DVD / CD PLAYER DV-505/DVF-R4050/-S SERVICE MANUAL © 2001-10 PRINTED IN KOREA B51-5758-00 (K/K) 3445 Front panel * (A60-) Window * (B10-) AUDIO OUTPUT COMPONENT VIDEO OUTPUT VIDEO OUTPUT Cr Cb Y S-VIDEO OPTICAL COAXIAL L R DIN socket (E68-0018-08) Top cover * (A01-) * Refer to parts list on page 19 . In compliance with Federal Regulations, following are repro- duction of labels on, or inside the product relating to laser product safety. KENWOOD-Corp. certifies this equipment conforms to DHHS Regulations No.21 CFR 1040. 10, Chapter 1, subchapter J. DANGER : Laser radiation when open and interlock defeated. AVOID DIRECT EXPOSURE TO BEAM. Caution : No connection of ground line if disassemble the unit. Please connect the ground line on rear panel, PCBs, Chassis and some others. Button * (K27-) Button * (K27-) Button * (K27-) Button(POWER) * (K27-) RCA jack (E63-1244-08) AC power cord bushing (J42-0350-08) AC power cord * (E30-) RCA jack (E63-1227-08) RCA jack (E63-1192-08) 70% www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 2 CONTENTS / ACCESSORIES / CAUTIONS CONTENTS / ACCESSORIES / CAUTIONS............. 2 DISASSEMBLY FOR REPAIR....................................3 BLOCK DIAGRAM ......................................................4 WIRING DIAGRAM.....................................................5 PC BOARD..............................................................10 SCHEMATIC DIAGRAM...........................................14 EXPLODED VIEW....................................................21 PARTS LIST.............................................................23 SPECIFICATIONS......................................Back cover Contents Cord RCA 1p (E30-7235-08) Cord RCA 3p (E30-2990-08) Remote control unit (1) (A70-1570-08) Batteries (R03/AAA) (2) *AC plug adaptor (1) (E03-0115-05) * Use to adapt the plug on the power cord to the shape of the wall outlet. (Accessory only for regions where use is necessary.) Note related to transportation and movement Before transporting or moving this unit, carry out the follow- ing operations. 1. Set the POWER key to ON without loading a disc. 2. Wait a few seconds and verify that the display shown appears. 3. Set the POWER key to OFF. Beware of condensation When the difference between the internal temperature of the unit and external atmosphere is large, dew (mist) may be produced on the internal parts of the unit. In such a case, turn the unit ON and leave it for a few hours until the condensation has dried up. Be especially careful in the following conditions: When the unit is brought into a place where there is a large differ- ence in temperature between the previous location, when the humidity of the listening room is high, etc. The marking is located on the rear panel and says that the component uses laser beams that have been clas- sified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit. CLASS 1 LASER PRODUCT The marking of products using lasers (Except for some areas) Operation to reset The microprocessor may fall into malfunction (impossibility to oper- ate erroneous display, etc.) when the power cord is unplugged while power is ON or due to an external factor. In this case, execute the following procedure to reset the microprocessor and return it to normal condition. ÷Please note that resetting the microprocessor clears the contents stored in, it returns the microprocessor to the condi- tion when it left the factory. 1In POWER ON condition, keep the DISC 3 key and the 4 4 4 4 4 (Skip) key pressed at the same time. 2When both keys are pressed, the region code of the unit, the software version, etc. will be displayed on the display. (When nothing is done, the display of this information continues.) Example: 71 . 16 . 06:14 3Press the DISC 4 key and the 4 4 4 4 4 key at the same time. "BYE" will be shown on the display. 4Press the ON/OFF key to go to Power OFF. 5When Power ON is performed with the ON/OFF key, the settings become the default factory settings. Cautions Accessories Attention Please contact our KENWOOD Service Department in your side if you want the service information; Circuit Description. Full Described Parts list and so. Information is available to you by internet from us. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 3 DISASSEMBLY FOR REPAIR 1. How to open the tray if it does not come out. (Fig. 1) 1. Turn the gear ccw in the direction of the arrow in the drawing through the hole on loading chassis bottom. 2. Pull out the tray frontward by hand when it comes just out. 2. How to Remove the Tray (Fig. 2) 1. Remove the front panel, front chassis, power supply and the left mecha. frame. 2. Pull out the tray frontward (1) to match the dent of tray (2) to the protrusions of the mecha. base (3). 3. Remove the tray upward (4). 3. How to assemble the Tray (Fig. 3,4) 1. Adjust the position of the plastic cam lifter (1) and main gear (2) in the drawing (1 so that the traverse unit will reach the lowest position. 2. Attach the tray in the direction (3, 4) of the arrow in the drawing. 3. Push the tray backward. 1 3 2 4 3 4 1 2 Fig. 1 Fig. 3 Fig. 4 Fig. 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 ADDR F-WE F-RESET F-DE D-RAS0- ADDR RDNOTWR DATA D-CAS0- D-CAS1- +3.3V DIGITAL VCC F/E SDATA EXIT-DATA +3.3V-RESET F/E SCL EXIT-BCLK EXIT-DATAVALID EXT-PSTART/ERROR +12V MOTOR VCC +8V MOTOR VCC +5V DIGITAL VCC SLIDER-IN(DRAWER-CCW-CTRL) SLIDER-OUT(DRAWER-CW-CTRL) SLIDER-OPEN/CLOSE(POWER-POSITION-P1) +12V ANALOG VCC +8V ANALOG VCC +5V DIGITAL VCC -8V ANALOG VCC +12V MOTOR VCC 5V FRONT +8V MOTOR VCC +3.3V DIGITAL VCC : AC240V~ 50Hz : AC230V~ 50Hz (X) (T,E) : AC110-120V/220-240V~ : AC120V 60Hz 50/60Hz (K,P) (Y,M) F-CE F-OE(DRAM OE) -27V FL AC FL AC +5VS STBY ON/OFF CNTL IR REMOCON +5.6VS VFD DATA OUT VFD STB VFD DATA IN PCM1748E-DATA LRCLK BCK PCMCLK PCM1748E-CS PCM1748E-CLK AUDIO-MUTE CVBS-OUT Y-OUT R(Cr)-OUT C-OUT B(Cb)-OUT G(Y)-OUT 9 10 8 6 7 SPDIF PIXCLK-27MHz SCL SDA VIDEO-MUTE VFD CLK DATA IRQ2 POWER CTL L AUDIO R AUDIO GND BLUE-OUT GREEN-OUT RED-OUT CVBS-OUT L-CH OUT R-CH OUT IC201 STI5519 FLASH MEMORY IC401 8MBIT SST39VF800505 HY57V651620 SDRAM-64MBIT IC301 F/E & MECHA TVM MECHA SMPS IC901 CXP825P400-1 DAC PCM1748KE L.P.F BA4560 IC303-A-A MIXED MUTE VIDEO JK803-A S-VIDEO JK803-B JK701 Cr Cb Y RCA 3V COAXIAL JK801 IC805 BUFFER OPTICAL IC501 74HCU04 M24C02 EEPROM IC202 SCART PART RCA PART HNV-06SS75 FL 125MHz L.P.F MIXED R-CH L-CH TR BUFFER & B.N.F. & B.N.F. BUFFER TR & B.N.F. BUFFER TR & B.N.F. BUFFER TR & B.N.F. BUFFER TR & B.N.F. BUFFER TR CVBS-OUT Y-OUT C-OUT R(Cr)-OUT B(Cb)-OUT G(Y)-OUT CVBS- TV SCART JK804 ONLY (E,T) TYPE (E,T) TYPE EXCEPT DIGITAL OUT MPEG DV-505,DVF-R4050 DV-505/DVF-4050/-S 4 BLOCK DIAGRAM www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 5 CIRCUIT DESCRIPTION Port No. Port Name I/O Main Function Alternate function Input Output Audio DAC 51 DAC SCLK O Over sampling clock EXT AUD CLOCK 52 DAC PCMOUT0 O PCM out 0 EXD AUD DATA 53 DAC PCMOUT1 - PCM out 1(Unused) EXT AUD REQ 54 DAC PCMOUT2 - PCM out 2(Unused) 55 DAC PCMCLK I/O PCM clock 56 DAC LRCLK O Left/Right clock EXT AUD WCLK 57 SPDIF OUT O SPDIF out 48 VDD PCM - VDD(+3V3) 49 VSS PCM - GND Clock & Reset 124 RESET I Chip reset 122 VDD PLL - VDD PLL 123 VSS PLL - GND 120 PIX CLK I 27MHz main clock PIOs and communication 186 PIO0(0) T STROBE I/O PIO0(0) UART0 data 187 PIO0(1) MOD SW I/O PIO0(1) ATAPI RD 188 PIO0(2) O Rotary motor (+) 189 PIO0(3) O Rotary sen 190 PIO0(4) O Disc sen 191 PIO0(5) SLIDER SENSOR OPEN/CLOSE (CLOSE POSITION) I/O PIO0(5) 192 PIO0(6) SLIDER SENSOR OPEN/ CLOSE (DRAWER POSITION) I/O PIO0(6) 193 PIO0(7) SLIDER IN (DRAWER CCW/CTRL) I/O PIO0(7) 194 PIO1(0) SDA I/O PIO1(0) SSC0 data (MTSR out/MRST in) 195 PIO1(1) SCL I/O PIO1(1) SSC0 clock 196 PIO1(2) SLIDER OUT (DRAWER CW/CTRL) I/O PIO1(2) PARA DVALID 197 PIO1(3) TXD(JIG) I/O PIO1(3) UART2 TXD 200 PIO0(4) RXD(JIG) I/O PIO1(4) UART2 RXD 201 PIO1(5) FRONT TXDI I/O PIO1(5) PARA SYNC UART1 RXD 202 TRIGGER IN I/O Trigger in for DCU 203 TRIGGER OUT I/O Trigger out for DCU 204 PIO2(0) H/P IND - Unused 205 PIO2(1) FRONT RXD I/O PIO2(1) PARA SYNC 206 PIO2(2) - Unused 207 PIO2(3) - Unused 208 PIO2(4) AUDIO MUTE I/O Audio mute 1 PIO2(5) RGB SEL(BLANK) I/O RGB sel. (blank) 2 PIO2(6) VIDEO MUTE I/O Video mute 3 PIO2(7) 16: 9 INDICATOR I/O 16 : 9 indicator 6 PIO3(0) SCART H(TV/AUX) I/O PIO3(0) PARA DATA(0) 7 PIO3(1) POWER CTL I/O PIO3(1) PARA DATA(1) 8 PIO3(2) I/O Unused PARA DATA(2) 9 PIO3(3) I/O Unused PARA DATA(3)/ CAPTURE IN0 10 PIO3(4) IR REMOCON I/O Unused 11 PIO3(5) I/O Unused PARA DATA(5)/ CAPTURE IN2 UART2 RTS(RTS2) Port list sorted by function for MPEG IC(Main IC201) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 6 CIRCUIT DESCRIPTION Port No. Port Name I/O Main Function Alternate function Input Output 12 PIO3(6) I/O Unused PARA DATA(6)/ UART1 CTS(CTS1) COMP OUT1 13 PIO3(7) DVD RESET I/O PIO3(7) PARA DATA(7)/ UART2 CTS(CTS2) COMP OUT0 39 PIO4(0)HP MUTE - Unused 40 PIO4(1) - Unused 41 PIO4(2) - Unused 42 PIO4(3) DAC RESET - Unused 43 PIO4(4) PLL CS - Unused 44 PIO4(5) DAC CLOCK O DAC clock 45 PIO4(6) DAC DATA O DAC data 46 PIO4(7) DAC CS I/O PIO4(0~7) YC(0~7) Reserved 20 B WCLK I/O Unused 21 B V4 I/O Connected to GND 22 NRSS OUT I/O Unused 103 ADC SCLK I/O Unused 104 ADC LRCK I/O Unused 105 ADC DATA I/O Unused 106 ADC PCMCLK O Unused EMI Interface 161~170 CPU ADR(1~10) O ADR(1~10) 173~183 CPU ADR(11~21) O ADR(11~21) 141~148 CPU DATA(0~7) I/O DATA(0~7) 151~158 CPU DATA(8~15) I/O DATA(8~15) 138 CPU RAS1 I/O Unused 131 CPU WAIT I Connected to GND 130 CPU RW O Unused 128 CPU BE(0) O BYTE 0 ENABLE 129 CPU BE(1) O BYTE 1 ENABLE 139 CPU CAS0 O Unused 140 CPU CAS1 O Unused 135 CPU CE(0) O Unused 134 CPU CE(1) O Unused 133 CPU CE(2) O Chip Sel. BANK2 132 CPU CE(3) O Chip Sel. BANK3 118 CPU PRO CLK O SDRAM clock 117 CPU OE I/O Output enable Interrupt 127 IRQ(0) I Unused 126 IRQ(1) I Unused 125 IRQ(2) I IRQ(2) (MD IRQ) Timers 116 PWM0 I/O Unused HSYNC 115 PWM1 I/O Pulse width modula o Boot from ROM3 114 PWM2 I/O Unused VSYNC JTAG 113 TCK I Test clock 112 TDI I Test data in 111 TDO O Test data out 110 TMS I Test mode select 109 TRST4 I Test reset Front-end 16 B DATA I 12S data SER Data 17 B BCLK I 12S bit clock SER BCLK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 7 CIRCUIT DESCRIPTION Port No. Port Name I/O Main Function Alternate function Input Output 18 B FLAG I 12S error flag DVD SER VALID 19 B SYNC I 12S selector/ABS time SER SYNC Video DAC 27,26,25 R/G/B (OUT) O R/G/B output 32~34 Y/C/CV (OUT) O Y/C/CV output 29 I REF RG I I REF DAC RGB 28 V REF RG I V REF DAC RGB 36 I REF YCC I I REF DAC YCC 35 V REF YCC I Y REF DAC YCC 23 VDD RGB - YDDA RGB = 2.5V 24 VSS RGB - GND 30 VDD YCC - YDDA YCC = 2.5V 31 VSS YCC - GND Shared memory interface 69~66 SMI ADR(0~3) O Address bus SDRAM 58~63 SMI ADR(4~9) O Address bus SDRAM 70~73 SMI ADR(10~13) O Address bus SDRAM 84~93 97~102 SMI DATA(0~15) I/O Data bus SDRAM 74,75 SMI CS(0,1) O Chip select bank 0,1 76 SMI RAS O RAS SDRAM 77 SMI CAS O CAS SDRAM 78 SMI WE O SDRAM write enable 79,80 SMI DQML, U O DQ MASK EN LOW, UP 82 SMI CLKIN I SDRAM clock in 95 SMI CLKOUT O SDRAM clock out Power supply 4,47,81,107 136,159,184 VDD3.3 - 3.3V Power supply 14,37,64,94 119,149,171,198 VDD2.5 - 2.5V Power supply 5,15,38,50,65,83 96,108,121,137 VSS - GND 150,160,172,185,199 Pin No. Pin Name I/O Description 1 BCK I Audio data bit clock input. 2 DATA I Audio data digital input. 3 LRCK I Audio data latch enable input. 4 DGND - Digital ground. 5 VDD - Digital power supply (+3.3v). 6 VCC - Analog power supply (+5v). 7 VOUTL O Analog output for L-channel. 8 VOUTR O Analog output for R-channel. 9 AGND - Analog ground. 10 VCOM - Common voltage decoupling. 11 ZEROR O Zero flag output for R-channel. 12 ZEROL O Zero flag output for L-channel. 13 MD I Mode control data input. 14 MC I Mode control clock input. 15 ML I Mode control latch input. 16 SCK I System clock input D/A Converter : PCM1748(IC302) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 8 CIRCUIT DESCRIPTION Pin No. Pin Name I/O Description 38 CLK I The system clock input. all other inputs are registered to the SDRAM on the rising edge of CLK 37 CKE - Controls internal clock signal and when deactivated,the SDRAM will be one of the states among power down, suspend or self refresh. 19 CS - Enables or disables all inputs except CLK, CKE, and DQM. 20,21 BA0,BA1 - Selects bank to be activated during RAS activity. Selects bank to be read/written during CAS activity. 22~26 A0~A11 - Row address : RA0~RA11, Column address : CA0~CA7 29~35 Auto-precharge flag : A10 16,17,18 WE,CAS,RAS - WE, CAS and RAS define the operation. 15,39 LDQM,UDQM I/O Controls output buffers in read mode and masks input data in write mode. 2,4,5,7,8,10 11,13,42,44 DQ0~DQ15 I/O Multiplexed data input/output pin. 45,47,48,50 1,3,9,14,27 VCC/VCC Q - Power supply for internal circuits and input buffers. 43,49 10 VSS/VSS Q - Ground terminal. 36,40 NC - Unused. 64 Bit SDRAM : HY57V651620B(IC301) Pin No. Pin Name I/O Description 25,24~16,8~1 A0~A18 I Address Inputs 29,31,33,35 DQ0~DQ7 I/O Data Input/Outputs, Command Inputs 38,40,42,44 30,32,34,36 DQ8~DQ14 I/O Data Input/Outputs 39,41,43 45 DQ15 I/O Data Input/Outputs or Address input 26 CE - Chip Enable 28 QE - Output Enable 11 WE - Write Enable 12 RP - Reset/Block Temporary Unprotect 15 RY/BY o Ready/Busy/Output 47 BYTE - Byte/Word Organization 37 VCC - Supply Voltage 27,46 VSS - Ground Flash Memory : M29F400T-90N1(IC401) Block Diagram for D/A Converter BCK LRCK DATA ML MC MDI SCK Serial Input I/F 8X Oversampling Digital Filter with Function Controller Enhanced Multi-level Delta-Sigma modulator Function System Clock Manager System Clock Zero Detect Power Supply Control I/F DAC Output Amp and Low-pass Filter Vout L Vout R Vcom Output Amp and Low-pass Filter DAC ZERO L ZERO R VDD DGND VCC AGND www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 9 1 23 19 1 19 1 23 1 12 1 : AC240V~ 50Hz : AC230V~ 50Hz (X) (T,E) : AC110-120V/220-240V~ : AC120V 60Hz 50/60Hz (K,P) (Y,M) 1 2 5 1 1 5 5 1 5 1 1 15 1 15 1 12 2 1 1 2 1 12 12 1 (19) (19) 1 5 5 1 CP201 CP205 CC202 CN1 JK804 JK803-A JK803-B CN4 Rch Lch COAXIAL JK802 JK801 CN1 CN3 CN901 CN902 CN201 CP203 TEST JIG UNLOAD CP202 IC805 OPTICAL CN205 Cr Cb Y VIDEO OUTPUT VIDEO OUTPUT COMPONENT DIGITAL OUT AUDIO OUTPUT CP903 CN903 CN206 P406 CN904 CN905 B08 MAIN BOARD MECHA F/E BOARD OUTPUT BOARD POWER SUPPLY(SMPS) FRONT BOARD DV-505,DVF-4050 OPEN/CLOSE BOARD CONNECTION WIRING DIAGRAM www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 A C E G I B D F H J 2 1 3 5 7 4 6 L909 L912 L913 L914 R950 R943 R949 R947 R945 R944 R942 R946 R902 R926 C908 R927 R901 L902 C905 L905 D906 C904 J914 24 25 40 41 64 65 80 1 IC901 C903 R912 R922 R923 R931 R913 R932 R940 R939 R938 R933 C911 R911 R921 R805 1 2 3 C804 R806 R804 R815 C801 R801 R802 R807 C803 R808 R820 C817R R873 R872 R876 R877 R874 R819R R829 R865 R803 R863 PAL OPTION R864 R827L R827R R875 R826R J892 J894 E B Q801 E B Q803R B E Q815 E B Q802 B E Q803L R719 R717 C716 R718 R708 R709 C717 R720 R721 R705 R722 C718 R702 R730 R723 L706 L703 R714 R715 C17 J891 D710 D705 D706 D709 D708 D707 D701 D702 E Q702 B E Q704 C821 L705 R716 R731 R701 J890 B E Q701 C817L R819L R724 L704 B J943 J944 J945 1 2 J909 DISC4 DISC2 DISC1 DISC SKIP SEQUENCE MODE FAST REWARD FZST FORWARD DISC3 PLAY/PAUSE LUG92 DISC5 X901 J940 C916 C909 O O I I G G 1 38 1 2 CLOSE OPEN/ LUG91 C907 C906 C901 RM901 J937 J910 L901 J906 J942 J907 J941 J920 J912 J924 1 5 1 5 J917 J918 J928 L904 L903 CN901 CN902 FRONT BOARD CONNECTION BOARD D907 CN905 FL901 CN904 SW905 SW917 SW921 SW924 SW927 SW907 CN903 SW901 SW911 SW913 SW915 SW903 CP903 SW930 IC902 C802 1 2 23 22 C822 R826L C720 J17 J58 J3 J14 J40 J9 1 21 2 20 21 J2 C719 C703 J736 J13 L R L801 J10 J11 J16 J6 J57 C714 C713 LUG701 L804 J1 D711 CN01 CP01 JK803 JK804 IC805 JK801 JK701 JK802 C715 OUTPUT BOARD OPTICAL DIGITAL OUT COAXIAL OUTPUT AUDIO OUTPUT VIDEO OUTPUT VIDEO COMPONENT Refer to the schematic diagram for the value of resistors and capacitors. PC BOARD(Component side view) 7 8 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 R201P I G O 1 12 K 1 2 23 22 O R308L 1 1 28 54 27 1 1 7 14 8 8 16 9 4 8 5 C220S C327 C325 C323 C210 C206 C204 C232 C233 C201P C306L C306R C305R C305L C330 C301L C301R C220C C223C C223S C225S C224S R223S R222S C225C C224C R223C R222C C222C R221C R225C R224C C221C C222Y C223Y R221Y R225Y R224Y C221Y C222R R221R R225R R224R C221R C222G R221G R225G R224G C221G C222B R221B R225B R224B R220B R220G R220R R221 C220B C223B C223G C223R C220R C220Y C220G R270 R269 C226 C227 R263 R262 R409 R223 C221B C225B C224B R223B R222B C225Y C224Y R223Y R222Y C225R C224R R223R R222R C225G C224G R223G R222G C222S R221S R225S C221S R224S R308R C307L C307R R324 R307L R257 R217S R218C R219Y C235 R271 R201 R204 R203 R268 R267 R282 R283 R421 R422 R423 R424 R425 C241 R285 R236 C503 R503 R502 C502 R314 L501 C505 X501 C215 C240 C501 C406 C221 C218 R501 R256 R402 RA401 RA402 RA403 RA404 C239 C238 C237 R250 R228 R279 R280 R281 C217 R248 R249 C504 C216 R246 R247 R426 R237 R240 R289 R290 R239 R231 R234 R232 R213 R214 R215 R210Y 1 52 156 24 1 25 48 157 208 8 5 104 1 1 5 15 12 1 53 105 C303R C331 R304R C302R R301R R304L C303L R323 R322 C302L R301L R303L R302L R303R R302R R211C R212S R233 C321 R206B R207G R208R R238 R288 R241 R403 R401 RA408 RA407 RA406 RA405 RA304 RA305 RA306 RA307 RA301 RA302 RA303 R243 R244 R245 R251 R303 R304 R305 R306 R307 R308 R427 R428 R405 R406 R438 C230 C229 C228 R273 R274 R259 R258 R266 4 1 19 18 2 C225 R298 C234 R202 R222 R292 R291 R309L R309R R307R J208 J204 J203 J205 J206 D303 CP205 C E C E C E C E C E C E Q220G Q220B Q220R Q220Y Q220C Q220S B E Q201 B E Q202 B E Q203 B E Q302R B E Q301 B E Q302L B E Q301R CN208 IC21P IC303 IC302 CN207 CN205 MAIN BOARD E B Q221S E B Q301L E B Q221C E B Q221Y E B Q221R E B Q221G E B Q221B IC202 CP201 IC201 CP203 CN206 CN201 IC401 IC301 IC501 1 J202 J201 J207 L301 L211 C311 J1 J2 D301 P406 C003 C001 JW10 JW22 JW14 C004 C002 1 1 9 9 12 1 JW18 JW8 R003 R004 L001 JW15 C005 JW20 JW24 R002 JW7 R001 JW3 JW21 JW6 JW17 JW13 P1001 P1002 CP211 CP210 P004 P406B P1004 P1003 P027 IC001 P003 IC002 MECHA. BOARD D002 D001 K L N P R T M O Q S 2 1 3 5 7 4 6 Refer to the schematic diagram for the value of resistors and capacitors. PC BOARD(Component side view) 9 10 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 A C E G I B D F H J 2 1 3 5 7 4 6 CP201 CN201 CP202 Q201 Q202 MECHA F/E BOARD Q203 D303 CN206 SCART OPTION FLASH MEMORY EEP ROM MPEG P406 156 155 154 153 152 151 150 149 148 147 146 145 144 143 142 141 140 139 138 137 136 135 134 133 132 131 130 129 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105 104 103 102 101 100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 CPU DATA(13) CPU DATA(12) CPU DATA(11) CPU DATA(10) CPU DATA(9) CPU DATA(8) VSS VDD2 5 CPU DATA(7) CPU DATA(6) CPU DATA(5) CPU DATA(4) CPU DATA(3) CPU DATA(2) CPU DATA(1) CPU DATA(0) CPU CAS1 CPU CAS0 CPU RAS1 VSS VDD3 3 CPU CE(0) CPU CE(1) CPU CE(2) CPU CE(3) CPU WAIT CPU RW CPU BE(1) CPU BE(0) IRQ(0) IRQ(1) IRQ(2) RESET VSS PLL VDD PLL VSS PIX CLK VDD2 5 CPU PROCLK CPU OE PWM0 PWM1 PWM2 TCK TD1 TD0 TMS TRST VSS VDD3 3 ADC PCM CLK ADC DATA ADC LRCLK ADC SCLK SMI DATA(15) SMI DATA(14) SMI DATA(13) SMI DATA(12) SMI DATA(11) SMI DATA(10) VSS SMI CLK OUT VDD2 5 SMI DATA(9) SMI DATA(8) SMI DATA(7) SMI DATA(6) SMI DATA(5) SMI DATA(4) SMI DATA(3) SMI DATA(2) SMI DATA(1) SMI DATA(0) VSS SMI CLK IN VDD3 3 SMI DQMU SMI DQML SMI WE SMI CAS SMI RAS SMI CS(1) SMI CS(0) SMI ADR(13) SMI ADR(12) SMI ADR(11) SMI ADR(10) SMI ADR(0) SMI ADR(1) SMI ADR(2) SMI ADR(3) VSS VDD2 5 SMI ADR(9) SMI ADR(8) SMI ADR(7) SMI ADR(6) SMI ADR(5) SMI ADR(4) SPDIF OUT DAC LRCLK DAC PCM CLK DAC PCM OUT2 DAC PCM OUT1 PIO2(5) RGB SEL(BLANK) PIO2(6) VIDEO MUTE PIO2(7) 16:9 INDICATOR VDD3 3 VSS PIO3(0) SCART H(TV/AUX) PIO3(1) PIO3(2) PIO3(3) PIO3(4) IR(REMOCON) PIO3(5) PIO3(6) PIO3(7) DVD RESET VDD2 5 VSS B DATA B BCLK B FLAG B SYNC B WCLK B V4 NRSS OUT VDD RGB VSS RGB B OUT G OUT R OUT V REF RG I REF RG VDD YCC VSS YCC Y OUT C OUT CV OUT V REF YC I REF YC VDD2 5 VSS PIO4(0) H/P MUTE PIO4(1) PIO4(2) PIO4(3) DAC RESET PIO4(4) PLL CS PIO4(5) DAC CLOCK PIO4(6) DAC DATA PIO4(7) DAC CS VDD3 3 VDD PCM VSS PCM VSS DAC SCLK DAC PCM OUTO CPU DATA(14) CPU DATA(15) VDD3 3 VSS CPU ADR(1) CPU ADR(2) CPU ADR(3) CPU ADR(4) CPU ADR(5) CPU ADR(6) CPU ADR(7) CPU ADR(8) CPU ADR(9) CPU ADR(10) VDD2 5 VSS CPU ADR(11) CPU ADR(12) CPU ADR(13) CPU ADR(14) CPU ADR(15) CPU ADR(16) CPU ADR(17) CPU ADR(18) CPU ADR(19) CPU ADR(20) CPU ADR(21) VDD3 3 VSS PIO0(0) T STROBE PIO0(1) MOD SW PIO0(2) PIO0(3) PIO0(4) PIO0(5) PIO0(6) SLIDER SENSOR OPEN/CLOSE(DRAWER POSITION PI1) PIO0(7) SLIDER IN(DRAWER CCW CTRL) PIO1(0) SDA PIO1(1) SCL PIO1(2) SLIDER OUT(DRAWER CW CTRL) PIO1(3) TXD(JIG) VDD2 5 VSS PIO1(4) RXD(JIG) PIO1(5) FRONT TXDI TRIGGER IN TRIGGER OUT PIO2(0) H/P IND PIO2(1) FRONT RXD PIO2(2) PIO2(3) PIO2(4) AUDIO MUTE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 A15 A14 A13 A12 A11 A10 A9 A8 NC NC WE RP NC NC RY/BY A18 A17 A7 A6 A5 A4 A3 A2 A1 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 A16 BYTE VSS DQ15 DQ7 DQ14 DQ6 DQ13 DQ5 DQ12 DQ4 VCC DQ11 DQ3 DQ10 DQ2 DQ9 DQ1 DQ8 DQ0 OE VSS CE A0 1 2 3 4 E0 E1 E2 VSS 8 7 6 5 VDD WC SCL SDA RA405 47 161 162 164 163 167 168 166 165 RA406 47 178 176 177 175 173 174 RA408 47 170 169 RA407 47 R407 47 R408 47 R410 47 R409 47 179 180 182 181 R263 47 R262 47 188 189 191 190 196 193 192 R289 47 R290 47 197 200 186 187 R264 75 R265 75 202 203 157 158 RA404 47 155 156 151 154 152 153 RA403 47 142 145 148 146 147 RA402 47 143 144 RA401 47 141 148 147 145 146 143 144 141 142 R401 47 R402 47 R256 47 R403 47 100u10 + C221 0.01 C220 10 R254 0.1 C219 47 0.1 C222 10K R255 R288 10K 10K 113 112 111 110 109 0.1 C218 115 0.1 C223 10K 47 133 128 RA306 47 RA307 47 RA304 47 RA305 47 0 J301 +3.3V R309 100 R308 100 R307 100 R306 100 R305 100 R303 100 R304 100 R302 100 R301 100 4.7K R310 4.7K R312 4.7K R311 4.7K R313 76 74 77 78 79 80 82 RA303 47 RA302 47 RA301 47 R234 47 R233 100 10P C213 10P C214 +2.5V 102 101 100 99 93 92 97 98 89 88 90 91 87 84 86 85 69 68 71 70 62 67 66 63 59 58 60 61 3 1 6 47 2 47 47 0.1 C201 R292 R203 100 R204 100 R201 100 R202 100 16 19 18 17 13 C202 0.1 100u10 + C204 0.01 C203 2.2uH L201 R205 100u10 C206 + 0.01 C205 L202 2.2uH R207G R208R R206B R210Y R211C R212S R209 R219Y 10 R218C 10 R217S 10 C207 0.1 R215 47 R214 47 R213 47 0.01 C209 100u10 + C210 L203 2.2uH R230 0 C208 0.1 47 R232 10P C211 47 R231 10P C212 34 33 32 44 45 46 25 26 27 51 52 +3.3V +2.5V 73 72 R253 R252 R404 R251 117 128 132 R223 47 208 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 D GND SECTOR START DATA VALID DATA(EXT DATA) BIT CLOCK(EXT BCLK) D GND RESET(3V3 RESET) DXX INTERRUPT(IRQ2) SCL SDA D GND M GND +3.3V +5VD D GND A GND +12VM 1 2 3 4 5 RESET MAIN FRONT TXD FRONT RXD TV/AUX +5.6VS 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 158 148 147 157 155 145 146 156 152 141 142 151 153 143 144 154 117 161 132 162 163 165 164 166 167 168 180 181 182 175 169 170 173 174 177 176 178 179 128 47K R413 + C406 100u10 R415 1.8K R270 1.8K R269 0.1 C225 47 R268 47 R267 10 R266 17 16 18 19 0 J204 0 J203 R273 100 R274 100 68P C226 0.1 C234 68P C227 13 10K R406 10K R405 186 141 142 148 145 143 144 147 146 117 133 128 187 0.1 C401 C402 0.1 0.1 C403 0.1 C224 +5V +12V +8V 1K R250 0 R249 0.1 C217 4.7K R246 4.7K R247 10K R248 470P C216 117 12 12 +3.3V +5V +12V +3.3V +5V +12V +5V +12V +8V +3.3V +2.5V +3.3V +2.5V +5V +2.5V +3.3V +5V +2.5V +3.3V +5V +3.3V +2.5V +3.3V +2.5V +2.5V +3.3V +3.3V +2.5V +5V +3.3V +2.5V +3.3V +2.5V +3.3V C405 1000P C404 1000P + C228 47u16 + C229 47u16 + C230 47u16 L204 L205 L206 2.2uH L209 470u6.3 C233 + R220R 10 R220B 10 R220G 10 19 14 16 18 17 15 13 12 11 10 9 8 7 6 3 5 4 2 1 19 14 16 18 17 15 13 12 11 10 9 8 7 6 3 5 4 2 1 NC R216 4.7K +5.6V +5.6V L208 0 +5.6V +5.6V 1K R228 L211 0.1 C235 1K R257 R271 4.7K 100 R221 10 R438 C241 33P C240 100P C238 100P C239 100P C237 100P R279 0 R282 47 R283 47 R285 47 10K R281 10K R280 10K R298 1 1 4 12 10 11 9 7 8 5 6 2 3 1 R421 47 R422 47 R424 47 R423 47 R428 47 R427 47 R426 47 R425 47 R436 47K R435 47K R433 47K R434 47K R432 47K R430 47K R431 47K R429 47K 192 193 196 7 190 189 188 191 0 R437 ROU MO- ROU MO+ DISK SEN ROU SEN ID MO+ OPEN SEN ID MO- CLOSE SEN +8V MOTOR M GND M GND +5VD R291 R222 7 55 57 +3.3V 100u10 + C232 +5.6V 56 C243 10P 10P C242 C245 10P C244 10P +5V +12VM IC201 IC401 IC202 MAIN BOARD 0.5V 0V 0V 3.1V 0V 2.7V 0V 3.1V 2.2V 0V 0V 3.1V 0V 3.1V 3.1V 0V 3.1V 3.1V 3.2V 3.1V 3.1V 2.4V 0V 3.1V 3.11V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 2.2V 3.11V 0V 0V 0V 0V 0V 0V 3.1V 3.1V 0V 3.1V 3.1V 2.2V 0V 2.2V 0V 3.11V 0V 3.1V 3.1V 3.1V 3.1V 1.4V PLAY : 1.7V 0V 1.2V 0V 0.7V 1.2V 0V 0.7V 0.5V 0V PLAY : 1.5V 3.3V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 3.1V 3.1V 0V 3.1V 5.3V 3.3V 3.7V 5.0V 3.3V 5.2V 12.2V 3.3V 3.1V 3.1V 1.4V 5.3V 3.1V 3.1V 3.1V 3.11V 3.1V 3.1V 3.1V 3.1V 3.3V 1.5V 0V 0V STOP : 1.0V STOP : 1.3V PLAY : 1.6V PLAY : 1.4V STOP : 1.6V 2.2V 0V STOP : 3.1V STOP : 0V PLAY : 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.12V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.11V 3.0V 2.2V 1.5V 3.1V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.11V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 0V 3.1V 3.1V 0V 0V 2.4V 0V 0V 0V 0V 0V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 3.1V 3.1V 0V 0V 0V 0V 3.5V 3.5V 0.78V 0V 0V 0V 3.16V 0V 0V 1.8V 0.3V 0V 0V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 K L N P R T M O Q S CP203 CN205 CP205 Q220R Q220G Q220B IC201 : STI5519 IC202 : M24C02WMN6 IC301 : HY57V651620 IC401 : IC501 : M74HCU04M1R Q220R,220G,220B,220C,220Y,220S Q201,202 KTC3198 : CN1 Lch 1 Rch 2 JK802 COAXIAL OPTICAL JK801 Cb Y JK804 Cr JK803-A JK803-B CONNECTION JTAG TEST VIDEO OUT COMPONENT VIDEO OUT DIGITAL OUT OUTPUT AUDIO HEX INVERTER (SINGLE STAGE) 64 BIT SDRAM R OUT G OUT B OUT E,ES,T,TS D710 D709 D707 D708 D705 D706 Q702 D702 Q701 D701 Q704 E,ES,T,TS TYPE ONLY Q815 D711 Q801 Q802 E,ES,T,TS TYPE ONLY TYPE ONLY Q221R Q221G Q221B Q221C Q220C Q220S Q221S S OUT C OUT Q220Y Y OUT Q221Y A-B-B-A-A D301 Q301L IC303- Q302L Q301 Q302R Q301R IC303- A-B-B-A-B DAC AUDIO PART PCM1748 DV505/DVF-R4050 Q701,801,815 KTC3875S : KRC107S Q702,704 : Q802 KTA1504S : 1SS355 D701 D702,705-710 D711 IN4148 ZNR5V1B0.2W : : : IC21P KIA7806 : IC302 : PCM1748KE IC303 BA4560F : KTN2907 : Q221B,221G,221R,221C,221S,221Y KTD1304 : Q301 DTC114YKA : Q301L,301R DTC323TK : Q302L,302R DTA114YKA : D303 D301 1SS355 UDZ2.2B : : K,P,Y,YS,X,M3 DAC MUTE L.P.F. Q203 KTC3875S : B LINE B LINE GND LINE SIGNAL LINE DATA LINE K,P,Y,YS,X,M3 TYPE ONLY TYPE ONLY E,ES,T,TS TYPE ONLY CN905 CN904 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 VCC DQ0 VCC Q DQ1 DQ2 VSS Q DQ3 DQ4 VCC Q DQ5 DQ6 VSS Q DQ7 VCC LDQM WE CAS RAS CS BA0 BA1 A10 A0 A1 A2 A3 VCC 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 VSS DQ15 VSS Q DQ14 DQ13 VCC Q DQ12 DQ11 VSS Q DQ10 DQ9 VCC Q DQ8 VSS NC UDDM CLK CKE NC A11 A9 A8 A7 A6 A5 A4 VSS 1 2 3 4 5 6 7 AO QO A1 Q1 A2 Q2 GND 14 13 12 11 10 9 8 VCC A3 Q3 A4 Q4 A5 Q5 +2.5V +3.3V +2.5V 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 TRGI OUT TRGI IN GND(OPTION) TMS GND TCK GND TDI GND TDO +5VD TXD(JIG) RXD(JIG) JTAG RST TRST 1 2 3 4 5 6 7 8 9 10 11 12 +8V A GND -8V +12V SCART +5.6VS +3.5VD D GND +2.5VD +5VD +12V MOTOR M GND +8V MOTOR 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 D GND SPDIF A GND AUDIO R A GND AUDIO L A GND CVBS A GND C OUT A GND Y OUT A GND R OUT(Cr) A GND G OUT(Y) A GND B OUT(Cb) +5VD +12V SCART TV/AUX 16.9 BLANK 72 73 70 69 68 67 66 79 78 77 76 74 91 85 90 89 88 87 86 84 60 59 58 62 61 63 80 82 71 93 92 97 99 98 100 101 102 R315 47K 0.1 C312 + C311 100u10 0 R314 0 L301 +3.3V +3.3V +3.3V L501 + C505 470u6.3 0.1 C504 1M R503 C503 X501 C502 56 R502 100 R501 20P C501 0 J202 0 J201 0.1 C215 10K R243 10K R244 10K R245 R236 47K 47 R240 47 R239 47 R238 47 R241 47 10K R242 109 200 197 111 112 113 110 115 202 203 10 R226R 390P C224R 12 R224R 8.2 R225R 390P C225R 2.7uH L220R 3300P C221R + C223R 220u16 0.1 C222R 2.2K R222R 75 R223R 820 R221R 470u10 + C220R R226G C224G C221G R225G 3300P R222G 2.2K R223G 75 R221G 820 C220G 470u10 12 R224G C225G 390P 390P 2.7uH L220G 220u16 C223G C222G 8.2 0.1 + 10 3300P R225B C221B C224B 470u10 2.2K R222B 75 R223B R221B C220B 820 12 R224B 8.2 C225B 390P 390P L220B 2.7uH 220u16 C222B C223B 0.1 + 10 R226B 27 26 25 25 26 27 FRONT LEFT V-A GND COMPOSITE 9 8 FRONT RIGHT V-A GND V-A GND V-A GND 5 6 7 3 4 SPDIF 1 2 D GND V-A GND BLUE A GND Y RED GREEN C A GND 17 18 14 15 16 12 13 10 11 21 SCART H(TV/AUX) 16.9 INDICATION RGB-SELECT 23 22 +12VA 20 +5VD 19 +2.5V +5V +8V +12V +12V +8V +2.5V +3.3V +2.5V +3.3V +3.3V +3.3V +3.3V 0 R827L 0 R827R 1 2 3 5 4 OUT VCC GND 2 1 3 1 2 10 8 9 7 6 0 R877 0 R874 0 R876 1 3 1 2 4 0 R820 + + + +5.6V +5V +5.6V +5V +5V 2 1 10 9 GREEN 13 11 14 12 BLUE AL OUT AR OUT 7 5 3 SENSE 8 6 4 18 17 CVBS IN 21 19 Y/CVBS OUT 20 BLK 15 C/RED 16 10u50 + C713 1K R714 10u50 C714 1K R715 + 100P C716 39 R721 39 R719 39 R720 39 R722 39 R717 39 R718 100P C717 100P C718 L704 L706 100 R702 75 R705 + C703 100u10 180 R724 1K R723 100u10 C719 1K R716 100 R730 100 R701 L703 39 R731 100u10 C715 R708 1K R709 1K L705 0.1 C821 75 R865 + C822 220u6.3 470 R864 R829 + + + 47u16 4.7K R803 10 R804 R802 100 R801 R807 100 R806 180 R805 100P C804 0.01 C803 0 R808 0.1 C801 0 R815 +5V +12V +5V +5V +12V +5V R873 R875 470u6.3 + C720 3 1 6 25 26 27 57 120 R227R 120 R227G 120 R227B 2 R224Y 820 12 R226Y C221Y 3300P + 10 C222S 220u16 C223S R225S R224C C221C R223C 2.2K R222C 75 + 820 R221C 12 L220C 390P 390P C225C C224C 2.7uH R227C 120 33 C222C C223C 220u16 R225C 8.2 3300P + 0.1 R223S 75 R222S 2.2K + R227S C225S 390P C224S 390P R226C 10 120 2.7uH L220S 8.2 34 R224S R221S 820 12 R226S C221S 3300P 0.1 + 10 C220S 34 470u10 33 470u10 390P 390P C225Y R223Y R222Y 2.2K C224Y 75 C220Y R221Y 32 + 470u10 C223Y C222Y 220u16 R225Y L220Y 2.7uH 8.2 0.1 R227Y 120 32 C220C 34 33 SCK 1 4 6 OUT L VCC 7 VDD D GND 5 2 LRCK DATA 3 BCK 13 11 V COM ZERO R 10 ZERO L MD 12 MC ML 14 15 16 OUT R A GND 8 9 10P C328 10P C329 + C327 10u16 560P C326 + C325 1000u10 560P C324 C323 + 560P C322 45 55 46 44 56 52 51 2.2uH L302 R321 33 5 6 4 7 5.6K R302L 47u16 + C301L 47K R301L 330P C303L 9.1K R304L 100K R308L 100 R309L 330 R307L 0.1 C304L 2200P C302L 47u16 C305L + 3.9K R303L 47u16 + C306L 100P C307L R322 470 R323 + C331 1000u6.3 180K R324 C303R 0.1 3.9K R303R C304R 2200P C302R R301R 47K C301R 47u16 5.6K R302R R304R 9.1K 8 100 R307R C305R 47u16 + C307R R308R 100K 100P C306R 47u16 3 2 1 330P R309R 100 + + 8 +8 6 4 6 4 +12V +2.5V +8V 208 +8V 8V OUT GND IN 100u10 C201P + 0 R201P L210 R237 AUSTRALIA SOUTH AMERICA EUROPE CANADA U.K. U.S.A. COUNTRY DESTINATION X M3 T,TS P E,ES 22P ABB. K C502, 10P C321 R872 2 +5.6V +3.3V +5V +3.3V +3.3V 32 24P C503 (BLANK) +5V +5V +12V +12V B +B 47u16 0 C802 0 0 Y,YS PX SST39VF800505K IC401 SST39VF800505E SST39VF800505X 10K 209 R205, 15K 15K 220 200 220 R206B,207G,208R, 210Y,211C,212S YES R829 NO YES 6.8K 1.2K 0 R945 0 1 2 3 4 5 RESET RXD TXD SCART CTL +5.6VS 1 2 3 4 5 RESET RXD TXD SCART CTL +5.6VS IC301 IC501 IC805 OUTPUT BOARD MAIN BOARD JK701 IC302 IC21P CONNECTION BOARD 3.1V 0V 2.8V 2.8V 0V 0V 0V 0V 2.8V 2.6V 3.3V 2.5V 3.2V 4.2V 4.8V 2.6V 4.2V 4.8V 2.6V 4.8V 2.6V 4.2V 3.3V 2.6V 4.8V 4.2V 2.6V 4.2V 4.8V 2.6V 4.8V 4.2V 2.7V 3.2V 2.7V 2.7V 0V 2.7V 2.9V 3.2V 2.7V 2.9V 0V 2.9V 3.2V 0V 3.1V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 3.1V 3.1V 3.1V 3.1V 0V 2.9V 3.2V 3.2V 3.2V 3.2V 3.2V 3.1V 3.1V 3.1V 0V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.1V 3.3V 3.1V 3.1V 3.1V 3.1V 3.1V 0V 9.0V 0V 5.9V 1.6V 1.5V 0V 1.5V 0V 3.1V 5.9V 2.9V 2.9V 3.1V 3.1V 0V 2.9V 0V -7.8V 0V 0V 0V 0V -7.8V 0.27V 0V 0.3V 0V 0.27V 0V 1.6V 9.0V 1.6V 0V 12.4V 0V 1.6V 5.3V 1.74V 0V 1.7V 1.58V 4.1V 9.6V 4.7V -8.6V 0V 0V 0V 0V 8.9V 0V 0V 1.8V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 U W Y AA AC V X Z AB AD Y22-8580-10 DV-505/DVF-4050/-S CN901 CN902 SW901 SW903 SW905 SW907 PLAY/ PAUSE STOP FAST FORWARD FAST REWARD CN1 D1-D4 D5 ZD1 PC1 D6 CN3 CN4 D7 D8 ZD2 D9 D10 D12 D15 U4 D17 D13 POWER SW VFD/CONTROLLER /DRIVER ZD2 : 1N5226B D13 D10,12 D15 ZD1 D7 : SR204 1N5239B : 1N5819 SF24 HER105 : : : : U2 KA7809 D1-4,17 D6,8,9 D5 1N4007 1N4937 HER107 : : : U1 KA1M0380RB : R8501V-40 1N4148 : D906 D904 : CXP825P400-1 IC901 W02-2801-08 : : RM901 +9.0V AVR MSW1 KA431AZ U4 : D906 D904 SW917 DISC 2 MODE SW913 SW915 SKIP SW911 SEQUENCE DISK 1 DISK SW927 DISC 5 SW924 SW921 DISC 4 DISC 3 CN903 SW930 OPEN/ CLOSE IC902 KIA7045P : REMOTE CONT. SENSOR RESET IC T95-0184-08 : PC1 CP903 1 2 3 4 5 GND +5VFL AC -27VFL AC -5VFL AC +5.6VS 1 2 3 4 5 RESET TXD SCART CTL +5.6VS 80 79 78 77 76 75 74 73 72 71 70 69 68 62 61 60 50 49 48 47 46 45 44 43 42 41 25 26 27 28 29 30 31 32 33 34 35 36 37 1 2 3 4 5 6 7 8 9 10 11 12 13 POWER CTL SCART CTL G0 G1 G2 G3 SEG14 SEG13 SEG12 SEG11 SEG10 SEG9 SEG8 SEG7 SEG6 SEG5 KEY IN1 KEY IN2 KEY IN3 -RST E XTAL XTAL VSS SEG0 SEG1 RXD RMC RESET MAIN VIDEO MUTE 2 AUDIO MUTE MODE SEL 38 37 35 34 33 32 31 30 29 28 27 26 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 3 2 1 1G 2G 3G 4G 5G 6G 20P 19P 18P 17P 16P 15P 14P 13P 12P 11P 10P 9P 8P 7P 6P P5 P4 P3 P2 P1 +5.5V +5.5V 27V 1 2 T2A VR1 0.1 C1 TH1 LF1 C4 C3 C2 0.1 C6 2200P R1 150K 2W R2 56K 1W C5 47u400 + 3 4 DRAIN VCC 2 1 FB GND 0.047 C7 1K R3 47u50 C8 + T1 1 2 3 4 5 GND FL5V+ -27V FL5V- 5.5VS 1 2 3 4 5 6 7 8 9 10 11 12 +9VA AGND -8VA +12VA P/REST +3.5V DGND +2.5V +5V +12VM MGND +9VM 100u16 C9 + 1K 1/4W R5 3.0 1/4W R4 12K 1/4W R8 47u50 C10 + 20 R7 120 R6 2.2 1/4W R9 1K 1/4W R10 100u16 C11 + 6 4 1 2 8 7 9 14 12 13 10 15 11 1000P C12 10 R11 100u25 C14 + 560 1W R12 220u25 C13 + 15uH L1 VI VO GND 3.3 1/2W R13 100u16 C15 + 100 1W 470u10 R14 C17 + 15uH 470u10 C16 + L2 470u10 C19 1000u10 + C18 L3 7uH + 120 R18 1u50 + C20 10 R20 18K R19 1.5K R22 2.2K R21 820 R24 150 R23 R25 390 1/4W 1000P C24 220 1/4W R26 100u16 C21 + 14 27V 8V 8V +9V +9V +9V +5.5V +5.5V +5.5V +3.5V +3.5V +2.5V +12V +12V +12V +5V +12V +12V 1500P 1500P 1/2W +B 36 25 4 NC 17 18 15 16 14 REGION 23 24 MODEL SEL 20 21 22 OPTION 19 SEG18 SEG16 SEG15 51 SEG17 53 52 SEG20 SEG19 55 54 SEG21 57 56 59 58 63 64 SEG4 SEG3 SEG2 39 38 40 65 67 66 57 56 54 55 51 50 52 53 42 43 45 44 47 46 48 49 41 36 37 38 39 40 70 68 69 66 67 65 + C907 470u6.3 22uH L901 0.1 C905 + C906 100u6.3 10 R950 + C916 470u6.3 0.1 C908 47K R926 22K R927 L903 10 1/4W L902 0 10 1/4W L904 RXD 0 0 L909 L914 L913 0 0 L912 8 1 77 74 +B IN GND 47u16 C901 + 10K R902 100 R901 F1 NP F1 NP P21 P22 P23 NC NP NP F2 F2 X901 C911 0.1 26 25 27 55 54 52 53 49 48 50 51 42 40 41 43 45 44 46 47 37 38 39 36 56 57 58 58 70 69 67 68 65 66 77 74 1 8 4.7K R911 10K R912 75K R913 R921 R922 R923 10K 75K 4.7K 4.7K 10K R932 R931 R945 10K R946 0 L905 10K R938 10K R939 10K R940 2 1 2 1 75K R933 25 26 27 R943 47K C909 0.1u50 + IN +B GND C904 0.1 AC250V F1 0.1 C903 +B +B +B +B +B +B +B +5.5V 1/4W DV-505 IC901 FL901 U1 U2 POWER SUPPLY BOARD FRONT BOARD RM901 IC902 -27.9V 5.6V -8.5V 12.2V 9.0V 5.3V 11.2V 5.6V 3.3V 2.5V 3G 4G 5G 1a a g d f b e c 2a 1a 2a 1a 2a 1a 1a 2a j col j j j n n n h 6G (1G-5G) 2G 1G col Dp Dp P1 2G 3G 5G 4G 6G DVD 1G P2 P3 P5 1b 1b 1b 1b 1b P4 1a 1a 1a 1a 1a P8 1h 1n 1n col col 1n P9 P7 1e 1e 1f 1f 1d 1d P6 1c 1c 2 1 SEQ. 2g Dp Dp 1 DISC RANDOM 2g P17 P16 P14 P15 PCB P12 P13 P11 2f 2f 2d 2e 2d 2e 2b 2b 2c 2c 2g 2f 2d 2e 2b 2c 2g 2j INTRO 2j 2f 2d 2e 2b 2c 2a 2a 2a 2a P10 1g 1g 1e 1e 1f 1f 1d 1d 1c 1c 1g 1e 1f 1d 1c 1g 1g P20 (3) (5) PROG. ALL S P19 P18 VCD HOUR TITLE CHAP TRACK MIN SEC C D REPEAT MP3 A B P21 (2) (4) P22 3 (1) 1 5 P23 2 4 CAUTION: For continued safety, replace safety critical com- ponents only with manufacturer's recommended parts (refer to parts list). indicates safety critical components. For continued protection against risk of fire, replace only with same type and rating fuse(s). To reduce the risk of electric shock, leakage-current or resistance measurements shall be carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance is returned to the cus- tomer. The DC voltage is an actual reading measured with a high impedance type voltmeter with no signal input. The mea- surement value may vary depending on the measuring instruments used or on the product. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 Parts with exploded numbers larger than 700 are not supplied. AAx2 AAx2 ACx2 3x10 3x10 2.6x4 3 3x8 3x18 : N09-5407-08 : N09-5408-08 : N09-5409-08 : N09-5410-08 : N89-3008-46 : N09-5411-08 AA AB AC AD AE AF DVF-R4050(2/2) 1 3 4 5 6 9 2 7 8 7 8 7 8 10 7 8 7 RM 26 25 12 14 17 8 13 18 15 19 820 LM 823 822 822 822 24 CC202 16 774 773 744 AD AB AD AF AE AE AB AB AD AD AA AE AE AA 1 2 3 A B EXPLODED VIEW(MECHANISM) DV-505/DVF-4050/-S 21 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DVF-R4050(1/2) SW930 SW901 SW903 SW911 SW913 SW915 SW917 SW921 SW905 SW924 SW927 SW907 DISC SKIP SEQUENCE MODE DISC 1 DISC 2 DISC 3 DISC 4 DISC 5 COAXIAL IC805 JK801 JK802 OPTICAL OUTPUT AUDIO JK803 JK804 S-VIDEO COMPONENT VIDEO OUTPUT OUTPUT VIDEO 619 623 622 601 631 608 609 610 612x2 613x2 772 718 737 614 648 616 649 624 607 604 602 603 772 650x2 650x2 715 760 721 761 764 770 762 771 721 3x8 (BLK) 4x8 (BLK) 4x8 3x10 WASHER : N89-3008-45 : N09-5268-08 : N09-5369-08 : N89-3010-46 : N15-1030-46 A B B' C D Ax2 Ax2 A B(B') B(B') B(B') B(B') A C C C C C C A Cx2 C C C C C C C C C C C C C C C D C A C D A Cx2 Cx2 Cx2 Cx2 Cx2 Cx2 Cx2 Cx2 C CC202 Ax2 Ax3 A A 1 2 C E D Parts with exploded numbers larger than 700 are not supplied. EXPLODED VIEW(UNIT) DV-505/DVF-4050/-S 22 www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 23 PARTS LIST Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks - ✽ H50-4199-08 BOX OUT DVF-R40J96000039080 XM3 A N89-3008-45 SCREW 3MM 8MM D55164800XX A N89-3008-45 SCREW-ST 3MM 0655049000XX A N89-3008-45 SCREW-ST 3MM 8M55127120XX B N09-5268-08 SCREW-ST 4MM 8M55127090XX KPETY B’ N09-5369-08 SCREW-ST 4MM 8.55085860XX ESTSYS B’ N09-5369-08 SCREW-ST 4MM 8.55085860XX X C N89-3010-46 SCREW-ST 3MM 1055127070XX D N15-1030-46 WASHER-SPR 3.3M55127310XX C1 ,2 C92-0252-08 CERAMIC 0.1UF 275VAC C3 ,4 C92-0253-08 CERAMIC 1500PF 400VAC C5 C92-0254-08 ELECTRO 47UF 400WV C6 C92-0255-08 CERAMIC 2200PF 1KV C7 CK45FB1H473K CERAMIC 0.047UF K C8 CE04LW1H470M ELECTRO 47UF 50WV C9 CE04LW1C101M ELECTRO 100UF 16WV C10 CE04LW1H470M ELECTRO 47UF 50WV C11 CE04LW1C101M ELECTRO 100UF 16WV C12 C92-0256-08 CERAMIC 1000PF 1KV C13 CE04LW1E221M ELECTRO 220UF 25WV C14 CE04LW1E101M ELECTRO 100UF 25WV C15 CE04LW1C101M ELECTRO 100UF 16WV C16 ,17 CE04LW1A471M ELECTRO 470UF 10WV C18 CE04LW1A102M ELECTRO 1000UF 10WV C19 CE04LW1A471M ELECTRO 470UF 10WV C20 CE04LW1H010M ELECTRO 1.0UF 50WV C21 CE04LW1C101M ELECTRO 100UF 16WV C24 C92-0257-08 CERAMIC 1000PF 400VAC F1 F50-0195-08 FUSE CT2A 250VAC L1 ,2 L32-1042-08 COIL 150K,CC150B L3 L32-1043-08 CHOKE COIL 7UH LF1 L79-1288-08 LINE FILTER DY-2030S T1 ✽ L07-3161-08 POWER TRANSFORMER,YST00020 R1 RS14GB3D154J FL-PROOF RS 150K J 2W R2 RS14GB3A563J FL-PROOF RS 56K J 1W R11 RD14BB2H100J RD 10 J 1/2W R12 RS14GB3A561J FL-PROOF RS 560 J 1W R13 RD14BB2H3R3J RD 3.3 J 1/2W R14 RS14GB3A101J FL-PROOF RS 100 J 1W MSW1 ✽ S68-0143-08 PUSH SW YSW00001 D1 -4 1N4007 DIODE D5 HER107 DIODE D6 1N4937 DIODE D7 HER105 DIODE D8 ,9 1N4937 DIODE D10 SF24 DIODE D12 SF24 DIODE D13 1N5819 DIODE D15 SR204 DIODE D17 1N4007 DIODE PC1 T95-0184-08 PHOTO COUPLER LTV817B ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 2 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks 601 2C ✽ B10-3822-08 WINDOW DV505 J85300035010 KP 601 2C ✽ B10-3823-08 WINDOW DVFR4050J85300035020 EESTTS 601 2C ✽ B10-3823-08 WINDOW DVFR4050J85300035020 YM3 602 2C ✽ B43-0310-04 BADGE AL KENWOOJ60550010000 603 2C ✽ A60-2206-08 PANEL FRONT BLAJ85000032010 KPETY 603 2C ✽ A60-2207-08 PANEL FRONT SILJ85000032020 ESTSYS 603 2C ✽ A60-2207-08 PANEL FRONT SILJ85000032020 XM3 604 2C ✽ K27-2475-08 BTN POWER BLACKJ85200155010 KPETY 604 2C ✽ K27-2476-08 BTN POWER SILVEJ85200155020 ESTSYS 604 2C ✽ K27-2476-08 BTN POWER SILVEJ85200155020 XM3 607 1C ✽ A70-1570-08 ASS’Y REMOCON DJ54000002400 608 2C ✽ K27-2477-08 BTN 4KEY BLACK J85200152010 KPETY 608 2C ✽ K27-2478-08 BTN 4KEY SILVERJ85200152020 ESTSYS 608 2C ✽ K27-2478-08 BTN 4KEY SILVERJ85200152020 XM3 609 2C ✽ K27-2479-08 BTN 7KEY BLACK J85200153010 KPETY 609 2C ✽ K27-2480-08 BTN 7KEY SILVERJ85200153020 ESTSYS 609 2C ✽ K27-2480-08 BTN 7KEY SILVERJ85200153020 XM3 610 2D ✽ K27-2473-08 BTN O/C BLACK J85200154010 KPETY 610 2D ✽ K27-2474-08 BTN O/C SILVER J85200154020 ESTSYS 610 2D ✽ K27-2474-08 BTN O/C SILVER J85200154020 XM3 612 2E ✽ J02-1510-08 FOOT KENWOOD DVJ85900505000 613 2E ✽ J02-1529-08 FOOT KENWOOD BLJ85900505020 614 1D ✽ D21-2927-08 SHAFT POWER SW J85820004010 KPETY 614 1D ✽ D21-2928-08 SHAFT POWER SW J85820004020 ESTSYS 614 1D ✽ D21-2928-08 SHAFT POWER SW J85820004020 XM3 616 1C ✽ A01-3854-08 COVER TOP BLACKJ60100004310 KPETY 616 1C ✽ A01-3855-08 COVER TOP SILVEJ60100004320 ESTSYS 616 1C ✽ A01-3855-08 COVER TOP SILVEJ60100004320 XM3 619 1D ✽ A29-1173-08 DOOR TRAY BLACKJ85600023010 KPETY 619 1D ✽ A29-1174-08 DOOR TRAY SILVEJ85600023020 ESTSYS 619 1D ✽ A29-1174-08 DOOR TRAY SILVEJ85600023020 XM3 622 1E ✽ E30-7250-08 WIRE-MCRDM 0.7555190780XX KPYYS 622 1E ✽ E30-7251-08 WIRE-MCRDM 0.7555190790XX EESM3 622 1E ✽ E30-7252-08 WIRE-MCRDM 0.7555190800XX TTS 622 1E ✽ E30-7253-08 WIRE-MCRDM 0.7555190820XX X 623 1E J42-0350-08 BUSHING-AC CORDJ65100000100 624 1C E03-0115-05 AC PLUG ADAPTER M3 631 2C ✽ F19-1125-08 COVER WINDOW DVJ85500014000 ESTSYS 631 2C ✽ F19-1125-08 COVER WINDOW DVJ85500014000 XM3 648 1C E30-2990-08 CORD RCA 3P1500J94330001000 649 1C E30-7235-08 CORD RCA 1P 010J94310007000 650 2D,2E ✽ J02-1538-08 CUSHION FOOT 20J67200009200 - ✽ B60-5088-08 I/B,EN J90200018610 - ✽ B60-5089-08 I/B,FR J90200018620 PEES - ✽ B60-5092-08 I/B,GE/NE J90200018650 EES - ✽ B60-5093-08 I/B,IT/ES J90200018660 EESM3 - ✽ H50-4192-08 BOX OUT DV505 J96000039010 KP - ✽ H50-4193-08 BOX OUT DVF-R40J96000039020 E - ✽ H50-4194-08 BOX OUT DVF-R40J96000039030 ES - ✽ H50-4195-08 BOX OUT DVF-R40J96000039040 T - ✽ H50-4196-08 BOX OUT DVF-R40J96000039050 TS - ✽ H50-4197-08 BOX OUT DVF-R40J96000039060 Y - ✽ H50-4198-08 BOX OUT DVF-R40J96000039070 YS ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 1 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . DV-505/DVF-R4050 POWER SUPPLY www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 24 PARTS LIST Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks C223B CE04LW1C221M ELECTRO 220UF 16WV C223C CE04LW1C221M ELECTRO 220UF 16WV C223G CE04LW1C221M ELECTRO 220UF 16WV C223R CE04LW1C221M ELECTRO 220UF 16WV C223S CE04LW1C221M ELECTRO 220UF 16WV C223Y CE04LW1C221M ELECTRO 220UF 16WV C224B CK73GB1H391K CHIP C 390PF K C224C CK73GB1H391K CHIP C 390PF K C224G CK73GB1H391K CHIP C 390PF K C224R CK73GB1H391K CHIP C 390PF K C224S CK73GB1H391K CHIP C 390PF K C224Y CK73GB1H391K CHIP C 390PF K C225B CK73GB1H391K CHIP C 390PF K C225C CK73GB1H391K CHIP C 390PF K C225G CK73GB1H391K CHIP C 390PF K C225R CK73GB1H391K CHIP C 390PF K C225S CK73GB1H391K CHIP C 390PF K C225Y CK73GB1H391K CHIP C 390PF K C226,227 CC73GCH1H680J CHIP C 68PF J C228-230 CE04LW1C470M ELECTRO 47UF 16WV C232 CE04LW1A101M ELECTRO 100UF 10WV C233 CE04LW0J471M ELECTRO 470UF 6.3WV C234,235 CK73GB1E104Z CHIP C 0.10UF Z C237-241 CC73GCH1H101J CHIP C 100PF J C242-245 CC73GCH1H100D CHIP C 10PF D C301-310 CK73GB1E104Z CHIP C 0.10UF Z C301L CE04LW1C470M ELECTRO 47UF 16WV C301R CE04LW1C470M ELECTRO 47UF 16WV C302L CK73GB1H222K CHIP C 2200PF K C302R CK73GB1H222K CHIP C 2200PF K C303L CK73GB1H331K CHIP C 330PF K C303R CK73GB1H331K CHIP C 330PF K C304L CK73GB1E104Z CHIP C 0.10UF Z C304R CK73GB1E104Z CHIP C 0.10UF Z C305L CE04LW1C470M ELECTRO 47UF 16WV C305R CE04LW1C470M ELECTRO 47UF 16WV C306L CE04LW1C470M ELECTRO 47UF 16WV C306R CE04LW1C470M ELECTRO 47UF 16WV C307L CC73GCH1H101J CHIP C 100PF J C307R CC73GCH1H101J CHIP C 100PF J C311 CE04LW1A101M ELECTRO 100UF 10WV C312 CK73GB1E104Z CHIP C 0.10UF Z C321 CC73GCH1H100D CHIP C 10PF D C322 CK73GB1H561K CHIP C 560PF K C323 CE04LW1C470M ELECTRO 47UF 16WV C324 CK73GB1H561K CHIP C 560PF K C325 CE04LW1A102M ELECTRO 1000UF 10WV C326 CK73GB1H561K CHIP C 560PF K C327 CE04LW1C100M ELECTRO 10UF 16WV C328,329 CC73GCH1H100D CHIP C 10PF D C330 CE04KW0J331M ELECTRO 330UF 6.3WV C331 CE04LW0J102M ELECTRO 1000UF 6.3WV C401-403 CK73GB1E104Z CHIP C 0.10UF Z C404,405 CK73GB1H102K CHIP C 1000PF K C406 CE04LW1A101M ELECTRO 100UF 10WV ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 4 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks TH1 NTC10D7 THERMISTOR U1 KAIM0380RB IC U2 KA7809 IC U4 KA431AZ IC VR1 ✽ SVC471D-10A VARISTOR YVA32110 ZD1 N5239B ZENER DIODE ZD2 1N5226B ZENER DIODE CC201 ✽ E35-3211-08 FFC-JUMPER 19X 55191150NR CC202 3B,1E ✽ E35-3212-08 FPC CABLE 19P 1J4112191001X KPYYSX CC202 3B,1E ✽ E35-3213-08 FPC CABLE 23P 1J4112231001X EESTTS CN01 ✽ E35-3214-08 FPC PLUG 23P 1.55124620XX EESTTS CN01 E40-8985-08 FPC PLUG 19P 1.55124600XX KPYYSX CP201 ✽ E35-3215-08 FPC PLUG 19P 1.55124680XX JK701 E40-8779-08 SCART CONNECTORJ44372100205 EESTTS JK801 ✽ E63-1244-08 JACK RCA 1P O WJ44301000900 JK802 E63-1227-08 JACK RCA 2P,WR,J44302000600 JK803 ✽ E68-0018-08 CON DIN SCKT MI55191220XX JK804 E63-1192-08 JACK RCA 3P,RBGJ44303000200 KPYYSX C201,202 CK73GB1E104Z CHIP C 0.10UF Z C201P CE04LW1A101M ELECTRO 100UF 10WV C203 CK73GB1H103K CHIP C 0.010UF K C204 CE04LW1A101M ELECTRO 100UF 10WV C205 CK73GB1H103K CHIP C 0.010UF K C206 CE04LW1A101M ELECTRO 100UF 10WV C207 CK73GB1E104Z CHIP C 0.10UF Z C208 CK73GB1E104Z CHIP C 0.10UF Z C209 CK73GB1H103K CHIP C 0.010UF K C210 CE04LW1A101M ELECTRO 100UF 10WV C211-214 CC73GCH1H100D CHIP C 10PF D C215 CK73GB1E104Z CHIP C 0.10UF Z C216 CK73GB1H471K CHIP C 470PF K C217-219 CK73GB1E104Z CHIP C 0.10UF Z C220 CK73GB1H103K CHIP C 0.010UF K C220B CE04LW1A471M ELECTRO 470UF 10WV C220C CE04LW1A471M ELECTRO 470UF 10WV C220G CE04LW1A471M ELECTRO 470UF 10WV C220R CE04LW1A471M ELECTRO 470UF 10WV C220S CE04LW1A471M ELECTRO 470UF 10WV C220Y CE04LW1A471M ELECTRO 470UF 10WV C221 CE04LW1A101M ELECTRO 100UF 10WV C221B CK73GB1H332K CHIP C 3300PF K C221C CK73GB1H332K CHIP C 3300PF K C221G CK73GB1H332K CHIP C 3300PF K C221R CK73GB1H332K CHIP C 3300PF K C221S CK73GB1H332K CHIP C 3300PF K C221Y CK73GB1H332K CHIP C 3300PF K C222-225 CK73GB1E104Z CHIP C 0.10UF Z C222B CK73GB1E104Z CHIP C 0.10UF Z C222C CK73GB1E104Z CHIP C 0.10UF Z C222G CK73GB1E104Z CHIP C 0.10UF Z C222R CK73GB1E104Z CHIP C 0.10UF Z C222S CK73GB1E104Z CHIP C 0.10UF Z C222Y CK73GB1E104Z CHIP C 0.10UF Z ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 3 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . MAIN www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 25 PARTS LIST Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks R205 RK73GB1J103J CHIP R 10K J 1/16W EESTTS R205 RK73GB1J153J CHIP R 15K J 1/16W KPYYSX R206B RK73GB1J201J CHIP R 200 J 1/16W EESTTS R206B RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R207G RK73GB1J201J CHIP R 200 J 1/16W EESTTS R207G RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R208R RK73GB1J201J CHIP R 200 J 1/16W EESTTS R208R RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R209 RK73GB1J153J CHIP R 15K J 1/16W R210Y RK73GB1J201J CHIP R 200 J 1/16W EESTTS R210Y RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R211C RK73GB1J201J CHIP R 200 J 1/16W EESTTS R211C RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R212S RK73GB1J201J CHIP R 200 J 1/16W EESTTS R212S RK73GB1J221J CHIP R 220 J 1/16W KPYYSX R213-215 RK73GB1J470J CHIP R 47 J 1/16W R216 RK73GB1J472J CHIP R 4.7K J 1/16W R217S RK73GB1J100J CHIP R 10 J 1/16W R218C RK73GB1J100J CHIP R 10 J 1/16W R219Y RK73GB1J100J CHIP R 10 J 1/16W R220B RK73GB1J100J CHIP R 10 J 1/16W R220G RK73GB1J100J CHIP R 10 J 1/16W R220R RK73GB1J100J CHIP R 10 J 1/16W R221 RK73GB1J101J CHIP R 100 J 1/16W R221B RK73GB1J821J CHIP R 820 J 1/16W R221C RK73GB1J821J CHIP R 820 J 1/16W R221G RK73GB1J821J CHIP R 820 J 1/16W R221R RK73GB1J821J CHIP R 820 J 1/16W R221S RK73GB1J821J CHIP R 820 J 1/16W R221Y RK73GB1J821J CHIP R 820 J 1/16W R222 RK73GB1J470J CHIP R 47 J 1/16W EESTTS R222B RK73GB1J222J CHIP R 2.2K J 1/16W R222C RK73GB1J222J CHIP R 2.2K J 1/16W R222G RK73GB1J222J CHIP R 2.2K J 1/16W R222R RK73GB1J222J CHIP R 2.2K J 1/16W R222S RK73GB1J222J CHIP R 2.2K J 1/16W R222Y RK73GB1J222J CHIP R 2.2K J 1/16W R223 RK73GB1J470J CHIP R 47 J 1/16W R223B RK73GB1J750J CHIP R 75 J 1/16W R223C RK73GB1J750J CHIP R 75 J 1/16W R223G RK73GB1J750J CHIP R 75 J 1/16W R223R RK73GB1J750J CHIP R 75 J 1/16W R223S RK73GB1J750J CHIP R 75 J 1/16W R223Y RK73GB1J750J CHIP R 75 J 1/16W R224B RK73GB1J120J CHIP R 12 J 1/16W R224C RK73GB1J120J CHIP R 12 J 1/16W R224G RK73GB1J120J CHIP R 12 J 1/16W R224R RK73GB1J120J CHIP R 12 J 1/16W R224S RK73GB1J120J CHIP R 12 J 1/16W R224Y RK73GB1J120J CHIP R 12 J 1/16W R225B RK73GB1J8R2J CHIP R 8.2 J 1/16W R225C RK73GB1J8R2J CHIP R 8.2 J 1/16W R225G RK73GB1J8R2J CHIP R 8.2 J 1/16W R225R RK73GB1J8R2J CHIP R 8.2 J 1/16W R225S RK73GB1J8R2J CHIP R 8.2 J 1/16W ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 6 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks C501 CC73GCH1H200J CHIP C 20PF J C502,503 CC73GCH1H220J CHIP C 22PF J KPYYSX C502,503 CC73GCH1H240G CHIP C 24PF G EESTTS C504 CK73GB1E104Z CHIP C 0.10UF Z C505 CE04LW0J471M ELECTRO 470UF 6.3WV C703 CE04LW1A101M ELECTRO 100UF 10WV EESTTS C713,714 CE04LW1H100M ELECTRO 10UF 50WV EESTTS C715 CE04LW1A101M ELECTRO 100UF 10WV EESTTS C716-718 CC73FCH1H101J CHIP C 100PF J EESTTS C719 CE04LW1A101M ELECTRO 100UF 10WV EESTTS C720 CE04LW0J471M ELECTRO 470UF 6.3WV C801 CK73FB1E104Z CHIP C 0.10UF Z C802 CE04LW1C470M ELECTRO 47UF 16WV C803 CK73FB1H103K CHIP C 0.010UF K C804 CC73FCH1H101J CHIP C 100PF J C821 CK73FB1E104Z CHIP C 0.10UF Z EESTTS C822 CE04LW0J221M ELECTRO 220UF 6.3WV EESTTS C901 CE04LW1C470M ELECTRO 47UF 16WV C903-905 CK73GB1E104Z CHIP C 0.10UF Z C906 CE04LW0J101M ELECTRO 100UF 6.3WV C907 CE04LW0J471M ELECTRO 470UF 6.3WV C908 CK73GB1E104Z CHIP C 0.10UF Z C909 CE04LW1H0R1M ELECTRO 0.1UF 50WV C911 CK73GB1E104Z CHIP C 0.10UF Z C916 CE04LW0J471M ELECTRO 470UF 6.3WV L201-203 L32-1046-08 COIL CHIP 2U2H 1404174091 L204-206 L32-1047-08 BEAD CHIP/TAP F5512667050 L208 RK73GB1J000J CHIP R 0 J 1/16W L209 L32-1046-08 LF-SMD 2U2H +101404174091 L210 L32-1047-08 BEAD CHIP/TAP F5512667050 L211 L32-1045-08 BEAD CHIP/TAP F5512671050 L220B L32-1048-08 COIL CHIP 2U7H 1404175091 L220C L32-1048-08 COIL CHIP 2U7H 1404175091 L220G L32-1048-08 COIL CHIP 2U7H 1404175091 L220R L32-1048-08 COIL CHIP 2U7H 1404175091 L220S L32-1048-08 COIL CHIP 2U7H 1404175091 L220Y L32-1048-08 COIL CHIP 2U7H 1404175091 L301 RK73GB1J000J CHIP R 0 J 1/16W L302 L32-1046-08 COIL CHIP 2U2H 1404174091 L501 L32-1047-08 BEAD CHIP/TAP F5512667050 L703-706 RK73FB2A000J CHIP R 0 J 1/10W EESTTS L901 L90-0371-08 COIL AX/TAP 22uJ2616222026X L902 RK73GB1J000J CHIP R 0 J 1/16W L903,904 RD14BB2E100J RD 10 J 1/4W L905 RK73GB1J000J CHIP R 0 J 1/16W L909 RK73GB1J000J CHIP R 0 J 1/16W L912-914 RK73GB1J000J CHIP R 0 J 1/16W X501 L77-2354-08 CRYSTAL 27.000M55128980NR X901 L77-2355-08 RESONATOR 10.0M55126140NR J201-204 RK73GB1J000J CHIP R 0 J 1/16W J301 RK73GB1J000J CHIP R 0 J 1/16W J914 RK73GB1J000J CHIP R 0 J 1/16W R201-204 RK73GB1J101J CHIP R 100 J 1/16W R201P RK73GB1J000J CHIP R 0 J 1/16W ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 5 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 26 PARTS LIST Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks R303R RK73GB1J392J CHIP R 3.9K J 1/16W R304L RK73GB1J912J CHIP R 9.1K J 1/16W R304R RK73GB1J912J CHIP R 9.1K J 1/16W R307L RK73GB1J331J CHIP R 330 J 1/16W R307R RK73GB1J101J CHIP R 100 J 1/16W R308L RK73GB1J104J CHIP R 100K J 1/16W R308R RK73GB1J104J CHIP R 100K J 1/16W R309L RK73GB1J101J CHIP R 100 J 1/16W R309R RK73GB1J101J CHIP R 100 J 1/16W R310-313 RK73GB1J472J CHIP R 4.7K J 1/16W R314 RK73GB1J000J CHIP R 0 J 1/16W R315 RK73GB1J473J CHIP R 47K J 1/16W R321 RK73GB1J330J CHIP R 33 J 1/16W R322 RK73GB1J000J CHIP R 0 J 1/16W R323 RK73GB1J471J CHIP R 470 J 1/16W R324 RK73GB1J184J CHIP R 180K J 1/16W R401-404 RK73GB1J470J CHIP R 47 J 1/16W R405,406 RK73GB1J103J CHIP R 10K J 1/16W R407-410 RK73GB1J470J CHIP R 47 J 1/16W R413 RK73GB1J473J CHIP R 47K J 1/16W R415 L32-1047-08 BEAD CHIP/TAP F5512667050 R421-428 RK73GB1J470J CHIP R 47 J 1/16W R429-436 RK73GB1J473J CHIP R 47K J 1/16W R437 RK73GB1J000J CHIP R 0 J 1/16W R438 RK73GB1J100J CHIP R 10 J 1/16W R501 RK73GB1J101J CHIP R 100 J 1/16W R502 RK73GB1J560J CHIP R 56 J 1/16W R503 RK73GB1J105J CHIP R 1.0M J 1/16W R701,702 RK73FB2A101J CHIP R 100 J 1/10W EESTTS R705 RK73FB2A750J CHIP R 75 J 1/10W EESTTS R708,709 RK73FB2A102J CHIP R 1.0K J 1/10W EESTTS R714-716 RK73FB2A102J CHIP R 1.0K J 1/10W EESTTS R717-722 RK73FB2A390J CHIP R 39 J 1/10W EESTTS R723 RK73FB2A102J CHIP R 1.0K J 1/10W EESTTS R724 RK73FB2A181J CHIP R 180 J 1/10W EESTTS R730 RK73FB2A101J CHIP R 100 J 1/10W EESTTS R731 RK73FB2A390J CHIP R 39 J 1/10W EESTTS R801 RK73FB2A101J CHIP R 100 J 1/10W R802 RK73FB2A000J CHIP R 0 J 1/10W R803 RK73FB2A472J CHIP R 4.7K J 1/10W R804 RK73FB2A100J CHIP R 10 J 1/10W R805 RK73FB2A181J CHIP R 180 J 1/10W R806 RK73FB2A101J CHIP R 100 J 1/10W R807,808 RK73FB2A000J CHIP R 0 J 1/10W R815 RK73FB2A000J CHIP R 0 J 1/10W R827L RK73FB2A000J CHIP R 0 J 1/10W R827R RK73FB2A000J CHIP R 0 J 1/10W R829 RK73FB2A000J CHIP R 0 J 1/10W KPYYSX R864 RK73FB2A471J CHIP R 470 J 1/10W EESTTS R865 RK73FB2A750J CHIP R 75 J 1/10W EESTTS R872,873 L32-1046-08 BEAD CHIP/TAP F5512671050 R874 RK73FB2A000J CHIP R 0 J 1/10W KPYYSX R875 L32-1046-08 BEAD CHIP/TAP F5512671050 R876,877 RK73FB2A000J CHIP R 0 J 1/10W KPYYSX R901 RK73GB1J101J CHIP R 100 J 1/16W ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 8 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks R225Y RK73GB1J8R2J CHIP R 8.2 J 1/16W R226B RK73GB1J100J CHIP R 10 J 1/16W R226C RK73GB1J100J CHIP R 10 J 1/16W R226G RK73GB1J100J CHIP R 10 J 1/16W R226R RK73GB1J100J CHIP R 10 J 1/16W R226S RK73GB1J100J CHIP R 10 J 1/16W R226Y RK73GB1J100J CHIP R 10 J 1/16W R227B RK73GB1J121J CHIP R 120 J 1/16W R227C RK73GB1J121J CHIP R 120 J 1/16W R227G RK73GB1J121J CHIP R 120 J 1/16W R227R RK73GB1J121J CHIP R 120 J 1/16W R227S RK73GB1J121J CHIP R 120 J 1/16W R227Y RK73GB1J121J CHIP R 120 J 1/16W R228 RK73GB1J102J CHIP R 1.0K J 1/16W R230 RK73GB1J000J CHIP R 0 J 1/16W R231,232 RK73GB1J470J CHIP R 47 J 1/16W R233 RK73GB1J101J CHIP R 100 J 1/16W R234 RK73GB1J470J CHIP R 47 J 1/16W R236 RK73GB1J473J CHIP R 47K J 1/16W R237-241 RK73GB1J470J CHIP R 47 J 1/16W R242-245 RK73GB1J103J CHIP R 10K J 1/16W R246 RK73GB1J472J CHIP R 4.7K J 1/16W R247 RK73GB1J472J CHIP R 4.7K J 1/16W R248 RK73GB1J103J CHIP R 10K J 1/16W R249 RK73GB1J000J CHIP R 0 J 1/16W R250 RK73GB1J102J CHIP R 1.0K J 1/16W R251 RK73GB1J103J CHIP R 10K J 1/16W R252 RK73GB1J470J CHIP R 47 J 1/16W R253 RK73GB1J103J CHIP R 10K J 1/16W R254 RK73GB1J100J CHIP R 10 J 1/16W R255 RK73GB1J103J CHIP R 10K J 1/16W R256 RK73GB1J470J CHIP R 47 J 1/16W R257 RK73GB1J102J CHIP R 1.0K J 1/16W R262,263 RK73GB1J470J CHIP R 47 J 1/16W R264,265 RK73GB1J750J CHIP R 75 J 1/16W R266 RK73GB1J100J CHIP R 10 J 1/16W R267,268 RK73GB1J470J CHIP R 47 J 1/16W R269,270 RK73GB1J182J CHIP R 1.8K J 1/16W R271 RK73GB1J472J CHIP R 4.7K J 1/16W R273,274 RK73GB1J101J CHIP R 100 J 1/16W R279 RK73GB1J000J CHIP R 0 J 1/16W R280 RK73GB1J103J CHIP R 10K J 1/16W R281 RK73GB1J103J CHIP R 10K J 1/16W R282,283 RK73GB1J470J CHIP R 47 J 1/16W R285 RK73GB1J470J CHIP R 47 J 1/16W R288 RK73GB1J103J CHIP R 10K J 1/16W R289,290 RK73GB1J470J CHIP R 47 J 1/16W R291,292 RK73GB1J470J CHIP R 47 J 1/16W EESTTS R298 RK73GB1J103J CHIP R 10K J 1/16W R301-309 RK73GB1J101J CHIP R 100 J 1/16W R301L RK73GB1J473J CHIP R 47K J 1/16W R301R RK73GB1J473J CHIP R 47K J 1/16W R302L RK73GB1J562J CHIP R 5.6K J 1/16W R302R RK73GB1J562J CHIP R 5.6K J 1/16W R303L RK73GB1J392J CHIP R 3.9K J 1/16W ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 7 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 27 PARTS LIST Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks Q201-203 KTC3875S TR KTC3875S SOT2097046092 Q220B KTN2907 TR PNP KTN2907A5513869056 Q220C KTN2907 TR PNP KTN2907A5513869056 Q220G KTN2907 TR PNP KTN2907A5513869056 Q220R KTN2907 TR PNP KTN2907A5513869056 Q220S KTN2907 TR PNP KTN2907A5513869056 Q220Y KTN2907 TR PNP KTN2907A5513869056 Q221B KTD1304 TR NPN KTD1304 5513871092 Q221C KTD1304 TR NPN KTD1304 5513871092 Q221G KTD1304 TR NPN KTD1304 5513871092 Q221R KTD1304 TR NPN KTD1304 5513871092 Q221S KTD1304 TR NPN KTD1304 5513871092 Q221Y KTD1304 TR NPN KTD1304 5513871092 Q301 DTC114YKA TR NPN DTC114YK5513318092 Q301L ✽ DTC323T TR CHIP NPN DTC5503943092 Q301R ✽ DTC323T TR CHIP NPN DTC5503943092 Q302L DTA114YKA TR CHIP PNP DTA5513319092 Q302R DTA114YKA TR CHIP PNP DTA5513319092 Q701 KTC3875S TR KTC3875S SOT2097046092 EESTTS Q702 KRC107S TR CHIP NPN KRC5505124092 EESTTS Q704 KRC107S TR CHIP NPN KRC5505124092 EESTTS Q801 KTC3875S TR KTC3875S SOT2097046092 Q802 KTA1504S TR CHIP PNP KTA2097048092 Q815 KTC3875S TR KTC3875S SOT2097046092 EESTTS RM901 W02-2801-08 RMC SENSOR NJL6J2411120014X 1 1B ✽ J99-0838-08 AC PLASTIC PLAT55020070XX 2 1B ✽ J99-0839-08 AC PLASTIC DRAW55020080XX 3 1B ✽ G02-1745-08 AC SPRING CLIP 20712060XX 4 1B ✽ D15-0448-08 AC PLASTIC PULL20711410XX 5 1B ✽ D21-2929-08 AC METAL SHAFT 20711380XX 6 1B ✽ D13-2586-08 AC MLD GEAR WOR20710170XX 7 1A,1B ✽ D14-0827-08 AC PLASTIC ROLL20712170XX 8 1A,1B D14-0819-08 AC RUBBER ROLLE20712120XX 9 1B ✽ D13-2587-08 AC MLD GEAR HEL20710180XX 10 1B ✽ G10-0597-08 FELT BK 30.0MM 20634190XX 12 2A ✽ N19-1530-08 WASHER-SPR 8.0M55190760XX 13 2A ✽ D13-2588-08 AC MLD GEAR MAI55020110XX 14 2B ✽ N19-1529-08 WASHER 55MM 55190600XX 15 2B ✽ D12-0165-08 AC PLASTIC CAM 20712230XX 16 2B ✽ A10-3573-08 AC PLASTIC BASE55020090XX 17 2B ✽ D40-1770-08 OK KIT TVK 15-110733290XX 18 2A ✽ D13-2589-08 AC MLD GEAR DRI20712240XX 19 2A ✽ D13-2590-08 AC MLD GEAR PUL20712250XX 24 3A ✽ D16-0785-08 AC RUBBER BELT 20712270XX 25 2A ✽ D16-0784-08 AC RUBBER BELT 20710160XX 26 2A ✽ D16-0783-08 AC RAW WHEEL B20584560XX AA ✽ N09-5407-08 SCREW-ST 3MM 1020692310XX AB ✽ N09-5408-08 SCREW-ST 3MM 1020692300XX AC ✽ N09-5409-08 SCREW 2.6MM 4MM20349530XX AD ✽ N09-5410-08 SCREW-SPEC 3MM 20366370XX AE N89-3008-46 SCREW-ST 3MM 0820349380XX AF ✽ N09-5411-08 SCREW 3*18 J80200031820 LM 3A T42-1116-08 AD ASY MOTOR DC20581800XX RM 2B ✽ T42-1121-08 AD ASY MOTOR DC20581820XX ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 0 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . Ref. No Add- ress New Parts Parts No. Description Desti- nation Re- marks R902 RK73GB1J103J CHIP R 10K J 1/16W R911 RK73GB1J472J CHIP R 4.7K J 1/16W R912 RK73GB1J103J CHIP R 10K J 1/16W R913 RK73GB1J753J CHIP R 75K J 1/16W R921 RK73GB1J472J CHIP R 4.7K J 1/16W R922 RK73GB1J103J CHIP R 10K J 1/16W R923 RK73GB1J753J CHIP R 75K J 1/16W R926 RK73GB1J473J CHIP R 47K J 1/16W R927 RK73GB1J223J CHIP R 22K J 1/16W R931 RK73GB1J472J CHIP R 4.7K J 1/16W R932 RK73GB1J103J CHIP R 10K J 1/16W R933 RK73GB1J753J CHIP R 75K J 1/16W R938-940 RK73GB1J103J CHIP R 10K J 1/16W R943 RK73FB2A473J CHIP R 47K J 1/10W R945 RK73GB1J000J CHIP R 0 J 1/16W KPYYS R945 RK73GB1J122J CHIP R 1.2K J 1/16W EESTTS R945 RK73GB1J682J CHIP R 6.8K J 1/16W X R946 RK73GB1J103J CHIP R 10K J 1/16W R950 RK73GB1J100J CHIP R 10 J 1/16W RA301-307 ✽ R92-1333-08 RES CHIP/TAP,4A55129820NR RA401-408 ✽ R92-1333-08 RES CHIP/TAP,4A55129820NR SW901 S70-0092-08 SWITACT HOR 50M20404680NR SW903 S70-0092-08 SWITACT HOR 50M20404680NR SW905 S70-0092-08 SWITACT HOR 50M20404680NR SW907 S70-0092-08 SWITACT HOR 50M20404680NR SW911 S70-0092-08 SWITACT HOR 50M20404680NR SW913 S70-0092-08 SWITACT HOR 50M20404680NR SW915 S70-0092-08 SWITACT HOR 50M20404680NR SW917 S70-0092-08 SWITACT HOR 50M20404680NR SW921 S70-0092-08 SWITACT HOR 50M20404680NR SW924 S70-0092-08 SWITACT HOR 50M20404680NR SW927 S70-0092-08 SWITACT HOR 50M20404680NR SW930 S70-0092-08 SWITACT HOR 50M20404680NR D301 UDZ2.2B D-ZENER CHIP/TAJ2242422514X D303 1SS355 DIODE CHIP 1SS32049651091 D701 1SS355 DIODE CHIP 1SS32049651091 EESTTS D702 ZNR5V1B0.2W D-CHIP ZENER 5VJ2242451514X EESTTS D705-710 ZNR5V1B0.2W D-CHIP ZENER 5VJ2242451514X EESTTS D711 1N4148 DIODE AX/TAP, S7043654016 D904 1N4148 DIODE AX/TAP, S7043654016 D906 RB501V-40 DIODE SCHOTTKY J2242510011X FL901 ✽ HNV-06SS75 DISPLAY HNV-06S55155560NR IC21P KIA7806 IC REG KIA7806A20361320NR IC201 STI5519 IC DECODER STi555130350NR IC202 M24C02WMN6 IC EEPROM M24C20940740NR IC301 HY57V651620 IC SDRAM HY57V655156290NR IC302 PCM1748KE IC DAC PCM1748K55156030NR IC303 BA4560F IC OPAMP BA456055128990NR IC401 ✽ SST39VF800505E ICFLASH SST39VF55177660NR EESTTS IC401 ✽ SST39VF800505K ICFLASH SST39VF55177660NR KPYYS IC401 ✽ SST39VF800505X ICFLASH SST39VF55177660NR XM3 IC501 ✽ M74HCU04M1R IC HEX INVERTER55133310NR IC805 GP1F32T FIBER OPT GP1F3J2123829001X IC901 ✽ CXP825P400-1 IC-MICROCONT CX55156830NR IC902 KIA7045P IC-REGNEGFXD KI55191090NR ✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert. 9 L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components . MECHANISM www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 28 PARTS LIST HOW TO READ THE PARTS LIST ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS MODEL ABB. Australia Canada China England Europe Germany Korea DV-505 - - - - - - - - DVF-4050 - - - - T E - - DVF-4050-S - X - TS ES - - MODEL ABB. Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area DV-505 - - - - - - K - DVF-4050 - - Y - - - - - DVF-4050-S - - YS - - - - - www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 DV-505/DVF-4050/-S 22 SPECIFICATIONS 14-6,Dogenzaka 1-chome, Shibuya-ku, Tokyo, 150-8501 Japan KENWOOD SERVICE CORPORATION P.O BOX 22745, 2201 East Dominguez St., Long Beach, CA 90801-5745, U.S.A. KENWOOD ELECTRONICS CANADA INC. 6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8 KENWOOD ELECTRONICS LATIN AMERICA S.A. P.O BOX 55-2791, Piso 6 plaza Chase, Cl. 47 y Aquilino de la Guardia Panama, Republic de Panama KENWOOD ELECTRONICS BRASIL LTDA. Alameda Ministro Rocha Azevedo No. 456, Edificio Jaú, 10o Andar, Cerqueira César, Cep 0140-001, São Paulo-SP-Brasil KENWOOD ELECTRONICS U.K. LIMITED KENWOOD House, Dwight Road, Watford, Herts., WD1 8EB., United Kingdom KENWOOD ELECTRONICS BELGIUM N.V. Leuvensesteenweg 248 J, 1800 Vilvoorde, Belgium KENWOOD ELECTRONICS DEUTSCHLAND GMBH Rembrücker Str. 15, 63150 Heusenstamm, Germany KENWOOD ELECTRONICS FRANCE S.A. 13 Boulevard Ney, 75018 Paris, France KENWOOD ELECTRONICS ITALIA S.p.A. Via G. Sirtori, 7/9 20129, Milano, ltaly KENWOOD IBÉRICA S.A. Bolivia, 239-08020 Barcelona, Spain KENWOOD ELECTRONICS AUSTRALIA PTY. LTD. (A.C.N. 001 499 074) 16 Giffnock Avenue, North Ryde, N.S.W. 2113, Australia KENWOOD ELECTRONICS (HONG KONG) LTD. Unit 3712-3724, Level 37, Tower 1, Metroplaza, 223 Hing Fong Road, Kwai Fong N.T., Hong Kong KENWOOD ELECTRONICS GULF FZE P.O.Box 61318, Jebel Ali, Dubai, U.A.E. KENWOOD ELECTRONICS SINGAPORE PTE LTD. No. 1 Genting Lane #02-02, KENWOOD Building, Singapore, 349544 KENWOOD ELECTRONICS (MALAYSIA) SDN BHD. #4.01 Level 4, Wisma Academy Lot 4A, Jalan 19/1 46300 Petaling Jaya Selangor Darul Ehsan Malaysia KENWOOD ELECTRONICS (THAILAND) CO., LTD. 2019 New Pechburi Road, Bangkapi, Huaykwang, Bangkok, 10320 Thailand Note: Component and circuit are subject to modification to insure best operation under differing local conditions. This manual is based on Europe (E) standard, and provides information on regional circuit modification through use of alter- nate schematic diagrams, and information on regional component variations through use of parts list. Notes Notes Notes [Type] System..................................................... DVD video player system Signal read system ......................................... Semiconductor laser [D/A Conversion Section] D/A conversion ....................................................................... 24 Bit Oversampling ................... 8 fs (Sampling frequency; 44.1, 48 kHz) 4 fs (Sampling frequency; 96 kHz) [Audio section] Frequency response Sampling frequency ; 44.1 kHz .......................... 4 Hz ~ 20 kHz Sampling frequency ; 48 kHz ............................. 4 Hz ~ 22 kHz Sampling frequency ; 96 kHz ............................. 4 Hz ~ 42 kHz Signal to noise ratio ............................................... More than 98 dB Dynamic range ....................................................... More than 95 dB Total harmonic distortion .......................Less than 0.005 % (1 kHz) Channel separation .................................. More than 95 dB (1 kHz,) Wow and flutter .......................................... Below measurable limit Analog output level/impedance ........................................2 V / 1 kΩ Digital output level/impedance COAXIAL .......................................................... 0.5 Vp-p / 75 Ω OPTICAL ................ -21 dBm ~ -15 dBm (Wave length 660 nm) [Video Section] Video output format ......................................................... NTSC/PAL Video compression DVD ............................................................................... MPEG-2 Composite video output level ............................................ 1 Vp-p (75 Ω load, sync. negative) S-video output level (Y-signal) ............................. 1 Vp-p (75 Ω load, sync. negative) (C-signal) NTSC ...................................................... 0.286 Vp-p (75 Ω) PAL ......................................................... 0.300 Vp-p (75 Ω) Horizontal resolution .........................................More than 480 lines Video signal to noise ratio...................................... More than 60 dB [General] Power consumption ................................................................ 20 W Dimensions................................................... W:440 mm (17-5/16") H: 127 mm(5") D: 440 mm (17-5/16") Weight (net) .............................................................. 6.8 kg (15.0 lb) KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. ÷ Sufficient performance may not be exhibited at extremely cold locations (Where water freezes). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
