DPC-5.3 SERVICE MANUAL SERVICE MANUAL DVD CHANGER Black model MODEL DPC-5.3 120V AC, 60Hz BUDD Ref. No. 3736 Sep, 2002 RC-503DV DISC SKIP SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Specifications and features are subject to change without notice. DVD Changer Power supply AC 120 V, 60 Hz Power consumption 20 W Weight 15.0 lbs External dimensions 17 1/8" x 5 1/16" x 16 15/16" (W/H/D) Signal system NTSC Frequency range (digital audio) 48 kHz sampling 4 Hz to 22 kHz 96 kHz sampling 4 Hz to 42 kHz Signal-to-noise ratio (digital audio) More than 98 dB Audio dynamic range (digital audio) More than 95 dB Harmonic distortion (digital audio) Less than 0.008 % Wow and flutter Below measurable level Operating conditions Temperature: 5 C to 35 C (41 F to 95 F) Operation status: Horizontal Outputs Video output 1.0 V (p-p), 75 ohm, negative sync., pin jack x 1 S-video output (Y) 1.0V (p-p), 75 ohm , negative sync. (C) 0.286 V (p-p), 75 ohm , Mini DIN 4-pin x 1 Component video output (Y) 1.0 V (p-p), 75 ohm , negative sync., pin jack x 1 (PB)/(PR) 0.7 V (p-p), 75 ohm pin jack x 2 Audio output (digital output Optical) Optical connecter x 1 Audio output (digital output Coaxial) 0.5 V (p-p), 75 ohm , pin jack x 1 Audio output (analog output) 2.0 V (rms), 320 ohm , pin jack (L, R) x 2 DPC-5.3 SPECIFICATIONS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SERVICE PROCEDURE 1. Replacing the fuses 2. Safety-check out (Only U.S.A. model) After correcting the original service problem perform the following safety check before releasing the set to the customer Connect the insulating-resistance tester between the plug of power supply cord and terminal GND on the back panel. Specifications: More than 10M ohm at 500V REF.NO. PART NO. DESCRIPTION F1 SR-5, T 2A 250VCA T 2.0A This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse , For fuse rating, refer to the marking adjust to the symbol. Ce symbole indique que le fusible utilise est e lent. Pour une protection permanente, n'utiliser que des fusibles de meme type. Ce demier est indique la qu le present symbol est apposre. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. POUR EVITER LES CHOCS ELECTRIQUE, INTRODUIRE LA LAME LA PLUS LARGE DA LA FICHE DANS LA BORNE CORRESPONDANTE DA LA PRISE ET POUSSER JUSQU' AU FOND. WARNING : CAUTION : ATTENTION : The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instruction in the literature accompanying the appliance. 1. Ground for the work-desk. Place a conductive sheet such as a sheet of copper (with impedance lower than 10M ohm) on the work-desk and place the set on the conductive sheet so that the chassis. 2. Grounding for the test equipments and tools. Test equipments and toolings should be grounded in order that their ground level is the same the ground of the power source. 3. Grounding for the human body. Be sure to put on a wrist-strap for grounding whose other end is grounded. Be particularly careful when the workers wear synthetic fiber clothes, or air is dry. 4. Select a soldering iron that permits no leakage and have the tip of the iron well-grounded. 5. Do not check the laser diode terminals with the probe of a circuit tester or oscilloscope. PRECAUTIONS LASER CAUTION Initialization of setup 1. Press the "CD PLAY" and "DISC 3" key to the same timing on the front panel. You will see that the program is updated by watching the version in the FL tube. 2. Push the power switch. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DP-C5.3 EXPLODED VIEW-1 CHASSIS A 1 2 3 4 5 B C D E F G H S2 S1 S1 S2 S2 46 S2 44 S2 S2 41 42 S1 S1 40 28 9 S6 39 54 55 S2 56 S2 36 30 43 23 S3 S6 S3 S2 24 S2 23 26 29 17 24 S2 21 S2 20 19 15 16 18 23 23 22 10 13 8 7 S5 S4 5 S2 2 3 4 14 1 S5 24 25 25 25 27 49 51 51 50 52 S4 S4 11 53 S2 S2 S2 S2 S2 38 12 47 48 6 1 2 58 60 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 EXPLODED VIEW-2 DVD Mechanism A 1 2 3 4 5 B C D 260 70 250 300 500 300 540 530 550 490 460 * 4 450 * 4 210 290 480 320 310 300 * 2 430 280 * 2 270 * 2 190 240 220 240 200 280 70 420 80 230 60 160 150 170 160 150 160 150 50 280 140 240 160 150 160 150 100 120 130 470 510 CLAMPER DVD ASS'Y BASE ASS'Y - CDM5G 90 110 440 520 *2 Part No. 55542660 Part No.55542650 300 560 300 300 300 5000 Assy Part No. 55542660 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 BLOCK DIAGRAM -5 POWER SUPPLY UNIT A 1 2 3 4 B C D E HOT > NUT > SW1 F1 AC INPUT LINE FILTER RECTIFIER & SMOOTHING CIRCUIT SNUBBER CIRCUIT . DRIVER CIRCUIT . VOLTAGE CONTROLLER CIRCUIT . OVER CURRENT PROTECTOR CIRCUIT VOLTAGE DETECTOR CIRCUIT +3.5V OUTPUT RECTIFIER & SMOOTHING CIRCUIT +2.5V OUTPUT RECTIFIER & SMOOTHING CIRCUIT +5V OUTPUT RECTIFIER & SMOOTHING CIRCUIT +9V OUTPUT RECTIFIER & SMOOTHING CIRCUIT -9V OUTPUT RECTIFIER & SMOOTHING CIRCUIT +12V OUTPUT RECTIFIER & SMOOTHING CIRCUIT +5.5V OUTPUT RECTIFIER & SMOOTHING CIRCUIT R2 R3 PC1 FL OUTPUT RECTIFIER & SMOOTHING CIRCUIT -27V OUTPUT RECTIFIER & SMOOTHING CIRCUIT www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 BLOCK DIAGRAM -4 DVD MECHANISM & OUTPUT CIRCUIT A 1 2 3 4 B C D E Flat cable Main circuit PC board MECHANISM CONTROL PC BOARD PICK UP AUDIO/VIDEO JACK AUDIO/VIDEO JACK www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 BLOCK DIAGRAM -3 DISPLAY SECTION A 1 2 3 4 B C D E From Power supply unit To Main PC board Key matrix www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 BLOCK DIAGRAM -2 MAIN CIRCUIT BOARD A 1 2 3 4 B C D E To Mechanism control To Pick up To Display To OUT To OUT CP25:04PIN CP25:06PIN CN27:SPDIF To OUT CP25:08PIN CP25:10PIN CP25:12PIN CP25:14PIN CP25:16PIN CP25:18PIN TR SWITCH CIRCUIT P SCAN ON/OFF IC MEMFLASH M29W800A T901N1 IC41 IC31 IC-DRAM HY57V651620BTC-8 125M 64M(1M x 16 x 4) IC- VIDEOPROC STI5519 MPEG VIDEO DECODER IC-LOGIC 74HC74 FLIF/FLOP CMOS IC-LOGIC 74HC86 GATE HCMOS INVERTER HCT IC-LOGIC M74HCU04M1R IC-OPEAMP BA4560F IC61 IC-CONV WN8728 D/A POWER SUPPLY UNIT www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 BLOCK DIAGRAM-1 OVER ALL A 1 2 3 4 5 B C D E F G H w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DV-CP500 SCHEMATIC DIAGRAM Main circuit PC board-1 A 1 2 3 4 5 B C D 100R-03 R504 100R-03 R501 20P-03 C506 20P-03 C501 1M-03 R503 R502 56R-03 C502 22P-03 X501 X-TAL 100N-03 C504 C505 470/6.3 L501 FCM2012H-102T04 D3V3 C503 22P-03 GND +3.3VM R415 FCM2012H-102T04 47K-03 R413 C406 100/10 ADD IC41 IC-M29F400T-90N1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 A15 A14 A13 A12 A11 A10 A9 A8 NC NC WE RP NC NC RY/BY A18 A17 A7 A6 A5 A4 A3 A2 A1 A16 BYTE VSS DQ15 DQ7 DQ14 DQ6 DQ13 DQ5 DQ12 DQ4 VCC DQ11 DQ3 DQ10 DQ2 DQ9 DQ1 DQ8 DQ0 QE VSS CE A0 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 F_ADDR17 F_ADDR16 F_ADDR15 F-ADDR14 F_ADDR13 F_ADDR12 F_ADDR11 F_ADDR10 F_ADDR09 F_ADDR20 F_RESET R411 DR-03 R412 DR-03 F_ADDR19 F_ADDR18 F_ADDR08 F_ADDR07 F_ADDR06 F_ADDR05 F_ADDR04 F_ADDR03 F_ADDR02 F_ADDR01 +5V6S 100N-03 C228 10R-03 R245 1K8-03 R246 1K8-03 R247 R248 47R-03 R249 47R-03 IC22 IC-M24C02 1 2 3 4 E0 E1 E2 VSS 8 7 6 5 VDD WC SCL SDA GND CP21 FPC-19P Pickup to Main PCB NC D_GND SECTOR_START DATA_VALID DATA BIT_CLOCK D_GND RESET DXX_INTERRUPT SCL SDA D_GND DRIVE_GND +3V3D +5VD D_GND A_GND DISC_M_POWER TRACK_M_POWER 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 From Display circuit PC board (To Connection PCB) To Mechanism control PCB (P406) Down load Jig www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SCHEMATIC DIAGRAM Main circuit PC board-2 A 1 2 3 4 5 B C D NC NC NC NC To Output PCB (CP01) To Power supply unit (CN2) To Output terminal PCB (CN01) Video signal out www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SCHEMATIC DIAGRAM-1 MAIN CIRCUIT PC BOARD A 1 2 3 4 5 B C D E F G H IC51 74HCU04 1N-03 C405 IC41 M29F400T-90N1 F_DATA15 F_DATA07 F_DATA14 F_DATA06 F_DATA13 F_DATA05 F_DATA12 F_DATA04 F_DATA11 F_DATA03 F_DATA10 F_DATA02 F_DATA09 F_DATA01 F_DATA08 F_DATA00 1N-03 C404 F_ADDR(01:21) F_ADDR01 F_ADDR02 F_ADDR03 F_ADDR04 F_ADDR05 F_ADDR06 F_ADDR07 F_ADDR08 F_ADDR09 F_ADDR10 F_ADDR11 F_ADDR12 F_ADDR13 F_ADDR14 F_ADDR15 F_ADDR16 F_ADDR17 F_ADDR18 F_ADDR19 F_ADDR20 R407 R408 R409 R410 47R-03 47R-03 47R-03 47R-03 RA45 47R RA46 47R RA47 47R RA48 47R 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 C215 100N-03 C216 100N-03 R239 R240 47R-03 47R-03 47R-03 R241 47R-03 R242 R243 R244 75R-03 TRIGIN 75R-03 TRIGOUT GND C217 100N-03 CN26 CP-2.0-AN-12P ROU-MO- ROU-MO+ ROU-SEN DISC-SEN CLOSE-SEN OPEN-SEN ID-MO- ID-MO+ +12V MOTOR M GND +5VD M GND 1 2 3 4 5 6 7 8 9 10 11 12 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 R269 R270 R271 R272 R273 R274 R275 R276 2R2-1/2W R277 +5VD 47K-03 47K-03 47K-03 47K-03 47K-03 47K-03 47K-03 47K-03 R261 R262 R263 R264 R265 R266 R267 R268 +12V_MOTOR 0R-03 R260 +3V3D GND +9VM +5V6S L205 FCM2012H-102T04 10K-03 R258 10K-03 R259 R256 47R-03 R257 47R-03 +5V6S C233 100P-03 CN21 CN-2.0-05P 1 RESET_MAIN 2 FRONT_TXD 3 FRONT_RXD 4 OPTION_NC 5 +5V6S 0R-03 R254 AGND 47/16 C222 0R-03 R250 (EXT_DATA) (EXT_BCLK) (3V3_R) (IRQ2) 47/16 C224 47/16 C223 FCM2012H-102T04 L203 L204 FCM2012H-102T04 +3V3 +5VD 10K-03 R251 100N-03 C225 68P-03 C226 68P-03 C227 R252 100R-03 R253 100R-03 F_DATA00 F_DATA01 F_DATA02 F_DATA03 F_DATA04 F_DATA05 F_DATA06 F_DATA07 F_DATA08 F_DATA09 F_DATA10 F_DATA11 F_DATA12 F_DATA13 F_DATA14 F_DATA15 F_DATA(00:15) 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 RA41 47R RA42 47R RA43 47R RA44 47R +3V3 +2V5 100N-03 C214 157 CPU_DATA(14) 158 CPU_DATA(15) 159 VDD3_3 160 VSS 161 CPU_ADR(1) 162 CPU_ADR(2) 163 CPU_ADR(3) 164 CPU_ADR(4) 165 CPU_ADR(5) 166 CPU_ADR(6) 167 CPU_ADR(7) 168 CPU_ADR(8) 169 CPU_ADR(9) 170 CPU_ADR(10) 171 VDD2_5 172 VSS 173 CPU_ADR(11) 174 CPU_ADR(12) 175 CPU_ADR(13) 176 CPU_ADR((14) 177 CPU_ADR(15) 178 CPU_ADR(16) 179 CPU_ADR(17) 180 CPU_ADR(18) 181 CPU_ADR(19) 182 CPU_ADR(20) 183 CPU_ADR(21) 184 VDD3_3 185 VSS 186 PIO0(0) T_STROBE 187 PIO0(1) MOD_SW 188 PIO0(2) 189 PIO0(3) 190 PIO0(4) 191 PIO0(5) 192 PIO0(6) SLIDER_SENSOR_OPEN/VLOSE 193 PIO0(7) SLIDER_IN (DRAWER_CCW_CTRL) 194 PIO1(0) SDA 195 PIO1(1) SCL 196 PIO1(2) SLIDER_OUT (DRAWER_CW_CTRL) 197 PIO1(3) TXD(JIG) 198 VDD2_5 199 VSS 200 PIO1(4) RXD(JIG) 201 PIO1(5) FRONT_TXD1 202 TRIGGER_IN 203 TRIGGER_OUT 204 PIO2(0) VIDEO_MUTE 205 PIO2(1) FRONT_RXD 206 PIO2(2) AUDIO_MUTE 207 PIO2(3) DAC_LATI2S_OUT 208 PIO2(4) DAC_SCKDSD_OUT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 PIO2(5) DAC_SDIOEM_IN/OUT PIO2(6) DAC_MUTEB_IN/OUT PIO2(7) DAC_CSBIWL_OUT VDD3_3 VSS PIO3(0) PRO_SCAN_ON/OFF PIO3(1) PIO(2) PIO(3) PIO3(4) IR(REMOTECONT) PIO3(5) PIO3(6) PIO3(7) DVD_RESET DVV2_5 VSS B_DATA B_BCLK B_FLAG B_SYNC B_WCLK B_V4 NRSS_OUT VDD_RGB VSS_RGB B_out G_OUT R_OUT V_REF_RG I_REF_RG VDD_YCC VSS_YCC Y_OUT C_OUT CV_OUT V_REF_YC I_REF_YC VDD2_5 VSS PIO4(0) PIO4(1) PIO4(2) PIO4(3) PIO4(4) PIO4(5) PIO4(6) PIO4(7) VDD3_3] VDD_PCM VSS_PCM VSS DAC_SCLK (BCK) DAC_PCMOUT0 (DATA) PCM_DATA_OUT R617 47R-03 PCM_BCK_OUT R616 47R-03 +2V5 L603 2U2H C617 100/10 C616 10N-03 100N-03 C615 GND R103 R104 R105 R106 R107 R108 R109 R110 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 47R-03 18K-03 R102 100N-03 C105 300R-03 300R-03 300R-03 R10Y R10C R10S R11S R11C R11Y 10R-03 10R-03 10R-03 R11R R11G R11B 10R-03 10R-03 10R-03 300R-03 300R-03 300R-03 R10B R10G R10R 10N-03 C104 C103 100/10 L102 2U2H C101 100/10 10N-03 C102 2U2H L101 +2.5VA 470/6.3 C203 100N-03 C204 AGND PM0026STB PM0026DATA PM0026CLK +3V3D R609 4K7-03 R613 47R-03 R611 47R-03 R610 47R-03 R608 47R-03 R607 47R-03 100R-03 R135 47R-03 R205 10N-03 C229 R206 10K-03 +3V3D PRO_SCAN_ON_OFF 1SS355(SMD) D101 C132 100N(SMD) GND 4K7(S) R136 +5VD DAC_CSBIWL_OUT DAC_SDIDEM_IN/OUT DAC_SCKSD_OUT DAC_LATI3S_OUT AUDIO_MUTE 104 103 102 101 100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 SPDIF 56 PCM_LR$CIN 55 PCM_MCLK 54 53 ADC_LRCLK ADC_SCLK SMI_DATA(15) SMI_DATA(14) SMI_DATA(13) SMI_DATA(12) SMI_DATA(11) SMI_DATA(10) VSS SMI_CLKOUT VDD2_5 SMI_DATA(9) SMI_DATA(8) SMI_DATA(7) SMI_DATA(6) SMI_DATA(5) SMI_DATA(4) SMI_DATA(3) SMI_DATA(2) SMI_DATA(1) SMI_DATA(0) VSS SMI_CLKIN VDD3_3 SMI_DQMU SMI_DQML SMI_WE SMI_CAS SMI_RAS SMI_CS(1) SMI_CS(0) SMI_ADR(13) SMI_ADR(12) SMI_ADR(11) SMI_ADR(10) SMI_ADR(0) SMI_ADR(1) SMI_ADR(2) SMI_ADR(3) VSS VDD2_5 SMI_ADR(9) SMI_ADR(8) SMI_ADR(7) SMI_ADR(6) SMI_ADR(5) SMI_ADR(4) SPDIF_OUT (LRCIN) DAC_LRCLK (MCLK) DAC_PCMCLK DAC_PCMOUT2 DAC_PCMOUT1 PCM OUT 6-CHANNEL AUDIO DECODER PAL/NTSC/SECAM ENCODER 10-BIT DAC 10-BIT DAC 10-BIT DAC INTERFACE FRONT-END 3-PWM Outputs 12C Controller 2-UARTS 38-Bit Programable I/O IC21 FLASH MEMORY INTERFACE CPU MEMORY PROGRAMABLE GENERATOR CLOCK PLL DIAGNOSTICS CONTROLLER AND SYSTEM SERVICE KARAOKE MODULE SDRAM MEMORY INTERFACE SHARED MEMORY 4KB SRAM DATA-CACHE 2KB 2KB CACHE INSTRUCTION 156 155 154 153 152 151 150 149 148 147 146 145 144 143 142 141 140 139 138 137 136 135 134 133 132 131 130 129 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105 CPU_DATA(13) CPU_DATA(12) CPU_DATA(11) CPU_DATA(10) CPU_DATA(9) CPU_DATA(8) VSS VDD2_5 CPU_DATA(7) CPU_DATA(6) CPU_DATA(5) CPU_DATA(4) CPU_DATA(3) CUP_DATA(2) CPU_DATA(1) CPU_DATA(0) CPU_CAS1 CPU_CAS0 CPU_RAS1 VSS VDD3_3 CPU_CE(0) CPU_CE(1) CPU_CE(2) CPU_CE(3) CPU_WAIT CPU_RW CPU_BE(1) CPU_BE(0) IRQ(0) IRQ(1) IRQ(2) RESET VSS_PLL VDD_PLL VSS PIX_CLK VDD2_5 CPU_PROCLK CPU_OE PWM0 PWM1 PWM2 TCK TDI TDO TMS TRST VSS VDD3_3 ADC_PCMCLK ADC_DATA PROG_H +3V3D DTA114TS Q101 DTC114YS Q102 R111 3K3-03 10K-03 R22G 13K7-03-1% R23G 5K6-03 R12G 36K-03 R13G 10/16 C10G Q10G DTC114YKA Q11G KTN2222 Q12G KTN2222 Q13G KTN2907A 2K2-03 R14G 13K7-03-1% R24G R15G 680(SMD) C11G 10/16 5K6-03 R17G Q14G DTC114YKA 36K-03 R16G 13K7-03-1% R24B 10/16 C11B R15B 680(SMD) 5K6-03 R17B 36K-03 R16B Q14B DTC114YKA Q13B KYN2907A Q11B KTN2222 Q12B KTN2222 2K2-03 R14B 36K-03 R13B 5K6-03 R12B 10/16 C10B Q10B CTC114YKA 13K7-03-1% R23B 10K-03 R22B AGND 1K(SMD) R137 Q103 KTC3875(S) C12R 1/50 C12B 1/50 100N-03 C12C C106 22/16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 VCC1 CIN MUTE1 VIN SELECT YIN BIAS GND1 NC GND1 NC CY CLP Cb MUTE2 Cr GND2 VCC2 C GND2 CVBS GND2 Y GND2 CY GND2 Cb GND2 Cr 6dB 6dB 6dB 6dB 6dB 6dB 13.5MHz 13.5MHz 13.5MHz IC12 IC-MM1568 LPF LPF LPF LPF LPF LPF 10N-03 C12C 100N-03 C12S 100N-03 C12Y 100N-03 C13C 75R-03 R25C C13S 100/16 C14S 22/16 75R-03 R25S 13Y 100/16 C14Y 22/16 75R-03 R25Y C13G 100/16 C14G 22/16 C13B 100/16 75R-03 R25G 75R-03 R25B 75R-03 R25R C14B 22/16 C13R 100/16 C14R 22/16 AGND 10K-03 R29R 10K-03 R29B 10K-03 R29C 10K-03 R29C 10K-03 R29S 10K-03 R29Y 10N-03 C131 C130 100/16 IC13 TL431 82R-03 R114 R113 3K6-05 1K4-05 R112 0.5% 0.5% C113 100N-03 VR11 200 Q15G KTN2907A Q15B KTN2907A Q15R KTN2907A 2R2-03 R116 1N-03 C114 1N-03 C116 R18R 1K(SMD) 100(SMD) R19R R20R 75(SMD) R18B 1K(SMD) 100(SMD) R19B R20B 75(SMD) R18G 1K(SMD) 100(SMD) R19C R20G 75(SMD) 360R-03 R115 C111 1N-03 100N-03 C112 C110 1N-03 C109 1N-03 C108 1N-03 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 C107 1N-03 VDD3 VIB9 VIB8 VIB7 VIB6 VIB5 VIB4 VIB3 GND GND GND VIB2 VIB1 VIB0 DOS1 DOS0 TEST2 TEST1 TEST0 VDD3 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 VDD3 SPR4/VO6 SPR5/VO7 SPR6/VO8 GND SPR7/VO9 CLMP AGND VG AVDD2 FSADJ VREF AVDD2 DAO_R AGND DAO_B AVDD2 DAO_Y AGND VDD2 IC PM0026A VDD3 SRN CLK GND RAM2 RAM3 RAM4 RAM5 GND GND GND VDD3 VO0 VO1 SPR0/VO2 SPR1/VO3 SPR2/VO4 SPR3/VO5 GND VDD3 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 VDD2 CSB SDTA SCLK RAM1 RAM0 CKPOL VIA9 VIA8 VIA7 VIA6 VIA5 VIA4 VIA3 VIA2 VIA1 VIA0 NVS NHS VDD3 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 C129 1N-03 VSYNC HSYNC R138 100R-03 R134 100R-03 R127 100R-03 R128 100R-03 R129 100R-03 R130 47K-03 R131 47K-03 R132 100R-03 1N-03 C125 PM0026STB PM0026DATA PM0026CLK L604 BEAD 120 ohm 47R-03 R619 R618 100R-03 C620 10P-03 10P-03 C621 GND +2V5 +3V3 0R-03 J301 SASSR13 SADDR12 SADDR11 SADDR10 SADDR00 SADDR01 SADDR02 SADDR03 SADDR09 SADDR08 SADDR07 SADDR06 SADDR05 SADDR04 R302 100R-03 R301 100R-03 RA33 47R RA32 47R RA31 47R 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 F_RESET R124 2R2-03 R123 2R2-03 1N-03 C123 10R-03 R126 100/16 C124 100/16 C122 1N-03 C121 10R-03 R125 +2V5D +3V3D 1N-03 C120 R122 47K-03 R121 47K-03 R120 47K-03 R119 47K-03 C119 1N-03 +2V5A +5VA R118 2R2-03 100/16 C117 100N-03 C118 GND 10K-03 R22R 13K7-03-1% R23R Q11R KTN2222 Q12R KTN2222 10/16 C10R 5K6-03 R12R 36K-03 R13R 2K2-03 R14R Q13R KTN2907A Q10R DTC114YKA R15R 680(SMD) 13K7-03-1% R24R C11R 10/16 5K6-03 R17R 36K-03 R16R Q14R DTC114YKA 10R-03 R117 100/16 C115 PCM_LRCIN_OUT PCM_DATA_OUT PCM_BCK_OUT PCM_MCLK_OUT CN27 CP_2.0_ST_02P 1 2 1.SPDIF 2.D_GND L301 0R-03 C311 100/10 100N-03 C312 GND 0R-03 R314 +3V3 SADDR(00:13) R309 R308 R307 R306 R305 R304 R303 100R-03 100R-03 100R-03 100R-03 100R-03 100R-03 100R-03 R310 R311 R312 R313 4K7-03 4K7-03 4K7-03 4K7-03 SADDR12 SADDR13 SADDR10 SADDR00 SADDR01 SADDR02 SADDR03 SDATA(00:15) SDATA00 SDATA01 SDATA02 SDATA03 SDATA04 SDATA05 SDATA06 SDATA07 SDATA15 SDATA14 SDATA13 SDATA12 SDATA11 SDATA10 SDATA09 SDATA08 SDATA07 SDATA06 SDATA05 SDATA04 SDATA03 SDATA02 SDATA01 SDATA00 RA37 47R RA36 47R RA35 47R RA34 47R 1 3 5 7 2 4 6 8 1 3 5 7 1 3 5 7 1 3 5 7 2 4 6 8 2 4 6 8 2 4 6 8 GND SDATA(00:15) IC31 SDRAM_4Mx16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 VCC DQ0 VCCQ DQ1 DQ2 VSSQ DQ3 DQ4 VCCQ DQ5 DQ6 VSSQ DQ7 VCC LDQM WE CAS RAS CS BA0 BA1 A10 A0 A1 A2 A3 VCC VSS DQ15 VSSQ DQ14 DQ13 VCCQ DQ12 DQ11 VSSQ DQ10 DQ9 VCCQ DQ8 VSS NC UDQM CLK CKE NC A11 A9 A8 A7 A6 A5 A4 VSS 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 SADR11 SADDR09 SADDR08 SADDR07 SADDR06 SADDR05 SADDR04 R315 47K(SMD) SDATA15 SDATA14 SDATA13 SDATA12 SDATA11 SDATA10 SDATA09 SDATA08 C133 100N-03 IC14 74AHC74 1 2 3 4 5 6 7 14 13 12 11 10 9 8 1RD 1D 1CP 1SD 1Q 1Q GND VCC 2RD 2D 2CP 2SD 2Q 2Q 1 2 3 4 5 6 7 14 13 12 11 10 9 8 IC15 74AHC86 GND VCC C134 100N-03 R147 10R-03 V_SYNC H_SYNC +9V 0R-03 R21P KIA7805API IC1P 100/10 C21P L210 FCM2012H-102T04 +5VA (VIDEO_AUDIO) -9V +12V_SCART +5V5S +3V5D +2V5D +5VD +9V_MOTOR 1 2 3 4 5 6 7 8 9 10 11 12 +9V A_GND -9V +12V_SCART +5V6S +3V5D D_GND +2V5D +5VD +9V_MOTOR M_GND NC CN25 CN_2.5_12P W4 0R_03 W3 0R_03 CP25 FPC_ST_23P(6216) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 1. DGND 2. SPDIF 3. AGND 4. AUDIO_R 5. AGND 6. AUDIO_L 7. AGND 8. CVBS 9. AGND 10. C_OUT 11. AGND 12. Y_OUT 13. AGND 14. R_OUT(Cr) 15. AGND 16. G_OUT(Y) 17. AGND 18. B_OUT(Cb) 19. +5VD 20. NC 21. PRO_SCAN_ON_OFF AGND AUDIO_R AUDIO_L CVBS C_OUT Y_OUT R_OUT(Cr) G_OUT(Y) B_OUT(Cb) +5VD PRO_SCAN TXD RXD R207 47R_03 R208 47R_03 +5VD DOWN LOAD JIG 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 10R-03 R414 GND FPC-ST_15P CP22 10K-03 R406 10K-03 R405 R404 R403 R402 R401 47R-03 47R-03 47R-03 47R-03 GND 10K-03 R237 47R-03 R238 +2V5 10R-03 R236 C210 100/10 10N-03 C211 10K-03 R234 47R-03 R235 C209 100N-03 +3V3 R232 10K-03 10K-03 R233 +2V5 100N-03 C213 100N-03 C212 +3V3 100R-03 R504 100R-03 R501 20P-03 C506 20P-03 C501 1 2 3 4 5 6 7 14 13 12 11 10 9 8 GND VCC 1M-03 R503 R502 56R-03 C502 22P-03 X501 X-TAL 100N-03 C504 C505 470/6.3 C503 22P-03 D3V3 GND L501 FCM2012H-102T04 F_ADDR17 F_ADDR16 F_ADDR15 F-ADDR14 F_ADDR13 F_ADDR12 F_ADDR11 F_ADDR10 F_ADDR09 F_ADDR20 F_RESET R411 DR-03 R412 DR-03 F_ADDR19 F_ADDR18 F_ADDR08 F_ADDR07 F_ADDR06 F_ADDR05 F_ADDR04 F_ADDR03 F_ADDR02 F_ADDR01 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 A15 A14 A13 A12 A11 A10 A9 A8 NC NC WE RP NC NC RY/BY A18 A17 A7 A6 A5 A4 A3 A2 A1 A16 BYTE VSS DQ15 DQ7 DQ14 DQ6 DQ13 DQ5 DQ12 DQ4 VCC DQ11 DQ3 DQ10 DQ2 DQ9 DQ1 DQ8 DQ0 QE VSS CE A0 GND R415 FCM2012H-102T04 47K-03 R413 C406 100/10 +3.3VM ADD R411 R412 R413 ATMEL 16M 0 ohm NC 4K7 ST 16M NC 0 ohm +5V6S 100N-03 C228 10R-03 R245 1K8-03 R246 1K8-03 R247 R248 47R-03 R249 47R-03 IC22 IC-M24C02 1 2 3 4 E0 E1 E2 VSS 8 7 6 5 VDD WC SCL SDA GND +3V3 +2V5 L201 0R-03 2U2H L202 C201 100/10 100N-03 C202 C CVBS Y CY Cb Cr SADDR(00:13) +3V3D F_RESET +3V3 470P-03 C205 4K7-03 R215 Q201 KTC3875(S) GND Q202 KTC3875(S) 100N-03 C206 1K-03 R218 1K-03 R214 4K7-03 R216 10K-03 R217 100N-03 C208 +3V3 R219 0R-03 JTAG TEST CONNECTION R220 0R-03 R222 10K-03 R223 10K-03 R224 10K-03 100N-03 C207 47K-03 R221 R225 47R-03 R226 47R-03 R227 47R-03 R228 47R-03 R229 47R-03 10K-03 R230 GND R231 0R-03 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1: TRIGOUT 2: TRIGIN 3: GND(Option) 4: TMS 5: GND 6: TCK 7: GND 8: TDI 9: GND 10: TDO 11: +5VD 12: TDX(JIG) 13: RXD(JIG) 14: JTAG_RST/ 15: TRST FPC_ST_15P CP23 L602 FCM2012H_102T04 +5VA +5VD L601 FCM2012H_102T04 10/50 C603 C604 560P-03 47/16 C601 C602 560P-03 R615 4K7-03 R614 47R-03 C605 10P-03 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 LRCIN DIN BCKIN MCLK ZERO DGND DVDD VOUTR AGND AVDD LAT125 SCKSD SDIDEM MUTEB MODE CSBIWL VREFP VREFN VMID VOUTL IC61 WM8728(SSOP) R612 4K7-03 47K-03 R605 33R-03 R602 33R-03 R601 C608 100/10 10/16 C606 C607 560P-03 AGND GND MCLK_IN BCK_IN DATA_IN LRC_IN +3V3 DAC_LAT125 DAC_SCKDSD DAC_SDIOEM DAC_CSBIWL 10P-03 C613 10P-03 C612 10P-03 C611 10P-03 C610 10P-03 C609 C61L 47/16 R61L 47K-03 R62L 4K7-03 C62L 2N7-03 R64L 9K1-03 R63L 3K9-03 C63L 330P-03 1 2 3 IC62-A BA4560 C65L 47/16 AGND 330R-03 R67L 47/16 C66R 100R-03 R65R R66R 100K-03 C67R 100P-03 Q61R DTC323TK(S) -9V Q61L DTC323TK(S) 820K-03 R606 47/16 C66L 100R-03 R65L R66L 100K-03 C67L 100P-03 AUDIO_L AUDIO_R Q601 DTA114YKA 0R-03 R604 Q602 DTC114YKA 1SS355(SMD) D601 A_MUTE +9VA 470R-03 R605 1N414B D602 330/6.3 C614 +9V BA4560 IC62-B 5 6 7 OUT 8 AGND 330R-03 R67R C65R 47/16 R64R 9K1-03 C63R 330P-03 R63R 3K9-03 C61R 47/16 R62R 4K7-03 C32R 2N7-03 47K-03 R61R 18K-03 R101 C618 10P-03 C619 10P-03 1 2 3 G +5VA 1 2 3 R201 R202 R203 R204 100R-03 100R-03 100R-03 100R-03 CP21 FPC-19P From Pickup to Main PCB From Display circuit PC board (to connection PCB) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 NC D_GND SECTOR_START DATA_VALID DATA BIT_CLOCK D_GND RESET DXX_INTERRUPT SCL SDA D_GND DRIVE_GND +3V3D +5VD D_GND A_GND DISC_M_POWER TRACK_M_POWER OUT STI5519 ST20 CPU C128 47P-03 C127 47P-03 C126 47P-03 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-2 OUTPUT TERMINAL PC BOARD A 1 2 3 4 5 B C D RS-232C TERMINAL From Main PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 RI IN/OUT JACJ PC BOARD E F G H NC NC 1K 1K VIDEO OUT S-VIDEO OUT VIDEO COMPONENT OUT 100R 100R NC NC FILTER CIRCUIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SCHEMATIC DIAGRAM-2 OUTPUT TERMINAL PC BOARD RI IN/OUT JACJ PC BOARD A 1 2 3 4 5 B C D E F G H NC NC 1K 1K VIDEO OUT S-VIDEO OUT VIDEO COMPONENT OUT RS-232C TERMINAL From Main PCB 100R 100R NC NC FILTER CIRCUIT w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 E F G H FL Tube FL91 From Power supply unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SCHEMATIC DIAGRAM A 1 2 3 4 5 B C D DISPLAY CIRCUIT PC BOARD To OUTPUT TERMINAL PC BOARD STANDBY LED PC BOARD To Front To Standby LED www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SCHEMATIC DIAGRAM A 1 2 3 4 5 B C D E F G H DISPLAY CIRCUIT PC BOARD To OUTPUT TERMINAL PC BOARD STANDBY LED PC BOARD To Front To Standby LED FL Tube FL91 From Power supply unit w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A 1 2 3 4 B C D E AC POWER SW1 F1 250V2A TNR1 10471K R1 1M 1/4W C1 104 LF1 C2 104 20MH C22 101 C23 102 D1-D4 1N4007 NT1 10D-9 C3 200V100 R2 2W47K C4 630V472 T1 EER2828 R41 3.3 R39 2.2 D8 UF4003 D9 UF4003 D10 SR206 C10 1KV102 R9 4.7 L3 4.7uH C11 25V470 C12 25V470 L2 4.7uH D11 SR204 C14 10V1000 C16 10V470 L1 4.7uH R21 1K R22 100 PC1/A R14 1.5KF C15 50V1 U2 431 R16 150 R17 820 R13 2.2K R15 18K R10 680 D13 SR1A0 R18 1K C18 10V470 R19 330 R20 330 D14 1N4007 CN2 U3 KA7809 I O G C13 50V22 +B GND -12V +12V RST +2.5 GND +2.5 +5 +9 GND NC GND +FL -27 -FL +5.65 CN1 1 2 3 4 5 1 2 3 4 5 6 7 8 9 10 11 12 R5 1K R6 10 ZD1 3.3V R7 4.7K C7 10V470 C8 50V100 C9 50V100 R8 1K C19 1KV101 D5 UF4007 R3 330K PC18 817 ZD3 9.1V C5 333 1 FB VCC U1 KA1L0365R C6 50V22 C21 152Y1 C17 10V1000 D12 SR204 D6 1N4148 R4 22 R40 2.2 D7 1N5819 NOTE 1. Resistor values are indicated in ohms unless otherwise specified ( K = 1.000 M = 1.000.000 ) 2. Capacitor values are indicated in microfarades or picofarades ( :microfarades :pocofarades) CAUTION Safety precaution to be followed during servicing 1) Since those parts marked with are critical parts for safety. use only the one described in the parts list. 2) Before returning the set to the customer make apprppriate laekage current or resistance measurements to determine the exposed parts are prpperly insulated from the supply circuit. DPC-5.3 SCHEMATIC DIAGRAM 5 POWER SUPPLY UNIT www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 SCHEMATIC DIAGRAM 4 MECHANISM SECTION A 1 2 3 4 B C D E CAROUSEL MOTOR PC BOARD www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 CP93 CN93 OPEN/CLOSE CN96 CN91 CP96 STANDBY LED CN92 CP94 CN1 CN2 CN3 AC120V 60Hz PC BOARD CONNECTION DIAGRAM OUTPUT TERMINAL PC BOARD CN25 CP25 CP01 CN27 CN01 CN21 CP22 CN26 CP95 P003 P406 B10 CP21 DISPLAY CIRCUIT PC BOARD OPEN/CLOSE SWITCH PC BOARD STANDBY LED PC BOARD POWER SUPPLY UNIT MAIN CIRCUIT PC BOARD TRAVERSE MECHA. Roulette motor PC board P027 To Roulette motor FFC FFC MECHANISM CONTROL PC BOARD RI IN/OUT JACK PC BOARD RS-232C TERMINAL www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PRINTED CIRCUIT BOARD VIEW 1 MAIN CIRCUIT PC BOARD A 1 2 3 4 5 B C D Bottom pattern and Bottom component www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PRINTED CIRCUIT BOARD VIEW 1 A 1 2 3 4 5 B C D Top pattern and Top component MAIN CIRCUIT PC BOARD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 2 Display circuit PC board A 1 2 3 4 5 B C D S927 S924 S921 S917 S915 S905 S907 S911 S927 S924 S921 S917 S915 S905 S907 CN93 DISC5 DISC4 DISC2 DISC3 DISC1 DISC SKIP S903 FF STOP S901 FR PLAY/PAUSE J902 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 E F G H S913 CN91 CN96 CN92 RM91 + FL91 S913 CN91 CN96 CN92 FL91 J901 C909 + C901 + C907 + C906 J903 J904 J920 IC91 Soldering side Component side www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 2 Display circuit PC board A 1 2 3 4 5 B C D E F G H S927 S924 S921 S917 S915 S905 S907 S911 S913 CN91 CN96 CN92 RM91 + FL91 S927 S924 S921 S917 S915 S905 S907 S913 CN91 CN96 CN92 FL91 CN93 DISC5 DISC4 DISC2 DISC3 DISC1 DISC SKIP S903 FF STOP S901 FR PLAY/PAUSE J902 J901 C909 + C901 + C907 + C906 J903 J904 J920 IC91 Soldering side Component side w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 3 A 1 2 3 4 5 B C D E F G H + C802 D711 CN01 IC85 JK81 JK82 JK83 CP01 Output terminal PC board Soldering side Component side 9 8 7 6 5 4 3 2 1 9 8 7 6 5 4 3 2 1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 3 A 1 2 3 4 5 B C D Output terminal PC board S Co 9 8 7 6 5 4 3 2 1 9 8 7 6 5 4 3 2 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 E F G H + C802 D711 CN01 IC85 JK81 JK82 JK83 CP01 Soldering side omponent side www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PRINTED CIRCUIT BOARD VIEW FROM SOLDERING SIDE 4 A 1 2 3 4 5 B C D JW13 JW17 JW6 JW21 JW3 R001 JW7 Roulette motor PC board Component side view Mechanism control PC board P1003 P1004 D-PHOTO GP2S28 WCL 060-05 UL24 D-PHOTO RP1574/GP1S58V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ri IN/OUT Jack PC board DPC-5.3 E F G H R002 JW14 JW22 C004 C003 C002 JW8 JW18 IC001 IC002 R003 R004 JW10 C001 D002 D001 JW20 - L001 C005 JW15 Component side view Soldering side view Component side view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ri IN/OUT Jack PC board DPC-5.3 PRINTED CIRCUIT BOARD VIEW FROM SOLDERING SIDE 4 A 1 2 3 4 5 B C D E F G H JW13 JW17 JW6 JW21 JW3 R001 JW7 R002 JW14 JW22 C004 C003 C002 JW8 JW18 IC001 IC002 R003 R004 JW10 C001 D002 D001 JW20 - L001 C005 JW15 Roulette motor PC board Component side view Mechanism control PC board Component side view Soldering side view P1003 P1004 D-PHOTO GP2S28 WCL 060-05 UL24 D-PHOTO RP1574/GP1S58V Component side view w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 5 A 1 2 3 4 5 B C D Connection PC board Standby LED PC board S931 CP96 S930 CP93 OPEN/CLOSE OPEN/CLOSE Switch PC board CP94 CP95 Soldering side Component side Soldering side Soldering side Soldering side D905 Inlet terminal PC board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 FW DOWNLOAD When the name of the binaly file you wantto downloding is "dvcp5111.bin", you may type "ttcmake dpc5.3fw1" in thr DOS prompt. Space Adifferent bin file requires a new data. 1. "TTCMAKE.EXE" file is downloaded to its own personal computer. (C-Drive) 2. "dvcp5111.bin" file is downloaded to its own personal computer. Fig. 1 (The same drive as 1.) 3. Call the "ttcmake dvcp5111" in the DOS prompt. 4. Call the file name of "dpc5.3" holder, and "ttcmake dvcp5111" . Fig. 2 5. Created the "ENTRISE. TTC" Fig. 3 6. File created by 5. is copied to CD-R. Caution: File format should be "ISO9660" TTCMAKE.EXE : application file dvcp5111.bin : Binaly file Fig. 1 Fig. 2 Fig. 3 C: >cd.. C: dpc5.3>ttcmake dvcp5111 C: cd dpc5.3 Confirm the firmware "CD PLAY" button and "DISC 3" button on the front panel should be pressed at the same time. --------- Factory EEPROM reset. Wattching the version of firmware in the FL tube. dps5.3 dps5.3 cd dpc5.3 dpc5.3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 DISASSEMBLY PROCEDURE Remove the roulette 1. Pull out the tray. 2. Stops in the position (cut deeply). 3. Remove in the direction of arrow. 4. Reassembly is performed by 3 to 1. Roulette Cut deep Short Land Replacement of DVD mechanism The laser diode in the optical pickup block so sensitive to static electricity, surge current and etc.. That the components are liable to be broken down or its reliability remarkable deteriorated. During repair, carefully take the following precautions. Do not touch the optical pickup object lens with the hands. 1. Remove the top cover with six screws. 2. Remove the tray. 3. Remove the roulette assembly. 4. Remove the roulette. (Roulette is removed as written below.) 5. Solder the LD output lands on the DVD optical pickup. Please perform right photo to reference. 6. Replace the pickup mechanism assembly etc. . After unsolder the laser diodes output lands. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 PACKING VIEW RC-503DV DPC-5.3 Rear side 50 230 205 60 80 100 110 130 120 150 210 240 220 250 105 170 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PRINTED CIRCUIT BOARD PARTS LIST MAIN CIRCUIT PC BOARD CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION C13B 20269020 30 PCE CE 100U0F +20% 16.0V 85C C13G 20269020 30 PCE CE 100U0F +20% 16.0V 85C C13R 20269020 30 PCE CE 100U0F +20% 16.0V 85C C13S 20269020 30 PCE CE 100U0F +20% 16.0V 85C C13Y 20269020 30 PCE CE 100U0F +20% 16.0V 85C CC21 55532610 NR PCE FFC-JUMPER 19X 1.25MM 220MM FOLD CC25 55238420 NR PCE FFC-JUMPER 23X 1.25MM 100MM CN21 55182960 NR PCE WIRECONASY UNIQUE 5P 130MM UL1007 PVC DISCRETE 26 1 CN25 55182970 NR PCE WIRECONASY UNIQUE 12P 150MM UL1007 PVC DISCRETE 26 1 CN26 55123450 PCE CONNECTOR 2.0MM 12 MA R NAT LW2003P12 0 0 CN27 55541130 NR PCE SOCKET AS DL 2.0MM BLUE 2P 270MM UL1533 SHIELD 26 1 CP21 55124680 PCE CONNECTOR 1.25MM 19 FE R WH GF120-19S-LS 2794 A6 CP22 55125910 NR PCE CONNECTOR 1.0MM 15 FE ST BK 00-6232-015-006-800 0 0 CP25 55124620 PCE CONNECTOR 1.25MM 23 FE ST WH GF120-23S-TS 2794 A6 D602 70436540 16 PCE D-SLP 1N4148 100.0V 150E-3A FING 55178960 PCE SPRING PLATE GND1 55135980 NR PCE LUG TERMINAL GND IC13 15069010 56 PCE IC-REGSPECKT TL431 IC1P 55491690 NR PCE IC-REGPOSFXD KIA7805AP NORMAL R277 55232770 NR PCE RMF 2R2 OHM +5% 500MI0W VR11 55307870 NR PCE PR 200R0 OHM +30% 100MI0W X501 55128980 NR PCE FILQZ 27M0 HZ +15 PPM 50.0 OHM FUNDAMENTAL 16P5 F J301 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W L101 55188040 91 PCE LF-SMD 2U2H +10% L102 55188040 91 PCE LF-SMD 2U2H +10% L201 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W L202 55188040 91 PCE LF-SMD 2U2H +10% L203 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L204 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L205 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L210 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L601 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L602 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L603 55188040 91 PCE LF-SMD 2U2H +10% Q101 55133190 92 PCE TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM Q12B 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q12G 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q12R 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q14B 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q14G 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q14R 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q15B 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A Q15G 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A Q15R 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A W003 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W W004 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W C101 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C103 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C106 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C10B 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C10G 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C10R 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C115 20269020 30 PCE ELECT. CAPCITOR 100U0F +20% 16.0V 85C C117 20269020 30 PCE ELECT. CAPCITOR 100U0F +20% 16.0V 85C C11B 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C11G 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C11R 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C122 20269020 30 PCE ELECT. CAPCITOR 100U0F +20% 16.0V 85C C124 20269020 30 PCE ELECT. CAPCITOR 100U0F +20% 16.0V 85C C12B 20268840 30 PCE ELECT. CAPCITOR 1U0F +20% 50.0V 85C C12R 20268840 30 PCE ELECT. CAPCITOR 1U0F +20% 50.0V 85C C130 20269020 30 PCE ELECT. CAPCITOR 100U0F +20% 16.0V 85C C14B 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C14G 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C14R 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C14S 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C14Y 20251930 30 PCE ELECT. CAPCITOR 22U0F +20% 16.0V 85C C201 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C203 20268620 30 PCE ELECT. CAPCITOR 470U0F +20% 6.3V 85C C210 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C21P 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C222 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C223 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C224 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C311 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C406 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C505 20268620 30 PCE ELECT. CAPCITOR 470U0F +20% 6.3V 85C C601 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C603 20268880 30 PCE ELECT. CAPCITOR 10U0F +20% 50.0V 85C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com C606 15002130 30 PCE ELECT. CAPCITOR 10U0F +20% 16.0V 85C C608 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C614 20269110 30 PCE ELECT. CAPCITOR 330U0F +20% 6.3V 85C C617 20268940 30 PCE ELECT. CAPCITOR 100U0F +20% 10.0V 85C C61L 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C61R 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C65L 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C65R 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C66L 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C C66R 20267830 30 PCE ELECT. CAPCITOR 47U0F +20% 16.0V 85C D101 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A D601 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A IC11 55388940 MS PCE IC-VIDEOPROC PM0026A LQFP80 PIONEER VIDEO PROCESSOR IC12 55389040 CP PCE IC-VIDEOPROC MM1568AJBE SSOP34A MITSUMI AMPLIFIER&DRIVER IC14 20997870 CQ PCE IC-SPECFUNC MC74HC74AD DUAL-D FLIP FLOP IC15 15178670 CQ PCE IC-LOGIC 74HC86 GATE HCMOS IC21 55130350 IC PCE IC-VIDEOPROC STI5519 MPEG VIDEO DECODER IC22 20940740 65 PCE IC-EEPROM M24C02WMN6 IC31 55156290 MS PCE IC-DRAM 100M0 HZ 8N0 64M(1M*16*4) HY57V651620BTC-8 125M IC41 55136720 MS PCE IC-MEMFLASH M29W800AT90N1 IC51 55133310 KV PCE IC-LOGIC M74HCU04M1R INVERTER HCT IC61 55291470 IP PCE IC-CONV WM8728 D/A IC62 55128990 CQ PCE IC-OPERAMP BA4560F DUAL OP L301 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W L501 55126670 50 PCE FBEAD SURFACE MT 1000OHM FCM2012H-102T04 L604 55126710 50 PCE FBEAD SURFACE MT 120OHM FCM2012C-121T06 Q102 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q103 20970460 92 PCE TR-SLPSWA KTC3875Y N 50V 150MI0A Q10B 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q10G 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q10R 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q11B 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q11G 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q11R 55388740 92 PCE TR-SLPSWA KTN2222AS P 40V -600MI0A Q13B 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A Q13G 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A Q13R 55137830 92 PCE TR-SLPSWA KTN2907AS N 50V -600MI0A Q201 20970460 92 PCE TR-SLPSWA KTC3875Y N 50V 150MI0A Q202 20970460 92 PCE TR-SLPSWA KTC3875Y N 50V 150MI0A Q601 55133190 92 PCE TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM Q602 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q61L 55039430 91 PCE TR-SSD DTC323TK N 2K2 OHM Q61R 55039430 91 PCE TR-SSD DTC323TK N 2K2 OHM PRINTED CIRCUIT BOARD PARTS LIST DISPLAY CIRCUIT PC BOARD CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION DISP C901 20342060 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C DISP C903 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP C904 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP C905 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP C906 20252050 30 PCE ELECT. CAPACITOR 100U0F +20% 6.3V 85C DISP C907 20268620 41 PCE ELECT. CAPACITOR 470U0F +20% 6.3V 85C DISP C908 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP C909 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C DISP C911 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP C917 20288040 91 PCE CCCFMIC 100N0F +80% -20% 16.0V Y5V DISP CN91 55255440 NR PCE SOCKET AS UNIQUE 5P 380MM UL2791 SHIELD 28 DISP CN92 55182990 NR PCE SOCKET AS UNIQUE 5P 220MM UL1007 PVC DISCRETE 26 1 DISP CN93 55199600 NR PCE SOCKET AS UNIQUE 2P 40MM UL1007 RIBBON 26 1 DISP CN94 55123320 PCE CONNECTOR 2.0MM 5 MA ST NAT LW2002P05 0 0 DISP CN95 55123320 PCE CONNECTOR 2.0MM 5 MA ST NAT LW2002P05 0 0 DISP CN96 55199610 NR PCE SOCKET AS UNIQUE 4P 70MM UL1007 RIBBON 26 1 DISP D904 70436540 16 PCE D-SLP 1N4148 100.0V 150E-3A DISP D906 55177870 88 PCE D-SR SCHOTTKY RB501V-40 40.0V 100MI0A DISP D917 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A DISP FING 55178960 PCE SPRING PLATE SPRING GND C5212 0.2T AVR520 DISP FL91 55390980 NR PCE DISPLAY HNV-12SM24 DISP IC91 55443360 MS PCE IC-MICROCONT CXP82532-310Q DV-CP500 DISP IC92 55191090 NR PCE IC-REGNEGFXD KIA7045P LOW VOLTAGE DROP DISP L901 14039360 91 PCE LF-SMD 22U0H +10% DISP L902 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W DISP L903 20538660 91 PCE RMGCFMIC 4R7 OHM +5% 62MI5W DISP L904 20538660 91 PCE RMGCFMIC 4R7 OHM +5% 62MI5W DISP L905 10328750 91 PCE RMGCFMIC 0 OHM +0% 62MI5W DISP L909 55126670 50 PCE FBEAD SURFAELECT. CAPACITOR MT 1000OHM FCM2012H-102T04 DISP L912 55126670 50 PCE FBEAD SURFAELECT. CAPACITOR MT 1000OHM FCM2012H-102T04 DISP L913 55126670 50 PCE FBEAD SURFAELECT. CAPACITOR MT 1000OHM FCM2012H-102T04 DISP L914 55126670 50 PCE FBEAD SURFAELECT. CAPACITOR MT 1000OHM FCM2012H-102T04 DISP L917 80440510 91 PCE RMGCFMIN 0 OHM +0% 100MI0W DISP L918 80440510 91 PCE RMGCFMIN 0 OHM +0% 100MI0W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DISP RM91 55156010 NR PCE IC-REMOTE NJL63H380A REELECT. CAPACITOR IVER 38KHZ DISP S901 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S903 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S905 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S907 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S911 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S913 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S915 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S917 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S921 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S924 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP S927 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P DISP X901 55126140 NR PCE RESONATOR 10M0 HZ 25.0 OHM 0F INLET TERMINAL PC BOARD (INCLUDED DISPLAY PCB) CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION INLT DCN1 55384200 NR PCE SOCKET AS UNIQUE 3P 630MM UL2547 26 INLT MCN1 55548930 NR PCE SOCKET AS DL 3.96MM 2P 500MM UL1617 INLT MCN2 55222010 PCE SOCKET MAINS INLET A/C INLET 7014-NGP OPEN/CLOSE SWITCH PC BOARD (INCLUDED DISPLAY PCB) CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION OPN/CL CP93 55090070 PCE CONNECTOR 2.0MM 2 MA ST NAT LW2002P0200T 0 0 OPN/CL S930 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P STANDBY SWITCH PC BOARD (INCLUDED DISPLAY PCB) CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION STBY CP96 55123310 PCE CONNECTOR 2.0MM 4 MA ST NAT LW2002P04 0 0 STBY D905 55125510 NR PCE D-LEM LTL-1CHE RD RND 3.0 DIFU 5.6CD STBY Q901 55133180 92 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM STBY S931 55145270 KX PCE SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P PRINTED CIRCUIT BOARD PARTS LIST OUTPUT TERMINAL PC BOARD CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION C701 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C C702 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C C703 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C C705 20252050 30 PCE ELECT. CAPACITOR 100U0F +20% 6.3V 85C C706 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C C707 20268840 30 PCE ELECT. CAPACITOR 1U0F +20% 50.0V 85C C802 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C CN01 55124620 PCE CONNECTOR 1.25MM 23 FE ST WH GF120-23S-TS 2794 A6 CN71 67472300 NR PCE CONNECTOR -SPE 87204-6063 SUB D FE 2.77MM 9 -- 1630 A1 CP01 55090070 PCE CONNECTOR 2.0MM 2 MA ST NAT LW2002P0200T 0 0 D711 70436540 16 PCE D-SLP 1N4148 100.0V 150E-3A D801 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A D802 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A FCN1 55171520 PCE CONNECTOR 2.0MM 5 MA ST NAT MOLEX 35336-0510 0 0 FCN2 55177410 PCE CONNECTOR 2.0MM 3 MA ST NAT MOLEX 35336-0310 0 0 GND1 55135980 NR PCE LUG GND GND2 55135980 NR PCE LUG GND IC71 55197900 CQ PCE IC-SPECFUNC UPD4721 DRIVERS/REELECT IC85 55164740 NR PCE D-LEM GP1F32T RD RND CL JK81 55270580 PCE JACK 1P W/GND RCA-139PJ JK82 55266550 PCE JACK 2P WR W/GND CAP RCA-235P JK83 55266570 PCE JACK DIN SCKT MIX SOCKET RCA & S-VIDEO RCA-138JP1S JK84 55266540 PCE JACK PHONO SCKT RCA 3P RUG W/GND CAP RCA-328P L801 55126710 50 PCE FBEAD SURFAELECT. CAPACITOR MT 120OHM FCM2012C-121T06 L802 55126710 50 PCE FBEAD SURFAELECT. CAPACITOR MT 120OHM FCM2012C-121T06 L803 55126710 50 PCE FBEAD SURFAELECT. CAPACITOR MT 120OHM FCM2012C-121T06 Q801 20970460 92 PCE TR-SLPSWA KTC3875Y N 50V 150MI0A Q802 20970480 92 PCE TR-SLPSWA KTA1504Y P -50V -150MI0A Q87L 55039430 92 PCE TR-SSD DTC323TK N 2K2 OHM Q87R 55039430 92 PCE TR-SSD DTC323TK N 2K2 OHM PRINTED CIRCUIT BOARD PARTS LIST DIGITAL FILTER PC BOARD CIRCUIT NO. PART NO. Pkg Unit DESCRIPTION DCP1 55090080 PCE CONNECTOR 2.0MM 3 MA ST NAT LW2002P03 0 0 DG91 55190890 PCE CON PHONO SCKT REMOTEIH 2 PINS DP91 55207930 KV PCE PHOTCOUP PC-17T1 FCP1 55206580 PCE CONNECTOR 2.0MM 5 MA R NAT BD'BD SOCKET MOLEX 35237-0510 0 0 DD01 20496510 85 PCE D-SLP 1SS355 35.0V 225MI0A IC01 55164460 CQ PCE IC-OPERAMP NJM4556AM DUAL OP IC1L 55164460 CQ PCE IC-OPERAMP NJM4556AM DUAL OP IC1R 55164460 CQ PCE IC-OPERAMP NJM4556AM DUAL OP C04L 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C C04R 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com C05L 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C C05R 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C DC01 20267830 30 PCE ELECT. CAPACITOR 47U0F +20% 16.0V 85C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 EX-VIEW PARTS LIST NO. PARTS No PARTS NAME 1 55384980 PLATE BADGE DVD 2 55382960 DOOR TRAY 3 55223420 WINDOW DISPLAY 4 55204210 LOGO BADGE INTEGRA 5 55186710 FACET STANDBY 6 55259110 COVER POWER BUTTON 7 55184600 SHAFT POWER SWITCH 8 55204250 POWER BUTTON 9 55184650 STANDBY BUTTON 10 55448310 POWER/STANDBY SWITCH PC BOARD ASSY (INCLUDE DISP. 11 55244670 BUTTON CD PLAY 12 55221140 SHIELD COVER SENSOR 13 55164930 HOLDER FL 14 55382610 PANEL FRONT 15 55204260 BUTTON OPEN/CLOSE DPC5.2 16 55244680 BUTTON 9KEY 17 55145270 TACT SWITCH VERTICAL 18 55448310 OPEN/CLOSE SWITCH PC BOARD ASSY (INCLUDE DISP. PCB) 19 55448310 DISPLAY PC BOARD ASSY 20 55178960 SPRING GND C5212 0.2T 21 55236110 CABINET CHASSIS FRONT 22 55201610 RUBBER SPACER 14.5*14.5*22 23 55174550 SHIELD GASKET 12 X 8 X 20 24 55125120 FOOT 25 55141370 FOOT RUBBER 26 5518662A CABINET CHASSIS MAIN 27 55190770 FELT 38X120X0.3T BK 28 55405550 SHIELD COVER 29 55190690 SHIELD COVER DOWN LOAD 30 55448320 OUTPUT TERMINAL PC BOARD ASSY 36 67472300 D SUB CONNECTOR 39 55383140 REAR PANEL 40 55174610 BRACKET MECHA RIGHT 41 55371600 MECHANISM ASSY CDM5G(TVM503R-1) 42 55186680 BRACKET FRAME MECHA R 43 55186600 COVER TOP 44 5518667A BRACKET FRAME MECHA L 46 55190680 SHIELD COVER CONNECT BOARD 47 55516410 SHIELD PLATE MPEG 48 55514090 SHIELD COVER PROTECT 49 55448290 MAIN PC BOARD ASSY 50 55190160 BRACKET GROUND 51 55186640 BRACKET MAIN PCB 52 55332110 POWER SUPPLY UNIT 53 55202510 SHIELD COVER POWER SUPPLY UNIT 54 55222010 INLET TERMINAL 55 55448310 INLET TERMINAL PC BOARD 56 55222020 BRACKET INLET 58 55448330 RI IN/OUT JACK PC BOARD 60 SR-5, T2A FUSE, 250VCA T 2.0A S1 838130068 SCREW 3TTB+6B S2 838130088 SCREW 3TTB+8B S3 238440088 SCREW 4TTB+8BC(BC) S4 55127120 SCREW 3MM 8MM WITH WASHER S5 55127180 SCREW 3MM 8MM S6 838430108 SCREW 3TTB+8B(BC) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 EX-VIEW P NO. PARTS No 1 55384980 2 55382960 3 55223420 4 55204210 5 55186710 6 55259110 7 55184600 8 55204250 9 55184650 10 55448310 11 55244670 12 55221140 13 55164930 14 55382610 15 55204260 16 55244680 17 55145270 18 55448310 19 55448310 20 55178960 21 55236110 22 55201610 23 55174550 24 55125120 25 55141370 26 5518662A 27 55190770 28 55405550 29 55190690 30 55448320 36 67472300 39 55383140 40 55174610 41 55371600 42 55186680 43 55186600 44 5518667A 46 55190680 47 55516410 48 55514090 49 55448290 50 55190160 51 55186640 52 55332110 53 55202510 54 55222010 55 55448310 56 55222020 58 55448330 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PACKING VIEW PARTS LIST NO. PART NO. Unit DESCRIPTION 50 55383370 PCE CARTON BOX DPC5.3 INTEGRA 60 55184410 PCE ENDCAP CUSHION RIGHT 70 55184420 PCE ENDCAP CUSHION LEFT 100 55176530 PCE AUDIO CONNECTION CABLE 105 55547410 PCE POWER CORD 110 55383400 PCE INSTRUCTION MANUAL 120 55231700 PCE POLY BAG FOAM SHEET 130 55188250 PCE WARRANTY CARD 150 55170650 PCE POLY BAG 260MM X 410MM 170 20194780 PCE CABLE-TIE THE FITMOS PLASTIC 205 29110148 M PP TAPE 210 55208740 PCE CUSHION -- 80.0MM X 35.0MM 0 0 220 2010389 PCE RI CABLE 230 5544550A PCE AC PRI LABEL POS DPC-5.3(B) 240 55445530 PCE REMOTE CONTROLLER RC-503DV 250 3010054 PCE BATTERY 1.5V AAA 1.15 AH www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Pos Tocom# SName Step 0010 55448270 ASSY MECH BOM DPC-5.3 OEM ENGPAWW 0020 55448280 ASSY BOM PKG DPC-5.3 ENGPAWW 0030 55448290 ASSY EMBD IMA MAIN BD DPC-5.3 ENGCAWW 0040 55448310 ASSY EMBD IMA FRONT BD DPC-5.3 ENGCAWW 0050 55448320 ASSY EMBD IMA OUT BD DPC-5.3 ENGCAWW 0060 55448330 ASSY EMBD IMA DIGI/FILTER BD DPC-5.3 ENGCAWW 0070 55371600 ASSY MSA ASY CDM5G(TVM503R-1) ENGPAWW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DPC-5.3 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 http://www.onkyo.co.jp/ ONKYO CORPORATION Integra Division of ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 E-mail: integra@onkyousa.com http://www.integrahometheater.com Integra Division of PN 0Mxxxx D01xx Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
