HEADS) IS NOISY A WAVE OF VIDEO SIGNAL AT PIN 35 OF IC4001 ? CHECK CYLINDER. IS NOISY A WAVE OF VIDEO SIGNAL AT PIN 17 OF IC1001 ? CHECK IC4001. IS NOISY A WAVE OF VIDEO SIGNAL AT PIN 19 OF IC1001 ? CHECK IC1001. IS NOISY A WAVE OF VIDEO SIGNAL OF EMITTER OF Q4201 ? CHECK Q4201. CHECK J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-16 NO NO NO YES YES YES IS THERE CHROMA SIGNAL AT PIN 40 OF IC4001 ? CHECK J4201, J601, CIRCUIT AROUND IT. IS THERE CHROMA SIGNAL AT PIN 35 OF IC4001 ? CHANGE IC4001. IS THERE CHROMA SIGNAL AT PIN 19 OF IC1001 ? CHANGE IC1001. CHECK CIRCUIT AROUND OF J4201. NO COLOR DURING SELF RECORDING AND PLAYBACK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-17 AT PLAY, AUDIO DOES NOT APPEAR NO NO NO YES NO YES YES YES AT E-E, DOES AUDIO APPEAR ? REFER TO SECTION "E- E DOES NOT APPEAR". IS THE VOLTAGE AT PIN 4 OF IC4001 ABOUT 2.5V ? CHECK C4024 AND AROUND CIRCUIT OF IT. IS THERE AUDIO SIGNAL AT PIN 96 OF IC4001 ? CHECK CIRCUIT AROUND AT PIN 97 OF IC4001. IS THERE AUDIO SIGNAL AT PIN 22 AND PIN 24 OF IC5501 ? CHECK CIRCUIT AROUND AT PIN 22 AND PIN 24 OF IC5501. CHECK WHETHER THERE ARE NOT A DAMAGE, DIRT IN AUDIO HEAD. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-18 NO NO NO YES YES YES CAPSTAN DD MOTOR NOT ROTATING IN PLAYBACK, IS THE VOLTAGE AT PIN 5 OF CP1002 12.6V ? CHECK POWER BLOCK. IS THE VOLTAGE AT PIN 8 OF CP1002 5V ? IN PLAYBACK, IS THE VOLTAGE AT PIN 4 CP1002 ABOUT 2V ? IS PIN 102 OF IC1001 ABOUT 2.5V ? CHANGE IC1001. DOES DD MOTOR ROTATE NOW ? IF NOT, REPLACE IT. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-19 THE AUDIO CAN NOT RECORD NO NO YES NO YES YES IS BIAS LEVEL AT T4001 OK ? IS THE VOLTAGE OF T4001 AT PIN 2 5V ? CHECK POWER BLOCK. IS THERE AUDIO SIGNAL AT PIN 5 OF T4001 ? CHECK A/C HEAD AND CIRCUIT AROUND OF IC4001. CHECK SNAPPING OF A WIRE IN T4001 AND CIRCUIT AROUND IT. NO YES NO NO YES YES IS THERE AUDIO SIGNAL AT PIN 80 OF IC4001 ? CHECK THE CIRCUIT FROM TUNER AND AUDIO INPUT JACK TO PIN 80 OF IC4001. IS THERE AUDIO SIGNAL AT PIN 97 OF IC4001 ? CHANGE IC4001. IS THERE AUDIO SIGNAL AT PIN 5 OF T4001 ? CHANGE IC4001. CHECK LEAD WIRE OF A/C HEAD AND CONNECTOR. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-20 NO NO YES YES THE CASSETTE INSERT, BUT THE TAPE DOES NOT MOVE DOES THE MODE APPEAR AT DISPLAY ? CHECK LOADING MOTOR AND MODE SENSOR RELATION DEPARTMENT. DOES OPERATE WITH REMOTE CONTROL ? CHECK IC1001. CHECK OPERATION PCB. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-21 NO NO NO YES YES YES NO YES IS THERE VIDEO SIGNAL AT PIN 40 OF IC4001 ? CHECK CIRCUIT OF VIDEO SIGNAL FROM VIDEO IN OR TUNER TO IC4001. IS BASE OF Q4003 5V ? IS PIN 90 OF IC1001 5V ? CHANGE IC1001. IS THERE VIDEO AT PIN 35 OF IC4001 ? CHANGE IC4001. CHECK THE CYLINDER UNIT AND CIRCUIT AROUND OF CP4001. RECORDING MECHANISM WORKS, BUT NO VIDEO RECORD FROM INPUT JACK OR TUNER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-22 NO YES NO YES NO YES NO YES NO YES E-E DOES NOT APPEAR (THE PICTURE DOES NOT APPEAR FROM TUNER) DOES NORMALITY AUDIO JACK CONNECT ? CONNECTION IS DONE OVER AGAIN. ARE THERE THE VOLTAGE OF MB(5V), BM(5V), PB5V(5V) TU32V(32V) ? CHECK POWER BLOCK. CHECK THE PICTURE. IS THERE VIDEO SIGNAL AT PIN 24 OF TU6001 ? CHANGE TU6001. IS THERE VIDEO SIGNAL AT PIN 35 OF IC4001 ? CHANGE IC4001. IS THERE VIDEO SIGNAL AT PIN 19 OF IC1001 ? CHANGE IC1001. CHECK J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-23 NO NO NO NO NO YES YES YES YES YES E-E AUDIO (MONO) DOES NOT APPEAR DOES E-E AUDIO (STEREO) APPEAR ? REFER TO SECTION "E-E AUDIO (STEREO) DOES NOT APPEAR". IS THE VOLTAGE AT PIN 21, 54, 56, 57, 75 AND 87 OF IC4001 5V ? CHECK POWER BLOCK. IS THERE PIN 92 OF IC1001 0V ? CHANGE IC1001. IS THERE AUDIO SIGNAL AT PIN 10 AND PIN 15 OF IC5501 ? CHANGE J601. IS THERE AUDIO SIGNAL AT PIN 53, 57, 59 AND 61 OF IC5501 ? CHANGE IC5501. CHECK CIRCUIT AROUND OF J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-24 NO NO NO NO YES YES YES YES E-E AUDIO (STEREO) DOES NOT APPEAR IS VOLTAGE AT PIN 25, 40 AND 51 5V ? CHECK POWER BLOCK. IS VOLTAGE AT PIN 58 12V ? CHECK POWER BLOCK. IS THERE AUDIO SIGNAL AT PIN 10 AND 15 OF IC5501 ? CHANGE J601. IS THERE AUDIO SIGNAL AT PIN 53, 57, 59 AND 61 OF IC5501 ? CHANGE IC5501. CHECK CIRCUIT AROUND OF J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-25 NO TUNER AUDIO (MONO) DOES NOT APPEAR YES YES YES NO NO DOES E-E AUDIO (MONO) APPEAR ? REFER TO SECTION "E-E AUDIO (MONO) DOES NOT APPEAR". IS THERE AUDIO SIGNAL AT PIN 48 OF IC5501 ? CHECK CIRCUIT AROUND OF TU6001 AT PIN 22. IS THERE AUDIO SIGNAL A COLLECTOR OF Q4203 AND Q4204 ? CHANGE Q4203 AND Q4204. CHECK CIRCUIT AROUND OF J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-26 NO YES NO YES NO YES NO NO YES YES TUNER AUDIO (STEREO) DOES NOT APPEAR DOES TUNER AUDIO (MONO) APPEAR ? REFER TO SECTION "TUNER AUDIO (MONO) DOES NOT APPEAR". DOES E-E AUDIO (STEREO) APPEAR ? REFER TO SECTION "E-E AUDIO (STEREO) DOES NOT APPEAR". AT THE TIME OF CHANNEL SWITCHING, DOES DISPLAY OF THE STEREO GO OUT THE SCREEN ? CHANGE IC5501. IS THERE AUDIO SIGNAL AT PIN 48 OF IC5501 ? CHECK CIRCUIT AROUND OF TU6001. IS THERE AUDIO SIGNAL AT PIN 53 AND 57 OF IC5501 ? CHANGE IC5501. CHECK CIRCUIT AROUND OF J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-27 PB AUDIO (HI-FI) DOES NOT APPEAR YES NO NO NO NO YES YES YES DOES E-E AUDIO (STEREO) APPEAR ? REFER TO SECTION "E-E AUDIO (STEREO) DOES NOT APPEAR". DOES NORMAL PB AUDIO APPEAR ? REFER TO SECTION "AT PLAY, AUDIO DOES NOT APPEAR". IS THERE AUDIO SIGNAL AT PIN 22 AND 24 OF IC5501 ? CHECK CIRCUIT OF HEAD AMP AND CYLINDER UNIT. IS THERE AUDIO SIGNAL AT PIN 53 AND 57 OF IC5501 ? CHANGE IC5501 . CHECK CIRCUIT AROUND OF J4201. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TROUBLESHOOTING GUIDE E-28 NO NO NO NO YES YES YES YES HI-FI AUDIO CAN NOT RECORD DOES E-E AUDIO APPEAR ? REFER TO SECTION "E-E AUDIO (MONO) DOES NOT APPEAR". IS THERE AUDIO SIGNAL AT PIN 10 AND 15 OF IC5501 ? CHECK CIRCUIT AROUND OF TU6001 AND J601. IS THERE AUDIO SIGNAL AT PIN 22 AND 24 OF IC5501 ? CHANGE IC5501. IS THERE A SIGNAL AT PIN 7, 8 AND 9 OF CP4001 ? CHECK IC4001. CHECK CYLINDER UNIT. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com IC DESCRIPTIONS OEC0090A (IC1001) No. PORT PIN NAME I/O DESCRIPTION 1 SVSS SVSS — Ground. 2 CTLREF CTLREF OUT Output terminal for AMP REFERENCE. 3 CTL(+) CTL(+) I/O Input and output terminal of Control Head. 4 CTL(-) CTL(-) I/O Input terminal of Control Head. 5 CTLBIAS CTLBIAS IN Input terminal for Control Bias. 6 CTLFB CTLFB IN Input terminal for Control Feedback. 7 CTLAMP(O) CTLAMP(O) OUT Output terminal for Control Amp Output. 8 CTLSMT(I) CTLSMT(I) IN Input terminal for Control SMT Input. 9 CFG CFG IN Input terminal for Capstan FG input. 10 SVCC SVCC — P.CON +5 V. 11 AFCPC AFCPC IN Condenser connection for AFC PC. 12 AFCOSC AFCOSC IN Condenser connection for AFC OSC. 13 AFCLPF AFCLPF IN Condenser connection for AFC LPF. 14 C.SYNC/H.SYNC C.SYNC OUT Output terminal for composite C SYNC. 15 V.SYNC V.SYNC IN Input terminal for video V.SYNC signal. 16 CVIN2 CVIN2 IN Input terminal for video signal. 17 CVIN1 CVIN1 IN Input terminal for video signal. 18 OSDVCC OSDVCC — AT +5 V. 19 CVOUT CVOUT OUT Output terminal for video signal. 20 OSDVSS OSDVSS — Ground. 21 4/2FSCOUT 4FSCOUT OUT 4 FSC pulse. 22 4/2FSCIN 4FSCIN IN 4 FSC pulse. 23 AVSS AVSS — Ground. 24 ANB VIDEO_ENV IN Input terminal of Video RF envelope. 25 ANA BOT IN Tape start sensor input signal. 26 AN9 EOT IN Tape end sensor input signal. 27 AN8 MSSEN_B IN Input terminal of mecha state sensor. 28 AN7 MSSEN_A IN 29 AN6 KEY_B IN Main unit key input. 30 AN5 KEY_A IN 31 AN4 STEREO SEL IN Input terminal of stereo selector. 32 AN3 Hi-Fi_ENV IN Input terminal of HIFI sound envelope signal. 33 AN2 AFT.S.CURVE IN AFT S.CURVE input for tuner. 34 P01/AN1 P01/AN1 IN Not used. 35 P00/AN0 P00/AN0 IN 36 AVCC AVCC — AT +5 V. 37 P10/IRQ0 POWER_FAIL IN 50/60 Hz pulse input made by AC power. 38 P11/IRQ1 NC OUT Not used. 39 P12 P12 IN AT +5 V. 40 P13 P13 IN 41 P14 P14 IN 42 P15 HEAT SW OUT Not used. 43 P16/IC REMOCON IN IN Receive the remote control signal input. F1-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com IC DESCRIPTIONS OEC0090A (IC1001) No. PORT PIN NAME I/O DESCRIPTION 44 P17 32KHz_MONITOR OUT Not used. 45 P67 OTPB_LED OUT Output terminal control for OTPB-LED voltage drive. 46 P66 STBY_LED OUT Not used. 47 P65 NC OUT 48 P64 CYL_SPEED_UP OUT Output terminal for correct cylinder during SLOW. 49 P63 MS_SENS_CTL OUT Output terminal to drive sensor control. 50 P62 POWER_ON-L OUT For control of the user power switch ON/OFF. 51 P63 POWER_ON-H OUT 52 P60 TRICK_PB/EE_H OUT Special effect playback.(CUE/REVIEW/STILL/SLOW etc) 53 P37 TAB_SW IN Input terminal for judge the tape if it has TAB or not. 54 P36 SERVICE IN Input terminal for Service Mode. 55 P35 FL_CS OUT Timing output of data transmission and receiving with FIP drive. 56 VCC VCC — AT +5V. 57 VSS VSS — Ground. 58 P27 NC OUT Not used. 59 SCL0 IIC_CLK_0 OUT Output Clock terminal for I2CBUS communivation. 60 SDA0 IIC_DATA_0 OUT Output Data terminal for I2CBUS communivation. 61 P24 NC OUT Not used. 62 P23 NC OUT 63 SCK1 FL_CLK OUT Timing output of data transmission and receiving with FIP drive. 64 SO1 SO1/FL_SD_OUT OUT Indication data and mode transmission to FIP drive. 65 SI1 SI1 IN Input terminal of DATA FZTAT input. 66 P47 NC OUT Not used. 67 P46 LDM_FWD OUT Output signal to control the rotation direction of the loading motor. 68 P45 LDM_RVS OUT 69 P44 REEL-S IN Input terminal of reel sensor SUPPLY. 70 P43 REEL-T IN Input terminal of reel sensor TAKE UP. 71 P42 CAP_FWD-L OUT Capstan forward and backward command. 72 P41 JUST_CLOCK_IN IN Not used. 73 P40 VV-H OUT Output terminal for select Playback/Recording at the circuit of sound. 74 FWE FWE IN Input terminal of FZTAT signal( L: low signal input). 75 X2 X2 OUT Subclock pluse (32.768KHz). 76 X1 X1 IN Subclock pluse (32.768KHz). 77 /RES /RES IN RESET will be done when the voltage goes to HIGH after the restart signal. 78 OSC1 OSC1 IN Connect the main crystal (10MHz). 79 VSS VSS — Ground. 80 OSC2 OSC2 OUT Connect the main crystal (10MHz). 81 VCL VCL IN Condenser connection for VCC. 82 MD0 MD0 IN Input terminal of FZTAT signal. 83 PWM2 CAP_LIMIT OUT Switch the maximum out put current of the CAPSTAN Motor 84 P33 CENT_LED OUT Output terminal for center LED control. 85 P32 CAP_HI-H OUT Output terminal for capstan speed high. 86 SV1 SV1 OUT Not used. F1-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com IC DESCRIPTIONS OEC0090A (IC1001) No. PORT PIN NAME I/O DESCRIPTION 87 SV2 SV2 OUT Not used. 88 P70 REC/EE/PB OUT Recording/Playback switch Head Amp. 89 P71 YC_DOC/XO_CTL OUT Set to XO mode or not at EE.Make effective the DOC or not at VV. 90 P72 V.REC.START-H OUT Output terminal for REC signal when record. 91 P73 SP-L/LP-M/EP-H OUT Valuse speed output Playback/Recording. 92 P74 AUDIO_MUTE-H OUT Mute signal of Audio mute. 93 P75 AUDIO_OUT_MUTE-L OUT L for at AUDIO MUTE and POWER OFF.H for except above case. 94 P76 INPUT_SEL OUT Control the Audio/Video input signal. 95 P77 EE-H OUT Output terminal for select Playback/Recording at the circuit of sound. 96 P80 TV/VCR-H OUT Output terminal of switch selector TV/VCR. 97 P81 TUNER-L OUT Output low at tuner and output high at external input/play. 98 P82 VIDEO_MUTE-H OUT Mute signal of Video mute. 99 C.ROT C.ROTARY OUT Color Rotary Control output. 100 H.AMP.SW H.AMP_SW OUT Switching output of Head Amp SW. 101 COMP COMP IN Comparison results input of Playback Envelope level on SP/LP Heads (4 Heads). 102 P85 CAP_FULL OUT Output the HIGH during the acceleration force of Capstan Motor at SLOW mode. 103 DPG DPG IN Input terminal for DRUM PG signal. 104 DFG DFG IN Input terminal for DRUM FG signal. 105 VIDEO FF VIDEO_H.SW OUT Output terminal of signal Video head switching. 106 AUDIO FF Hi-Fi_H.SW OUT Output terminal of signal HI-FI sound head switching. 107 DRUM PWM DRUM_PWM OUT Output terminal for PWM of Drum Motor. 108 CAP PWM CAP_PWM OUT Output terminal for PWM of Capstan Motor. 109 VPULSE DUMMY.V.SYNC OUT Output terminal of Video Pluse signal. 110 VSS VSS — Ground. 111 C.SYNC C.SYNC IN Input terminal for composite C SYNC. 112 VCC VCC — AT +5V. F1-3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SERVO TIMING CHART IC1001 (OEC0090A) F2-1 • WAVEFORM CHANGES DEPENDED ON THE TAPE SPEED DFG 104 PIN DPG 103 PIN V-SYNC (TRICK PB) 109 PIN REC CTL (REC) 7 PIN V-SYNC (E-E) 111 PIN H. SW. P 105 PIN CH 1 CH 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com LIGHT RECEIVING(H) FWD STP3 PB FWD PB FF/REW STB OFF SUB MAIN OFF OFF ON SYSTEM SWITCH MODE PB SLOW : SETTING SPEED TO SERVO FWD RVS EJECTION UNLOADING STP3 VSR F. SLOW PB/STP STP2 FF/REW LOADING DIRECTION (FWD) : CAPSTAN FWD ROTATING DIRECTION : CAPSTAN RVS ROTATING DIRECTION : MECHANICAL MOVEMENT AND CAPSTAN ROTATING : MECHANICAL MOVEMENT (NO CAPSTAN ROTATING) R. SLOW LIGHT GUARD LIGHT RECEIVING EOT BOT MSSEN A MSSEN B LOADING ARM PINCH ROLLER LIGHT RECEIVING LIGHT GUARD LIGHT RECEIVING LIGHT GUARD LIGHT GUARD (L) T BRAKE S BRAKE TENSION TAPE IN STP FF/FWD POWER OFF FF/REW STP HEAD CLEANING CLUTCH DIRECT CONNECTION CASSETTE DOWN FWD (WHEN MSSEN A IS CHANGED FROM LIGHT GUARD TO LIGHT RECEIVING, CASSETTE IN WILL BE DETECTED) TAPE LOADING FWD RVS (VCP) (VCR) PB/STP STP3 FF/REW PB/STP Maintains the Direct Connection for STOP2, too. F2-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SEMICONDUCTOR BASE CONNECTIONS DIODE 1SS133T-77 1N4005E-G23 TMPG06-12A-G3 1SS244T-77 SID1050CM SLZ-345B-02-T1 ENE271D-10A MTZJ13B T-77 21DQ04N-TA2B1 MTZJ27D T-77 RGP10JE-G3 MTZJ33B T-77 UG2D-G23 MTZJ5.1C T-77 MTZJ5.6C T-77 MTZJ6.8B T-77 IC 64PIN 32PIN 8PIN 3PIN 8PIN 100PIN AN3662FBP BU2977FS S-24C08ADPA-01 KIA431 BA6955AN LA71067M-MPB RE5VS31A 112PIN OEC0090A CATHODE ANODE CATHODE ANODE 1 1 1 1 23 1 1 G-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SEMICONDUCTOR BASE CONNECTIONS TRANSISTOR 2SA1015Y(TPE2) 2SC4160-OEC-YAC2SC2412KT146 R,STLP621(D4-GR-LF2RPI-352Q01R DTA114EKAT146 PNA2604M010R 2SA1318(S,T)-AA DTA124EKAT146 2SC1815Y(TPE2) DTC124EKAT146 2SC3331(S,T,U)-A 2SD1246(S,T)-AA 2SD734(E,F)-AA SG-260 E A K C E CB B CE E C B 1 E C K A G O I C E G-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Y/C/AUDIO/CCD/HEAD AMP BLOCK DIAGRAM H-1 X4001 3.579545MHz 40 100 98 97 25 42 96 28 85 83 82 5 7 46 4 6 44 59 55 30 19 14 13 93 2 1 3 78 76 H.AMP SW REC AMP FE HEAD (HOT) FE HEAD (GND) 2 1 CP4003 FE HEAD CP4002 6 5 4 AUDIO PB AUDIO REC CTL+ HEAD AUDIO CONTROL 3 2 1 AE HEAD(-) AE HEAD(+) CTL- CTL+ CTL- Q4008 BUFFER SYSCON Y/C/A/CCD/H.AMP IC IC4001 LA71067M-MPB TUNER 49 Q4009 BUFFER VX01 62 61 PULL 51 TIMMING 53 CCD OUT DRIVER CLAMP 47 16 17 15 12 11 34 31 35 84 H.SW 88 90 91 89 H.SW H L H L H L PB.EE P R WC DC DETAL ENH NL EMPHA REC FM-EQ FM MOD P R AGC AMP KIL FM AGC DELAY PB FM-EQ PB PHASE-EQ R P C-LPF GCA B-UP AMP ACC AMP Main CONV 3.58M BPF2 AUTO BIAS P R KIL B.D. PB AMP 3.58M BPF1 DOUBLE LIM FM DEM SUB LPF V/I CONV P R Y-LPF YNR/ COMB N.L. DEEM NC1 Y/C MIX SYNC SEP VCA CLAMP 1/2 FBC Chara INS. 6dB P R P R V-AGC T4001 CLAMP EQ AMP LINE AMP MUTE ALC SP/LP/EP-H INPUT_SEL TRICK_PB-H/EE-H DOC_XO_CTL REC/EE/PB H.AMP_SW C.ROTARY H.SW AUDIO_MUTE-H V.REC_ST-H ENV.DET DUMMY_V.SYNC OSD_V C.SYNC FRONT_V_IN TUNER_V FROM_NORMAL_A 4FSC 6 2 3 1 5 Q4006 BIAS OSC Q4005 BIAS CTL 99 Q4003 SW Q4001, Q4002 AUDIO PB SW SYSCON 4 P.CON+5V T/C R/P AUDIO R/P HA SW IN C ROT RF SW IN AUDIO MUTE H.A R/P ENV DET OPERATION/ DISPLAY 94 COMP COMP OUT Q4004 BUFFER FSC FSC TUNER HIFI/ DEMODULATOR CP4001 3 2 1 EP/LP-CH1 (R) EP/LP COM EP/LP-CH2 (L) CYL 6 5 4 SP CH1 (R) SP COM SP CH2 (L) 9 8 7 HF1 (R) HF COM HF2 (L) HF1 HF_COM HF2 HIFI/ DEMODULATOR TO_NORMAL_A HIFI/ DEMODULATOR Q4007 BUFFER SYSCON AUDIO SIGNAL (PB) AUDIO SIGNAL(REC) RECORD LUMINANCE SIGNAL PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL TUNER VIDEO SIGNAL PLAYBACK COLOR SIGNAL 80 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TUNER BLOCK DIAGRAM 2 RF-SW SW6001 TU6001 3 5 TUNER_V TUNER_A REAR OUT JACK J4201 3 Q4201 BUFFER VIDEO_OUT 23 24 SYSCON Y/C/AUDIO/ CCD/HEAD AMP 2 22 TV/VCR 2 6 12 11 IIC_CLK IIC_DATA AFT-S.CURVE SYSCON 16 +32V H-2 15 FSC Y/C/AUDIO/ CCD/HEAD AMP 13 14 4 P.CON+5V 4 AUDIO_OUT-R AUDIO_OUT-L RF_CONV_A.OUT Q4203 MUTE SW Q4204 MUTE SW Q4202 SW AUDIO_OUT_MUTE-L TUNER_L Q6001 SW HIFI/DEMODULATOR POWER TUNER VIDEO SIGNAL RECORD LUMINANCE SIGNAL PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL PLAYBACK COLOR SIGNAL AUDIO SIGNAL(PB) AUDIO SIGNAL(REC) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SYSCON/TIMER/SERVO IC1001 OEC0090A Y/C/AUDIO/ CCD/HEAD AMP POWER ON-L DRUM PWM MS SEN-B POWER FAIL TRICK PB-H/EE-H KEY-B KEY-A DUMMY V.SYNC C.ROTARY SP-L/LP-M/EP-H 50 29 107 27 37 88 30 99 105 109 SYSTEM CONTROL BLOCK DIAGRAM KEY-A DISPLAY/ OPERATION POWER_ON-L POWER_FAIL POWER VIDEO H.SW 91 DPG 103 DFG 104 4FSC 4 FSC IN 22 AUDIO MUTE-H 92 X1001 10MHz OSC 2 OSC 1 78 80 REC/EE/PB 52 TUNER CYL SPEED UP 48 D1001 P.CON_5V REM IN 43 BOT-H EOT-H 25 26 REEL-S 69 REEL-T 70 REEL SENS Q1002 1 2 VCC BOT P.CON+5V_A BOT SENSOR Q101 EOT SENSOR Q1006 REEL SENS Q1001 P.CON+5V CP1003 3 5 CYL PG CYL FG CP1001 7 CYL DRIVE CAP PWM 108 CAP LIMIT 83 CAP FULL 102 CAP FG 9 CAP FWD-L 71 3 4 I LIMIT CTL CP1002 6 FG 7 CAP.M F/R 2 1 4 3 MS SENS CTL 49 MS SEN-A 28 2 1 4 3 MS_SEN A Q1005 MS_SEN B Q1004 2 3 4 1 2 3 4 1 Q1003 SENSOR SW. MICRO MOTOR CAPSTAN DD UNIT DECK BLK AT+5V H.AMP SW 100 TRICK_PB-H/EE-H DUMMY_V.SYNC C.ROTARY SP/LP/EP-H H.SW AUDIO_MUTE-H REC/EE/PB H.AMP_SW V ENV V.REC ST-H 90 24 CV IN1 17 ENV.DET V.REC_ST-H OSD_V CTL(+) 3 CTL(-) 4 CV OUT AFT S.CURVE 33 19 VCR-H 96 IIC SDA IIC CLK 59 60 VIDEO_OUT TV/VCR IIC_DATA IIC_CLK KEY-B REM_IN AFT-S.CURVE CTL+ CTL- P.CON+5V LDM FWD 67 LDM RVS 68 TAB SW 53 REC DOWN SW 2 4 1 8 5 IC1002 BA6955AN 3 4 LDM- LDM+ CP1003 M LOADING MOTOR AT+12.6V LOADING MOTOR DRIVER RESET 77 3 1 2 IC1003 RE5VS31A AT+5V SYSTEM RESET D1009 7 5 6 EEPROM IC1099 S-24C08ADPA-01 DOC_XO_CTL 89 INPUT SEL 94 DOC_XO_CTL INPUT_SEL C.SYNC 111 C.SYNC H-3 SCL SDA COMP 101 COMP S01/FL SD OUT FL S CLK 64 63 FL CS OTPB LED 45 55 CENT LED 84 S01/FL_SD_OUT FL_S_CLK FL_CS OTPB_LED Q1007 SENS CTL ST SELECT 31 HIFI H.SW 106 HIFI ENV 32 ST_SELECT HIFI_H.SW HIFI_ENV.DET TUNER-L 97 AUDIO OUT MUTE-L 93 TUNER-L AUDIO_OUT MUTE-L IIC_DATA IIC_CLK AUDIO_MUTE-H V.REC_ST-H HIFI/ DEMODULATOR RECORD LUMINANCE SIGNAL PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL PLAYBACK COLOR SIGNAL CYLINDER AFC SIGNAL CYLINDER APC SIGNAL CAPSTAN AFC SIGNAL w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HIFI AUDIO/H.AMP/DEM IC IC5501 AN3662FBP 57 15 53 27 42 10 29 30 59 36 48 56 43 28 24 21 22 45 62 61 AUDIO_OUT_L HIFI_H.SW RF_CONV_A.OUT TUNER_A AUDIO_MUTE-H V. REC_ST-H HIFI_ENV. DET IIC_CLK IIC_DATA AUDIO_OUT_R ST_SELECT FRONT_A_IN-L FRONT_A_IN-R HF2 HF_COM FSC HF1 FROM_NORMAL_A TO_NORMAL_A TUNER SYSCON Y/C/AUDIO/CCD /HEAD AMP 51 58 40 P.CON 12V P.CON 5V INPUT SW AMP AMP RFC OUTPUT SW PNR BPF FM LIM DEM BLOCK AMP AMP AGC LOGIC VCO-FO ADJ LOGIC H-4 DISPLAY/OPERATION HIFI/DEMODULATOR BLOCK DIAGRAM AUDIO SIGNAL (PB) AUDIO SIGNAL (REC) 25 DBX NOISE REDUCTION L/R MIX REC LPF VCO w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com V651 SVV-07SS22 HEATER_DC + HEATER_DC - SYSCON REM_IN 26 25 2 1 OS651 14 4 6 9 23 17 5 1 POWER 23 24 26 25 10 32 18 2 1 KEY-A KEY-B OTPB SW STOP/EJECT REC/OTR PLAY FF/CUE REW/REV KEY A KEY B 1 2 STILL/PAUSE CP602 CP651 3 -30V AT+5V S01/FL_SD_OUT FL_S_CLK FL_CS 1 2 H-5 CH.DOWN CH.UP J601 2 4 7 6 5 3 1 ONE TOUCH PB KEY B 8 7 CP607 FRONT_V_IN 5 FRONT_A_IN-L FRONT_A_IN-R 3 1 ONE TOUCH PB KEY B 8 6 CP652 FRONT_V_IN 4 FRONT_A_IN-L FRONT_A_IN-R 2 1 OTPB POWER D602 Q651 FRONT_A_IN-L FRONT_A_IN-R FRONT_V_IN OTPB_LED HI-FI/DEMODULATOR Y/C/AUDIO/CCD/ HEAD AMP DISPLAY/OPERATION BLOCK DIAGRAM 29 11 17 31 30 FIP DRIVER IC IC651 BU2977FS AUDIO SIGNAL(REC) RECORD LUMINANCE SIGNAL RECORD COLOR SIGNAL w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com POWER BLOCK DIAGRAM P.CON+5V_A P.CON+5V P.CON+12V +32V Q502 Q511 Q503 Q510 POWER_FAIL SYSCON CONTROL PHOTO COUPLER SW. T501 12 13 11 4 5 IC501 KIA431 VOLTAGE CTL. IC 1 2 PHOTO COUPLER L501 AC IN Q509 Q518 P.CON 5V SW OSD P.CON 5V SW POWER_ON-L D505, D508 D523, D528 2 10 9 Q512 P.CON 12V SW AT+12.6V Q513 P.ON SW H-6 7 6 8 HEATER_DC + HEATER_DC - -30V DISPLAY/ OPERATION AT+5V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 CP101 52044-0445 1 2 3 4 Q101 RPT-38PB113 BOT SENSOR S105 S106 S103 S104 S101 S102 OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS DESCRIBED IN PARTS LIST ONLY CRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: DANS LA NOMENCLATURE DES PIECES N’UTILISER QUE CELLS DECRITES DANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: I-1 (DECK PCB) SYSCON VE8851 VCC BOT LDM- LDM+ 5.1 0 PCB550 FROM/TO M101 LOADING MOTOR DECK SCHEMATIC DIAGRAM w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 AUDIO SIGNAL(REC) RECORD COLOR SIGNAL RECORD LUMINANCE SIGNAL CP602 IMSA-9604S-04Z13 1 2 3 4 CP607 IMSA-9604S-08Z13 1 2 3 4 5 6 7 8 NC H E H E H E J601 JPJ3656-01-432 HIFI FRONT JACK 1 2 3 4 5 6 7 R601_1 13K 1/4W R602_1 6.8K 1/4W R603_1 3.9K 1/4W R604_1 2.7K 1/4W R605_1 3.3K 1/4W R607_1 1.5K 1/4W R609_1 390 1/4W R608_1 390 1/4W R610_1 2.7K 1/4W R614_1 3.3K 1/4W SW607 SKQNAED010 STILL/PAUSE SW608 SKQNAED010 CH.UP SW606 SKQNAED010 CH.DOWN SW605 SKQNAED010 STOP/EJECT SW604 SKQNAED010 REC/OTR SW603 SKQNAED010 FF/CUE SW602 SKQNAED010 PLAY SW601 SKQNAED010 REW/REV SW610 SKQNAED010 POWER SW609 SKQNAED010 OTPB D602 SLZ-345B-02-T1 OTPB OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME I-2 PCB270 PCB280 (OPERATION 1 PCB) (OPERATION 2 PCB) (CP651) (CP652) VE9868 VE9869 TO DISPLAY R GND GND FRONT_A_IN-R FRONT_A_IN-L FRONT_V_IN KEY B ONE TOUCH PB GND FROM/TO DISPLAY V L KEY A GND KEY B NC OPERATION SCHEMATIC DIAGRAM w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PRINTED CIRCUIT BOARDS I-3 DECK SOLDER SIDE OPERATION1 SOLDER SIDE OPERATION2 SOLDER SIDE SW607 SW605 SW606 SW608 SW601 SW602 SW603 SW604 R601_1 R602_1 R603_1 R604_1 R605_1 R607_1 CP602 SW610 SW609 D602 J601 R614_1 R608_1 R609_1 R610_1 CP607 CP101 Q101 S103 S104 S101 S102 S105 S106 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com R6005 C6001 C1030 C6013 R651 C6009 R6009 R506 R510 R516 C515 R518 IC5501 C5544 C5543 R5510 R5520 R5517 C5530 R5514 R5516 R5508 R5507 IC4001 R4204 R4205 R4043 R4001 R4011 R4002 R4003 R4034 R4032 C4027 R4022 R4023 R4025 R4010 R4015 R4009 R4004 R4012 R4008 R4013 R4051 R4048 R4049 C4049 R4041 R4047 R4045 R4044 R4046 R4059 R4018 R4050 R4057 R4055 R1045 R1044 R1007 R4021 R4069 R4068 R4067 R1087 R4211 R4210 C5503 R5503 R1011 C1010 R4060 C4053 C4052 C4054 C4056 C4047 C4041 C4025 C4020 C4018 Q4003 C4005 C4006 R4020 C4009 C4003 C5540 C5546 C5545 C5542 C5541 C5524 C5515 C5508 C5507 C5506 C4028 C4029 C4032 C4036 C4048 C5527 C5518 C5553 C4055 C5504 Q513 C501 C507 Q1007 C5514 R4070 R4072 R4029 R4017 Q4202 C4067 C4068 R4053 R1016 R661 C6004 Q6001 R6008 C6007 C4074 IC651 C660 C655 C662 C663 Q4205 C6014 R4065 R4202 R4206 R6006 R4212 R662 C1036 R1040 R1048 R1038 C1025 C1024 C1009 R1046 R1047 IC1001 R1024 R1001 R1014 R1043 R1032 R1022 C1018 C1019 R1027 R1025 C1044 R1006 R1049 R1051 R1067 C1014 R1034 R1060 C1008 C1006 R1009 C1015 C1007 Q651 C1001 C1022 R1030 R1053 C1034 R1063 C1049 C1038 C1041 C1020 R1015 C1004 C1066 R1008 R1004 R5513 C1040 R1033 R1012 R503 R1083 R1029 R1028 R1061 R1062 Q1003 R4079 C1053 Q518 Q4008 C1027 R1010 C1031 R1037 R4081 C4077 R5502 R1013 C511 C510 W841 W840 R4040 C1050 R530 R1005 S101Y S101X PRINTED CIRCUIT BOARDS SYSCON I-4 17 33 49 1 1 31 51 81 1 29 57 85 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com IC1002 CP1002 TU6001 SW6001 Q1002 Q1001 SW1001 CP4001 CP4003 D652 IC1099 D1004 C6008 OS651 W810 J4201 FH502 FH501 L501 Q510 F501 L504 D515 L505 C514 D514 R527 Q511 R505 W069 C5548 C5547 C5517 C5534 C5536 C5538 C5523 C5521 C5539 C5533 C5532 C5525 C5526 C5529 C5537 C658 C5512 C5511 C5509 W025 T4001 Q4001 Q4002 Q4004 C4016 C4011 C4001 W172 Q4201 C4209 Q4204 Q4203 C5510 C5552 C5516 C4002 Q4006 Q4005 C4010 L4003 R6004 C4024 C4022 C4017 W070 W068 C4043 Q4009 C4058 C4059 C4060 C4061 C4062 C4034 C4031 C4033 C4030 Q4007 R5519 C5505 W802 W805 W066 C4019 C4026 C4023 C4021 C4037 Q1006 Q512 C517 Q509 W170 TP5501 TP1002 TP4001 W097 D5501 W080 C4045 C4057 W031 W033 W032 C5502 X4001 D519 L4007 W099 C5501 R4033 W096 R4201 R4207 L4005 L4008 W167 W804 C4035 Q502 D1003 C508 L4001 IC501 TP4201 W144 L6001 W092 W094 W065 C6003_1 C505 C4050 W150 W100 D523 D508 D528 D505 CP501 C4204 C4203 C5549 C1033 C520 C6010 L4002 W012 V651 D503 B501 C5531 T501 W014 C5513 C502 C506 W130 C4070 C4039 C524 D1005 S101Y W151 C4071 W071 W146 R508 L5502 W817 W168 R4016 L6002 W159 W109 L5501 L5504 W171 W161 W147 W148 W149 R1017 R1020 L6003 R6010 W834 R4027 D512 TP1001 W095 C4044 Q1005 Q1004 C4004 CP1001 CP1003 CP651 CP4002 R4062 D1001 W011 W030 D506 W122 D520 R1003 D1002 W024 W827 W038 W073 W037 X1001 C1016 C1013 L1003 W091 IC1003 W107 R663 W075 W133 W116 W115 W090 R1057 CP652 W021 W832 C657 W027 R1050 R1058 C1029 W020 W026 W023 W825 D1009 W111 W128 W127 W160 W048 W141 W143 W112 D517 R501 D651 W078 W162 W129 W121 W119 W120 W118 W108 W101 W102 W154 C503 W002 W056 D524 R520 R523 R1019 W103 W126 W125 W132 W131 W134 W124 C522 W035 W049 W050 W001 R525 R529 W106 W105 W077 W110 R1031 W009 D513 W041 W040 W052 W015 W838 W036 W022 W083 D1006 R4063 W140 W113 W137 W114 W047 R1056 W054 C656 C5555 C1021 W060 W058 W059 W046 C1052 D526 C4201 W142 D504 D502 W028 W007 D1007 W053 W072 D4001 W006 W062 C1032 W079 W836 R502 C504 C523 C519 D527 W173 R504 C512 R512 B502 C509 D511 R514 D507 R513 D510 R534 R511 Q503 W152 W153 W158 W157 W166 W852 W018 W017 W086 W085 W093 W164 W163 W156 W088 W087 W084 W098 W019 W029 W003 W004 W016 W010 W139 W136 W135 W138 C518 W082 W081 W008 W043 W061 W044 W055 W063 W064 W045 W807 W829 C4038 W835 W801 W814 D509 R1064 S102Y S102X W176 R4007 C4078 S103Y S103X C1028 PRINTED CIRCUIT BOARDS SYSCON I-5 RISK OF FIRE - REPLACE AS MARKED. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com R6005 C6001 C1030 C6013 R651 C6009 R6009 R506 R510 R516 C515 R518 IC5501 C5544 C5543 R5510 R5520 R5517 C5530 R5514 R5516 R5508 R5507 IC4001 R4204 R4205 R4043 R4001 R4011 R4002 R4003 R4034 R4032 C4027 R4022 R4023 R4025 R4010 R4015 R4009 R4004 R4012 R4008 R4013 R4051 R4048 R4049 C4049 R4041 R4047 R4045 R4044 R4046 R4059 R4018 R4050 R4057 R4055 R1045 R1044 R1007 R4021 R4069 R4068 R4067 R1087 R4211 R4210 C5503 R5503 R1011 C1010 R4060 C4053 C4052 C4054 C4056 C4047 C4041 C4025 C4020 C4018 Q4003 C4005 C4006 R4020 C4009 C4003 C5540 C5546 C5545 C5542 C5541 C5524 C5515 C5508 C5507 C5506 C4028 C4029 C4032 C4036 C4048 C5527 C5518 C5553 C4055 C5504 Q513 C501 C507 Q1007 C5514 R4070 R4072 R4029 R4017 Q4202 C4067 C4068 R4053 R1016 R661 C6004 Q6001 R6008 C6007 C4074 IC651 C660 C655 C662 C663 Q4205 C6014 R4065 R4202 R4206 R6006 R4212 R662 C1036 R1040 R1048 R1038 C1025 C1024 C1009 R1046 R1047 IC1001 R1024 R1001 R1014 R1043 R1032 R1022 C1018 C1019 R1027 R1025 C1044 R1006 R1049 R1051 R1067 C1014 R1034 R1060 C1008 C1006 R1009 C1015 C1007 Q651 C1001 C1022 R1030 R1053 C1034 R1063 C1049 C1038 C1041 C1020 R1015 C1004 C1066 R1008 R1004 R5513 C1040 R1033 R1012 R503 R1083 R1029 R1028 R1061 R1062 Q1003 R4079 C1053 Q518 Q4008 C1027 R1010 C1031 R1037 R4081 C4077 R5502 R1013 C511 C510 W841 W840 R4040 C1050 R530 R1005 S101Y S101X PRINTED CIRCUIT BOARDS SYSCON I-6 17 33 49 1 1 31 51 81 1 29 57 85 IC1002 CP1002 TU6001 SW6001 Q1002 Q1001 SW1001 CP4001 CP4003 D652 IC1099 D1004 C6008 OS651 W810 J4201 FH502 FH501 L501 Q510 F501 L504 D515 L505 C514 D514 R527 Q511 R505 W069 C5548 C5547 C5517 C5534 C5536 C5538 C5523 C5521 C5539 C5533 C5532 C5525 C5526 C5529 C5537 C658 C5512 C5511 C5509 W025 T4001 Q4001 Q4002 Q4004 C4016 C4011 C4001 W172 Q4201 C4209 Q4204 Q4203 C5510 C5552 C5516 C4002 Q4006 Q4005 C4010 L4003 R6004 C4024 C4022 C4017 W070 W068 C4043 Q4009 C4058 C4059 C4060 C4061 C4062 C4034 C4031 C4033 C4030 Q4007 R5519 C5505 W802 W805 W066 C4019 C4026 C4023 C4021 C4037 Q1006 Q512 C517 Q509 W170 TP5501 TP1002 TP4001 W097 D5501 W080 C4045 C4057 W031 W033 W032 C5502 X4001 D519 L4007 W099 C5501 R4033 W096 R4201 R4207 L4005 L4008 W167 W804 C4035 Q502 D1003 C508 L4001 IC501 TP4201 W144 L6001 W092 W094 W065 C6003_1 C505 C4050 W150 W100 D523 D508 D528 D505 CP501 C4204 C4203 C5549 C1033 C520 C6010 L4002 W012 V651 D503 B501 C5531 T501 W014 C5513 C502 C506 W130 C4070 C4039 C524 D1005 S101Y W151 C4071 W071 W146 R508 L5502 W817 W168 R4016 L6002 W159 W109 L5501 L5504 W171 W161 W147 W148 W149 R1017 R1020 L6003 R6010 W834 R4027 D512 TP1001 W095 C4044 Q1005 Q1004 C4004 CP1001 CP1003 CP651 CP4002 R4062 D1001 W011 W030 D506 W122 D520 R1003 D1002 W024 W827 W038 W073 W037 X1001 C1016 C1013 L1003 W091 IC1003 W107 R663 W075 W133 W116 W115 W090 R1057 CP652 W021 W832 C657 W027 R1050 R1058 C1029 W020 W026 W023 W825 D1009 W111 W128 W127 W160 W048 W141 W143 W112 D517 R501 D651 W078 W162 W129 W121 W119 W120 W118 W108 W101 W102 W154 C503 W002 W056 D524 R520 R523 R1019 W103 W126 W125 W132 W131 W134 W124 C522 W035 W049 W050 W001 R525 R529 W106 W105 W077 W110 R1031 W009 D513 W041 W040 W052 W015 W838 W036 W022 W083 D1006 R4063 W140 W113 W137 W114 W047 R1056 W054 C656 C5555 C1021 W060 W058 W059 W046 C1052 D526 C4201 W142 D504 D502 W028 W007 D1007 W053 W072 D4001 W006 W062 C1032 W079 W836 R502 C504 C523 C519 D527 W173 R504 C512 R512 B502 C509 D511 R514 D507 R513 D510 R534 R511 Q503 W152 W153 W158 W157 W166 W852 W018 W017 W086 W085 W093 W164 W163 W156 W088 W087 W084 W098 W019 W029 W003 W004 W016 W010 W139 W136 W135 W138 C518 W082 W081 W008 W043 W061 W044 W055 W063 W064 W045 W807 W829 C4038 W835 W801 W814 D509 R1064 S102Y S102X W176 R4007 C4078 S103Y S103X C1028 RISK OF FIRE - REPLACE AS MARKED. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 S101X S101Y CAUTION: DIGITAL TRANSISTOR Q4003 DTA124EKA SW CP4001 TOC-C09X-A1 1 2 3 4 5 6 7 8 9 CP4002 IMSA-9604S-06Z13 1 2 3 4 5 6 TUNER VIDEO SIGNAL IC4001 LA71067M-MPB Y/C/AUDIO/CCD/HEAD AMP IC 1 10 100 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 32 33 34 35 36 37 38 39 4 40 41 42 43 44 45 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 61 62 63 64 65 66 67 68 69 7 70 71 72 73 74 75 76 77 78 79 8 80 81 82 83 84 85 86 87 88 89 9 90 91 92 93 94 95 96 97 98 99 CP4003 TMC-T02X-E1 1 2 DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C4071 100 6.3V KA C4010 47 6.3V KA C4017 1 50V KA C4024 4.7 25V KA C4004 47 6.3V KA C4016 4.7 25V KA C4058 22 6.3V KA C4043 1 50V KA C4001 47 6.3V KA C4011 1 50V KA C4034 1 50V KA T4001 1626007 COIL,BIAS OSC 1 2 3 4 5 6 C4078 100P B C4068 0.0018 B C4074 470P CH C4025 0.0022 B C4027 820P CH C4009 0.1 F C4052 0.1 F C4029 0.047 F C4028 0.1 B C4002 0.022 100V TF C4048 0.01 B C4050 0.01 F C4044 0.1 F C4067 470P CH C4020 0.01 B C4041 390P CH C4038 0.1 TF C4049 200P CH C4047 18P CH C4005 0.01 B C4006 0.015 B C4003 0.1 F C4054 0.01 B C4055 0.022 F C4018 0.0012 B C4036 0.022 B C4032 0.022 B C4053 0.01 B C4056 0.1 F C4077 100P CH R4007 100 1/4W R4059 1K R4040 1K R4070 1K R4041 1K R4011 22K R4022 6.8K R4034 820 R4068 47K R4020 10K R4032 27K R4053 1.8K R4065 2.2K R4051 27K R4027 180 1/4W R4060 220K R4062 220K 1/4W R4063 3.3M R4016 15 1/4W R4009 2.2K R4002 10K R4003 10K R4050 680K R4023 8.2K R4013 10K R4021 27K R4004 27K R4008 12K R4072 18K R4012 18K R4025 330K R4049 1.5K R4048 4.7K R4015 2.2 R4010 3.3K R4069 47K R4067 47K R4055 10K R4029 2.2M R4018 6.8K R4001 560 R4033 1K 1/4W R4017 10K R4043 3.3K R4044 8.2K R4045 1.8K R4046 1K R4057 1.8K R4079 680K R4047 18K R4081 10K D4001 1SS133 C4039 1 50V KA C4045 47 6.3V KA C4070 47 6.3V KA C4019 1 50V KA C4026 22 6.3V KA C4059 4.7 25V KA C4060 1 50V KA C4022 10 16V KA C4035 100 6.3V KA C4057 22 6.3V KA C4023 22 6.3V KA C4021 33 6.3V KA C4061 1 50V KA C4033 1 50V KA C4037 1 50V KA C4031 1 50V KA C4030 10 16V KA C4062 1 50V KA Q4008 2SC2412K BUFFER Q4006 2SD734 BIAS OSC Q4004 2SC1815Y BUFFER Q4001 2SC3331 AUDIO PB SW Q4002 2SC3331 AUDIO PB SW Q4007 2SC1815Y BUFFER W835 W805 W802 W821 TP4001 V.ENV W801 L4007 100uH Q4005 2SA1318 BIAS CTL Q4009 2SA1015Y BUFFER X4001 3.579545MHz L4003 100uH L4002 47uH 0305 L4001 22uH 0305 L4008 47uH 0305 L4005 22uH 0305 AUDIO SIGNAL(REC) AUDIO SIGNAL(PB) PLAYBACK LUMINANCE SIGNAL PLAYBACK COLOR SIGNAL RECORD LUMINANCE SIGNAL RECORD COLOR SIGNAL P.CON+5V SP/LP/EP-H INPUT_SEL TO_NORMAL_A P.CON+5V GND FSC FSC FSC TO_NORMAL_A FROM_NORMAL_A 4FSC HF1 HF_COM TUNER_V HF2 GND DOC_XO_CTL INPUT_SEL 4FSC H.SW H.AMP_SW P.CON+5V ENV.DET AUDIO_MUTE-H C.ROTARY TUNER_V DUMMY_V.SYNC V.REC_ST-H FRONT_V_IN CTL+ CTL- COMP ENV.DET C.SYNC SP/LP/EP-H OSD_V TRICK_PB-H/EE-H COMP REC/EE/PB OSD_V FROM_NORMAL_A C.SYNC DUMMY_V.SYNC FRONT_V_IN P.CON+5V V.REC_ST-H CTL+ CTL- TRICK_PB-H/EE-H AUDIO_MUTE-H V.REC_ST-H H.SW C.ROTARY H.AMP_SW REC/EE/PB DOC_XO_CTL P.CON+5V I-7 FROM/TO HIFI/DEMODUTATOR FROM DISPLAY Y/C/AUDIO/CCD/HEAD AMP SCHEMATIC DIAGRAM (SYSCON PCB) 0.7 0.7 0.4 FROM/TO HIFI/DEMODUTATOR FROM/TO SYSCON PCB010 FROM/TO TUNER TO FE HEAD FROM/TO HEAD AUDIO CONTROL EP/LP_COM SP_COM HF_COM FROM/TO CYL FROM POWER 1.9 3.7 0 5.2 5.2 3.7 NC NC NC 1 FE HEAD(GND) FE HEAD(HOT) AUDIO PB AE HEAD(+) CTL- CTL+ AUDIO REC AE HEAD(-) HF2(L) HF1(R) EP/LP-CH2 (L) EP/LP-CH1 (R) SP-CH2 (L) SP-CH1 (R) 4 5 0 0 5.1 0 0 0 0 1.9 5.1 0 0 1.8 1.8 1.8 1.8 0 0 0 2.3 2.3 0 0 4.0 2.3 5.0 5.0 5.0 2.3 0 0 2.5 2.5 1.0 0 1.0 0 1.0 5.0 0 0 0 0 0 5.0 NC 5.0 2.4 2.4 2.4 2.4 VIDEO OUT AFC DET SYNC AUTO-BIAS VSS VSS R P TIMMING ACC AMP PB H.A CH3 OUT REC SP OUT REC EP ALC-LEVEL PB-Y R P NC1 DEEN N.L. MIX Y/C PB-C 1 3 2 R P P R AFTER BEFORE R P R P KIL R P NOMAL HA TEST P R R P R P TEST R P R NOMAL VHS SQPB SW SW H.AMP H.AMP L H CH1 CH2 CH4 L H L H H.A GND Y-Vcc Y-GND 4Fsc IN OUT C.SYNC BGA BGA TEST R-EQ PHASE-EQ PB CLOCK PULL OUT CCD DRIVER FM-EQ S-EQ AFC REC APC PB APC REC BPF1 3.58M BPF2 3.58M CONV V/I DEM FM SUB LPF ENH DETAIL EMPHA NL LIM DOUBLE Y-LPF YNR/COMB INS. Chara 6DB SEP SYNC 1/2 FBC TC2 AGC V-AGC CLAMP VCP CLAMP VCA CLAMP VDD C-VCC 5V ALWAYS SLD VCO 320FH VX01 C-LPF BGA DET ACC AMP B-UP C-GND REG DET KIL KIL KIL B.D. GCA AMP CONV Main BPF 4.21M BALANCER CONV Sub MOD FM REC FM-EQ DC WC FM AGC DELAY FM-EQ PB + AMP AGC IN IN AMP CTL R HA SW C ROT RF SW MUTE AUDIO R/P R/P AUDIO R/P Y/C FILT REC AGC COMP OUT ENV DET H.A VCC H.A GND AMP LINE BIAS AUTO MUTE A.GND P A-Vcc 2.3V Vref ALC /EE PB Vref AMP REC: EP/LP PB:EP REC PB/EE AMP EQ NC 0 3 NC VMX187 2 NC 5.2 5.1 0.3 0.4 0.4 3.9 5.1 3.3 5.0 3.2 2.5 2.3 2.3 0.3 1.8 0.4 0.4 0 5.0 1.5 4.8 1.4 3.0 2.4 1.7 0 0 0.4 0.4 2.0 1.6 3.3 2.5 4.8 2.5 3.4 2.9 3.1 2.3 0.8 2.6 3.3 0 3.3 3.9 2.7 2.1 1.8 3.0 1.4 2.7 1.9 4.9 2.3 2.3 2.5 2.3 0.8 0.8 0.8 0.8 5.0 0.3 2.3 0.7 2.2 0 2.3 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 S103Y S103X S102Y S102X CYLINDER APC SIGNAL CYLINDER AFC SIGNAL CAUTION: DIGITAL TRANSISTOR CP1003 IMSA-9604S-04Z14 1 2 3 4 Q1006 PNA2604M010R EOT SENSOR DANS LA NOMENCLATURE DES PIECES N’UTILISER QUE CELLS DECRITES DANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: DESCRIBED IN PARTS LIST ONLY CRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: D1003 TMPG06-12A CP1002 TMC-J08P-B1 1 2 3 4 5 6 7 8 Q1001 SG-260 REEL SENS 1 2 3 4 Q1002 SG-260 REEL SENS 1 2 3 4 Q1007 DTC124EKA SENS.CONTROL IC1001 OEC0090A SYSCON/TIMER/SERVO 110 101 102 103 104 105 106 107 108 109 112 111 1 10 100 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 32 33 34 35 36 37 38 39 4 40 41 42 43 44 45 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 61 62 63 64 65 66 67 68 69 7 70 71 72 73 74 75 76 77 78 79 8 80 81 82 83 84 85 86 87 88 89 9 90 91 92 93 94 95 96 97 98 99 IC1099 S-24C08ADPA-01 EEP ROM 1 2 3 4 5 6 7 8 IC1002 BA6955AN LOADING MOTOR DRIVER 1 2 3 4 5 6 7 8 SW1001 SPVF130100 REC DOWN SW 1 2 3 4 Q1004 RPI-352Q01R MS_SEN B 1 2 3 4 Q1005 RPI-352Q01R MS_SEN A 1 2 3 4 CP1001 IMSA-9604S-07Z14 1 2 3 4 5 6 7 IC1003 RE5VS31A SYSTEM RESET 1 2 3 D1001 SID1050CM DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C1052 22 6.3V KA C1028 0.047 5.5V F C1032 4.7 25V KA C1021 33 6.3V KA C1029 100 6.3V KA C1013 22 6.3V KA C1050 0.01 B C1036 0.1 B C10070.18 B C1008 0.0047 B C1006 0.022 B C1004 0.022 B C1041 0.001 B C1019 0.1 B C1018 150P CH C1020 0.022 B C1009 0.1 B C1030 0.1 B C1014 0.1 B C1022 0.001 B C1001 1 B C1044 15P CH C1038 1 F C1049 330P CH C1027 0.1 B C1066 0.0027 B C1024 18P CH C1025 18P CH C1015 0.001 CH C1053 0.1 B C1040 0.1 B C1034 1 F C1031 0.0015 B C1010 0.001 B R1064 1K 1/4W R1001 5.6K R1024 15K R1012 56K R1040 22K R1048 22K R1038 22K R1056 1K 1/4W R1027 15K R1022 150K R1007 6.8K R1083 33K R1050 100 1/4W R1087 33K R1044 3.3K R1045 3.3K R1019 47K 1/4W R1006 47K R1033 22K R1057 22K 1/4W R1008 1K R1004 1K R1009 1K R1014 56K R1029 22K R1049 4.7K R1030 6.8K R1025 470 R1028 22K R1032 10K R1011 2.2K R1003 82K 1/4W R1060 47K R1016 270 R1031 1.2M 1/4W R1046 10K R1047 10K R1015 22K R1053 470K R1067 4.7K R1005 120 1/4W R1058 1K 1/4W R1061 10K R1034 1M R1051 5.6K R1062 33K R1010 10K R1043 470K R1063 330 R1017 560 1/4W R1020 560 1/4W R1037 22K R1013 22K D1004 1N4005E D1002 1N4005E D1009 1SS133 D1007 1SS133 C1033 10 100V YK C1016 47 6.3V KA Q1003 2SC2412K SENSOR SW W825 TP1002 H.SW W814 TP1001 SERVICE W836 W827 L1003 12uH X1001 10MHz PLAYBACK LUMINANCE SIGNAL PLAYBACK COLOR SIGNAL RECORD LUMINANCE SIGNAL RECORD COLOR SIGNAL P.CON+5V_A P.CON+5V_CAP P.CON+5V AT+12.6_V AT+5V AT+5V[M-CON] CAP_LIMIT POWER_ON-L POWER_ON-L RESET LDM.R LDM.F CENT_LED REEL-T REEL-S IIC_CLK CAP_F/R FL_S_CLK IIC_DATA DOC_XO_CTL SO1/FL_SD_OUT IIC_DATA INPUT_SEL POWER_FAIL POWER-FAIL 4FSC IIC_CLK H.SW H.AMP_SW ENV.DET AUDIO_MUTE-H GND C.ROTARY GND DUMMY_V.SYNC GND V.REC_ST-H GND CTL+ MODE_VCC MODE_VCC CTL- FL_CS COMP C.SYNC SP/LP/EP-H REC/EE/PB TAB_SW TRICK_PB-H/EE-H DOC_XO_CTL TRICK_PB-H/EE-H REC/EE/PB OSD_V V.REC_ST-H SP/LP/EP-H POWER_ON-L AUDIO_MUTE-H SEN_LED LDM.R AUDIO_OUT_MUTE-L CYL_DRIVE LDM.F INPUT_SEL IIC_CLK LDM.F LM- LM+ IIC_DATA TV/VCR OTPB_LED TV/VCR LDM.R TUNER_L AFT-S.CURVE TUNER_L VIDEO_MUTE-H REM_IN VIDEO_MUTE-H EOT BOT C.ROTARY AUDIO_OUT_MUTE-L H.AMP_SW VIDEO_OUT COMP CONTROL_IN LM- CYL_PG LM+ POWER-FAIL CYL_FG H.SW V.REC_ST-H HIFI_H.SW HIFI_ENV.DET CYL_DRIVE HIFI_H.SW AUDIO_MUTE-H AFT-S.CURVE TAB_SW IIC_CLK DUMMY_V.SYNC HIFI_ENV.DET IIC_DATA ST_SELECT ST_SELECT C.SYNC CENT_LED CYL_DRIVE CTL+ FL_CS SO1/FL_SD_OUT CYL_FG FL_S_CLK CTL- REM_IN CYL_PG KEY-A VIDEO_OUT MS_SEN-B MS_SEN-A KEY-B ENV.DET KEY-A OSD_V OSD_V KEY-B 4FSC BOT EOT OTPB_LED REEL-T REEL-S SEN_LED MODE_VCC MS_SEN-B MS_SEN-A RESET CAP_LIMIT CONTROL_IN CAP_F/R TRICK PB-H/EE-H (SYSCON PCB) SYSTEM CONTROL SCHEMATIC DIAGRAM I-8 FROM/TO DISPLAY (CP101) CYL VCC 5V GND CYL DRIVE CYL PG CYL +B CYL FG CYL GND FROM/TO Y/C/AUDIO/CCD/H.AMP NC NC NC NC 9 10 FROM/TO HIFI/DEMODULATOR 0 0 1.2 0 1.2 2.4 0.9 1.3 0.9 5.0 0 4.8 4.8 PCB010 VSS A2 A1 A0 SDA SCL TEST VCC 0 0 0 0 VCC FROM TO SENSOR FROM/TO CAP MOTOR LDM- LDM+ BOT VCO GND I LIMIT CTL CAP.M F/R VCC(5V) NC NC NC NC NC NC NC NC (CAP) (LDM) (S/S) VMX187 11 FROM/TO TUNER CAP FG SV2 SV1 REM IN C SYNC/H SYNC 87 POWER FAIL VSS (GND) CENT LED REEL S REEL T KEY-A 31 CVSS(GND) CVCC CV OUT P12 P13 P14 4FSCOUT/2FSCOUT 4FSCIN/2FSCIN KEY-B BOT-H V ENV AVCC (BACK UP) 32KHz MONITOR VCC (BACK UP) VSS (GND) FWE X2 X1 RESET OSC1 OSC2 VCL MD0 VSS (GND) H.AMP SW COMP DPG DFG VIDEO H.SW HIFI H.SW DRUM PWM CAP PWM DUMMY_V.SYNC C SYNC VCC (BACK UP) CV IN2 V CYNC CV IN1 AFC LPF AFC OSC AFC PC CTL REF CTL(+) CTL(-) CTL BIAS CTL FB CTL AMP(O) CTL SMT(I) CAP FG SVCC (P.CON5V) SVSS (GND) 29 55 56 30 112 111 86 85 AVSS (GND) MS SEN-A MS SEN-B EOT-H ST SELECT HiFi ENV AFT S.CURVE P01/AN1 P00/AN0 MS SENS CTL CYL SPEED UP NC OTPB LED POWER ON-L TAB SW POWER ON-H SERVICE NC IIC CLK IIC SDA NC NC SI1 NC NC LDM FWD LDM RVS CAP FWD-L CAP LIMIT VV-H REC/EE/PB DOC XO CTL V.REC ST-H SP-L/LP-M/EP-H AUDIO MUTE-H AUDIO OUT MUTE-L INPUT SEL EE-H VCR-H TUNER-L VIDEO MUTE-H C.ROTARY HEATER SW STBY LED FL CS FL S CLK SO1/FL SD OUT CAP FULL JUST CLK CAP HI-H NC NC 0 0 4.9 0 FROM/TO CYL MOTOR (CYL) CAP GND 0 0 0 0 TSD POWER SAVE CONTROL LOGIC NC 6 7 IN GND OUT 0 8 NC FROM/TO POWER NC NC 11.8 0.1 0.1 11.8 5.1 5.0 1.1 1.1 5.6 0.5 1.2 5.0 5.0 4.9 4.9 5.0 0 2.5 2.5 2.5 0.7 2.7 2.5 2.5 2.3 5.0 1.9 1.9 1.7 0.4 1.3 3.2 2.8 5.0 2.8 0 0 2.5 0 2.3 0 0 1.3 1.2 5.0 5.0 0 3.5 2.5 0 0 4.9 1.9 0 4.9 4.9 4.9 0 4.9 0 0 0 0 2.6 1.2 0 5.0 0 0 5.0 0.6 4.9 0 0 4.8 5.0 0 0 4.8 4.7 0 0 0 0 4.7 4.9 0 1.6 4.9 0 1.1 3.3 4.9 2.5 0 2.4 3.3 4.9 2.3 4.9 0 0 0 0 0 0 0 0 4.9 2.6 NC 0 4.9 4.9 0 2.5 0 0 2.7 0 3.2 2.5 2.5 2.8 2.8 0 0 0.5 4.9 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 TU6001 TMDH2-A05A 10 11 12 13 14 15 16 17 18 2 21 22 23 24 25 26 27 28 3 4 5 6 8 9 H H H E J4201 JPJ4311-011432 REAR OUT JACK 1 2 3 4 SW6001 SSAB110100 RF-SW 1 2 3 4 5 CAUTION: DIGITAL TRANSISTOR DANS LA NOMENCLATURE DES PIECES N’UTILISER QUE CELLS DECRITES DANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: DESCRIBED IN PARTS LIST ONLY CRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: Q4205 DTC124EKA VIDEO MUTE SW Q6001 DTC124EKA SW CAUTION: DIGITAL TRANSISTOR Q4202 DTA124EKA MUTE SW TUNER VIDEO SIGNAL DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C6010 220 6.3V YK C6014 0.001 B C6007 27P CH C6009 0.01 B C4203 470PB C4204 470P B C6001 22P CH C6004 0.01 B C6013 0.1 F R4201 4701/2W R6010 270 1/4W R6009 1K R6008 1K R4210 100 R4207 2.7K 1/4W R4211 2.7K R6006 10K R6005 22K R4206 390 R4212 390 R4204 10K R4205 10K R4202 75 R6004 1K1/4W C4209 10 16V KA C6008 47 6.3V KA C4201 470 6.3V YK C6003_1 10 16V KA Q4204 2SC1815Y MUTE SW Q4203 2SC1815Y MUTE SW W804 W810 TP4201 VIDEO OUT W834 W852 L6003 15uH Q4201 2SA1015Y BUFFER L6002 22uH 0305 L6001 100uH 0305 AUDIO SIGNAL(REC) AUDIO SIGNAL(PB) PLAYBACK LUMINANCE SIGNAL PLAYBACK COLOR SIGNAL RECORD LUMINANCE SIGNAL RECORD COLOR SIGNAL RF_CONV_A.OUT FSC P.CON+5V TV/VCR TUNER_V IIC_CLK IIC_DATA P.CON+5V P.CON+12V AUDIO_OUT-R FSC AUDIO_OUT-L +32V RF_CONV_A.OUT AT+5V TUNER_A VIDEO_MUTE-H AUDIO_OUT_MUTE-L TUNER_A VIDEO_OUT TUNER_V AFT-S.CURVE TUNER_L +32V P.CON+12V P.CON+5V AT+5V GND IIC_CLK IIC_DATA TV/VCR AFT-S.CURVE TUNER_L VIDEO_MUTE-H AUDIO_OUT_MUTE-L VIDEO_OUT I-9 FROM/TO Y/C/AUDIO/CCD/H.AMP FROM/TO HIFI/DEMODULATOR NC FROM POWER (TUNER) FSC (SYSCON PCB) TUNER SCHEMATIC DIAGRAM FROM/TO SYSCON NC NC CH3 CH4 0 5.0 0 0 0 0 0 0 0 L V R NC SIF OUT NC A.IN CH MB V.IN CONTROL RF AGC CE CLOCK DATA BM PB 5V TU 32V IF TP IF OUT A.OUT AFT V.OUT NC PCB010 VMX187 0 0 4.9 2.8 3.2 3.2 0 0 4.9 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 IC5501 AN3662FBP HI-FI AUDIO/HEAD AMP/DEM IC 1 10 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 32 33 34 35 36 37 38 39 4 40 41 42 43 44 45 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 61 62 63 64 7 8 9 DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C5509 2.2 50V KA C5529 10 16V KA C5512 10 16V KA C5513 1 50V KA C5521 0.22 50V KA C5516 22 16V KA C5552 22 16V KA C5510 10 16V KA C5511 22 6.3V KA C5531 100 6.3V KA C5537 10 16V KA C5553 0.001 B C5515 0.022 B C5524 0.1 B C5503 0.0018 B C5504 0.1 B C5508 0.1 B C5507 0.1 B C5541 0.01 B C5542 0.1 B C5514 0.1 B C5546 0.015 B C5544 0.01 B C5545 0.1 B C5543 0.01 B C5549 0.01 Y C5540 0.015 B C5530 0.01 F C5506 0.1 B R5520 22K R5517 1K R5510 33K R5502 390 R5503 1.5K R5519 3.3K 1/4W R5508 6.8K R5516 6.8K R5507 47K R5514 47K R5513 2.2M D5501 1SS133 C5538 10 16V KA C5536 10 16V KA C5534 33 6.3V KA C5505 1 50V KA C5532 10 16V KA C5533 1 50V KA C5526 10 16V KA C5525 10 16V KA C5527 10 6.3V TT +-10% C5555 47 16V YK C5518 3.3 10V TT +-10% C5502 10 16V KA C5523 4.7 25V KA C5517 0.22 50V KA C5547 10 16V KA C5548 10 16V KA C5501 10 16V KA C5539 33 6.3V KA TP5501 HIFI ENV. W817 L5502 100uH L5501 100uH 0305 L5504 22uH 0305 AUDIO SIGNAL(REC) AUDIO SIGNAL(PB) FSC IIC_CLK P.CON+5V P.CON+5V IIC_DATA TUNER_A AUDIO_MUTE-H FRONT_A_IN-R FRONT_A_IN-L AUDIO_OUT-R AUDIO_OUT-L RF_CONV_A.OUT TUNER_A V.REC_ST-H AUDIO_OUT-R HIFI_ENV.DET HIFI_H.SW ST_SELECT AUDIO_OUT-L HF2 P.CON+12V GND RF_CONV_A.OUT HF1 HF_COM FSC TO_NORMAL_A FROM_NORMAL_A TO_NORMAL_A FROM_NORMAL_A P.CON+5V P.CON+12V GND V.REC_ST-H HIFI_ENV.DET HIFI_H.SW AUDIO_MUTE-H IIC_CLK IIC_DATA ST_SELECT FRONT_A_IN-R FRONT_A_IN-L I-10 NC FROM/TO TUNER FROM DISPLAY FROM POWER FROM/TO Y/C/AUDIO/CCD/H.AMP PCB010 FROM/TO SYSCON (SYSCON PCB) HIFI/DEMODULATOR SCHEMATIC DIAGRAM NC AMP SW2 PNR LCH DBX NOISE REDUCTION MUTE DE-EMPH 75uS SAP SW22R MIX L SWITCH (L.R)/SAP LPF DEMOD SAP DEMOD L.R PLL SL DET PILOT AMP DET RFC MATRIX FILTER STEREO VCA INPUT - - + AGC HIFI MIX SW16 R R FROM 3PIN FROM 1PIN CURR AMP HA2 HA1 SW21 SW9 SW12 PB REC S/N S/N TIMING HOLD SW LINER BS BS HIFI MIX NORMAL SW18 L L L R MUTE SW19 SW17 R L SW4 SW10 SW14 SW13 L H SW11 SW15 DET NOISE HPF DET REC LPF MIX LCH VCO REC LPF VCO RCH SW NOISE FM UM LIMIT AUDIO LIMIT AUDIO PB LPF PB LPF PC RCH BPF LCH BPF PC SW NOISE PNR RCH CTL ZZ-PROM LOGIC ADJ VCO-F0 MUTE LOGIC VREF1 INPUT_SW(L) INPUT_SW(R) DEM_BLK NC NC NC NC NC NC 0 0 2.1 0 0 0 2.0 0 0 0.7 0 0.7 0 2.5 0.7 0 0 0 0 2.2 0 1.2 0 VMX187 13 AN3662FBP USA 2.5 2.5 2.3 2.6 0.3 2.5 2.4 2.6 2.6 0.2 0.7 5.1 3.7 1.9 1.9 1.9 2.5 2.5 2.5 1.7 5.1 4.8 4.8 2.4 2.8 3.6 0 3.6 3.2 5.1 3.4 6.0 2.4 6.0 12.0 6.0 0.7 2.5 2.5 2.5 0.4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 R511 68 1W R514 1 1W R508 330 1/4W R529 330 1/4W T501 8122004 1 10 11 12 13 2 3 4 5 6 7 8 9 BLADE WIDE BLACK WHITE 2 1 CD501 0R614902 AC120V 60Hz CP501 THL-P03P-B1 1 2 B502 BL01RN1-A63 B501 BL02RN1-R62 1.6A 250V 1.6A 250V IC501 KIA431 VOLTAGE CTL IC 1 2 3 F501 1.6A250V L505 22uH L504 22uH TYPE 1.6A 250V (F501). (F501). CAUTION: ATTENTION: D’INCEIE N’UTILISER QUE DES FUSIBLE DE MEME POUR UNEPROTECTION CONTINUE LES RISQUES REPLACE ONLY WITH THE SAME TYPE FUSE 1.6A 250V FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, L501 0R3A433F20 1 2 3 4 FH502 EYF-52BC FH501 EYF-52BC CAUTION: DIGITAL TRANSISTOR DANS LA NOMENCLATURE DES PIECES N’UTILISER QUE CELLS DECRITES DANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: DESCRIBED IN PARTS LIST ONLY CRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: D517 MTZJ27D D513 MTZJ13B D520 MTZJ33B D526 MTZJ5.6C Q511 TLP621(D4-GR-LF2) PHOTO COUPLER 1 2 3 4 Q510 TLP621(D4-GR-LF2) PHOTO COUPLER 1 2 3 4 Q513 DTC124EKA P.ON SW DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C506 100 10V YK C508 82 200V WA C514 1000 10V YK C518 10 100V YK C517 1 50V KA C519 470 25V YK C520 470 10V YK C522 220 25V YK C523 10 100V YK C524 0.0033 250V RS C510 0.018 B C511 0.012 B C501 0.0082 B C509 100P 500V B C512 0.01 500V E C502 0.0027 500V B C507 0.0047 B C515 0.0082 B C504 0.1 250V ECQUL C505 0.0033 250V RS R513 1K 1/4W R505 1.8K 1/4W R512 33K 1/2W R534 330K 1/2W R504 22K 1/4W R510 1K R518 4.3K +-1% R506 390 R502 3.3M 1/2W R527 120K 1/2W R516 3.3K +-1% R503 22K R525 100 1/4W R520 33K 1/4W R523 390 1/4W R530 2.2K R501 27 1/4W D510 1SS133 D511 RGP10JE D514 UG2D D512 21DQ04N D502 UG2D D505 1N4005E D523 1N4005E D508 1N4005E D528 1N4005E D506 1SS133 D515 1SS244 D524 1SS133 D504 1N4005E D1006 1N4005E D1005 1N4005E D519 21DQ04N D503 1SS244 D507 1SS133 D527 1SS133 C503 100 10V KA Q503 2SC4160-OEC-YAC1 SWITCHING Q502 2SD734 CONTROL Q512 2SD734 P.CON+12V SW Q509 2SD1246 P.CON+5V SW Q518 2SC2412K OSD P.CON5V SW W807 W832 W838 W829 P.CON+5V P.CON+12V GND GND +32V P.CON+12V AT+5V P.CON+5V P.CON+5V GND POWER_ON-L MODE_VCC P.CON+5V_CAP AT+12.6_V P.CON+5V_A P.CON+5V GND GND GND GND AT+5V AT+5V[M-CON] POWER_FAIL AT+5V -30V HEATER_DC+ HEATER_DC- GND TO DISPLAY I-11 TO Y/C/AUDIO/CCD/H.AMP TO HIFI/DEMODULATOR 4.0 NC (SYSCON PCB) POWER SCHEMATIC DIAGRAM 0.4 0 0.1 0 GND OUT IN 0.1 12 2.5 0 PCB010 VMX187 TO TUNER (TUNER) 12.7 0 0 FROM/TO SYSCON 5.6 (LDM) (CAP) (CYL) (S/S) 151.1 0.5 5.1 -0.4 76.7 76.9 2.5 5.7 4.0 6.3 5.6 5.6 5.1 12.8 12.9 12.1 5.8 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 IC651 BU2977FS FIP DRIVER IC 1 10 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 32 4 5 6 7 8 9 V651 SVV-07SS22 1 10 11 12 13 14 15 16 17 18 19 2 20 21 22 23 25 26 4 5 6 7 8 9 Vout B+ GND OS651 PIC26043LO 1 2 3 CP651 IMSA-9604S-04Z14 1 2 3 4 D651 MTZJ5.1C D652 MTZJ6.8B CP652 IMSA-9604S-08Z14 1 2 3 4 5 6 7 8 CAUTION: DIGITAL TRANSISTOR Q651 DTA114EKA OTPB SW DURING PLAYBACK MEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C657 47 35V YK C658 10 16V KA C663 47P SL C662 47P SL C660 0.001 B C655 0.1 F R662 2.2 R661 47K R651 75 R663 10 1/4W C656 100 6.3V YK W840 W841 AUDIO SIGNAL(REC) RECORD LUMINANCE SIGNAL RECORD COLOR SIGNAL P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 7G 6G 5G 4G 3G 2G 1G HEATER_DC- HEATER_DC+ P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 7G 6G 5G 4G 3G 2G 1G -30V AT+5V GND FRONT_A_IN-R FRONT_A_IN-L FRONT_V_IN SO1/FL_SD_OUT FL_S_CLK FL_CS KEY-A KEY-B OTPB_LED REM_IN FRONT_V_IN KEY-A FRONT_A_IN-L KEY-B FRONT_A_IN-R (SYSCON PCB) DISPLAY SCHEMATIC DIAGRAM I-12 (CP602) (CP607) TO HIFI/DEMODULATOR S5 S4 S1 VDD G4 G3 G9 G8 G7 G6 G5 S16/G11 S15/G12 S14/G13 S13/G14 S10 S9 S8 S6 VEE SO SI VSS OSC VSS SCK CS K4 K3 K2 K1 VDD NC OTR 2G 3G 4G 5G 6G 7G 1G SLPM APM VCR ATR NC NC PCB010 FROM POWER VMX187 KEY B KEY A GND GND FROM OPERATION GND FRONT_V_IN FRONT_A_IN-L FRONT_A_IN-R GND GND ONE TOUCH PB KEY B FROM/TO OPERATION 5.0 0 TO Y/C/AUDIO/CCD/H.AMP FROM/TO SYSCON 4.9 5.0 0 5.0 4.9 -25.5 -25.5 0 2.4 0.21 4.7 0 4.7 0.5 0 0 0 0 4.9 -20.3 -15.9 -5.5 -7.7 -8.0 -15.9 -27.1 -7.6 -18.1 -7.9 -12.2 -25.4 -25.4 -25.4 -17.8 -25.4 -25.4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H A B C D E F G H 2 1 3 4 5 6 7 8 2 1 3 4 5 6 7 8 7 6 5 4 3 2 1 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 CP652 8 7 6 5 4 3 2 1 CP607 BLADE WIDE BLACK WHITE 2 1 CD501 AC120V_60Hz TU6001 10 11 12 13 14 15 16 17 18 2 21 22 23 24 25 26 27 28 3 4 5 6 8 9 9 8 7 6 4 5 3 2 1 CP4001 6 5 4 3 2 1 CP4002 6 5 4 3 2 1 2 1 CP4003 2 1 CP4003 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 DANS LA NOMENCLATURE DES PIECES N’UTILISER QUE CELLS DECRITES DANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE THE TIME THIS INTERCONNECTION DIAGRAM IS THE LATEST AT NOTE: DESCRIBED IN PARTS LIST ONLY CRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: 4 3 2 1 CP101 4 3 2 1 CP1003 4 3 2 1 CP651 4 3 2 1 CP602 I-13 A/C HEAD F/E HEAD M101 LOADING MOTOR LM DECK VE8851 PCB550 AND RF CONVERTER TUNER,DEMODULATOR SYSCON OPERATION 2 VE9868 PCB270 OPERATION 1 INTERCONNECTION DIAGRAM CP1001 FG FG.PG GND PG VCC DRV GND CYL VCC 5V GND CYL VCC 5V GND CYL PG CYL +B CYL FG CYL GND CYL DRIVE CYL GND CYL PG CYL +B CYL FG CYL DRIVE GND DRIVE CONTROL VCC MICRO MOTOR M2003 CD4001 FFC CD601 CD602 FFC FFC CD1002 FFC FRONT A IN-R FRONT A IN-L GND GND FRONT V IN GND KEY B ONE TOUCH PB FRONT A IN-R FRONT A IN-L GND GND FRONT V IN GND KEY B ONE TOUCH PB J601 VE9869 PCB280 AUDIO IN (R) AUDIO IN (L) VIDEO IN HIFI FRONT JACK GND GND GND KEY B KEY B KEY A KEY A TO OS651 COMMAND TRANSMITTER TM601 DATA B+ TM601 OS651 FROM GND J4201 REAR OUT JACK AUDIO OUT(R) VIDEO OUT AUDIO OUT(L) 4 ch 3 ch SW6001 RF SW CP501 2 1 H5002 FE HEAD (HOT) FE HEAD (GND) FE HEAD (HOT) FE HEAD (GND) SP COM HF2 (L) HF COM EP/LP COM SP-CH2 (L) SP-CH1 (R) HF1 (R) EP/LP-CH2 (L) EP/LP-CH1 (R) VCC BOT LDM- LDM+ VCC BOT LDM- LDM+ AE HEAD(+) AE HEAD(-) CTL- CTL+ AUDIO REC AUDIO PB VMX187 PCB010 FFC CD1001 Q101 BOT SENSOR WHITE RED FR OUT FR IN NC NC BM DATA CLOCK CE PB 5V TU 32V (RF AGC) (BT) CE CLOCK DATA BM PB 5V NC NC TU 32V IF TP IF OUT A.IN V.IN A.IN MB CH CONTROL CH MB V.IN CONTROL NC SIF OUT SIF OUT AFT A.OUT AFT CP1002 UN4001 CAPSTAN DD UNIT V.OUT EP/LP HEAD HI-FI HEAD SP HEAD V.OUT 3 2 1 9 8 7 5 4 6 CYLINDER UNIT AE HEAD(+) AE HEAD(-) AE AUDIO CONTROL CTL- CTL+ AUDIO REC AUDIO PB H5001 M2001 G O VCC MR FG SENSOR ROTOR MAGNET COIL MAIN HALL SENSOR LOGIC SWITCH OUT IN HALL VCC HALL VCC(5V) CAP.M F/R FG VCO(12V) CTL I LIMIT MOTOR GND w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com J-1 WAVEFORMS 1 4 POWER ON 10µs 500mV/div 2 POWER ON 100ns 100mV/div 3 PB 1ms 100mV/div PB 500µs 200mV/div 13 11 PB 200µs 1.0V/div PB 2µs 50.0V/div PB 5ms 1.0V/div 12 5 REC 5µs 20.0V/div 6 8 7 PB 200ms 1.0V/div PB 200ms 1.0V/div POWER ON 50ns 500mV/div PB 500µs 1.0V/div 9 PB 10ms 1.0V/div 10 SYSCON POWER HIFI/DEMODULATOR Y/C/AUDIO/CCD/ HEAD AMP NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com K1-1 703 703 703 704 PCB010 (SYSCON PCB) TU6001 J4201 T501 611 612 616 609 613 632 619 702 702 702 702 633 618 615 617 705 701 PCB280 (OPERATION 2 PCB) 601 PCB270 (OPERATION 1 PCB) 631 631 602 604 605 626 608 610 620 621 622 623 624 606 607 625 627 628 629 701 701 603 614 630 634 MECHANICAL EXPLODED VIEW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY 601 S4-C9A-2B7-200 CABINET,FRONT ASS'Y 1 602 ---- CABINET,FRONT 1 603 S1-1WP-D05-790 PLATE,DISPLAY 1 604 S1-2WP-J06-840 FLAP 1 605 S2-344-900-130 BADGE,BRAND 1 606 S3-5WP-D06-960 BUTTON,CHANNEL 1 607 S3-5WP-D06-020 BUTTON,OTPB 1 608 S3-5WP-D06-910 BUTTON,REC 1 609 S0-1WP-A03-420 HOLDER,DECK(FIP) 1 610 S3-5WP-D06-920 BUTTON,STOP/EJECT 1 611 S0-4WP-A00-070 HOLDER,DECK(R) 1 612 ---- SHIELD,CASE HEAD AMP ASS'Y 1 613 ---- RUBBER,SYSCON 8x15xT17.5 1 614 ---- FILM,DECORATION 1 615 ---- PLATE,BOTTOM 1 616 ---- PLATE,COVER POWER 1 617 S0-2WP-A06-460 PLATE,JACK 1 618 ---- SHEET,RATING 1 619 S0-2WS-B00-150 CABINET,TOP 1 620 S3-5WP-D06-930 BUTTON,FF 1 621 S3-5WP-D06-940 BUTTON,REW 1 622 S3-5WP-D06-950 BUTTON,BASE 1 623 S3-5WP-D06-970 BUTTON,PAUSE 1 624 S3-5WP-D06-980 RING,OTPB 1 625 S3-5WP-D06-890 BUTTON,POWER 1 626 S3-5WP-D06-900 BUTTON,PLAY 1 627 S3-8WP-A00-110 HOLDER,BUTTON(1) 1 628 S3-8WP-A00-120 HOLDER,BUTTON(2) 1 629 S3-8WP-A00-130 HOLDER,BUTTON(3) 1 630 S4-3WK-A00-320 SPR,FLAP 1 631 ---- CUSHION,LEG 2 632 S5-OP7-000-360 HOLDER,EOT SENSOR 1 633 ---- SHEET,COVER 1 634 ---- LABEL,ENEGY STAR 1 701 S1-102-268-040 SCREW,TAP BIND 2.6-8 10 702 S1-072-408-020 SCREW,TAP BIND 4-8 4 703 S1-071-40B-940 SCREW,TAP(S)PAN 4-29 3 704 87-078-174-010 SCREW TAP TITE(S)BIND 4-6 1 705 S1-102-30A-020 VT2+3-10 1 ACCESSORY REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY 1 S6-CQL-050-230 CABLE SI-C108-41 1 2 S6-CNB-A50-040 CORD,RCA PIN 06CNBA5004 1 3 S7-660-DD0-100 TRANSMITTER SBJY0P0012A 1 4 S4-C9A-201-000 INSTRUCTION BOOK 1 K1-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 515 360 K2-1 CHASSIS EXPLODED VIEW (TOP VIEW) 321 348 507 H5001 506 305 304 301 347 316 313 508 315 338 512 310 361 359 368 357 366 306 366 358 365 351 363 323 324 362 353 320 335 319 349 318 336 328 512 314 508 313 502 H5002 511 509 329 330 502 502 PCB550 (DECK PCB ASS'Y) 303 AA AD AD AD AD AA AD AD AA AA AB AB AD AD BA AA 352 503 503 367 501 356 317 369 309 355 Applying positions AA, AB, AC, AD and BA for the grease or oil are displayed for this section. Check if the correct grease or oil is applied for each position. NOTE: PART NO. CLASS MARK GREASE G-555G AA G-488M AB MG-33 AD FL-721 AC FL OIL No. 6115 BA OIL 300 505 334 AA UN4001 M2003 510 M101 364 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CHASSIS EXPLODED VIEW (BOTTOM VIEW) K2-2 AB 302 M2001 511 340 514 341 343 511 503 345 339 342 504 332 346 311 333 346 312 331 514 344 AA AA AA AD AD AA AA AA AA AA AC AA 307 354 326 327 322 513 350 308 337 AA 325 AD AA AD NOTE: Applying positions AA, AB, AC, AD and BA for the grease or oil are displayed for this section. Check if the correct grease or oil is applied for each position. PART NO. CLASS MARK GREASE G-555G AA G-488M AB FL-721 AC FL OIL No. 6115 BA OIL MG-33 AD 300 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CHASSIS REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY REF. NO. PART NO. DESCRIPTION Q'TY 300 ---- DECK ASS'Y A4C931B420A 360 S5-OP9-006-860 TAPE GUIDE R 1 361 S5-OP9-007-140 COVER,SENSOR L3 1 301 S5-OA5-000-220 AHC ASS'Y 1 362 S5-OP9-006-880 LEVER,FLAP 1 302 S5-OP2-002-900 BELT,CAPSTAN (S) 1 363 S5-OP9-006-900 CASS HOLDER 1 303 S5-OP9-007-100 LEVER,REC 1 364 S5-OP6-005-400 DRIVER,WORM 1 304 S5-OP5-000-830 BASE,AC HEAD 1 365 S5-OP9-007-130 LOCKER,R2 1 305 S5-OP8-003-240 SPR,AC HEAD 1 366 S5-OP9-006-940 SPR,PACK 2 306 S5-OA0-003-670 MAIN CHASSIS ASS'Y (S-Z) 1 367 S5-OP9-006-950 BRACKET,TOP 1 307 S5-OA2-000-820 CLUTCH ASS'Y (S2) 1 368 ---- SPR,CASS EARTH 1 308 S5-OA2-000-800 ARM,IDLER ASS'Y (S) 1 369 S5-OP8-003-410 SPRING,P/R ARM 1 309 S5-OP6-005-560 ARM,SS BRAKE (S) 1 501 87-654-075-410 SCREW,TAP 2.6-10 1 310 S5-OP2-002-920 REEL,T (S) 1 502 S1-072-268-040 VT2+2.6-8 3 311 S5-OA3-000-610 LOAD ARM S ASS'Y 1 503 87-743-073-010 VT2+2.6-6 3 312 S5-OA3-000-620 LOAD ARM T ASS'Y 1 504 87-743-073-410 SCREW,TAP 2.6-6 3 313 S5-OA4-002-090 G-ROLLER ASS'Y 2 505 S1-0A1-268-040 SCREW,WASHER(A)M2.6-8 1 314 S5-OA4-001-880 BASE,INCL S ASS'Y 1 506 S1-0B1-264-040 SCREW,WASHER(B)M2.6-4 1 315 S5-OA4-001-960 BASE,INCL T(S) ASS'Y 1 507 87-261-035-410 SCREW,PAN M2-6 3 316 S5-OA4-001-990 P5-3 ARM ASS'Y(S) 1 508 87-261-032-410 SCREW,PAN M2-3 2 317 S5-OA4-002-050 PINCH ROLLER BLOCK 1 509 87-258-091-010 U+M3-3 2 318 S5-OA4-001-750 TENSION ARM ASS'Y 1 319 S5-OA4-001-840 TENSION BAND ASS'Y (S) 1 510 S1-0A1-235-040 SEMS A M2.3-5 2 511 S2-P26-600-5N0 PW(CUT)2.6-6-0.5 3 320 S5-OA4-001-780 PINCH ROLLER LEVER ASS'Y 1 512 S2-Q26-47C-5N0 POLY,WASHER 2.6-4.7 2 321 S5-OA6-001-880 BRAKE T ASS'Y (S) 1 513 S2-P18-450-5N0 PW(CUT)1.8-4.5-0.5 1 322 S5-OA6-001-910 CAP BRAKE ASS'Y(S) 1 514 S3-ETW-300-000 E-RING 3 2 323 S5-OA9-002-130 LINK ASS'Y 1 515 S1-0A1-265-040 SCREW,WASHER(A) M2.6-5 3 324 S5-OA9-002-160 LINK LEVER ASS'Y 1 325 S5-OP2-002-840 LEVER,CLUTCH (S) 1 CP101 ---- CONN,PWB SIDE 1 326 S5-OP2-002-850 ACTUATOR,CLUTCH 1 H5001 S5-23D-910-340 HEAD,AC 1 327 S5-OP2-002-980 GEAR,COUPLING 1 H5002 S5-43D-020-130 HEAD,FE 1 328 S5-OP2-002-910 REEL,S (S) 1 ! M101 S5-96P-780-010 MOTOR(LOADING) 1 329 S5-OP6-005-410 WORM 1 ! M2001 S5-103-980-300 CAPSTAN DD UNIT F2QSB02 1 M2003 S5-893-110-050 MICRO MOTOR F2OEL82 1 330 S5-OP6-005-630 BRACKET,MOTOR 1 PCB550 ---- DECK PCB ASS'Y 1 331 S5-OP3-001-780 GEAR,MAIN LOADING 1 Q101 S0-007-003-200 PHOTO,TR RPT-38PB113 1 332 S5-OP3-001-790 GEAR,LOADING S 1 ! UN4001 S4-C93-1B5-000 CYLINDER UNIT ASSY A4C931B50 1 333 S5-OP3-001-800 GEAR,LOADING T 1 334 S5-OP3-001-860 HOLDER,LOADING GEAR 1 335 S5-OP4-004-720 ADJUST,TENSION 1 336 S5-OP4-004-920 HOLDER,TENSION 1 337 S5-OP4-004-900 LEVER,TENSION 1 338 S5-OP4-004-750 COVER,P4 1 339 S5-OP6-005-430 GEAR,JOINT 1 340 S5-OP6-005-440 GEAR,MIDDLE 1 341 S5-OP6-005-540 CAM,MAIN (S) 1 342 S5-OP6-005-460 CAM,P5 1 343 S5-OP6-005-650 CAM,PINCH ROLLER 1 344 S5-OP6-005-610 ROD,MAIN(S) 1 345 S5-OP7-000-350 REFLECTOR,LED 1 346 S5-OP8-003-180 SPR,LOADING GEAR 2 347 S5-OP8-003-340 SPR,P5 (S) 1 348 S5-OP8-003-350 SPR,BRAKE T (S) 1 349 S5-OP8-003-220 SPR,TENSION 1 350 S5-OP8-003-360 SPR,CAP BRAKE (S) 1 351 S5-OP8-003-420 SPRING,LOCKER (S) 1 352 S5-OP8-003-260 SPR,LINK 1 353 S5-OP8-003-280 SPR,DAMPER 1 354 S5-OP8-003-300 SPR,RING 1 355 S5-OP8-003-370 SPR,SS BRAKE (S) 1 356 S5-OP9-006-800 OPENER,CASS 1 357 S5-OP9-007-040 CASS,SIDE L(VA) 1 358 S5-OP9-006-840 CASS SIDE R 1 359 S5-OP9-007-090 TAPE GUIDE L (P,R) 1 K2-3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ELECTRICAL REPLACEMENT PARTS LIST REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION SYSCON PCB ASS'Y *** CAPACITORS *** *** RESISTORS *** C5517 87-010-545-040 CAP,E 0.22-50 V C5518 S2-35M-13R-3K0 CAP,TANTAL 3.3-10V ! R508 S6-55U-433-1J0 RES,FUSE 330-1/4W C5521 87-010-545-040 CAP,E 0.22-50 V ! R511 87-025-576-060 RES,M 68-1W C5523 87-016-334-080 CAP,E 4.7-25V ! R514 S3-X18-101-0J0 RES,M MOR1W010JB/B 1 C5525 87-015-075-040 CAP,E 10-16V ! R527 S0-X2X-212-4J0 RES,120K-1/2W C5526 87-015-075-040 CAP,E 10-16V ! R529 S6-55U-433-1J0 RES,FUSE 330-1/4W C5527 S2-35M-010-0K0 CCA,TANTAL 10-6.3V C5529 87-015-075-040 CAP,E 10-16V *** CAPACITORS *** C5531 87-015-677-010 CAP,E 100-6.3V C5532 87-015-075-040 CAP,E 10-16V ! C503 87-010-263-080 CAP,E 100-10V C5533 87-015-695-080 CAP,E 1-50V ! C504 S2-122-B10-4M0 CAP,MP 0.1-250V C5534 S0-E7T-033-0M0 CAP,E 33-6.3V ! C505 SB-NLE-0ML-3M0 CAP,0.0033-250V AC C5536 87-015-075-040 CAP,E 10-16V ! C506 S0-2LU-110-1M0 CAP,E 100-10V C5537 87-015-075-040 CAP,E 10-16V ! C508 S0-2AF-C82-0M0 CAP,E 82-200V C5538 87-015-075-040 CAP,E 10-16V C509 S0-JTS-L51-2J0 CAP,CER 100PF-500V C5539 S0-E7T-033-0M0 CAP,E 33-6.3V C512 87-010-983-010 CAP,CER 0.01-500V C5547 87-015-075-040 CAP,E 10-16V ! C514 87-010-236-080 CAP,E 1000-10V C5548 87-015-075-040 CAP,E 10-16V C517 87-015-695-080 CAP,E 1-50V C5552 87-016-053-080 CAP,E 22-16V ! C518 S0-2LU-810-0M0 CAP,E 10-100V C5555 S0-2LU-247-0M0 CAP,E 47-16V ! C519 87-010-387-010 CAP,E 470-25V C6003 87-015-075-040 CAP,E 10-16V ! C520 S0-2LU-147-1M0 CAP,E 470-10V C6008 87-010-549-010 CAP,E 47-6.3V ! C522 S0-2LU-322-1M0 CAP,E 220-25V C6010 S0-2LU-022-1M0 CAP,E 220-6.3V ! C523 S0-2LU-810-0M0 CAP,E 10-100V ! C524 SB-NLE-0ML-3M0 CAP,0.0033-250V AC *** DIODES *** C656 S0-2LU-010-1M0 CAP,E 100-6.3V C657 S0-2LU-447-0M0 CAP,E 47-35V ! D502 S2-3T0-UG2-D00 DIODE,UG2D-G23 C658 87-015-075-040 CAP,E 10-16V ! D503 87-A40-488-080 DIODE,1SS244T-77 C1013 87-010-076-040 CAP,E 22UF-6.3V ! D504 S2-LXE-658-000 DIODE,1N4005E-G23 C1016 87-010-549-010 CAP,E 47-6.3V ! D505 S2-LXE-658-000 DIODE,1N4005E-G23 C1021 S0-E7T-033-0M0 CAP,E 33-6.3V D506 S1-7T0-024-400 DIODE,1SS244T-77 C1029 87-015-677-010 CAP,E 100-6.3V ! D507 87-020-465-010 DIODE,1SS133T C1028 S5-JXT-P47-3Z0 CAP,E 0.047F-5.5V ! D508 S2-LXE-658-000 DIODE,1N4005E-G23 C1032 87-016-334-080 CAP,E 4.7-25V D509 S6-E02-711-0A0 DIODE VARISTA ENE271D-10A ! C1033 S0-2LU-810-0M0 CAP,E 10-100V D510 87-020-465-010 DIODE,1SS133T C1052 87-010-076-040 CAP,E 22UF-6.3V D511 87-A40-286-080 DIODE,RGP10JE-G3 C4001 87-010-549-010 CAP,E 47-6.3V ! D512 S2-8T1-DQ0-400 DIODE,21DQ04N-TA2B1 C4004 87-010-549-010 CAP,E 47-6.3V D513 S9-7U0-130-1B0 ZENER,MTZJ13B C4010 87-010-549-010 CAP,E 47-6.3V ! D514 S2-3T0-UG2-D00 DIODE SILICON UG2D-G23 C4011 87-015-695-080 CAP,E 1-50V ! D515 87-A40-488-080 DIODE,1SS244T-77 C4016 87-016-334-080 CAP,E 4.7-25V D517 S9-7T0-270-1D0 ZENER,MTZJ27D C4017 87-015-695-080 CAP,E 1-50V D519 S2-8T1-DQ0-400 DIODE,21DQ04N-TA2B1 C4019 87-015-695-080 CAP,E 1-50V D520 87-002-743-080 ZENER,MTZJ33B T77 C4021 S0-E7T-033-0M0 CAP,E 33-6.3V ! D523 S2-LXE-658-000 DIODE,1N4005E-G23 C4022 87-015-075-040 CAP,E 10-16V D524 87-020-465-010 DIODE,1SS133T C4023 87-010-076-040 CAP,E 22UF-6.3V D526 SM-TZ5-6C0-000 ZENER,MTZ5.6CT-77 C4024 87-016-334-080 CAP,E 4.7-25V ! D527 87-020-465-010 DIODE,1SS133T C4026 87-010-076-040 CAP,E 22UF-6.3V ! D528 S2-LXE-658-000 DIODE,1N4005E-G23 C4030 87-015-075-040 CAP,E 10-16V D651 87-070-136-010 ZENER,MTZJ5.1C T C4031 87-015-695-080 CAP,E 1-50V D652 S3-Z68-V10-000 ZENER,MTZJ6.8B C4033 87-015-695-080 CAP,E 1-50V D1001 S0-106-000-600 LED,SID1050CM C4034 87-015-695-080 CAP,E 1-50V D1002 S2-LXE-658-000 DIODE,1N4005E-G23 C4035 87-015-677-010 CAP,E 100-6.3V D1003 S9-3T1-120-1A0 ZENER,TMPG06-12A-G3 C4037 87-015-695-080 CAP,E 1-50V D1004 S2-LXE-658-000 DIODE,1N4005E-G23 C4039 87-015-695-080 CAP,E 1-50V D1005 S2-LXE-658-000 DIODE,1N4005E-G23 C4043 87-015-695-080 CAP,E 1-50V D1006 S2-LXE-658-000 DIODE,1N4005E-G23 C4045 87-010-549-010 CAP,E 47-6.3V D1007 87-020-465-010 DIODE,1SS133T C4057 87-010-076-040 CAP,E 22UF-6.3V D1009 87-020-465-010 DIODE,1SS133T C4058 87-010-076-040 CAP,E 22UF-6.3V D4001 87-020-465-010 DIODE,1SS133T C4059 87-016-334-080 CAP,E 4.7-25V D5501 87-020-465-010 DIODE,1SS133T C4060 87-015-695-080 CAP,E 1-50V C4061 87-015-695-080 CAP,E 1-50V *** ICS *** C4062 87-015-695-080 CAP,E 1-50V C4070 87-010-549-010 CAP,E 47-6.3V ! IC501 S1-KJ9-A43-100 IC,KIA431 C4071 87-015-677-010 CAP,E 100-6.3V IC651 S0-7F5-297-700 IC,BU2977FS C4201 S0-2LU-047-1M0 CAP,E 470-6.3V IC1001 S5-4F5-009-0A0 IC,OEC0090A C4209 87-015-075-040 CAP,E 10-16V ! IC1002 S0-7SQ-955-AN0 IC,BA6955AN C5501 87-015-075-040 CAP,E 10-16V IC1003 SE-1J0-S31-AH0 IC,RE5VS31A C5502 87-015-075-040 CAP,E 10-16V IC1099 S4-C9A-2B0-150 IC,S-24C08ADPA-01 C5505 87-015-695-080 CAP,E 1-50V IC4001 S0-3F3-106-7M0 IC,LA71067M-MPB C5509 87-010-402-080 CAP,E 2.2-50V IC5501 S0-1F6-2FB-P00 IC,AN3662FBP C5510 87-015-075-040 CAP,E 10-16V C5511 87-010-076-040 CAP,E 22UF-6.3V *** TRANSISTORS *** C5512 87-015-075-040 CAP,E 10-16V C5513 87-015-695-080 CAP,E 1-50V ! Q502 SD-3T0-073-400 TR,2SD734(E,F,G)-AA C5516 87-016-053-080 CAP,E 22-16V ! Q503 SC-300-416-000 TR,2SC4160-OEC K3-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ELECTRICAL REPLACEMENT PARTS LIST REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION *** TRANSISTORS *** *** CONNECTORS *** ! Q509 SD-3T0-124-600 TR,2SD1246(S,T)-AA CP4001 S6-972-906-200 CONN PWB SIDE ! Q510 S0-025-004-800 PHOTO,COUPLER TLP621 CP4002 S6-9J7-600-190 CONN,IMSA-9604S-06Z13 ! Q511 S0-025-004-800 PHOTO,COUPLER TLP621 CP4003 S6-971-203-200 CONN ! Q512 SD-3T0-073-400 TR,2SD734(E,F,G)-AA Q513 87-026-236-080 TR,DTC124EK *** CRYSTAL & CERAMIC OSCILLATORS *** ! Q518 89-324-122-080 TR,2SC2412KT Q651 87-026-227-080 TR,DTA114E X1001 S0-0CT-010-020 X'TAL,HC-49/U Q1001 S0-02M-005-700 PHOTO COUPLER SG-260 X4001 S0-0CF-3R5-120 X'TAL HC-49/U Q1002 S0-02M-005-700 PHOTO COUPLER SG-260 Q1003 89-324-122-080 TR,2SC2412KT *** TUNER *** Q1004 S0-027-005-300 PHOTO COUPLER RPI-352Q01 Q1005 S0-027-005-300 PHOTO COUPLER RPI-352Q01 ! TU6001 S1-626-000-180 RF UNIT TMDH2-A05A Q1006 S0-001-003-800 PHOTO TR,PNA2604M010R Q1007 87-026-236-080 TR,DTC124EK *** FUSES *** Q4001 SC-3T0-333-100 TR,2SC3331(S,T,U)-A Q4002 SC-3T0-333-100 TR,2SC3331(S,T,U)-A ! F501 S8-0PA-1R6-010 FUSE,23301.6 Q4003 87-026-228-080 TR,DTA124EK FH501 S6-710-T00-060 HOLDER,FUSE EYF-52B Q4004 89-318-154-080 TR,2SC1815Y FH502 S6-710-T00-060 HOLDER,FUSE EYF-52B Q4005 89-113-187-080 TR,2SA1318(S,T) Q4006 SD-3T0-073-400 TR,2SD734(E,F,G)-AA *** OTHERS *** Q4007 89-318-154-080 TR,2SC1815Y Q4008 89-324-122-080 TR,2SC2412KT OS651 S7-7Q0-000-180 REMOTE RECEIVER PIC26043LO Q4009 89-110-154-080 TR,2SA1015Y(TPE2) Q4201 89-110-154-080 TR,2SA1015Y(TPE2) V651 S9-6F7-9R0-040 CRT,SVV-07SS22 Q4202 87-026-228-080 TR,DTA124EK Q4203 89-318-154-080 TR,2SC1815Y OPERATION 1 PCB ASS'Y Q4204 89-318-154-080 TR,2SC1815Y Q4205 87-026-236-080 TR,DTC124EK *** SWITCHES *** Q6001 87-026-236-080 TR,DTC124EK SW601 S5-042-01T-320 SW,TACT *** COILS *** SW602 S5-042-01T-320 SW,TACT SW603 S5-042-01T-320 SW,TACT B501 S2-4AT-034-810 CORE,BEADS BL02RN1-R62T2 SW604 S5-042-01T-320 SW,TACT B502 S2-4AT-036-550 CORE,BEADS BL01RN1-A63T6 SW605 S5-042-01T-320 SW,TACT SW606 S5-042-01T-320 SW,TACT ! L501 S2-9T0-000-830 COIL,LINE FILTER 0R3A433F20 SW607 S5-042-01T-320 SW,TACT L504 87-003-147-010 COIL,22UH SW608 S5-042-01T-320 SW,TACT L505 87-003-147-010 COIL,22UH L1003 87-003-282-010 COIL,12UH *** CONNECTORS *** L4001 S2-167-F22-0J0 COIL,22UH EL0305RA-220J L4002 S2-167-F47-0J0 COIL,47UH EL0305RA-470J CP602 S6-9J7-400-190 CONN,IMSA-9604S-04Z13 L4003 87-005-096-010 COIL,100UH L4005 S2-167-F22-0J0 COIL,22UH EL0305RA-220J OPERATION 2 PCB ASS'Y L4007 87-003-152-010 COIL,100UH L4008 S2-167-F47-0J0 COIL,47UH EL0305RA-470J *** DIODE *** L5501 S2-167-F10-1J0 COIL,100UH EL0305RA-101J L5502 87-003-152-010 COIL,100UH D602 S0-213-5Q1-600 LED,SLZ-345B-02 L5504 S2-167-F22-0J0 COIL,22UH EL0305RA-220J L6001 S2-167-F10-1J0 COIL,100UH EL0305RA-101J *** JACK *** L6002 S2-167-F22-0J0 COIL,22UH EL0305RA-220J L6003 87-003-146-010 COIL,15UH J601 S6-0X4-310-100 JACK,RCA T4001 S3-162-600-7S0 COIL,BIAS OSC *** SWITCHES *** *** TRANSFORMERS *** SW609 S5-042-01T-320 SW,TACT SW610 S5-042-01T-320 SW,TACT ! T501 S4-812-200-440 TRANS,SWITCHING 8122004 *** CONNECTORS *** *** JACKS *** CP607 S6-9J7-800-190 CONN,IMSA-9604S-08Z13 J4201 S6-024-110-060 JACK RCA AND OTHERS *** SWITCHES *** *** CONNECTORS *** SW1001 S5-082-210-010 SW,LEAF SW6001 S5-012-010-100 SW,SLIDE SSAB110 CD601 S2-2F0-810-030 CORD,JUMPER 2F081003 CD602 S2-2F0-407-020 CORD,2F040702 *** CONNECTORS *** CD1001 S2-2F0-407-020 CORD,2F040702 CD1002 S2-2F0-615-010 CORD,JUMPER 2F061501 ! CP501 S6-973-200-390 CORD UX CONNECTOR CD4001 S2-2F0-717-010 CORD,JUMPER 2F071701 CP651 S6-9J7-400-290 CONN,PCB SIDE IMSA-9604S-04Z14 CP652 S6-9J7-800-290 CONN,IMSA-9604S-08Z14 *** AC CORD *** CP1001 S6-9J7-700-290 CONN,IMSA-9604S-07Z14 CP1002 S6-972-805-900 CONN PWB SIDE ! CD501 S2-0R6-149-020 CORD AC BUSH CP1003 S6-9J7-400-290 CONN,PCB SIDE IMSA-9604S-04Z14 K3-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 737004 Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
